- Page 1 WORKSHOP MANUAL .68CAL PLANET ECLIPSE: 180R .68CAL...
- Page 2 WARNING READ CAREFULLY BEFORE USE THE PLANET ECLIPSE 180R IS NOT A TOY. PAINTBALL SAFETY RULES MUST BE FOLLOWED AT Never allow pressurised gas to come into contact with any part of your body. ALL TIMES. Alwaysremovethefirststageregulator and relieve all residual gas pressure from the 180R before Careless or improper use of the 180R, including failure to follow instructions and warnings within disassembly.
-
Page 3: Table Of Contents
DOES NOT FULLY CYCLE SOLENOID LEAK CONSTANT HIGH VELOCITY INLINE REGULATOR / POPS LEAK BREAKING PAINT IN THE BREECH INCONSISTANT SHOT TO SHOT FPS INEFFICIENT / LOW SHOT COUNT PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 4: 180R Bolt System
SWITCH BODY SPRING GUIDE 5MM BALL BEARING JOINER M2.5 SPRING WASHER SWITCH SPOOL SPOOL SPRING BOLT GUIDE BOLT NOTE: CS3 AND 180R SPOOL ASSEMBLIES AND JOINER PARTS ARE NOT INTERCHANGABLE PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 5: Can Assembly
CAN ASSEMBLY 020 NBR70 O-RING 017 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 6: Bolt Assembly
BOLT ASSEMBLY 015 NBR90 O-RING 013 NBR70 O-RING 14X2 NBR70 O-RING BOLT BOLT TIP PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 7: Bolt Guide Assembly
BOLT GUIDE ASSEMBLY 017 NBR70 O-RING 013 NBR70 O-RING 6 X 1.5 NBR70 O-RING 20 X 1.2 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 8: Spool Assembly
SPOOL ASSEMBLY 012 NBR70 O-RING 011 NBR70 O-RING SPOOL SPOOL INSERT NOTE: CS3 AND 180R SPOOL ASSEMBLIES ARE NOT INTERCHANGABLE PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 9: Switch Assembly
SWITCH ASSEMBLY 016 NBR70 O-RING SWITCH PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 10: Switch Body Assembly
SWITCH BODY ASSEMBLY 021 NBR70 O-RING SWITCH BODY 20X1.2 NBR70 O-RING 4X1 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 11: Regulator Assembly
008 NBR70 O-RING ADJUSTER CAP PURGE POPPET REGULATOR SPRING 015 NBR70 O-RING 10-32 UNF X 1” CAP HEAD SOCKET REGULATOR SEAL SCREW PURGE POPPET SPRING 011 NBR70 O-RING POPS ASSEMBLY PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 12: Solenoid Assembly
3-WAY BODY 3-WAY SPOOL M1.6 X 5 COUNTER SUNK SCREW SOLENOID PILOT FRAME GASKET SOLENOID PLATE GASKET SOLENOID PLATE SOLENOID BODY PIN M2 X 16 CROSS PAN HEAD SCREW PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 13: Frame Sub-Assembly
M2.5 X 5 CAP HEAD SOCKET SCREW BS WIRE BS BOARD M2.5 X 5 CAP HEAD SOCKET SCREW TRIGGER SPRING TRIGGER ASSEMBLY 6-32UNC X 0.125 SOCKET SET SCREW - CUP POINT THREADED TRIGGER PIN PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 14: Trigger Assembly
SCREW - CUP POINT 6-32UNC X 0.1875 SOCKET SET SCREW - CUP POINT M2.5 X 5 CAP HEAD SOCKET SCREW 6-32UNC X 0.1875 SOCKET SET SCREW - CUP POINT TRIGGER SHOE PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 15: Battery Housing Assembly
BATTERY HOUSING ASSEMBLY 6-32 UNC X 0.25/0.3125 SOCKET COUNTER SUNK SCREW BATTERY CONNECTOR 6-32 UNC X 0.25/0.3125 SOCKET COUNTER SUNK SCREW BATTERY HOUSING BATTERY (PP3, 6LR61 / 6LP3146, 11604A) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 16: Pops Assembly
005 NBR90 O-RING 007 NBR70 O-RING POPS PIN 004 NBR70 O-RING POPS INSERT 004 NBR70 O-RING POPS CROSS PIN POPS BODY POPS LATCH SPRING POPS BONNET POPS LATCH BUTTON PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 17: Feedneck Assembly
006 NBR70 O-RING FEED SWIVEL LOCATING FEED TUBE LOCATING FEED LEVER CLAMPING FEED WHEEL 004 NBR70 O-RING FEED SCREW FEED INSERT 10-32 UNF X 0.5” CAP HEAD SOCKET SCREW PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 18: Breech Sensor (Bs) Assembly
BREECH SENSOR (BS) ASSEMBLY BREECH SENSOR (BS) BS COVER CLIP RUBBER DETENT M1.6 X 5 COUNTER SUNK SCREW LIGHT PIPE ASSEMBLY BS COVER PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 19: Service Indicator - Lubrication Required
6X1.5 NBR70 O-RING BOLT (OUTSIDE FACE) 013 NBR70 O-RING 013 NBR70 O-RING 14X2 NBR70 O-RING CAN (INSIDE FACE) 015 NBR90 O-RING 020 NBR70 O-RING BOLT (INSIDE FACE) 017 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 20: Service Indicator - Service Required
021 NBR70 O-RING 016 NBR70 O-RING SWTCH BODY (INSIDE FACE) SWITCH (INSIDE FACE) 012 NBR70 O-RING 011 NBR70 O-RING SPOOL (OUTSIDE FACE) *In addition to the ‘lubrication’ guide on previous page PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... - Page 21 PISTON (OUTSIDE FACE) 008 NBR70 O-RING (INTERNAL) 014 NBR70 O-RING 015NBR70 O-RING 011 NBR70 O-RING REGULATOR SEAL PURGE POPPET (OUTSIDE FACE) REGULATOR ADJUSTER (INSIDE FACE) POPS BODY (INSIDE FACE) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD...
-
Page 22: Leaks Down The Barrel
14X2 NBR70 O-RING (C) 017 NBR70 O-RING (C) 017 NBR70 O-RING (R) SPOOL SWITCH BODY SWITCH 011 NBR70 O-RING (C) METAL BODY (INSIDE FACE) (R) (INSIDE FACE) (R) 012 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 23: First Shot Drop Off (Fsdo)
BOLT (OUTSIDE FACE) (R) 013 NBR70 O-RING (R) 6 X 1.5 NBR70 O-RING (R) 013 NBR70 O-RING (C) 017 NBR70 O-RING (R) SWITCH BODY SWITCH 016 NBR70 O-RING (R) INSIDE FACE (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 24: 21 'Puffs' When Trigger Is Pulled
021 NBR70 O-RING (R) VALVE BODY (INSIDE FACE)(R) 6X1.5 NBR70 O-RING (R) (IF THIS O-RING IS DAMAGED, INCORRECTLY SIZED OR NOT LUBRICATED CORRECTLY THEN THE MARKER MAY EXHIBIT CONSTANT LOW VELOCITY) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 25: Does Not Fully Cycle
017 NBR70 O-RING (R) BOLT (R) 013 NBR70 O-RING (R) 14X2 NBR70 O-RING (R) CAN (R) 3-WAY HOUSING 6X1 NBR70 O-RING (R) 3-WAY HOUSING (R) #6 SPOOL SEAL (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 26: Solenoid Leak
6 X 1 NBR70 O-RING (C) SOLENOID PLATE (R) 180R BODY (R) #6 SOLENOID SEAL (C) FRAME FRAME (R) SOLENOID PLATE GASKET (R) 3-WAY BODY (R) FRAME GASKET (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 27: Constant High Velocity
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES (C) = COMMON FAULT (R) = RARE FAULT REGULATOR ADJUSTER SCREW REGULATOR PISTON REGULATOR SEAL (R) PURGE POPPET (R) REGULATOR PISTON (C) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 28: Inline Regulator / Pops Leak
FRAME (INTENRAL) 008 NBR70 O-RING (C) 015 NBR70 O-RING (R) FRAME (INSIDE FACE) (R) POPS BODY (R) 011 NBR70 O-RING (R) 007 NBR70 O-RING (R) 005 NBR90 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 29: Breaking Paint In The Breech
BREAKING PAINT IN THE BREECH CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES (C) = COMMON FAULT (R) = RARE FAULT DETENTS BOLT GUIDE 013 NBR70 O-RING (R) RUBBER DETENT (C) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 30: Inconsistant Shot To Shot Fps
(R) = RARE FAULT REGULATOR PISTON REGULATOR BODY REGULATOR SEAL REGUALTOR SEAL (R) 014 NBR70 O-RING (C) 008 NBR70 O-RING (C) PISTON (C) POPS ASSEMBLY POPS INTERNAL PORTING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... -
Page 31: Inefficient / Low Shot Count
(C) = COMMON FAULT (R) = RARE FAULT SWITCH SPOOL BOLT GUIDE 012 NBR70 O-RING (R) 6 X 1.5 NBR70 O-RING (R) SWITCH BODY 016 NBR70 O-RING (C) 021 NBR70 O-RING (C) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD... - Page 32 Warren, RI, 02885, USA Manchester, M17 1GA, England Düsseldorf 40233, Germany Call: +1 401 247 9061 Call: +44(0) 161 872 5572 Call +49 (0) 211 210 230-0 info.usa@planeteclipse.com info.europe@planeteclipse.com planeteclipse.com/contact 21003-WM004 PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL 180R © 2023 PLANET ECLIPSE LTD...
