Ladder Logic
User Manual

3.4.2 MNETCR.CONTROL

This controller tag structure is used to request special tasks from the module. For
more information, see Special Function Blocks (page 110).
Controller Tag
BootTimer
WarmBoot
ColdBoot
EventCmdTrigger
EventCmdPending
ClientID
EventCmd
CmdControl
CmdControlTrigger
CmdControlPending
IPAddress
WriteCmdBits

3.4.3 MNETCR.STATUS

This controller tag structure contains module and Client status data. For a more
complete description of the MNETCR.STATUS controller tag structure, refer to
the Status Data Definition (page 97).
Controller Tag
PassCnt
BlockStats
CmdBits
ClientStatsTrigger
ClientIDReq
ClientStatus
ClientIDRec
CmdErrorList
ClientStatsPending
Page 82 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
Data Type
TIMER
BOOL
BOOL
BOOL
BOOL
INT
MNETCREVENTCMD
MNETCRCMDCONTROL
BOOL
BOOL
MNETCRIPADDRESS
INT[30]
Data Type
INT
MNETCRBLOCKSTATS
INT[30]
BOOL
INT
MNETCRCLIENTSTATS[30]
INT
INT[16]
BOOL
MVI56E-MNETCR ♦ ControlLogix Platform
Description
Timer used to clear both cold and warm
boot requests
Configuration data reset in the module
Hardware reset of the module
Initiates Event Command
Allows Event Command
Client ID to poll a server with the Event
Command.
Holds Event Command configuration
Holds Command Control status
Initiates Command Control
Halts rung until module is ready
IP address statistics including triggers
Selects individual Clients to activate its
commands.
Description
Program cycle counter
Block Statistics
Commands bits array to be used for 30
Clients
Get Client Status
Client ID requested
Client status requests
Client ID received.
Command Error List
Allows Get Client Status
