APPENDIX A
APPENDIX A FLEXANALOG PARAMETERSA.1 PARAMETER LIST
Table A–1: FLEXANALOG PARAMETERS (Sheet 1 of 4)
SETTING
DISPLAY TEXT
6144
SRC 1 Ia RMS
6146
SRC 1 Ib RMS
6148
SRC 1 Ic RMS
6150
SRC 1 In RMS
6152
SRC 1 Ia Mag
6154
SRC 1 Ia Angle
6155
SRC 1 Ib Mag
6157
SRC 1 Ib Angle
6158
SRC 1 Ic Mag
6160
SRC 1 Ic Angle
6161
SRC 1 In Mag
6163
SRC 1 In Angle
6164
SRC 1 Ig RMS
6166
SRC 1 Ig Mag
6168
SRC 1 Ig Angle
6169
SRC 1 I_0 Mag
6171
SRC 1 I_0 Angle
6172
SRC 1 I_1 Mag
6174
SRC 1 I_1 Angle
6175
SRC 1 I_2 Mag
6177
SRC 1 I_2 Angle
6178
SRC 1 Igd Mag
6180
SRC 1 Igd Angle
6208
SRC 2 Ia RMS
6210
SRC 2 Ib RMS
6212
SRC 2 Ic RMS
6214
SRC 2 In RMS
6216
SRC 2 Ia Mag
6218
SRC 2 Ia Angle
6219
SRC 2 Ib Mag
6221
SRC 2 Ib Angle
6222
SRC 2 Ic Mag
6224
SRC 2 Ic Angle
6225
SRC 2 In Mag
6227
SRC 2 In Angle
6228
SRC 2 Ig RMS
6230
SRC 2 Ig Mag
6232
SRC 2 Ig Angle
6233
SRC 2 I_0 Mag
6235
SRC 2 I_0 Angle
6236
SRC 2 I_1 Mag
6238
SRC 2 I_1 Angle
6239
SRC 2 I_2 Mag
6241
SRC 2 I_2 Angle
6242
SRC 2 Igd Mag
6244
SRC 2 Igd Angle
6656
SRC 1 Vag RMS
6658
SRC 1 Vbg RMS
GE Power Management
DESCRIPTION
SRC 1 Phase A Current RMS (A)
SRC 1 Phase B Current RMS (A)
SRC 1 Phase C Current RMS (A)
SRC 1 Neutral Current RMS (A)
SRC 1 Phase A Current Magnitude (A)
SRC 1 Phase A Current Angle (°)
SRC 1 Phase B Current Magnitude (A)
SRC 1 Phase B Current Angle (°)
SRC 1 Phase C Current Magnitude (A)
SRC 1 Phase C Current Angle (°)
SRC 1 Neutral Current Magnitude (A)
SRC 1 Neutral Current Angle (°)
SRC 1 Ground Current RMS (A)
SRC 1 Ground Current Magnitude (A)
SRC 1 Ground Current Angle (°)
SRC 1 Zero Sequence Current Magnitude (A)
SRC 1 Zero Sequence Current Angle (°)
SRC 1 Positive Sequence Current Magnitude (A)
SRC 1 Positive Sequence Current Angle (°)
SRC 1 Negative Sequence Current Magnitude (A)
SRC 1 Negative Sequence Current Angle (°)
SRC 1 Differential Ground Current Magnitude (A)
SRC 1 Differential Ground Current Angle (°)
SRC 2 Phase A Current RMS (A)
SRC 2 Phase B Current RMS (A)
SRC 2 Phase C Current RMS (A)
SRC 2 Neutral Current RMS (A)
SRC 2 Phase A Current Magnitude (A)
SRC 2 Phase A Current Angle (°)
SRC 2 Phase B Current Magnitude (A)
SRC 2 Phase B Current Angle (°)
SRC 2 Phase C Current Magnitude (A)
SRC 2 Phase C Current Angle (°)
SRC 2 Neutral Current Magnitude (A)
SRC 2 Neutral Current Angle (°)
SRC 2 Ground Current RMS (A)
SRC 2 Ground Current Magnitude (A)
SRC 2 Ground Current Angle (°)
SRC 2 Zero Sequence Current Magnitude (A)
SRC 2 Zero Sequence Current Angle (°)
SRC 2 Positive Sequence Current Magnitude (A)
SRC 2 Positive Sequence Current Angle (°)
SRC 2 Negative Sequence Current Magnitude (A)
SRC 2 Negative Sequence Current Angle (°)
SRC 2 Differential Ground Current Magnitude (A)
SRC 2 Differential Ground Current Angle (°)
SRC 1 Phase AG Voltage RMS (V)
SRC 1 Phase BG Voltage RMS (V)
L90 Line Differential Relay
A.1 PARAMETER LIST
A.1.1 FLEXANALOG PARAMETER LIST
A
A-1
