4.1.1 Rear Connections

Only Port 1 of the extreme right hand expansion ports should be used.
Ports Description
AUDIO 3.5mm Stereo jack socket. Used for external music on hold source input.
AUX If pressed during a restart of the control unit, the control unit
the System SD card.
If pressed for between 5 and 10 seconds when a system is running, the control unit will shutdown for 10
minutes.
CPU Indicates the status of the control unit.
· Alternate red/green = Starting up.
· Green on = Okay.
EXPANSION RJ45 socket. Used for direct connection to external expansion modules using the Expansion Interconnect
cable supplied with the expansion module.
EXT O/P 3.5mm Stereo jack socket. Used for switching external relay systems such as door entry controls. The
port contains two independent switches controlled by the IP Office.
INPUT AC power input port.
LAN RJ45 socket. With the WAN port forms a managed layer 3 Ethernet switch. The ports are full-duplex
10/100Mbps auto-sensing, MDI crossover ports.
Optional SD Used for the Optional
RESET This switch is used to restart the IP Office, optionally erasing the configuration and or the core software
in the process. See table below.
RS232 9-Way D-Type socket. Used for system maintenance.
System SD Used for the System
· Off = Card
· Green on = Card present.
· Green flashing = Card in use.
· Orange steady = Reset imminent.
WAN Not used in Essential Edition - PARTNER® Version
Used for connection of a
and for some locales may be a regulatory requirement.
Reset button.
Pressing the button while the control unit is starting up will pause the start up until the button is released. The effect of
pressing the button during normal operation will depend on how long the button is pressed and is indicated by the CPU
LED.
Press Duration CPU LED
(seconds)
0 to 5. Off
5 to 10. Orange
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
SD card. The LED is used in the same way as for the System SD (see below).
SD card,. The LED is used as follows.
shutdown.
function or protective
Action
None
Reboot When Free
System Component Details: Control Unit
skip booting
· Red on = No software.
· Flashing Red = Error/Shutdown.
· Red flashing = Card initializing or shutting down.
· Red fast flashing = Card full
· Red steady = Card failure/wrong type.
ground. Use of a ground for all systems is recommended
Summary
None.
Reboot when free with new incoming/outgoing call
barring. A reboot using the reset button is recorded in
the Audit Trail.
from the /primary folder on
