tHe Geo2 solenoid
assemblY
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
with the frame separated from the Geo2 body and the
Solenoid Assembly and bbSS Assembly unplugged from
the Circuit board (see page 55) use a 5/64" hex key to
undo and remove the two screws that hold the Solenoid
Assembly onto the Geo2 body
with the Solenoid Assembly completely removed from
the Geo2 body the bottom of the Geo2 body should now
resemble
in the bottom of the body are free from contamination
from any dirt, debris, paint or moisture and clear away
any excess grease if it appears to be blocking any of the
transfer holes.
Check the underside of the Solenoid Assembly to ensure
that it is also free from damage or debris
and remove the rubber gasket to clean the filter section as
shown in
that it lies flat in its designated groove in the manifold
body (see fiGure 13.5)
if you are replacing a defective Pilot Assembly, unscrew
it from the manifold now and replace it with a new Pilot
Assembly unit
58.
(see fiGure13.1).
fiGure 13.2 Ensure that the air transfer holes
replace the rubber gasket ensuring
fiGure 13.4
.
(see fiGure 13.6).
(see fiGure 13.3)
fiG 13.2
fiG 13.1
fiG 13.3 fiG 13.4
fiG 13.5
fiG 13.6
