Like Event Command blocks, Command Control blocks place commands into the
module's command priority queue. Unlike Event Command blocks, which contain
all the values needed for one command, Command Control is used with
commands already defined in the MNET Client x Command List.
Commands in the MNET Client x Command List may be either enabled for
routine polling or disabled and excluded from routine polling. A disabled
command has its bit in the MNETCR.CONTROL.WriteCmdBits controller tag set
to zero (0) and is skipped during routine polling. An enabled command has its bit
in the WriteCmdBits controller tag set to one (1) and is sent during routine
polling. However, Command Control allows any command in the predefined
MNET Client x Command List to be added to the command priority queue,
whether it is enabled for routine polling or not.
Command Control also gives you the option to use ladder logic to have
commands from the MNET Client x Command List executed at a higher priority
and out of routine order, if such an option might be required in special
circumstances.
A single Command Control block request can place up to 16 commands from the
MNET Client x Command List into the command priority queue.
Block Request from Processor to Module
Word Offset
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 to 41
ProSoft Technology, Inc.
Description
Command Control block identification code of 5001 to 5016.
The rightmost digit indicates the number of commands (1 to
16) to add to the command priority queue.
Client index (0 to 29)
This word contains the Command Index for the first
command to be entered into the queue.
Command Index 2
Command Index 3
Command Index 4
Command Index 5
Command Index 6
Command Index 7
Command Index 8
Command Index 9
Command Index 10
Command Index 11
Command Index 12
Command Index 13
Command Index 14
Command Index 15
Command Index 16
Spare
Reference
User Manual
Length
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
24
