Importing the Sample Add-On Instruction

Note: This section only applies if your processor is using RSLogix 5000 version 16 or higher. If you
have an earlier version, please see Using the Sample Program (page 150).
Before You Begin
Two Add-On Instructions are provided for the MVI56E-MNETCR module. The
first is required for setting up the module; the second is optional.
Copy the files from www.prosoft-technology.com. Save them to a convenient
location in your PC, such as Desktop or My Documents.
File Name
MVI56EMNETCR_AddOn_Rung_vXXX.L5X
MVI56EMNETCR_Optional_Rung_vXXX.L5X Optional L5X file containing additional Add-On
Page 16 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
Description
L5X file containing Add-On Instruction, user defined
data types, controller tags and ladder logic required
to configure the MVI56E-MNETCR module
Instruction with logic for changing Ethernet
configuration and clock settings.
