PLANET ECLIPSE GEO2 Operator's Manual page 46

cleaninG tHe breaK
beam sensor sYstem
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
Undo the retaining screw for the break beam Sensor cover
on the left hand side of the Geo2 using a 5/64" (2mm) hex
key (see fiGure 9.1).
remove the sensor cover to expose the back of the break
beam Sensor unit
carefully remove any debris, paint or moisture from the back
of the sensor unit and from inside the sensor cover.
lift the bbSS free from the Geo2 body and using another
dry cotton bud, remove any grease or debris build-up from
the front of the sensor unit
46.
(see fiGure 9.2). Using a dry cotton bud,
(see fiGure 9.3) .
fiG 9.1
fiG 9.2
fiG 9.3
