Configuring the MVI56E-MNETCR Module
User Manual
2.4.2 Using RSWho to Connect to the Module
You need to have RSLinx installed on your PC to use this feature. You also need an ENBT module
set up in the rack. For information on setting up the ENBT module, see Using CIPconnect to
Connect to the Module (page 63).
1
In the tree view in ProSoft Configuration Builder, right-click the MVI56E-
MNETCR module.
2
From the shortcut menu, choose D
3
In the Download dialog box, choose 1756 ENBT from the Select Connection
Type dropdown box.
Page 72 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
OWNLOAD FROM
MVI56E-MNETCR ♦ ControlLogix Platform
PC
D
.
TO
EVICE
ProSoft Technology, Inc.
