MVI56E-MNETCR ♦ ControlLogix Platform
Modbus TCP/IP Multi-Client Enhanced Communications Module for Remote Chassis
4 In the Connection Setup dialog box, click the B
open the ProSoft Discovery Service. Select the module, then right-click and
choose A
SSIGN
The module's default IP address is 192.168.0.250. Choose an unused IP
5
within your subnet, and then click OK.
Important: The temporary IP address is only valid until the next time the module is initialized. For
information on how to set the module's permanent IP address, see Ethernet Configuration (page
56).
ProSoft Technology, Inc.
T IP.
EMPORARY
Configuring the MVI56E-MNETCR Module
D ( ) button to
ROWSE EVICE S
User Manual
Page 59 of 161
