Cleaning The Purge Control Valve - PLANET ECLIPSE GEO2 Operator's Manual

cleaninG tHe PurGe
control ValVe (PcV)
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
This procedure is only required to fix a degassing issue with
the Geo2, and is NOT part of regular Geo2 maintenance.
if the Geo2 does not degas/degasses very slowly or fires
a shot when degassing, then the Purge Control valve may
require maintenance.
remove the inline regulator as covered on page 48. Turn
the Geo2 upside down to reveal the PCv Guide and PCv
. Using a 5/16" hex key unscrew the PCv
(see fiGure 10.17)
Guide, and remove the PCv Guide (A), PCv (b) and Spring
(C) from the Geo2 body (see fiGures 10.18 & 10.19).
inspect and clean the PCv and PCv Guide, paying
particular attention to the tip of the PCv. if the PCv or PCv
Guide is damaged replace with authentic Eclipse Parts.
These can be obtained from your nearest Eclipse Service
Centre (
see fiGure 10.20).
Place the PCv into the PCv Guide,
by the spring . Then (keeping the PCv
(fiGure 10.22)
Guide the correct way up) screw the PCv Guide back into
the Geo2 body (fiGure 10.23)
re-attach the inline regulator to the GEO2 as on page 49.
you have now cleaned the Purge Control valve.
WarninG: if You are at all unsure at PerforminG
tHe maintenance Procedure Please contact Your
nearest ecliPse serVice centre. (see PaGe 69)
tHe PurGe control ValVe and sPrinG must be
rePlaced correctlY, failure to comPlY WitH tHis
WarninG maY cause tHe marKer to fire a sHot
tHat could result in serious inJurY or deatH.
(fiGure 10.21) , followed
.
fiG 10.17 fiG 10.18
