5.8.2 Choosing the Controller Type
The sample application is for a 1756-L63 ControlLogix 5563 Controller. If you are
using a different model of the ControlLogix processor, you must configure the
sample program to use the correct processor model.
1
In the Controller Organization list, select the folder for the controller and then
click the right mouse button to open a shortcut menu.
2
On the shortcut menu, choose P
Properties dialog box.
3
Click the C
the Change Controller dialog box.
4
Open the T
5
Select the correct firmware revision for your controller, if necessary.
6
Click OK to save your changes and return to the previous window.
Page 152 of 161
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
T
or C
HANGE
YPE
HANGE
dropdown list, and then select your ControlLogix controller.
YPE
MVI56E-MNETCR ♦ ControlLogix Platform
. This action opens the Controller
ROPERTIES
C
button. This action opens
ONTROLLER
ProSoft Technology, Inc.
