Reference
User Manual
Word Offset
2
3
4
5
6 to 41
Get Module IP Address Block (9991)
Block Request from Processor to Module
Word Offset
0
1 to 41
Block Response from Module to Processor
Word Offset
0
1
2
3
4
5
6 to 41
Warm Boot Block (9998)
This block is equivalent to performing a software reset, and causes the module to
exit the program, reload the configuration file, and then restart the program. The
Warm Boot control block also initializes the application port(s) and status data,
and resets all internal registers to zero.
Note: In some cases, the read section of the module database (transferred from module to
processor) must keep its values after a reboot. To repopulate the module's registers with the last
values the module sent to the processor, set the Initialize Output Data parameter in the module
configuration to Y
Page 118 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
Description
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Spare data area
Description
9991
Spare data area
Description
0
Write Block ID
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Spare data area
.
ES
MVI56E-MNETCR ♦ ControlLogix Platform
Length
1
1
1
1
35
Length
1
40
Length
1
1
1
1
1
1
35
