tHe Geo2 triGGer
assemblY
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
remove the screws from the Geo2 frame that hold the
bearing carrier in place in the top of the frame
. Gently lift the bearing carrier and trigger assembly
14.1)
free from the frame taking care not to damage the micro-
switch or the Opto sensors
(see fiGure 14.2)
Using a 1/16" hex key, loosen the trigger pin retaining set
screw from the bottom of the trigger
Use a small hex key to push the trigger pin out of the
bearing carrier from one side (see fiGure 14.4)
Clean the trigger and bearing carrier thoroughly and also
clean the space within the frame that the trigger sits into.
Carefully remove the trigger spring from the spring hole
in the top of the trigger and clean off any paint debris or
moisture from it (see fiGure 14.5)
(see fiGure
.
.
(see fiGure 14.3)
.
.
fiG 14.1
fiG 14.2
fiG 14.3
fiG 14.4 fiG 14.5
