Diagnostics and Troubleshooting
User Manual
Controller Tag
PassCnt
BlockStats.Read
BlockStats.Write
BlockStats.Parse
BlockStats.Event
BlockStats.Cmd
BlockStats.Err
CmdBits[x]
ClientStatsTrigger
ClientIDReq
ClientStatus[x].CmdReq
ClientStatus[x].CmdResp
ClientStatus[x].CmdErr
ClientStatus[x].Requests
ClientStatus[x].Responses
ClientStatus[x].ErrSent
ClientStatus[x].ErrRec
ClientStatus[x].CfgErrWord
ClientStatus[x].CurErr
ClientStatus[x].LastErr
ClientIDRec
CmdErrorList[x]
ClientStatsPending
Page 98 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
Data Type
Description
INT
This value is incremented each time a complete
program cycle occurs in the module.
INT
Total number of read blocks transferred from the
module to the processor
INT
Total number of write blocks transferred from the
processor to the module
INT
Total number of blocks successfully parsed that were
received from the processor
INT
Total number of Event Command blocks received from
the processor
INT
Total number of Command Control blocks received
from the processor
INT
Total number of block errors recognized by the module
INT
Displays enabled or disabled status of all 16
commands in the Client x Command List for each
Client
BOOL
Initiates request for Client Status block from module
when set to 1
INT
Specifies Client (0-29) to request status data from
INT
Total number of command list requests sent from
Client
INT
Total number of command list responses received by
Client
INT
This value is incremented each time an error message
is received from a remote unit or a local error is
generated for a command.
INT
Not used
INT
Not used
INT
Not used
INT
Not used
INT
Configuration Error Word - This word contains a
bitmap that indicates general module configuration
errors.
INT
Most recent error code recorded for the Client
INT
Previous most recent error code recorded for the
Client
INT
Specifies Client (0-29) for which status data was
received in the most recently processed Client Status
block
INT
Command error code for each command (0-15) on the
specified Client's command list
BOOL
Temporary variable used to prevent a new Client
Status block request from being sent to the module
until the previously sent Client Status block request
has been completely processed and a response block
has been returned.
MVI56E-MNETCR ♦ ControlLogix Platform
ProSoft Technology, Inc.
