PLANET ECLIPSE GEO2 Operator's Manual page 26

tHe locK indicator
The Geo2 has a tournament lock which prevents the user
from making changes to any parameter that affects the
way in which the Geo2 shoots, without the need for tools.
This feature is necessary in order to make the Geo2 legal
for tournament play.
when the lock is enabled the lock indictor will show a
closed padlock
when the lock is disabled the lock indictor will show an
open padlock
To enable or disable the tournament lock see Accessing the
Menu System on page 32.
tHe batterY leVel
indicator
The battery level indicator is used to show the state of
the battery within the Geo2. when the battery is fresh the
indicator will show a 'full' battery and as the battery is
drained, so the indicator will show the battery emptying.
when the battery reaches a point at which the Geo2 will no
longer function reliably, the indicator will start to flash. At
this point the battery must be changed immediately.
As well as displaying the voltage level of the battery,
the indicator also warns if the battery being used has
an incorrect voltage to operate the electronics reliably.
The icon for a battery with an incorrect voltage output
is . if this icon is shown the battery must be replaced
immediately.
tHe Game timer
when the game timer is shown on the run screen then
it can be started by pressing the
timer will start to count down. The game timer can also
be configured to start on a trigger press with the
parameter (see page 45).
26.
.
.
button and the
when the game timer reaches the
the gamer timer will start
ALARM TIME
to flash and the audible alarm will
sound every second, provided that the
parameter is on.
SOUND
when the game timer reaches 00:00,
GAME OvEr will be displayed and the
audible alarm will sound continually,
provided that the
set to 'ON' .
To stop the game timer at any time
press and hold the
seconds.
To reset the game timer to it's preset
start time, push and hold the
for 1 second. The game timer will also be reset whenever
the Geo2 is switched off.
tHe sHot
counter
The shot counter will increment
every time that the Geo2 solenoid
is activated, regardless of whether
the shot counter is displayed or not.
when the shot counter is displayed on
the run screen it can be reset to 0 by
pressing and holding the
for 0.5 seconds.
There is also an optional shot gauge
that can be displayed on this run
screen. The gauge counts down from
a user adjustable number. To alter the
gauge settings see pages 44.
START
The gauge is reset whenever the Geo2 is switched off or
the button is pressed.
parameter is
SOUND
button for 0.5
button
button
