Diagnostics and Troubleshooting

In This Chapter

LED Status Indicators ............................................................................ 86

Using the Diagnostics Menu in ProSoft Configuration Builder ............... 89

Reading Status Data from the Module .................................................. 97
The module provides information on diagnostics and troubleshooting in the
following forms:

LED status indicators on the front of the module provide information on the
module's status.

Status data contained in the module can be viewed in ProSoft Configuration
Builder through the Ethernet port.

Status data values are transferred from the module to the processor.
