2.2 Partner® Constraints
IP Office Essential Edition - PARTNER®
Version Base Cards:
Phone 8 - Base
Phone 2 - Base
DS 8 - Base
ETR6 – Base
6DS+2POTS+VCM10 LE Combination
IP Office Essential Edition - PARTNER®
Version Daughter Cards:
ATM 4 Uni - daughter
PRI 1 Uni - daughter
IP Office Essential Edition - PARTNER®
Version Expansion Modules:
IP Office 500v2 PHONE 16
IP Office 500v2 DIGITAL STATION 16
Essential Edition - PARTNER® Version requires a presence of at least 1 ETR or Digital station to be used for TUI
administration. This needs the presence of at least 1 of the following cards:
· Comination Card
· DS8
· ETR-6
System capacity for the Essential Edition - PARTNER® Version is flexible and can use combinations of the following
hardware components:
Control unit (4 available slots – maximum of 4 of the following cards):
• Up to 2 Combination cards (each provides 6 DS ports; 2 POTS station ports; 4 POTS line ports; and supports
up to 10 SIP lines)
• Up to 3 ETR6 cards (each provides 6 ETR station ports)
• Up to 3 DS8 cards (each provides 8 digital station ports)
• Up to 3 Phone 8 cards (each provides 8 POTS station ports)
o Maximum of 3 because a combination card; DS-8 or ETR-6 must be present in system
• Up to 3 Phone 2 cards (each provides up to 2 POTS station ports)
o Maximum of 3 because a combination card; DS-8 or ETR-6 must be present in system
An ATM4 daughter card can be added to any ETR card or DS card, or Phone card increasing POTS line capacity. 1 PRI/T1
daughter card may be added to any ETR card or DS card or Phone card, increasing digital line capacity.
One expansion module may be added to the main control unit; providing additional growth capability. The supported
expansion modules are:
• DS16 Expansion Module (adds 16 additional digital station ports.)
• Phone 16 Expansion Module (adds 16 additional analog station ports)
Based on these configurations; an Essential Edition - PARTNER® Version may support up to 64 lines (1-PRI; 3 ATM4; up
to 10 SIP trunks) and up to 48 stations (Up to 18 ETR stations and/or 46 digital ports + 2 POTS). Maximum growth
capabilities are software blocked in the system.
Essential Edition - PARTNER® Version will support up to 10 SIP trunks, which can be assigned across multiple SIP service
providers.
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
Max allowed in
system
3
3
3
3
2
3
1
1
1
System Overview: Partner® Constraints
- Issue 1a (30 January 2010)
Page 15
