IP500 Digital Station Base Card

4.3.1 Digital Station

This card is used to add digital station (DS) extension ports to the IP 500v2 control unit. It provides 8 RJ45 DS extension
ports for use with Avaya digital phones not including IP phones. A further 4 RJ45 ports are provided for trunk connections
when an IP500 trunk card is fitted to this card.
Port Type Ports
Digit Station 1 to 8
Optional Trunk 9 to 12
Card Ports
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
· The card can be fitted with an IP500 trunk daughter card which uses
the base card ports for trunk connection.
· Maximum: 3 per control unit.
· The analog phone ports do not include a ringing capacitor. Where
this is a requirement, connection should be via a Master socket
containing ringing capacitors.
· If fitted with an IP Office 500 Analog Trunk daughter card, during
power failure phone ports 7 and 8 are connected to analog trunk
port 12. However during normal operation analog phone ports 7 and
8 are not useable.
This card provides 8 DS (digital station) ports for the connection of
Avaya digital phones other than IP phones.
· The card can be fitted with an IP Office 500 trunk daughter card
which uses the base card ports for trunk connection.
· Maximum: 3 per control unit.
· 4400 Series phones (4406D, 4412D and 4424D) are not supported
on this card. They are supported on an external expansion module.
· Supports
Provides 8 DS ports for
· Maximum per Control Unit: 3.
· IP500 Daughter Card Support:
Features
Phrase IP500 Analog
PortsProvides DS ports
for digital stations (except
4406D, 4412D and
4424D).
The card can be fitted
with one of the following
trunk daughter cards. The
trunk daughter card then
uses ports 9 to 12 on the
base card for its trunk
connections.
· IP500 Analog
Trunk Card.
digital stations
Port LEDs
· Green On - Phone detected.
· LED1 is used for base card status:
· Red On = Error
· Red Slow Flash = Initializing.
LED use depends daughter card type fitted.
· LED 9 is used for daughter card status.
· Red On = Error
· Red Slow Flash = Initializing.
Analog Trunk Daughter Card
supported
1.
· Red Flash every
5 seconds =
Card okay.
· Red Fast Flash =
System
shutdown.
· Red Flash every
5 seconds =
Card okay.
· Red Fast Flash =
System
shutdown.
