Analog Phone - Avaya IP Office Essential Edition PARTNER Version Reference Manual

Name
IPO 500 Extn Card Dgtl Sta 8

4.3.2 Analog Phone

This card is used to add analog phone extension ports to the IP 500v2 control unit. It is available in two variants,
providing either 2 or 8 analog extension ports.
Port Type Ports
Analog 1 to 8
Extension
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
· IP500 PRI Trunk
Card.
Description
IP Office 500 Extension Card Digital Station 8
· Supports
Provides either 8 or 2
variant.
· Maximum per control unit: 4.
· IP500 Daughter Card Support:
Features
· Phrase IP500 ETR Port
Supports ICLID modes
DTMFA, DTMFC,
DTMFD, FSK and UK20.
· REN 2 (1 for external
bell device).
· Off-Hook current:
25mA
· Ring Voltage: 40V.
· Intended for
connection to two-wire
analog phones, the
ports do not include a
ringing capacitor. For
connection to 4-wire
analog phones,
connection should be
via a master socket
with ringing capacitors.
· If fitted with an analog
trunk card, for the
Phone 8, during power
failure extension port 8
is connected to the
analog trunk port 12.
· Green on: Card fitted.
· Green flashing: Trunk in use.
PRI Trunk Daughter Card
· Off: No trunk present.
· Green on: Trunk present.
· Green flashing: Trunk in use.
analog phone ports depending on card
Port LEDs
No status LEDs are used for analog phone extensions.
· LED1 is used for base card status:
· Red On = Error
· Red Slow Flash = Initializing.
System Component Details: Base Cards
· Red/Green Fast
Flash (port 9) or
Green Fast Flash
(port 10): Alarm
indication signal
(AIS) from the
trunk remote end.
· Red with Green
Blink (port 9) or
Green Blink (port
10): Port in
loopback mode (set
through IP Office
System Monitor).
Part Number
700417330
1.
· Red Flash every
5 seconds =
Card okay.
· Red Fast Flash =
System
shutdown.
- Issue 1a (30 January 2010)
Page 51
