PLANET ECLIPSE GEO2 Operator's Manual page 15

sWitcHinG on tHe Geo2
To switch on the Geo2 press the
succession, referred to elsewhere in this manual as 'double-
clicking'. The Geo2 can also be switched on by pushing and
holding the button
(fiGure 3.1)
sWitcHinG off tHe Geo2
Press and hold the button until the display shows "
" release the button and re-press it to turn off the
off .
Geo2. Alternatively double click the
menu tree then press to turn off the Geo2.
firinG tHe Geo2
Pull the Trigger to fire the Geo2. The entire firing sequence
is controlled electronically by the Geo2 Circuit board,
enabling any user to easily achieve high rates of fire.
tHe Geo2 circuit board
There are four sockets on the Geo2 Circuit board; the bbSS
socket (a) , the Geo2 Solenoid socket (b) , the Auxiliary
socket to which third party products such as loaders and
rF transmitters can be connected using the relevant
wiring harness (c) and the Expansion board socket which
connects the Eclipse E-Portal USb Daughter board to the
Geo2 (d)
(see fiGure 3.2) .
2,3
The double clicking feature is user selectable, factory default is set
1
to on. It can be turned off using the Double Click parameter in the
Hardware Menu (see page 42).
The Auxiliary socket is turned on and off manually via the AUX
2
OUT parameter in the Hardware menu on page 42.
Eclipse E-Portal sold separately (see page 65).
3
button twice in quick
.
1
turn
button to enter the
1
b
c
a
d
