MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
4.2
Using the Diagnostics Menu in ProSoft Configuration Builder
Tip: You can have a ProSoft Configuration Builder Diagnostics window open for more than one
module at a time.
To connect to the module's Configuration/Debug Ethernet port:
1
In ProSoft Configuration Builder, select the module, and then click the right
mouse button to open a shortcut menu.
2
On the shortcut menu, choose D
3
In the Diagnostics window, click the S
the module's IP address.
ProSoft Technology, Inc.
.
IAGNOSTICS
U
C
ET
P
ONNECTION
Diagnostics and Troubleshooting
User Manual
button to browse for
Page 89 of 161
