Port Type Ports
EF 7 to 8
Optional 9 to 12
Trunk Ports
Name
IPO 500v2 EXTN CARD ETR6
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
Features
· ICLID mode Bellcore
202.
· If fitted with an IP500
Trunk Daughter card,
during power failure
both these ports are
connected to analog
trunk port 12.
· Phrase IP500 ETR
PortSupports ICLID
modes DTMFA,
DTMFC, DTMFD, FSK
and UK20.
· REN 2 (1 for external
bell device).
· Off-Hook current:
25mA
· Ring Voltage: 40V.
· Intended for
connection to two-
wire analog phones,
the ports do not
include a ringing
capacitor. For
connection to 4-wire
analog phones,
connection should be
via a master socket
with ringing
capacitors.
The ETR6 can be fitted
with an Analog Trunk
card
Description
IP Office 500v2 EXTN CARD ETR6
Port LEDs
No status LEDs are used for analog phone extensions.
LED use depends daughter card type fitted.
· LED 9 is used for daughter card status.
· Red On = Error
· Red Slow Flash = Initializing.
Analog Trunk Daughter Card
· Green on: Card fitted.
· Green flashing: Trunk in use.
PRI Trunk Daughter Card
· Off: No trunk present.
· Green on: Trunk present.
· Green flashing: Trunk in use.
System Component Details: Base Cards
· Red Flash every 5
seconds = Card okay.
· Red Fast Flash =
System shutdown.
· Red/Green Fast Flash
(port 9) or Green Fast
Flash (port 10): Alarm
indication signal (AIS)
from the trunk remote
end.
· Red with Green Blink
(port 9) or Green Blink
(port 10): Port in
loopback mode (set
through IP Office System
Monitor).
Part Number
700476039
