Title Page
GE Multilin
215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: (905) 294-6222 Fax: (905) 201-2098
Internet:
http://www.GEindustrial.com/multilin
G60 Generator Management Relay
UR Series Instruction Manual
Manual P/N: 1601-0110-K1 (GEK-113011)
Copyright © 2005 GE Multilin
GE Industrial Systems
G60 Revision: 4.6x
830715A1.CDR
ISO9001:2000
GE Multilin's Quality Management
System is registered to
ISO9001:2000
QMI # 005094
UL # A3775

Advertisement

Table of Contents

   Related Manuals for GE G60

   Summary of Contents for GE G60

  • Page 1 Title Page GE Industrial Systems G60 Generator Management Relay UR Series Instruction Manual G60 Revision: 4.6x Manual P/N: 1601-0110-K1 (GEK-113011) Copyright © 2005 GE Multilin 830715A1.CDR GE Multilin ISO9001:2000 215 Anderson Avenue, Markham, Ontario Canada L6E 1B3 GE Multilin's Quality Management...
  • Page 3 GE Industrial Systems ADDENDUM This Addendum contains information that relates to the G60 Generator Management Relay relay, version 4.6x. This addendum lists a number of information items that appear in the instruction manual GEK-113011 (revision K1) but are not included in the current G60 operations.
  • Page 5: Table Of Contents

    IMPORTANT CONCEPTS ................. 1-4 1.3 ENERVISTA UR SETUP SOFTWARE 1.3.1 PC REQUIREMENTS ..................1-5 1.3.2 INSTALLATION....................1-5 1.3.3 CONNECTING ENERVISTA UR SETUP WITH THE G60 ........ 1-7 1.4 UR HARDWARE 1.4.1 MOUNTING AND WIRING................1-10 1.4.2 COMMUNICATIONS..................1-10 1.4.3 FACEPLATE DISPLAY ..................1-10 1.5 USING THE RELAY...
  • Page 6 FLEXCURVES ....................5-44 5.4 FLEXLOGIC™ 5.4.1 INTRODUCTION TO FLEXLOGIC™..............5-51 5.4.2 FLEXLOGIC™ RULES ..................5-59 5.4.3 FLEXLOGIC™ EVALUATION ................5-59 5.4.4 FLEXLOGIC™ EXAMPLE ................5-60 5.4.5 FLEXLOGIC™ EQUATION EDITOR..............5-64 5.4.6 FLEXLOGIC™ TIMERS ...................5-64 5.4.7 FLEXELEMENTS™ ..................5-65 5.4.8 NON-VOLATILE LATCHES ................5-69 G60 Generator Management Relay GE Multilin...
  • Page 7 VIRTUAL OUTPUTS ..................6-4 6.2.6 REMOTE DEVICES ................... 6-4 6.2.7 DIGITAL COUNTERS ..................6-5 6.2.8 SELECTOR SWITCHES..................6-5 6.2.9 FLEX STATES ....................6-5 6.2.10 ETHERNET......................6-6 6.2.11 DIRECT INPUTS....................6-6 6.2.12 DIRECT DEVICES STATUS................6-7 GE Multilin G60 Generator Management Relay...
  • Page 8 BACKUP DISTANCE ..................9-6 9.1.11 STATOR GROUND FAULT ................9-7 9.1.12 OVEREXCITATION ..................9-10 9.1.13 FREQUENCY ....................9-11 9.1.14 ACCIDENTAL ENERGIZATION ...............9-11 9.1.15 INPUTS/OUTPUTS ..................9-12 9.1.16 FLEXLOGIC™ ....................9-13 9.2 PHASE DISTANCE THROUGH POWER TRANSFORMERS 9.2.1 OVERVIEW ......................9-14 viii G60 Generator Management Relay GE Multilin...
  • Page 9 LOGICAL NODES TABLE .................C-7 D. IEC 60870-5-104 D.1 IEC 60870-5-104 COMMUNICATIONS D.1.1 INTEROPERABILITY DOCUMENT ..............D-1 D.1.2 IEC 60870-5-104 POINT LIST .................D-10 E. DNP COMMUNICATIONS E.1 DNP PROTOCOL E.1.1 DEVICE PROFILE DOCUMENT................E-1 E.1.2 DNP IMPLEMENTATION...................E-4 GE Multilin G60 Generator Management Relay...
  • Page 10 COUNTERS..................... E-15 E.2.4 ANALOG INPUTS.................... E-16 F. MISCELLANEOUS F.1 CHANGE NOTES F.1.1 REVISION HISTORY..................F-1 F.1.2 CHANGES TO THE G60 MANUAL ..............F-1 F.2 ABBREVIATIONS F.2.1 STANDARD ABBREVIATIONS ................. F-4 F.3 WARRANTY F.3.1 GE MULTILIN WARRANTY................F-6 INDEX G60 Generator Management Relay...
  • Page 11: Getting Started

    • registration card (attached as the last page of the manual) • Fill out the registration form and return to GE Multilin (include the serial number located on the rear nameplate). • For product information, instruction manual updates, and the latest software updates, please visit the GE Multilin web- site at http://www.GEindustrial.com/multilin.
  • Page 12: Ur Overview

    This new generation of equipment must also be easily incorporated into automation systems, at both the station and enterprise levels. The GE Multilin Universal Relay (UR) has been developed to meet these goals. G60 Generator Management Relay...
  • Page 13: Hardware Architecture

    (dual) ring configuration. This feature is optimized for speed and intended for pilot- aided schemes, distributed logic applications, or the extension of the input/output capabilities of a single relay chassis. GE Multilin G60 Generator Management Relay...
  • Page 14: Software Architecture

    CTs and VTs is in the Introduction to AC Sources section in Chapter 5. A description of how digital signals are used and routed within the relay is contained in the Introduction to FlexLogic™ section in Chapter 5. G60 Generator Management Relay GE Multilin...
  • Page 15: Enervista Ur Setup Software

    Video capable of displaying 800 x 600 or higher in high-color mode (16-bit color) • RS232 and/or Ethernet port for communications to the relay The following qualified modems have been tested to be compliant with the G60 and the EnerVista UR Setup software. • US Robotics external 56K FaxModem 5686 •...
  • Page 16 “CD” if you do not have a web connection, then click the Check Now button to list software items for the G60. Select the G60 software program and release notes (if desired) from the list and click the Download Now button to obtain the installation program.
  • Page 17: Connecting Enervista Ur Setup With The G60

    1 GETTING STARTED 1.3 ENERVISTA UR SETUP SOFTWARE 10. Click Finish to end the installation. The G60 device will be added to the list of installed IEDs in the enerVista Launch- pad window, as shown below. 1.3.3 CONNECTING ENERVISTA UR SETUP WITH THE G60 This section is intended as a quick start guide to using the EnerVista UR Setup software.
  • Page 18 Enter the physical communications parameters (baud rate and parity settings) in their respective fields. Click the Read Order Code button to connect to the G60 device and upload the order code. If an communications error occurs, ensure that the EnerVista UR Setup serial communications values entered in the previous step corre- spond to the relay setting values.
  • Page 19 The Display Properties settings can now be edited, printed, or changed according to user specifications. Refer to Chapter 4 in this manual and the EnerVista UR Setup Help File for more information about the using the EnerVista UR Setup software interface. NOTE GE Multilin G60 Generator Management Relay...
  • Page 20: Ur Hardware

    Figure 1–4: RELAY COMMUNICATIONS OPTIONS To communicate through the G60 rear RS485 port from a PC RS232 port, the GE Multilin RS232/RS485 converter box is required. This device (catalog number F485) connects to the computer using a “straight-through” serial cable. A shielded twisted-pair (20, 22, or 24 AWG) connects the F485 converter to the G60 rear communications port.
  • Page 21: Using The Relay

    MESSAGE key from a setting value or actual value display returns to the header display. HIGHEST LEVEL LOWEST LEVEL (SETTING VALUE) ## SETTINGS # PASSWORD ACCESS LEVEL: ## PRODUCT SETUP # SECURITY Restricted ## SETTINGS ## SYSTEM SETUP GE Multilin G60 Generator Management Relay 1-11...
  • Page 22: Relay Activation

    Refer to the Changing Settings section in Chapter 4 for complete instructions on setting up security level passwords. NOTE 1.5.6 FLEXLOGIC™ CUSTOMIZATION FlexLogic™ equation editing is required for setting up user-defined logic for customizing the relay operations. See the Flex- Logic™ section in Chapter 5 for additional details. 1-12 G60 Generator Management Relay GE Multilin...
  • Page 23: Commissioning

    View the event recorder and oscillography or fault report for correct operation of inputs, outputs, and elements. If it is concluded that the relay or one of its modules is of concern, contact GE Multilin or one of its representatives for prompt service.
  • Page 24 1.5 USING THE RELAY 1 GETTING STARTED 1-14 G60 Generator Management Relay GE Multilin...
  • Page 25: Product Description

    Another option provides two 10BaseF fiber optic ports for redundancy. The Ethernet port supports IEC 61850, Modbus TCP, and TFTP protocols, and allows access to the relay via any standard web browser (G60 web pages). The IEC 60870- 5-104 protocol is supported on the Ethernet port. DNP 3.0 and IEC 60870-5-104 cannot be enabled at the same time.
  • Page 26: Ordering

    The information required to completely specify the relay is provided in the following table (see Chapter 3 for full details of relay modules). G60 Generator Management Relay GE Multilin...
  • Page 27 2.1 INTRODUCTION Table 2–3: G60 ORDER CODES G60 - * 00 - H * * - F ** - H ** - M ** - P ** - U ** - W ** Full Size Horizontal Mount G60 - * 00 - V F * - F ** - H ** - M **...
  • Page 28 4 dcmA Inputs, 4 dcmA Outputs (only one 5A module is allowed) INPUTS/OUTPUTS 8 RTD Inputs 4 RTD Inputs, 4 dcmA Outputs (only one 5D module is allowed) 4 dcmA Inputs, 4 RTD Inputs 8 dcmA Inputs G60 Generator Management Relay GE Multilin...
  • Page 29: Specifications

    The operating times are average times including variables such as fault inception angle or type of a voltage source (magnetic VTs and CVTs). Phase Element (21P) SIR = 0.1 SIR = 1 SIR = 10 SIR = 20 SIR = 30 Fault Location [%] 837717A1.CDR GE Multilin G60 Generator Management Relay...
  • Page 30 IEEE Moderately/Very/Extremely Limit angle: 40 to 90° in steps of 1, independent for Inverse; IEC (and BS) A/B/C and Short forward and reverse Inverse; GE IAC Inverse, Short/Very/ Angle accuracy: ±2° Extremely Inverse; I t; FlexCurves™ (programmable); Definite Time (0.01 s 0.00 to 250.00 Ω...
  • Page 31 < 30 ms at 1.10 × Pickup at 60 Hz Operate time: Level accuracy: ±0.5% of reading from 10 to 208 V VOLTS PER HERTZ Curve shapes: GE IAV Inverse, Definite Time Voltage: Phasor only Curve multiplier: Time Dial = 0 to 600.00 in steps of 0.01 Pickup level: 0.80 to 4.00 in steps of 0.01 pu V/Hz...
  • Page 32 0.000 to 1.250 pu in steps of 0.001 Accuracy: ± 0.5% of reading from 10 to 208 V Pickup delay: 0 to 65.535 s in steps of 0.001 Timing accuracy: ±3% or ±20 ms, whichever is greater Operate time: <50 ms G60 Generator Management Relay GE Multilin...
  • Page 33: User-programmable Elements

    Pickup & dropout delay: 0.000 to 65.535 s in steps of 0.001 chronize to a 3-bit control input NON-VOLATILE LATCHES Type: Set-dominant or Reset-dominant Number: 16 (individually programmed) Output: Stored in non-volatile memory Execution sequence: As input prior to protection, control, and FlexLogic™ GE Multilin G60 Generator Management Relay...
  • Page 34: Monitoring

    ±0.01 Hz (when voltage signal is used Accuracy: ±1.0% of reading for frequency measurement) I = 0.1 to 0.25 pu: ±0.05 Hz I > 0.25 pu: ±0.02 Hz (when current signal is used for frequency measurement) 2-10 G60 Generator Management Relay GE Multilin...
  • Page 35: Inputs

    Nominal AC voltage: 100 to 240 V at 50/60 Hz, 0.7 A INTERRUPTING CAPACITY Min/max AC voltage: 88 / 265 V at 48 to 62 Hz 100 000 A RMS symmetrical 10 000 A GE Multilin G60 Generator Management Relay 2-11...
  • Page 36: Outputs

    99% Settling time to a step change: 100 ms Isolation: 1.5 kV Driving signal: any FlexAnalog quantity Upper and lower limit for the driving signal: –90 to 90 pu in steps of 0.001 2-12 G60 Generator Management Relay GE Multilin...
  • Page 37: Communications

    1300 nm LED, Multimode –11 dBm asymmetry) channel delays using GPS satellite clock: 10 ms 1300 nm ELED, Singlemode –14 dBm 1300 nm Laser, Singlemode –14 dBm 1550 nm Laser, Singlemode –14 dBm GE Multilin G60 Generator Management Relay 2-13...
  • Page 38: Environmental

    CLEANING Attach mounting brackets using 20 inch-pounds (±2 inch-pounds) Normally, cleaning is not required; but for situations where dust of torque. has accumulated on the faceplate display, a dry cloth can be used. 2-14 G60 Generator Management Relay GE Multilin...
  • Page 39: Hardware

    RS232 communications port. The relay is secured to the panel with the use of four screws supplied with the relay. UR SERIES UR SERIES Figure 3–1: G60 VERTICAL MOUNTING AND DIMENSIONS GE Multilin G60 Generator Management Relay...
  • Page 40 3.1 DESCRIPTION 3 HARDWARE Figure 3–2: G60 VERTICAL SIDE MOUNTING INSTALLATION G60 Generator Management Relay GE Multilin...
  • Page 41 3 HARDWARE 3.1 DESCRIPTION Figure 3–3: G60 VERTICAL SIDE MOUNTING REAR DIMENSIONS Figure 3–4: G60 HORIZONTAL MOUNTING AND DIMENSIONS GE Multilin G60 Generator Management Relay...
  • Page 42: Module Withdrawal And Insertion

    NOTE The version 4.0 release of the G60 relay includes new hardware (CPU and CT/VT modules). The new CPU mod- ules are specified with the following order codes: 9E, 9G, and 9H. The new CT/VT modules are specified with the following order codes: 8F, 8G, 8H, 8J.
  • Page 43: Rear Terminal Layout

    (nearest to CPU module) which is indicated by an arrow marker on the terminal block. See the following figure for an example of rear terminal assignments. Figure 3–7: EXAMPLE OF MODULES IN F AND H SLOTS GE Multilin G60 Generator Management Relay...
  • Page 44: Wiring

    (front) FILTER DB-9 CONTACTS SHOWN WITH NO CONTROL POWER MODULE ARRANGEMENT No. 10AWG Minimum GROUND VT/CT Power Supply (Rear View) MODULES MUST BE GROUNDED IF TERMINAL IS PROVIDED 830721A3.CDR Figure 3–8: TYPICAL WIRING DIAGRAM G60 Generator Management Relay GE Multilin...
  • Page 45: Dielectric Strength

    RANGE OF THE RELAY. IF THE VOLTAGE IS APPLIED TO THE WRONG TERMINALS, DAMAGE MAY OCCUR! CAUTION The G60 relay, like almost all electronic relays, contains electrolytic capacitors. These capacitors are well known to be subject to deterioration over time if voltage is not applied periodically. Deterioration can be NOTE avoided by powering the relays up once a year.
  • Page 46: Ct/vt Modules

    CT connections for both ABC and ACB phase rotations are identical as shown in the Typical Wiring Diagram. The exact placement of a zero-sequence CT so that ground fault current will be detected is shown below. Twisted pair cabling on the zero-sequence CT is recommended. G60 Generator Management Relay GE Multilin...
  • Page 47 The phase voltage channels are used for most metering and protection purposes. The auxiliary voltage channel is used as input for the Synchrocheck and Volts/Hertz features. 827831AA-X5.CDR 827831AA-X3.CDR Figure 3–11: CT/VT MODULE WIRING Wherever a tilde “~” symbol appears, substitute with the Slot Position of the module. NOTE GE Multilin G60 Generator Management Relay...
  • Page 48: Contact Inputs/outputs

    Cont Op x Ioff Load b) Current with optional voltage monitoring Current monitoring only Both voltage and current monitoring (external jumper a-b is required) 827821A5.CDR Load c) No monitoring Figure 3–12: FORM-A /SOLID STATE CONTACT FUNCTIONS 3-10 G60 Generator Management Relay GE Multilin...
  • Page 49 ~6a, ~6c 2 Inputs Form-A ~7a, ~7c 2 Inputs Fast Form-C ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~8a, ~8c 2 Inputs Fast Form-C ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs GE Multilin G60 Generator Management Relay 3-11...
  • Page 50 OUTPUT TERMINAL OUTPUT ASSIGNMENT ASSIGNMENT Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State 2 Outputs Not Used 2 Outputs Solid-State Not Used 3-12 G60 Generator Management Relay GE Multilin...
  • Page 51 3 HARDWARE 3.2 WIRING 827719CY-X1.dwg Figure 3–13: DIGITAL INPUT/OUTPUT MODULE WIRING (1 of 2) GE Multilin G60 Generator Management Relay 3-13...
  • Page 52 – MOSFET Solid State Contact 827719CY-X2.dwg Figure 3–14: DIGITAL INPUT/OUTPUT MODULE WIRING (2 of 2) CORRECT POLARITY MUST BE OBSERVED FOR ALL CONTACT INPUT AND SOLID STATE OUTPUT CON- NECTIONS FOR PROPER FUNCTIONALITY. CAUTION 3-14 G60 Generator Management Relay GE Multilin...
  • Page 53 There is no provision in the relay to detect a DC ground fault on 48 V DC control power external output. We recommend using an external DC supply. NOTE GE Multilin G60 Generator Management Relay 3-15...
  • Page 54: Transducer Inputs/outputs

    (5A, 5C, 5D, 5E, and 5F) and channel arrangements that may be ordered for the relay. Wherever a tilde “~” symbol appears, substitute with the Slot Position of the module. NOTE 827831AB-X1.CDR Figure 3–16: TRANSDUCER INPUT/OUTPUT MODULE WIRING 3-16 G60 Generator Management Relay GE Multilin...
  • Page 55: Rs232 Faceplate Port

    Cabling for the RS232 port is shown in the following figure for both 9 pin and 25 pin connectors. The baud rate for this port is fixed at 19200 bps. NOTE Figure 3–17: RS232 FACEPLATE PORT CONNECTION GE Multilin G60 Generator Management Relay 3-17...
  • Page 56: Cpu Communications Ports

    To ensure maximum reliability, all equipment should have similar transient protection devices installed. Both ends of the RS485 circuit should also be terminated with an impedance as shown below. 3-18 G60 Generator Management Relay GE Multilin...
  • Page 57 When splicing optical fibers, the diameter and numerical aperture of each fiber must be the same. In order to engage or dis- engage the ST type connector, only a quarter turn of the coupling is required. GE Multilin G60 Generator Management Relay 3-19...
  • Page 58: Irig-b

    UR-series relays can be synchronized. The IRIG-B repeater has a bypass function to maintain the time signal even when a relay in the series is powered down. Figure 3–21: IRIG-B REPEATER 3-20 G60 Generator Management Relay GE Multilin...
  • Page 59: Direct I/o Communications

    3.3DIRECT I/O COMMUNICATIONS 3.3.1 DESCRIPTION The G60 direct inputs/outputs feature makes use of the Type 7 series of communications modules. These modules are also used by the L90 Line Differential Relay for inter-relay communications. The direct input/output feature uses the communica- tions channel(s) provided by these modules to exchange digital state information between relays.
  • Page 60 Channel 1 - G.703; Channel 2 - 1550 nm, single-mode, LASER IEEE C37.94, 820 nm, multi-mode, LED, 1 channel IEEE C37.94, 820 nm, multi-mode, LED, 2 channels OBSERVING ANY FIBER TRANSMITTER OUTPUT MAY CAUSE INJURY TO THE EYE. CAUTION 3-22 G60 Generator Management Relay GE Multilin...
  • Page 61: Fiber: Led And Eled Transmitters

    1 Channel 2 Channels 831720A3.CDR Figure 3–26: LASER FIBER MODULES When using a LASER Interface, attenuators may be necessary to ensure that you do not exceed Maximum Optical Input Power to the receiver. WARNING GE Multilin G60 Generator Management Relay 3-23...
  • Page 62: Interface

    Remove the top cover by sliding it towards the rear and then lift it upwards. Set the Timing Selection Switches (Channel 1, Channel 2) to the desired timing modes. Replace the top cover and the cover screw. 3-24 G60 Generator Management Relay GE Multilin...
  • Page 63 Loop Timing Mode for connections to higher order systems. For connection to a higher order system (UR- to-multiplexer, factory defaults), set to Octet Timing (S1 = ON) and set Timing Mode = Loop Timing (S5 = OFF and S6 = OFF). GE Multilin G60 Generator Management Relay 3-25...
  • Page 64: Rs422 Interface

    The shield pins (6a and 7b) are internally connected to the ground pin (8a). Proper shield termination is as follows: Site 1: Terminate shield to pins 6a and/or 7b; Site 2: Terminate shield to ‘COM’ pin 2b. 3-26 G60 Generator Management Relay GE Multilin...
  • Page 65 1 as shown in the following figure. If the Terminal Timing feature is not available or this type of connection is not desired, the G.703 interface is a viable option that does not impose timing restrictions. GE Multilin G60 Generator Management Relay 3-27...
  • Page 66 Figure 3–32: TIMING CONFIGURATION FOR RS422 TWO-CHANNEL, 3-TERMINAL APPLICATION Data Module 1 provides timing to the G60 RS422 interface via the ST(A) and ST(B) outputs. Data Module 1 also provides timing to Data Module 2 TT(A) and TT(B) inputs via the ST(A) and AT(B) outputs. The Data Module pin numbers have been omitted in the figure above since they may vary depending on the manufacturer.
  • Page 67: Rs422 And Fiber Interface

    When using a LASER Interface, attenuators may be necessary to ensure that you do not exceed Maximum Optical Input Power to the receiver. WARNING Shld. Tx - G.703 Rx - CHANNEL 1 Tx + Rx + SURGE FIBER CHANNEL 2 Figure 3–35: G.703 AND FIBER INTERFACE CONNECTION GE Multilin G60 Generator Management Relay 3-29...
  • Page 68: Ieee C37.94 Interface

    Loop Timed Internal Timing Mode xt te xt te xt te xt te xt te xt te xt te xt te xt te xt te Switch Internal Loop Timed 3-30 G60 Generator Management Relay GE Multilin...
  • Page 69 Once the clips have cleared the raised edge of the chassis, engage the clips simultaneously. When the clips have locked into position, the module will be fully inserted. Figure 3–36: C37.94 TIMING SELECTION SWITCH SETTING GE Multilin G60 Generator Management Relay 3-31...
  • Page 70 3.3 DIRECT I/O COMMUNICATIONS 3 HARDWARE 3-32 G60 Generator Management Relay GE Multilin...
  • Page 71: Human Interfaces

    To start using the EnerVista UR Setup software, a site definition and device definition must first be created. See the EnerV- ista UR Setup Help File or refer to the Connecting EnerVista UR Setup with the G60 section in Chapter 1 for details.
  • Page 72 Site List window will automatically be sent to the on-line communicating device. g) FIRMWARE UPGRADES The firmware of a G60 device can be upgraded, locally or remotely, via the EnerVista UR Setup software. The correspond- ing instructions are provided by the EnerVista UR Setup Help file under the topic “Upgrading Firmware”.
  • Page 73: Enervista Ur Setup Main Window

    Settings List control bar window Device data view window(s), with common tool bar Settings File data view window(s), with common tool bar Workspace area with data view tabs Status bar Figure 4–1: ENERVISTA UR SETUP SOFTWARE MAIN WINDOW GE Multilin G60 Generator Management Relay...
  • Page 74: Faceplate Interface

    IN SERVICE VOLTAGE TROUBLE CURRENT RESET TEST MODE FREQUENCY LED PANEL 1 TRIP OTHER USER 1 ALARM PHASE A PICKUP PHASE B USER 2 PHASE C NEUTRAL/GROUND USER 3 Figure 4–3: UR-SERIES VERTICAL FACEPLATE PANELS G60 Generator Management Relay GE Multilin...
  • Page 75: Led Indicators

    OTHER: Indicates a composite function was involved. • PHASE A: Indicates Phase A was involved. • PHASE B: Indicates Phase B was involved. • PHASE C: Indicates Phase C was involved. • NEUTRAL/GROUND: Indicates neutral or ground was involved. GE Multilin G60 Generator Management Relay...
  • Page 76 SYNCHROCHECK SETTINGS IN USE NO1 IN-SYNCH GROUP 1 NO2 IN-SYNCH GROUP 2 GROUP 3 GROUP 4 GROUP 5 GROUP 6 GROUP 7 GROUP 8 Figure 4–6: LED PANEL 2 (DEFAULT LABELS) G60 Generator Management Relay GE Multilin...
  • Page 77 Microsoft Word 97 or later software for editing the template. • 1 each of: 8.5" x 11" white paper, exacto knife, ruler, custom display module (GE Multilin Part Number: 1516-0069), and a custom module cover (GE Multilin Part Number: 1502-0015).
  • Page 78: Display

    MESSAGE key from a setting value or actual value display returns to the header display. HIGHEST LEVEL LOWEST LEVEL (SETTING VALUE) ## SETTINGS # PASSWORD ACCESS LEVEL: ## PRODUCT SETUP # SECURITY Restricted G60 Generator Management Relay GE Multilin...
  • Page 79: Changing Settings

    Press the MINIMUM: again to view the next context sensitive help message. MAXIMUM: 10.0 Two methods of editing and storing a numerical setting value are available. GE Multilin G60 Generator Management Relay...
  • Page 80 If you have any problem, press to view context sensitive help. Flash messages will sequentially appear for sev- eral seconds each. For the case of a text setting message, pressing displays how to edit and store new values. 4-10 G60 Generator Management Relay GE Multilin...
  • Page 81 ACCESS LEVEL Press the MESSAGE key until the message appears on the display. CHANGE SETTING COMMAND PASSWORD SETTINGS " ## SETTINGS # PASSWORD ACCESS LEVEL: ## PRODUCT SETUP # SECURITY Restricted GE Multilin G60 Generator Management Relay 4-11...
  • Page 82 (for each security level) before a new password can be entered. In the event that a password has been lost (forgotten), submit the corresponding Encrypted Password from the PASSWORD menu to the Factory for decoding. SECURITY 4-12 G60 Generator Management Relay GE Multilin...
  • Page 83: Overview

    See page 5-34. # INSTALLATION See page 5-39. ## SETTINGS # AC INPUTS See page 5-40. ## SYSTEM SETUP # POWER SYSTEM See page 5-41. # SIGNAL SOURCES See page 5-42. # FLEXCURVES See page 5-44. GE Multilin G60 Generator Management Relay...
  • Page 84 # MONITORING ELEMENTS See page 5-163. ## SETTINGS # CONTACT INPUTS See page 5-164. ## INPUTS / OUTPUTS # VIRTUAL INPUTS See page 5-166. # CONTACT OUTPUTS See page 5-167. # VIRTUAL OUTPUTS See page 5-169. G60 Generator Management Relay GE Multilin...
  • Page 85: Introduction To Elements

    (abbreviations used on scheme logic diagrams are defined in Appendix F). Some settings for current and voltage elements are specified in per-unit (pu) calculated quantities: pu quantity = (actual quantity) / (base quantity) GE Multilin G60 Generator Management Relay...
  • Page 86 The DPO event is created when the measure and decide comparator output transits from the pickup state (logic 1) to the dropout state (logic 0). This could happen when the element is in the operate state if the reset delay time is not ‘0’. G60 Generator Management Relay GE Multilin...
  • Page 87: Introduction To Ac Sources

    BACKGROUND The G60 may be used on systems with breaker-and-a-half or ring bus configurations. In these applications, each of the two three-phase sets of individual phase currents (one associated with each breaker) can be used as an input to a breaker fail- ure element.
  • Page 88 Source is a transformer winding, on which a three phase voltage is mea- sured, and the sum of the currents from CTs on each of two breakers is required to measure the winding current flow. G60 Generator Management Relay GE Multilin...
  • Page 89: Product Setup

    If an entered password is lost (or forgotten), consult the factory with the corresponding ENCRYPTED PASSWORD The G60 provides a means to raise an alarm upon failed password entry. Should password verification fail while accessing a password-protected level of the relay (either settings or commands), the FlexLogic™...
  • Page 90: Display Properties

    Some customers prefer very low currents to display as zero, while others prefer the current be displayed even when the value reflects noise rather than the actual signal. The G60 applies a cut- off value to the magnitudes and angles of the measured currents.
  • Page 91 VOLTAGE CUT-OFF LEVEL CURRENT CUT-OFF LEVEL as valid measurements. Unless dictated otherwise by a specific application, the default settings of “0.02 pu” for and “1.0 V” for are recommended. NOTE CURRENT CUT-OFF LEVEL VOLTAGE CUT-OFF LEVEL GE Multilin G60 Generator Management Relay...
  • Page 92: Clear Relay Records

    Selected records can be cleared from user-programmable conditions with FlexLogic™ operands. Assigning user-program- mable pushbuttons to clear specific records are typical applications for these commands. Since the G60 responds to rising edges of the configured FlexLogic™ operands, they must be asserted for at least 50 ms to take effect.
  • Page 93: Communications

    0 ms The G60 is equipped with up to 3 independent serial communication ports. The faceplate RS232 port is intended for local use and is fixed at 19200 baud and no parity. The rear COM1 port type is selected when ordering: either an Ethernet or RS485 port.
  • Page 94 MODBUS SLAVE ADDRESS grammed. For the RS485 ports each G60 must have a unique address from 1 to 254. Address 0 is the broadcast address which all Modbus slave devices listen to. Addresses do not have to be sequential, but no two devices can have the same address or conflicts resulting in errors will occur.
  • Page 95 DEADBAND: 30000 Range: 0 to 65535 in steps of 1 DNP OTHER DEFAULT MESSAGE DEADBAND: 30000 Range: 1 to 10080 min. in steps of 1 DNP TIME SYNC IIN MESSAGE PERIOD: 1440 min GE Multilin G60 Generator Management Relay 5-13...
  • Page 96 DNP VOLTAGE SCALE FACTOR Input points that are voltages will be returned with values 1000 times smaller (e.g. a value of 72000 V on the G60 will be returned as 72). These settings are useful when analog input values must be adjusted to fit within certain ranges in DNP masters.
  • Page 97 47, etc. The minimum number of binary input points that can be selected is 16 (1 block). If all of the BIN INPUT BLOCK X settings are set to “Not Used”, the standard list of 928 points will be in effect. The G60 will form the binary inputs points list from the settings up to the first occurrence of a setting value of “Not Used”.
  • Page 98 The G60 supports the Manufacturing Message Specification (MMS) protocol as specified by IEC 61850. MMS is supported over two protocol stacks: TCP/IP over ethernet and TP4/CLNP (OSI) over ethernet. The G60 operates as an IEC 61850 server. The Remote Inputs/Outputs section in this chapter describe the peer-to-peer GSSE/GOOSE message scheme.
  • Page 99 Internet Explorer or Netscape Navigator. This feature is available only if the G60 has the ethernet option installed. The web pages are organized as a series of menus that can be accessed starting at the G60 “Main Menu”. Web pages are available showing DNP and IEC 60870-5-104 points lists, Modbus registers, Event Records, Fault Reports, etc.
  • Page 100 NUMBER: The Trivial File Transfer Protocol (TFTP) can be used to transfer files from the G60 over a network. The G60 operates as a TFTP server. TFTP client software is available from various sources, including Microsoft Windows NT. The dir.txt file obtained from the G60 contains a list and description of all available files (event records, oscillography, etc.).
  • Page 101 G60 clock is closely synchronized with the SNTP/NTP server. It may take up to one minute for the G60 to signal an SNTP self-test error if the server is offline.
  • Page 102 MESSAGE (Modbus register address range) Fast exchanges (50 to 1000 ms) are generally used in control schemes. The G60 has one fast exchange (Exchange 1) and two slow exchanges (Exchanges 2 and 3). The settings menu for the slow EGD exchanges is shown below: !"...
  • Page 103: Modbus User Map

    See also the !" menu for manually setting the relay clock. COMMANDS SET DATE AND TIME setting allows changes to the date and/or time to be captured in the event record. REAL TIME CLOCK EVENTS GE Multilin G60 Generator Management Relay 5-21...
  • Page 104: User-programmable Fault Report

    The user programmable record contains the following information: the user-programmed relay name, detailed firmware revision (4.6x, for example) and relay model (G60), the date and time of trigger, the name of pre-fault trigger (specific Flex- Logic™ operand), the name of fault trigger (specific FlexLogic™ operand), the active setting group at pre-fault trigger, the active setting group at fault trigger, pre-fault values of all programmed analog channels (one cycle before pre-fault trigger), and fault values of all programmed analog channels (at the fault trigger).
  • Page 105: Oscillography

    64 samples per cycle, i.e. it has no effect on the fundamental calculations of the device. When changes are made to the oscillography settings, all existing oscillography records will be CLEARED. WARNING GE Multilin G60 Generator Management Relay 5-23...
  • Page 106: Data Logger

    Range: Off, any FlexAnalog parameter. See Appendix A: DATA LOGGER CHNL 16: MESSAGE FlexAnalog Parameters for complete list. Range: Not applicable - shows computed data only DATA LOGGER CONFIG: MESSAGE 0 CHNL x 0.0 DAYS 5-24 G60 Generator Management Relay GE Multilin...
  • Page 107 Stage 1: All 62 LEDs on the relay are illuminated. This is a quick test to verify if any of the LEDs is “burned”. This stage lasts as long as the control input is on, up to a maximum of 1 minute. After 1 minute, the test will end. GE Multilin G60 Generator Management Relay 5-25...
  • Page 108 Configure User-Programmable Pushbutton 1 by making the following entries in the SETTINGS !" menu: PRODUCT SETUP USER-PROGRAMMABLE PUSHBUTTONS USER PUSHBUTTON 1 “Self-reset” PUSHBUTTON 1 FUNCTION: “0.10 s” PUSHBTN 1 DROP-OUT TIME: 5-26 G60 Generator Management Relay GE Multilin...
  • Page 109: User-programmable Leds

    ‘Latched’, the LED, once lit, remains so until reset by the faceplate RESET button, from a remote device via a communi- cations channel, or from any programmed operand, even if the LED operand state de-asserts. GE Multilin G60 Generator Management Relay 5-27...
  • Page 110: User-programmable Self Tests

    ANY MINOR ALARM ANY SELF-TEST minor alarms continue to function along with other major and minor alarms. Refer to the Relay Self-Tests section in Chapter 7 for additional information on major and minor self-test alarms. 5-28 G60 Generator Management Relay GE Multilin...
  • Page 111: Control Pushbuttons

    LED test, switching setting groups, and invoking and scrolling though user-pro- grammable displays, etc. The location of the control pushbuttons in the following figure. An additonal four control pushbuttons are included when the G60 is ordered with twelve user programmable pushbuttons. STATUS...
  • Page 112: User-programmable Pushbuttons

    MESSAGE EVENTS: Disabled The G60 has 12 optional user-programmable pushbuttons available, each configured via 12 identical menus. The pushbut- tons provide an easy and error-free method of manually entering digital information (On, Off) into FlexLogic™ equations as well as protection and control elements. Typical applications include breaker control, autorecloser blocking, ground protec- tion blocking, and setting groups changes.
  • Page 113: Flex State Parameters

    The state bits may be read out in the "Flex States" register array beginning at Modbus address 900 hex. 16 states are packed into each register, with the lowest-numbered state in the lowest-order bit. There are 16 registers in total to accom- modate the 256 state bits. GE Multilin G60 Generator Management Relay 5-31...
  • Page 114: User-definable Displays

    Range: 0 to 65535 in steps of 1 DISP 1 ITEM 3 MESSAGE Range: 0 to 65535 in steps of 1 DISP 1 ITEM 4 MESSAGE Range: 0 to 65535 in steps of 1 DISP 1 ITEM 5: MESSAGE 5-32 G60 Generator Management Relay GE Multilin...
  • Page 115 This item is not being used - there is no corresponding DISP 1 ITEM 5: MESSAGE Tilde marker in Top or Bottom lines. Shows the resultant display content. USER DISPLAYS Current X 0.850 A → Current Y 0.327 A GE Multilin G60 Generator Management Relay 5-33...
  • Page 116: Direct Inputs/outputs

    128 kbps. For local relays configured with all other communication cards (i.e. 7E, 7F, 7G, 7L, 7M, 7N, 7P, 7R, 7S, 7T, 7W, 74, 75, 76 and 77), the baud rate will be set to 64 kbps. All IEDs communicating over direct inputs/outputs must be set to 5-34 G60 Generator Management Relay GE Multilin...
  • Page 117 2, 3, and 4, to the upstream device that monitors a single incomer of the busbar, as shown below. UR IED 1 BLOCK UR IED 4 UR IED 2 UR IED 3 842712A1.CDR Figure 5–7: SAMPLE INTERLOCKING BUSBAR PROTECTION SCHEME GE Multilin G60 Generator Management Relay 5-35...
  • Page 118 Figure 5–9: THREE-TERMINAL LINE APPLICATION A permissive pilot-aided scheme could be implemented in a two-ring configuration as shown below (IEDs 1 and 2 constitute a first ring, while IEDs 2 and 3 constitute a second ring): 5-36 G60 Generator Management Relay GE Multilin...
  • Page 119 IED 2 to IED 3: 0.2 of power system cycle The two communications configurations could be applied to both permissive and blocking schemes. Speed, reliability and cost should be taken into account when selecting the required architecture. GE Multilin G60 Generator Management Relay 5-37...
  • Page 120 MESSAGE EVENTS: Disabled The G60 checks integrity of the incoming direct input/output messages using a 32-bit CRC. The CRC Alarm function is available for monitoring the communication medium noise by tracking the rate of messages failing the CRC check. The monitoring function counts all incoming messages, including messages that failed the CRC check.
  • Page 121: Installation

    MESSAGE EVENTS: Disabled The G60 checks integrity of the direct input/output communication ring by counting unreturned messages. In the ring con- figuration, all messages originating at a given device should return within a pre-defined period of time. The Unreturned Messages Alarm function is available for monitoring the integrity of the communication ring by tracking the rate of unre- turned messages.
  • Page 122: System Setup

    1000:1 CT before summation. If a protection element is set up to act on SRC 1 currents, then a pickup level of 1 pu will operate on 1000 A primary. The same rule applies for current sums from CTs with different secondary taps (5 A and 1 A). 5-40 G60 Generator Management Relay GE Multilin...
  • Page 123: Power System

    GE Multilin G60 Generator Management Relay 5-41...
  • Page 124: Signal Sources

    CT and VT input. For CT inputs, this is the nominal primary and secondary current. For VTs, this is the connection type, ratio and nominal secondary voltage. Once the inputs have been specified, the configuration for each Source is entered, including specifying which CTs will be summed together. 5-42 G60 Generator Management Relay GE Multilin...
  • Page 125 CT/VT inputs that are used to provide the data. DSP Bank Source 1 Source 2 Amps Amps Source 3 51BF-1 51BF-2 Volts Amps Volts Amps Source 4 UR Relay Figure 5–12: EXAMPLE USE OF SOURCES GE Multilin G60 Generator Management Relay 5-43...
  • Page 126: Flexcurves

    1, i.e. 0.98 pu and 1.03 pu. It is recommended to set the two times to a similar value; otherwise, the linear NOTE approximation may result in undesired behavior for the operating quantity that is close to 1.00 pu. 5-44 G60 Generator Management Relay GE Multilin...
  • Page 127 Multiplier and Adder settings only affect the curve portion of the characteristic and not the MRT and HCT settings. The HCT settings override the MRT settings for multiples of pickup greater than the HCT Ratio. NOTE GE Multilin G60 Generator Management Relay 5-45...
  • Page 128 EnerVista UR Setup software generates an error message and discards the proposed changes. NOTE e) STANDARD RECLOSER CURVES The standard Recloser curves available for the G60 are displayed in the following graphs. 5-46 G60 Generator Management Relay...
  • Page 129 CURRENT (multiple of pickup) 842723A1.CDR Figure 5–16: RECLOSER CURVES GE101 TO GE106 GE142 GE138 GE120 GE113 0.05 7 8 9 10 12 CURRENT (multiple of pickup) 842725A1.CDR Figure 5–17: RECLOSER CURVES GE113, GE120, GE138 AND GE142 GE Multilin G60 Generator Management Relay 5-47...
  • Page 130 Figure 5–18: RECLOSER CURVES GE134, GE137, GE140, GE151 AND GE201 GE152 GE141 GE131 GE200 7 8 9 10 12 CURRENT (multiple of pickup) 842728A1.CDR Figure 5–19: RECLOSER CURVES GE131, GE141, GE152, AND GE200 5-48 G60 Generator Management Relay GE Multilin...
  • Page 131 Figure 5–20: RECLOSER CURVES GE133, GE161, GE162, GE163, GE164 AND GE165 GE132 GE139 GE136 GE116 0.05 GE117 GE118 0.02 0.01 7 8 9 10 12 CURRENT (multiple of pickup) 842726A1.CDR Figure 5–21: RECLOSER CURVES GE116, GE117, GE118, GE132, GE136, AND GE139 GE Multilin G60 Generator Management Relay 5-49...
  • Page 132 Figure 5–22: RECLOSER CURVES GE107, GE111, GE112, GE114, GE115, GE121, AND GE122 GE202 GE135 GE119 7 8 9 10 12 CURRENT (multiple of pickup) 842727A1.CDR Figure 5–23: RECLOSER CURVES GE119, GE135, AND GE202 5-50 G60 Generator Management Relay GE Multilin...
  • Page 133: Flexlogic

    Figure 5–24: UR ARCHITECTURE OVERVIEW The states of all digital signals used in the G60 are represented by flags (or FlexLogic™ operands, which are described later in this section). A digital “1” is represented by a 'set' flag. Any external contact change-of-state can be used to block an element from operating, as an input to a control feature in a FlexLogic™...
  • Page 134 Some types of operands are present in the relay in multiple instances; e.g. contact and remote inputs. These types of oper- ands are grouped together (for presentation purposes only) on the faceplate display. The characteristics of the different types of operands are listed in the table below. Table 5–4: G60 FLEXLOGIC™ OPERAND TYPES OPERAND TYPE STATE...
  • Page 135 5 SETTINGS 5.4 FLEXLOGIC™ The operands available for this relay are listed alphabetically by types in the following table. Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 1 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION CONTROL CONTROL PUSHBTN n ON Control Pushbutton n (n = 1 to 7) is being pressed.
  • Page 136 5.4 FLEXLOGIC™ 5 SETTINGS Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 2 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION ELEMENT: FxE 1 PKP FlexElement™ 1 has picked up FlexElements™ FxE 1 OP FlexElement™ 1 has operated FxE 1 DPO FlexElement™ 1 has dropped out ↓...
  • Page 137 5 SETTINGS 5.4 FLEXLOGIC™ Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 3 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION ELEMENT: PH DIR1 BLK A Phase A Directional 1 Block Phase Directional PH DIR1 BLK B Phase B Directional 1 Block...
  • Page 138 5.4 FLEXLOGIC™ 5 SETTINGS Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 4 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION ELEMENT: POWER SWING OUTER Positive Sequence impedance in outer characteristic. Power Swing Detect POWER SWING MIDDLE Positive Sequence impedance in middle characteristic.
  • Page 139 5 SETTINGS 5.4 FLEXLOGIC™ Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 5 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION ELEMENT: SYNC 1 DEAD S OP Synchrocheck 1 dead source has operated Synchrocheck SYNC 1 DEAD S DPO Synchrocheck 1 dead source has dropped out...
  • Page 140 5.4 FLEXLOGIC™ 5 SETTINGS Table 5–5: G60 FLEXLOGIC™ OPERANDS (Sheet 6 of 6) OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION SELF- ANY MAJOR ERROR Any of the major self-test errors generated (major error) DIAGNOSTICS ANY MINOR ERROR Any of the minor self-test errors generated (minor error)
  • Page 141: Flexlogic™ Rules

    When making changes to settings, all FlexLogic™ equations are re-compiled whenever any new setting value is entered, so all latches are automatically reset. If it is necessary to re-initialize FlexLogic™ during testing, for example, it is suggested to power the unit down and then back up. GE Multilin G60 Generator Management Relay 5-59...
  • Page 142: Flexlogic™ Example

    DIGITAL ELEMENT 1 on Dropout State=Pickup (200 ms) DIGITAL ELEMENT 2 Timer 1 State=Operated Time Delay on Pickup (800 ms) CONTACT INPUT H1c State=Closed VIRTUAL OUTPUT 3 827026A2.VSD Figure 5–26: LOGIC EXAMPLE WITH VIRTUAL OUTPUTS 5-60 G60 Generator Management Relay GE Multilin...
  • Page 143 Following the procedure outlined, start with parameter 99, as follows: 99: The final output of the equation is Virtual Output 3, which is created by the operator "= Virt Op n". This parameter is therefore "= Virt Op 3." GE Multilin G60 Generator Management Relay 5-61...
  • Page 144 87: The input just below the upper input to OR #1 is operand “Virt Op 2 On". 86: The upper input to OR #1 is operand “Virt Op 1 On". 85: The last parameter is used to set the latch, and is operand “Virt Op 4 On". 5-62 G60 Generator Management Relay GE Multilin...
  • Page 145 In the following equation, Virtual Output 3 is used as an input to both Latch 1 and Timer 1 as arranged in the order shown below: DIG ELEM 2 OP Cont Ip H1c On AND(2) GE Multilin G60 Generator Management Relay 5-63...
  • Page 146: Flexlogic Equation Editor

    TIMER 1 PICKUP DELAY: Sets the time delay to pickup. If a pickup delay is not required, set this function to "0". • TIMER 1 DROPOUT DELAY: Sets the time delay to dropout. If a dropout delay is not required, set this function to "0". 5-64 G60 Generator Management Relay GE Multilin...
  • Page 147: Flexelements

    The element can be programmed to respond either to a signal level or to a rate-of-change (delta) over a pre-defined period of time. The output operand is asserted when the operating signal is higher than a threshold or lower than a threshold as per user's choice. GE Multilin G60 Generator Management Relay 5-65...
  • Page 148 The FLEXELEMENT 1 DIRECTION following figure explains the application of the FLEXELEMENT 1 DIRECTION FLEXELEMENT 1 PICKUP FLEXELEMENT 1 HYS- settings. TERESIS 5-66 G60 Generator Management Relay GE Multilin...
  • Page 149 DIRECTION = Under; FLEXELEMENT INPUT MODE = Signed; FlexElement 1 OpSig FLEXELEMENT 1 PKP FLEXELEMENT DIRECTION = Under; FLEXELEMENT INPUT MODE = Absolute; FlexElement 1 OpSig 842706A2.CDR Figure 5–34: FLEXELEMENT™ INPUT MODE SETTING GE Multilin G60 Generator Management Relay 5-67...
  • Page 150 “Delta”. FLEXELEMENT 1 COMP MODE This setting specifies the pickup delay of the element. The setting FLEXELEMENT 1 PKP DELAY FLEXELEMENT 1 RST DELAY specifies the reset delay of the element. 5-68 G60 Generator Management Relay GE Multilin...
  • Page 151: Non-volatile Latches

    LATCH 1 SET: FLEXLOGIC OPERANDS Off=0 LATCH 1 ON Dominant LATCH 1 OFF Previous Previous SETTING State State LATCH 1 SET: Off=0 RESET 842005A1.CDR Figure 5–35: NON-VOLATILE LATCH OPERATION TABLE (N=1 to 16) AND LOGIC GE Multilin G60 Generator Management Relay 5-69...
  • Page 152: Grouped Elements

    Each of the six Setting Group menus is identical. (the default active group) automatically becomes active SETTING GROUP 1 if no other group is active (see the Control Elements section for additional details). 5-70 G60 Generator Management Relay GE Multilin...
  • Page 153 Use V_1 mem V_1 > 0.8 pu A < 0.05 pu Use V_1 B < 0.05 pu C < 0.05 pu V_1 < 0.1 pu SETTING FORCE SELF-POLAR: Off=0 827842A5.CDR Figure 5–36: MEMORY VOLTAGE LOGIC GE Multilin G60 Generator Management Relay 5-71...
  • Page 154 When set to “Non-directional”, the quadrilateral function applies a reactance line in the reverse direction instead of the directional comparators. Refer to Chapter 8 for addi- tional information. 5-72 G60 Generator Management Relay GE Multilin...
  • Page 155 PHS DIST Z1 REV REACH RCA COMP LIMIT DIR COMP LIMIT DIR COMP LIMIT DIR RCA 837720A1.CDR Figure 5–37: DIRECTIONAL MHO DISTANCE CHARACTERISTIC COMP LIMIT REV REACH 837800A1-X1.CDR Figure 5–38: NON-DIRECTIONAL MHO DISTANCE CHARACTERISTIC GE Multilin G60 Generator Management Relay 5-73...
  • Page 156 CTs are located at the same side as the read point. Therefore, the Z3 setting shall be set to “None”. See Chapter 8: Theory of Operation for more details, and Chapter 9: Application of Settings for information on how to calculate distance reach settings in applications involving power transformers. 5-74 G60 Generator Management Relay GE Multilin...
  • Page 157 The directional function uses the memory voltage for polarization. This setting typically equals the distance characteristic angle PHS DIST Z1 RCA • PHS DIST Z1 DIR COMP LIMIT: Selects the comparator limit angle for the directional supervising function. GE Multilin G60 Generator Management Relay 5-75...
  • Page 158 PH DIST Z1 SUPN ICA PH DIST Z1 OP CA OPEN POLE OP * NOTE: * D60 Only. Other UR models apply regular current seal-in for Z1. 837017A6.CDR Figure 5–41: PHASE DISTANCE ZONE 1 OP SCHEME 5-76 G60 Generator Management Relay GE Multilin...
  • Page 159 PH DIST Z1 SUPN IBC B - C > 3 PICKUP PH DIST Z1 SUPN ICA C - A > 3 PICKUP 837002AG.CDR Figure 5–43: PHASE DISTANCE ZONE 1 TO ZONE 3 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-77...
  • Page 160 Range: 0.10 to 500.00 in steps of 0.01 POWER SWING MIDDLE MESSAGE LFT BLD: 100.00 Ω Ω Range: 0.10 to 500.00 in steps of 0.01 POWER SWING INNER MESSAGE RGT BLD: 100.00 Ω 5-78 G60 Generator Management Relay GE Multilin...
  • Page 161 Two-step operation: If the 2-step mode is selected, the sequence is identical, but it is the outer and inner characteris- tics that are used to time the power swing locus. The Out-of-Step Tripping feature operates as follows for three-step and two-step Power Swing Detection modes: GE Multilin G60 Generator Management Relay 5-79...
  • Page 162 “Mho”, the element applies the right and left blinders as well. If the blinders are not required, their settings should be set high enough to effectively disable the blinders. Figure 5–44: POWER SWING DETECT MHO OPERATING CHARACTERISTICS 5-80 G60 Generator Management Relay GE Multilin...
  • Page 163 FlexLogic™ operands are auxiliary operands that could be used to facilitate testing POWER SWING TMR4 PKP and special applications. • FlexLogic™ operand shall be used to block selected protection elements such as distance POWER SWING BLOCK functions. GE Multilin G60 Generator Management Relay 5-81...
  • Page 164 POWER SWING QUAD REV REACH MID: This setting specifies the reverse reach of the middle quad characteristic. The angle of this reach impedance is specified by the setting. The setting is not used if the POWER SWING FWD RCA shape setting is “Mho”. 5-82 G60 Generator Management Relay GE Multilin...
  • Page 165 The delayed trip occurs when the impedance leaves the outer charac- teristic. This time delay is provided for extra security and should be set considering the fastest expected power swing. GE Multilin G60 Generator Management Relay 5-83...
  • Page 166 K_0, K_2 - three times the average change over last power cycle 842008A1.CDR K_1 - four times the average change over last power cycle Figure 5–48: POWER SWING DETECT SCHEME LOGIC (2 of 3) 5-84 G60 Generator Management Relay GE Multilin...
  • Page 167 POWER SWING BLK: L1 AND L4 LATCHES ARE SET DOMINANT L2, L3 AND L5 LATCHES ARE RESET DOMINANT Off=0 FLEXLOGIC OPERAND POWER SWING OUTGOING 827841A4.CDR Figure 5–49: POWER SWING DETECT SCHEME LOGIC (3 of 3) GE Multilin G60 Generator Management Relay 5-85...
  • Page 168: Stator Differential

    This element has a dual slope characteristic. The main purpose of the percent-slope characteristic is to prevent a maloper- ation caused by unbalances between CTs during external faults. CT unbalances arise as a result of the following factors: CT accuracy errors CT saturation 5-86 G60 Generator Management Relay GE Multilin...
  • Page 169 In order to provide additional security against maloperations during these events, the G60 incorporates saturation detection logic. When saturation is detected the element will make an additional check on the angle between the neutral and output current.
  • Page 170 FLEXLOGIC OPERANDS FLEXLOGIC OPERAND STATOR DIFF PKP C STATOR DIFF OP C STATOR DIFF SAT C STATOR DIFF DIR C FLEXLOGIC OPERAND STATOR DIFF OP 842707A1.CDR Figure 5–53: STATOR DIFFERENTIAL FINAL OUTPUT LOGIC 5-88 G60 Generator Management Relay GE Multilin...
  • Page 171: Phase Current

    # DIRECTIONAL 1 b) INVERSE TOC CURVE CHARACTERISTICS The inverse time overcurrent curves used by the time overcurrent elements are the IEEE, IEC, GE Type IAC, and I t stan- dard curve shapes. This allows for simplified coordination with downstream devices. If however, none of these curve shapes is adequate, FlexCurves™...
  • Page 172 5.041 4.827 38.634 22.819 14.593 11.675 10.130 9.153 8.470 7.960 7.562 7.241 51.512 30.426 19.458 15.567 13.507 12.204 11.294 10.614 10.083 9.654 10.0 64.390 38.032 24.322 19.458 16.883 15.255 14.117 13.267 12.604 12.068 5-90 G60 Generator Management Relay GE Multilin...
  • Page 173 0.60 1.835 1.067 0.668 0.526 0.451 0.404 0.371 0.346 0.327 0.311 0.80 2.446 1.423 0.890 0.702 0.602 0.538 0.494 0.461 0.435 0.415 1.00 3.058 1.778 1.113 0.877 0.752 0.673 0.618 0.576 0.544 0.518 GE Multilin G60 Generator Management Relay 5-91...
  • Page 174 = characteristic constant, and T = reset time in seconds (assuming energy capacity is 100% RESET is “Timed”) RESET Table 5–14: GE TYPE IAC INVERSE TIME CURVE CONSTANTS IAC CURVE SHAPE IAC Extreme Inverse 0.0040 0.6379 0.6200 1.7872 0.2461...
  • Page 175 = Reset Time in seconds (assuming energy capacity is 100% and RESET: Timed) RESET RECLOSER CURVES: The G60 uses the FlexCurve™ feature to facilitate programming of 41 recloser curves. Please refer to the FlexCurve™ section in this chapter for additional details. GE Multilin...
  • Page 176 (Mvr) corresponding to the phase-phase voltages of the voltage restraint characteristic curve (see the figure below); the pickup level is calculated as ‘Mvr’ times the setting. If the voltage restraint feature PHASE TOC1 PICKUP is disabled, the pickup level always remains at the setting value. 5-94 G60 Generator Management Relay GE Multilin...
  • Page 177 Multiplier PHASE TOC1 C DPO Multiplier-Phase C PHASE TOC1 C OP SETTING PHASE TOC1 PKP PHASE TOC1 VOLT RESTRAINT: PHASE TOC1 OP Enabled PHASE TOC1 DPO 827072A4.CDR Figure 5–55: PHASE TOC1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-95...
  • Page 178 Off = 0 PHASE IOC1 PKP SETTING PHASE IOC1 OP PHASE IOC1 BLOCK-B: PHASE IOC1 DPO Off = 0 SETTING 827033A6.VSD PHASE IOC1 BLOCK-C: Off = 0 Figure 5–56: PHASE IOC1 SCHEME LOGIC 5-96 G60 Generator Management Relay GE Multilin...
  • Page 179 CTs and the line-line voltage from the VTs, based on the 90° or ‘quadrature’ connection. If there is a requirement to supervise overcurrent elements for flows in opposite directions, such as can happen through a bus-tie breaker, two phase directional elements should be programmed with opposite ECA settings. GE Multilin G60 Generator Management Relay 5-97...
  • Page 180 Therefore, a coordination time of at least 10 ms must be added to all the instantaneous protec- tion elements under the supervision of the Phase Directional element. If current reversal is of a concern, a longer delay – in the order of 20 ms – may be needed. 5-98 G60 Generator Management Relay GE Multilin...
  • Page 181: Neutral Current

    # NEUTRAL CURRENT # NEUTRAL TOC1 See page 5–100. # NEUTRAL IOC1 See page 5–101. MESSAGE # NEUTRAL See page 5–102. MESSAGE # DIRECTIONAL OC1 # NEUTRAL See page 5–102. MESSAGE # DIRECTIONAL OC2 GE Multilin G60 Generator Management Relay 5-99...
  • Page 182 NEUTRAL TOC 1 SETTING NEUTRAL TOC1 PKP RESET: NEUTRAL TOC1 IN ≥ PICKUP NEUTRAL TOC1 DPO SOURCE: NEUTRAL TOC1 OP SETTING NEUTRAL TOC1 BLOCK: Off = 0 827034A3.VSD Figure 5–59: NEUTRAL TOC1 SCHEME LOGIC 5-100 G60 Generator Management Relay GE Multilin...
  • Page 183 NEUTRAL IOC1 PKP RESET DELAY : SETTING NEUTRAL IOC1 DPO NEUTRAL IOC1 OP 3( _0 - K _1 ) PICKUP NEUTRAL IOC1 BLOCK: Off=0 SETTING NEUTRAL IOC1 SOURCE: 827035A4.CDR Figure 5–60: NEUTRAL IOC1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-101...
  • Page 184 × × (EQ 5.17) – The positive-sequence restraint allows for more sensitive settings by counterbalancing spurious zero-sequence currents resulting from: • System unbalances under heavy load conditions. 5-102 G60 Generator Management Relay GE Multilin...
  • Page 185 REV LA = 80° (reverse limit angle = the ± angular limit with the ECA for operation) The above bias should be taken into account when using the neutral directional overcurrent element to directionalize other protection elements. GE Multilin G60 Generator Management Relay 5-103...
  • Page 186 NEUTRAL DIR OC1 OP CURR: This setting indicates whether the 3I_0 current calculated from the phase currents, or the ground current shall be used by this protection. This setting acts as a switch between the neutral and ground 5-104 G60 Generator Management Relay GE Multilin...
  • Page 187 “Calculated 3I0” mode of operation. Proper application of this element requires that the operating current and the polarizing voltage (or current) be mea- sured from the same side of the transformer. NOTE GE Multilin G60 Generator Management Relay 5-105...
  • Page 188: Ground Current

    # RESTRICTED GROUND MESSAGE # FAULT 4 The G60 relay contains one Ground Time Overcurrent, one Ground Instantaneous Overcurrent, and four Restricted Ground Fault elements. Refer to Inverse TOC Curve Characteristics on page 5–89 for additional information. 5-106 G60 Generator Management Relay...
  • Page 189 GROUND TOC 1 SETTING GROUND TOC1 PKP RESET: GROUND TOC1 IG ≥ PICKUP GROUND TOC1 DPO SOURCE: GROUND TOC1 OP SETTING GROUND TOC1 BLOCK: 827036A3.VSD Off = 0 Figure 5–63: GROUND TOC1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-107...
  • Page 190 The conversion range of a standard channel is from 0.02 to 46 times the CT rating. The conversion range of a sensitive channel is from 0.002 to 4.6 times the CT rating. NOTE 5-108 G60 Generator Management Relay GE Multilin...
  • Page 191 CT installed in the grounding path, or the ground current obtained by external summation of the neutral-side stator CTs. The Typical Applications of RGF Protec- tion diagram explains the basic application and wiring rules. GE Multilin G60 Generator Management Relay 5-109...
  • Page 192 The negative-sequence component of the restraining signal (IR2) is meant to provide maximum restraint during external phase-to-phase faults and is calculated as follows: 5-110 G60 Generator Management Relay GE Multilin...
  • Page 193 RST RESTD GND FT1 SLOPE: RESTD GND FT1 SOURCE: Differential > SLOPE * Restraining Currents ACTUAL VALUES RGF 1 gd Mag RGF 1 gr Mag 828002A2.CDR Figure 5–67: RESTRICTED GROUND FAULT SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-111...
  • Page 194 Igd = abs(3 × 3.3 + 0.0) = 10 pu, IR0 = abs(3 × 3.3 – (0.0)) = 10 pu, IR2 = 3 × 3.3 = 10 pu, IR1 = 3 × (3.33 – 3.33) = 0 pu, and Igr = 10 pu The differential current is 100% of the restraining current. 5-112 G60 Generator Management Relay GE Multilin...
  • Page 195: Negative Sequence Current

    The positive-sequence restraint allows for more sensitive settings by counterbalancing spurious negative- and zero- sequence currents resulting from: • System unbalances under heavy load conditions. • Transformation errors of Current Transformers (CTs). • Fault inception and switch-off transients. GE Multilin G60 Generator Management Relay 5-113...
  • Page 196 This allows for better protection coordination. The above bias should be taken into account when using the Negative Sequence Directional Overcurrent element to ‘directionalize’ other protection elements. 5-114 G60 Generator Management Relay GE Multilin...
  • Page 197 NEG SEQ DIR OC1 REV NEG SEQ DIR OC1 POS- Neg Sequence SEQ RESTRAINT: Zero Sequence _2 - K _1 PICKUP 827091A4.CDR _0 - K _1 PICKUP Figure 5–69: NEGATIVE SEQUENCE DIRECTIONAL OC1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-115...
  • Page 198: Generator Unbalance

    This is set to prevent false trips for faults that would be cleared normally by system protections. • GEN UNBAL STG1 TMAX: This is the maximum operate time of the stage 1 element. This setting can be applied to limit the maximum tripping time for low level unbalances. 5-116 G60 Generator Management Relay GE Multilin...
  • Page 199 GEN UNBAL STG2 DPO PKP DELAY: SETTING GEN UNBAL PKP GEN UNBAL SOURCE: FLEXLOGIC OPERAND I_2 > PICKUP x INOM GEN UNBAL OP FLEXLOGIC OPERAND GEN UNBAL DPO Figure 5–71: GENERATOR UNBALANCE SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-117...
  • Page 200 The Split Phase element allows a separate pickup setting to be applied for each phase. Additionally, the pickup can be biased by the load current (slope characteristic). Two modes of operation are supported (over and over-under). 5-118 G60 Generator Management Relay GE Multilin...
  • Page 201 In “Over” mode, the element will pickup if: > ≥ pickup min_load (EQ 5.26) – split bias load In “Over-under”, mode, the element will pickup if: > ≥ pickup min_load (EQ 5.27) – split bias load GE Multilin G60 Generator Management Relay 5-119...
  • Page 202: Split Phase Protection

    SPLIT PHASE A(C) SLOPE: This setting specifies the slope of split phase characteristic for each phase. This setting is used to bias the pickup of the element due to variations in generator loading. The slope is defined as the ratio of the 5-120 G60 Generator Management Relay GE Multilin...
  • Page 203 SPLIT PHASE DPO C SPLIT PHASE OP C ACTUAL VALUES SPLIT PHASE A CURRENT (PU) SPLIT PHASE B CURRENT (PU) SPLIT PHASE C CURRENT (PU) 830007A1.CDR LOAD CURRENT (PU) Figure 5–75: SPLIT PHASE PROTECTION LOGIC GE Multilin G60 Generator Management Relay 5-121...
  • Page 204: Voltage Elements

    = Pickup Level pickup At 0% of pickup, the operating time equals the setting. UNDERVOLTAGE DELAY NOTE 20 30 80 90 100 110 % of V pickup Figure 5–76: INVERSE TIME UNDERVOLTAGE CURVES 5-122 G60 Generator Management Relay GE Multilin...
  • Page 205 Source VT = Wye FLEXLOGIC OPERAND SETTING PHASE UV1 PKP PHASE UV1 MODE: FLEXLOGIC OPERAND Phase to Ground Phase to Phase PHASE UV1 OP FLEXLOGIC OPERAND PHASE UV1 DPO 827039AB.CDR Figure 5–77: PHASE UNDERVOLTAGE1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-123...
  • Page 206 PHASE OV1 C DPO Phase Phase PHASE OV1 C OP to Phase to Ground FLEXLOGIC OPERAND PHASE OV1 PKP FLEXLOGIC OPERAND PHASE OV1 OP FLEXLOGIC OPERAND PHASE OV1 DPO 827066A5.CDR Figure 5–78: PHASE OVERVOLTAGE SCHEME LOGIC 5-124 G60 Generator Management Relay GE Multilin...
  • Page 207 Off=0 DELAY : FLEXLOGIC OPERANDS < 3V_0 Pickup NEUTRAL OV1 OP SETTING NEUTRAL OV1 DPO NEUTRAL OV1 SIGNAL NEUTRAL OV1 PKP SOURCE: ZERO SEQ VOLT (V_0) 827848A1.CDR Figure 5–79: NEUTRAL OVERVOLTAGE1 SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-125...
  • Page 208 NEG SEQ OV DPO NEG SEQ OV OP SETTING > = V_2 or 3 V_2 NEG SEQ OV SIGNAL SOURCE: Source VT=Wye Source VT=Delta 3 V_2 827839A2.CDR Figure 5–80: NEG SEQ OV SCHEME LOGIC 5-126 G60 Generator Management Relay GE Multilin...
  • Page 209 Vx Pickup AUX UV1 PKP AUX UV1 DPO SETTING SETTING AUX UV1 OP AUX UV1 MINIMUM AUX UV1 SIGNAL VOLTAGE: SOURCE: < AUX VOLT Vx Vx Minimum 827849A2.CDR Figure 5–81: AUXILIARY UNDERVOLTAGE SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-127...
  • Page 210 Disabled This element is intended for monitoring overvoltage conditions of the auxiliary voltage. In the G60, this element is used to detect stator ground faults by measuring the voltage across the neutral resistor. The nominal secondary voltage of the aux- iliary voltage channel entered under "!
  • Page 211 VOLTS PER HERTZ 1 PKP VOLTS/HZ 1 BLOCK: VOLTS PER HERTZ 1 DPO Off = 0 VOLTS PER HERTZ 1 OP SETTING VOLTS/HZ 1 SOURCE: VOLT / Hz V/Hz 828003A5.CDR Figure 5–83: VOLTS PER HERTZ SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-129...
  • Page 212 TDM = Time Delay Multiplier (delay in sec.) V = fundamental RMS value of voltage (pu) F = frequency of voltage signal (pu) Pickup = volts-per-hertz pickup setpoint (pu) 1.00 1.20 1.40 1.60 1.80 2.00 Multiples of Voltz/Hertz Pickup 5-130 G60 Generator Management Relay GE Multilin...
  • Page 213: Loss Of Excitation

    = Radius of element 2 = Xd / 2 = Base impedance of the machine X’d = Transient reactance of the machine = Synchronous reactance of the machine 830711A1.CDR Figure 5–84: LOSS OF EXCITATION OPERATING CHARACTERISTICS GE Multilin G60 Generator Management Relay 5-131...
  • Page 214 20 ms 0 ms Enabled=0 FLEXLOGIC OPERAND SETTING LOSS EXCIT OP LOSS OF EXCITATION SOURCE: FLEXLOGIC OPERAND LOSS EXCIT PKP FLEXLOGIC OPERAND LOSS EXCIT DPO 830001AB.CDR Figure 5–85: LOSS OF EXCITATION SCHEME LOGIC 5-132 G60 Generator Management Relay GE Multilin...
  • Page 215: Accidental Energization

    The setting is entered in voltage pu values. As the element always responds to the line-to-line voltages, care must be applied in picking up the value depending on the VT connection. • ACCDNT ENRG OFFLINE: This setting specifies the FlexLogic™ operand indicating that the protected generator is off-line. GE Multilin G60 Generator Management Relay 5-133...
  • Page 216 VCG - VAG SETTING ACCDNT ENRG FLEXLOGIC OPERAND 0.25 s OFFLINE: ACCDNT ENRG ARMED Off = 0 SETTING ACCDNT ENRG ARMING MODE: UV or Offline = 1 830004A3.CDR Figure 5–86: ACCIDENTAL ENERGIZATION SCHEME LOGIC 5-134 G60 Generator Management Relay GE Multilin...
  • Page 217: Sensitive Directional Power

    The operating quantity is available for display as under !" ACTUAL VALUES METERING SENSITIVE DIRECTIONAL POWER . The element has two independent (as to the pickup and delay settings) stages for alarm and trip, respectively. 1(2) GE Multilin G60 Generator Management Relay 5-135...
  • Page 218 RCA = 0 SMIN < 0 SMIN > 0 OPERATE RESTRAIN RESTRAIN OPERATE RCA = 90 RCA = 270 SMIN > 0 SMIN < 0 842702A1.CDR Figure 5–88: DIRECTIONAL POWER ELEMENT SAMPLE APPLICATIONS 5-136 G60 Generator Management Relay GE Multilin...
  • Page 219 CHARACTERISTICS DIR POWER 1 OP 3Φ Reactive Power (Q) DIR POWER 1 STG2 DPO DIR POWER 1 STG2 OP SETTING DIR POWER 1 STG2 DELAY: 100ms 842003A2.CDR Figure 5–89: DIRECTIONAL POWER SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-137...
  • Page 220: Stator Ground

    Voltage measured at the neutral of the machine shall be configured as the Auxiliary VT bank. The element extracts the 3rd harmonic of the auxiliary voltage from the source in order to operate. 5-138 G60 Generator Management Relay GE Multilin...
  • Page 221 ). At power system 3 ⁄ × frequencies, the neutral resistance is therefore equal to equal , and at , the neutral resistance is For analysis, assume that 10 V 5Ω, and X 5Ω GE Multilin G60 Generator Management Relay 5-139...
  • Page 222 10 V 5Ω, X 5Ω, and k 0.15 In this case, we have the magnitude of the neutral voltage at: × × 0.15 (EQ 5.38) and the magnitude of the neutral and zero-sequence voltages 5-140 G60 Generator Management Relay GE Multilin...
  • Page 223 100% STATOR GND STG1(2) PICKUP: This setting specifies a pickup level for the operating quantity. It may be ben- eficial to measure the operating quantity under various load conditions for a particular machine in order to optimize this setting. This can be achieved using the Actual Values menu of the G60. •...
  • Page 224 3RD HARM NTRL UV MAX POWER This setting applies to three-phase power and is entered in pu. The base quantity is 3 × VT pu base × CT pu base. 5-142 G60 Generator Management Relay GE Multilin...
  • Page 225 SOURCE: Vaux (3rd harmonic) Min < 3 Phase Power < Max 3 Phase Real Power SETTINGS 3RD HARM NTRL UV VOLT SUPV: 830005A4.CDR > Pickup Figure 5–92: THIRD HARMONIC NEUTRAL UNDERVOLTAGE SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-143...
  • Page 226: Control Elements

    The assigned VIR- operand is used to control the “On” state of a particular settings group. TUAL OUTPUT 1 Figure 5–93: EXAMPLE FLEXLOGIC™ CONTROL OF A SETTINGS GROUP 5-144 G60 Generator Management Relay GE Multilin...
  • Page 227: Selector Switch

    SELECTOR 1 TIME-OUT: This setting defines the time-out period for the selector. This value is used by the relay in the following two ways. When the is “Time-out”, the setting specifies the required period of SELECTOR STEP-UP MODE GE Multilin G60 Generator Management Relay 5-145...
  • Page 228 3-bit control inputs. Note that the stepping up control input and 3-bit control TIME-OUT input have independent acknowledging signals ( , accordingly). SELECTOR 1 ACK SELECTOR 1 3BIT ACK 5-146 G60 Generator Management Relay GE Multilin...
  • Page 229 3BIT A1 3BIT A2 POS 1 POS 2 POS 3 POS 4 POS 5 POS 6 POS 7 BIT 0 BIT 1 BIT 2 STP ALARM BIT ALARM ALARM 842737A1.CDR Figure 5–94: TIME-OUT MODE GE Multilin G60 Generator Management Relay 5-147...
  • Page 230 3BIT A2 3BIT ACK POS 1 POS 2 POS 3 POS 4 POS 5 POS 6 POS 7 BIT 0 BIT 1 BIT 2 STP ALARM BIT ALARM ALARM 842736A1.CDR Figure 5–95: ACKNOWLEDGE MODE 5-148 G60 Generator Management Relay GE Multilin...
  • Page 231 SELECTOR 1 BIT ALARM 3-bit position out SELECTOR 1 ALARM SELECTOR 1 PWR ALARM SELECTOR 1 BIT 0 SELECTOR 1 BIT 1 SELECTOR 1 BIT 2 842012A1.CDR Figure 5–96: SELECTOR SWITCH LOGIC GE Multilin G60 Generator Management Relay 5-149...
  • Page 232: Underfrequency

    UNDERFREQ 1 DPO SETTING < 0 < f PICKUP1 UNDERFREQ 1 OP UNDERFREQ 1 MIN VOLT / AMP: ACTUAL VALUES UNDERFREQ 1 SOURCE: < Level VOLT / AMP Frequency 827079A6.CDR Figure 5–97: UNDERFREQUENCY SCHEME LOGIC 5-150 G60 Generator Management Relay GE Multilin...
  • Page 233: Overfrequency

    OVERFREQ 1 BLOCK: FLEXLOGIC OPERANDS OVERFREQ 1 RESET OVERFREQ 1 PKP DELAY : OVERFREQ 1 DPO OVERFREQ 1 OP SETTING < f PICKUP OVERFREQ 1 SOURCE: SRC1 Frequency 827832A3.CDR Figure 5–98: OVERFREQUENCY SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-151...
  • Page 234: Frequency Rate Of Change

    FREQ RATE 1 OC SUPV PICKUP: This setting defines minimum current level required for operation of the element. The supervising function responds to the positive-sequence current. Typical application includes load shedding. Set the pickup threshold to zero if no overcurrent supervision is required. 5-152 G60 Generator Management Relay GE Multilin...
  • Page 235 SETTINGS FREQ RATE 1 PKP FREQ RATE 1 MIN FREQUENCY: FREQ RATE 1 MAX FREQUENCY: F > MIN & F < MAX Calculate df/dt 832023A2.CDR Figure 5–99: FREQUENCY RATE OF CHANGE SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-153...
  • Page 236: Synchrocheck

    ∆F. This time can be calculated by: ------------------------------- - (EQ 5.41) 360° ----------------- - × ∆F 2 ∆Φ × where: ∆Φ = phase angle difference in degrees; ∆F = frequency difference in Hz. 5-154 G60 Generator Management Relay GE Multilin...
  • Page 237 SYNCHK1 LIVE V2 MIN VOLT: This setting establishes a minimum voltage magnitude for V2 in ‘pu’. Above this mag- nitude, the V2 voltage input used for synchrocheck will be considered “Live” or energized. GE Multilin G60 Generator Management Relay 5-155...
  • Page 238 The relay will use the phase channel of a three-phase set of voltages if pro- grammed as part of that source. The relay will use the auxiliary voltage channel only if that channel is programmed as part of the Source and a three-phase set is not. 5-156 G60 Generator Management Relay GE Multilin...
  • Page 239 SETTING CALCULATE SYNC1 SYNC DPO SYNCHK1 MAX FREQ Magnitude V2 SYNCHK1 V2 SIGNAL HYSTERESIS: SOURCE: Angle Calculate I F1-F2 I= SRC 2 Frequency F2 ACTUAL VALUE SYNC1: 827076AA.CDR Figure 5–100: SYNCHROCHECK SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-157...
  • Page 240: Digital Elements

    Some versions of the digital input modules include an active Voltage Monitor circuit connected across Form-A contacts. The voltage monitor circuit limits the trickle current through the output circuit (see technical specifications for Form-A). 5-158 G60 Generator Management Relay GE Multilin...
  • Page 241 1 PICKUP MESSAGE DELAY: 0.200 s DIG ELEM 1 RESET MESSAGE DELAY: 0.100 s DIG ELEM 1 BLOCK: MESSAGE Cont Ip 1 Off DIGITAL ELEMENT MESSAGE TARGET: Self-reset DIGITAL ELEMENT MESSAGE EVENTS: Enabled GE Multilin G60 Generator Management Relay 5-159...
  • Page 242 RESISTANCE POWER SUPPLY (V DC) (OHMS) (WATTS) I = Current Monitor 1000 5000 V = Voltage Monitor 10000 25000 By-pass 25000 Resistor 50000 Trip Coil 827074A1.vsd DC– Figure 5–103: TRIP CIRCUIT EXAMPLE 2 5-160 G60 Generator Management Relay GE Multilin...
  • Page 243: Digital Counters

    –2,147,483,648 counts, the counter will rollover to +2,147,483,647. • COUNTER 1 BLOCK: Selects the FlexLogic™ operand for blocking the counting operation. All counter operands are blocked. GE Multilin G60 Generator Management Relay 5-161...
  • Page 244 COUNTER 1 RESET: COUNTER 1 FROZEN: Off = 0 STORE DATE & TIME Date & Time SETTING COUNT1 FREEZE/RESET: Off = 0 827065A1.VSD SETTING COUNT1 FREEZE/COUNT: Off = 0 Figure 5–104: DIGITAL COUNTER SCHEME LOGIC 5-162 G60 Generator Management Relay GE Multilin...
  • Page 245: Monitoring Elements

    SRC1 50DD OP SRC1 VT FUSE FAIL DPO FLEXLOGIC OPERAND OPEN POLE OP D60 only RESET Reset-dominant FLEXLOGIC OPERAND SRC1 VT FUSE FAIL VOL LOSS 827093AG.CDR Figure 5–105: VT FUSE FAIL SCHEME LOGIC GE Multilin G60 Generator Management Relay 5-163...
  • Page 246: Inputs/outputs

    The DC input voltage is compared to a user-settable threshold. A new contact input state must be maintained for a user- settable debounce time in order for the G60 to validate the new contact state. In the figure below, the debounce time is set at 2.5 ms;...
  • Page 247 Event Records menu, make the following settings changes: "Breaker Closed (52b)" CONTACT INPUT H5A ID: "Enabled" CONTACT INPUT H5A EVENTS: Note that the 52b contact is closed when the breaker is open and open when the breaker is closed. GE Multilin G60 Generator Management Relay 5-165...
  • Page 248: Virtual Inputs

    SETTING “Virtual Input 1 to OFF = 0” VIRTUAL INPUT 1 ID: (Flexlogic Operand) SETTING Virt Ip 1 VIRTUAL INPUT 1 TYPE: Latched Self - Reset 827080A2.CDR Figure 5–107: VIRTUAL INPUTS SCHEME LOGIC 5-166 G60 Generator Management Relay GE Multilin...
  • Page 249: Contact Outputs

    This scheme is often called ‘trip seal-in’. This can be realized in the G60 using the ‘Cont Op 1 IOn’ FlexLogic™ operand to seal-in the contact output as follows: “Cont Op 1"...
  • Page 250 5 SETTINGS The G60 latching output contacts are mechanically bi-stable and controlled by two separate (open and close) coils. As such they retain their position even if the relay is not powered up. The relay recognizes all latching output contact cards and pop- ulates the setting menu accordingly.
  • Page 251: Virtual Outputs

    For example, if Virtual Output 1 is the trip signal from FlexLogic™ and the trip relay is used to signal events, the settings would be programmed as follows: "Trip" VIRTUAL OUTPUT 1 ID: "Disabled" VIRTUAL OUTPUT 1 EVENTS: GE Multilin G60 Generator Management Relay 5-169...
  • Page 252: Remote Devices

    The remote input/output facility provides for 32 remote inputs and 64 remote outputs. b) LOCAL DEVICES: ID OF DEVICE FOR TRANSMITTING GSSE MESSAGES In a G60 relay, the device ID that identifies the originator of the message is programmed in the SETTINGS PRODUCT SETUP !"...
  • Page 253: Remote Inputs

    Logic 0. When communication resumes, the input becomes fully operational. For additional information on GSSE/GOOOSE messaging, refer to the Remote Devices section in this chap- ter. NOTE GE Multilin G60 Generator Management Relay 5-171...
  • Page 254: Remote Outputs

    METHOD: GSSE For more information on GSSE/GOOSE messaging, refer to Remote Inputs/Outputs Overview in the Remote Devices section. NOTE 5.7.8 RESETTING !" !" PATH: SETTINGS INPUTS/OUTPUTS RESETTING Range: FlexLogic™ operand # RESETTING RESET OPERAND: 5-172 G60 Generator Management Relay GE Multilin...
  • Page 255: Direct Inputs/outputs

    APPLICATION EXAMPLES The examples introduced in the earlier Direct Inputs/Outputs section (part of the Product Setup section) direct inputs/out- puts are continued below to illustrate usage of the direct inputs and outputs. GE Multilin G60 Generator Management Relay 5-173...
  • Page 256 5.7 INPUTS/OUTPUTS 5 SETTINGS EXAMPLE 1: EXTENDING INPUT/OUTPUT CAPABILITIES OF A G60 RELAY Consider an application that requires additional quantities of digital inputs and/or output contacts and/or lines of program- mable logic that exceed the capabilities of a single UR-series chassis. The problem is solved by adding an extra UR-series IED, such as the C30, to satisfy the additional inputs/outputs and programmable logic requirements.
  • Page 257 "3" (effectively, this is a message from IED 1) DIRECT INPUT 6 BIT NUMBER: UR IED 2: "1" DIRECT INPUT 5 DEVICE ID: "2" DIRECT INPUT 5 BIT NUMBER: "3" DIRECT INPUT 6 DEVICE ID: "2" DIRECT INPUT 6 BIT NUMBER: GE Multilin G60 Generator Management Relay 5-175...
  • Page 258 In three-terminal applications, both the remote terminals must grant permission to trip. Therefore, at each terminal, Direct Inputs 5 and 6 should be ANDed in FlexLogic™ and the resulting operand configured as the permission to trip ( HYB POTT setting). 5-176 G60 Generator Management Relay GE Multilin...
  • Page 259: Transducer I/o

    –20 to +180 MW; in this case the value would be “–20” and the DCMA INPUT H1 MIN VALUE DCMA INPUT H1 MAX value “180”. Intermediate values between the min and max values are scaled linearly. VALUE GE Multilin G60 Generator Management Relay 5-177...
  • Page 260: Rtd Inputs

    CTs and VTs. Each channel is assigned a slot letter followed by the row number, 1 through 8 inclusive, which is used as the channel number. Both the output range and a signal driving a given output are user-programmable via the following settings menu (an exam- ple for channel M5 is shown). 5-178 G60 Generator Management Relay GE Multilin...
  • Page 261 VT ratio = 120. The nominal current is 800 A primary and the nominal power factor is 0.90. The power is to be monitored in both importing and exporting directions and allow for 20% overload compared to the nominal. GE Multilin G60 Generator Management Relay 5-179...
  • Page 262 0 to 1 mA. The VT secondary setting is 66.4 V, the VT ratio setting is 6024, and the VT connection setting is “Delta”. The voltage should be monitored in the range from 70% to 110% of nominal. 5-180 G60 Generator Management Relay GE Multilin...
  • Page 263 254.03 kV 1.27 kV – • ±0.5% of reading For example, under nominal conditions, the positive-sequence reads 230.94 kV and the worst-case error is 0.005 x 230.94 kV + 1.27 kV = 2.42 kV. GE Multilin G60 Generator Management Relay 5-181...
  • Page 264: Testing

    The Test Mode starts when the selected operand assumes a Logic 1 state. TIATE When in Test Mode, the G60 remains fully operational, allowing for various testing procedures. In particular, the protection and control elements, FlexLogic™, and communication-based inputs and outputs function normally.
  • Page 265: Force Contact Outputs

    USER PUSHBUTTON 1 PUSHBUTTON 1 FUNCTION Input 1 to initiate the Test mode, make the following changes in the !" menu: SETTINGS TESTING TEST MODE “Enabled” and “ ” TEST MODE FUNCTION: TEST MODE INITIATE: GE Multilin G60 Generator Management Relay 5-183...
  • Page 266 5.9 TESTING 5 SETTINGS 5-184 G60 Generator Management Relay GE Multilin...
  • Page 267 ## METERING # DIFFERENTIAL # SOURCE SRC 1 See page 6-11. # SOURCE SRC 2 # SOURCE SRC 3 # SOURCE SRC 4 # SYNCHROCHECK See page 6-14. # TRACKING FREQUENCY See page 6-14. GE Multilin G60 Generator Management Relay...
  • Page 268: Actual Values

    # EVENT RECORDS See page 6-17. # OSCILLOGRAPHY See page 6-17. # DATA LOGGER See page 6-18. ## ACTUAL VALUES # MODEL INFORMATION See page 6-19. ## PRODUCT INFO # FIRMWARE REVISIONS See page 6-19. G60 Generator Management Relay GE Multilin...
  • Page 269: Status

    The state displayed will be that of the remote point unless the remote device has been established to be “Offline” in which case the value shown is the programmed default state for the remote input. GE Multilin G60 Generator Management Relay...
  • Page 270: Contact Outputs

    The present state of up to 16 programmed Remote Devices is shown here. The message indi- ALL REMOTE DEVICES ONLINE cates whether or not all programmed Remote Devices are online. If the corresponding state is "No", then at least one required Remote Device is not online. G60 Generator Management Relay GE Multilin...
  • Page 271: Digital Counters

    Range: Off, On # FLEX STATES PARAM 1: Off ↓ Range: Off, On PARAM 256: Off MESSAGE There are 256 FlexState bits available. The second line value indicates the state of the given FlexState bit. GE Multilin G60 Generator Management Relay...
  • Page 272: Ethernet

    The UNRETURNED MSG COUNT CRC FAIL COUNT values can be cleared using the command. CLEAR DIRECT I/O COUNTERS values represent the state of the x-th direct input. DIRECT INPUT x G60 Generator Management Relay GE Multilin...
  • Page 273: Direct Devices Status

    # SLOW EXCHANGE 1 EXCH 1 SIGNATURE: EXCH 1 SIZE: MESSAGE These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size for the slow EGD exchanges are displayed. GE Multilin G60 Generator Management Relay...
  • Page 274: Metering Conventions

    PF = Lag WATTS = Negative VARS = Positive PF = Lead PF = Lag PF = Lead Current UR RELAY 827239AC.CDR S=VI Generator Figure 6–1: FLOW DIRECTION OF SIGNED VALUES FOR WATTS AND VARS G60 Generator Management Relay GE Multilin...
  • Page 275 • ABC phase rotation: • ACB phase rotation: -- - V -- - V -- - V -- - V -- - V -- - V The above equations apply to currents as well. GE Multilin G60 Generator Management Relay...
  • Page 276 The power system voltages are phase-referenced – for simplicity – to VAG and VAB, respectively. This, however, is a relative matter. It is important to remember that the G60 displays are always referenced as specified under SETTINGS !"...
  • Page 277: Stator Differential

    MESSAGE 0.000 0.0° SRC 1 PHASOR Ic: MESSAGE 0.000 0.0° SRC 1 PHASOR In: MESSAGE 0.000 0.0° SRC 1 ZERO SEQ I0: MESSAGE 0.000 0.0° SRC 1 POS SEQ I1: MESSAGE 0.000 0.0° GE Multilin G60 Generator Management Relay 6-11...
  • Page 278 SRC 1 POS SEQ V1: MESSAGE 0.000 0.0° SRC 1 NEG SEQ V2: MESSAGE 0.000 0.0° # AUXILIARY VOLTAGE SRC 1 RMS Vx: # SRC 1 0.000 SRC 1 PHASOR Vx: MESSAGE 0.000 0.0° 6-12 G60 Generator Management Relay GE Multilin...
  • Page 279 # SRC 1 0.000 SRC 1 NEG WATTHOUR: MESSAGE 0.000 SRC 1 POS VARHOUR: MESSAGE 0.000 varh SRC 1 NEG VARHOUR: MESSAGE 0.000 varh # FREQUENCY SRC 1 FREQUENCY: # SRC 1 0.00 Hz GE Multilin G60 Generator Management Relay 6-13...
  • Page 280: Synchrocheck

    # FREQUENCY RATE FREQUENCY RATE OF # OF CHANGE CHANGE 1: 0.00 Hz/s ↓ FREQUENCY RATE OF MESSAGE CHANGE 4: 0.00 Hz/s The metered frequency rate of change for the four elements is shown here. 6-14 G60 Generator Management Relay GE Multilin...
  • Page 281: Flexelements

    The effective operating quantities of the sensitive directional power elements are displayed here. The display may be useful to calibrate the feature by compensating the angular errors of the CTs and VTs with the use of the CALIBRATION settings. GE Multilin G60 Generator Management Relay 6-15...
  • Page 282: Stator Ground

    RTD INPUT xx -50 °C Actual values for each RTD input channel that is enabled are displayed with the top line as the programmed Channel ID and the bottom line as the value. 6-16 G60 Generator Management Relay GE Multilin...
  • Page 283: Records

    Chapter 5 for further details. A trigger can be forced here at any time by setting "Yes" to the command. Refer to the !" FORCE TRIGGER? COMMANDS menu for clearing the oscillography records. CLEAR RECORDS GE Multilin G60 Generator Management Relay 6-17...
  • Page 284: Data Logger

    It counts up at the defined sampling rate. If Data Logger channels are defined, then both values are static. Refer to the !" menu for clearing data logger records. COMMANDS CLEAR RECORDS 6-18 G60 Generator Management Relay GE Multilin...
  • Page 285: Model Information

    BOOT DATE: MESSAGE Date and time when the boot program was built. 2004/09/15 16:41:32 The shown data is illustrative only. A modification file number of 0 indicates that, currently, no modifications have been installed. GE Multilin G60 Generator Management Relay 6-19...
  • Page 286 6.5 PRODUCT INFORMATION 6 ACTUAL VALUES 6-20 G60 Generator Management Relay GE Multilin...
  • Page 287: Commands And

    The states of up to 32 virtual inputs are changed here. The first line of the display indicates the ID of the virtual input. The second line indicates the current or selected status of the virtual input. This status will be a logical state ‘Off’ (0) or ‘On’ (1). GE Multilin G60 Generator Management Relay...
  • Page 288 If an update occurs, the following message is shown. UPDATING... PLEASE WAIT There is no impact if there have been no changes to the hardware modules. When an update does not occur, the ORDER message will be shown. CODE NOT UPDATED G60 Generator Management Relay GE Multilin...
  • Page 289: Targets Menu

    In Service LED indicator is turned off • a RELAY OUT OF SERVICE event is recorded Most of the minor self-test errors can be disabled. Refer to the settings in the User-Programmable Self-Tests section in Chapter 5 for additional details. GE Multilin G60 Generator Management Relay...
  • Page 290 SYSTEM EXCEPTION Abnormal restart from modules Event driven. Contact the factory. being removed/inserted when powered-up, abnormal DC supply, or internal relay failure. WATCHDOG ERROR Some tasks are behind schedule. Event driven. Contact the factory. G60 Generator Management Relay GE Multilin...
  • Page 291: Theory Of Operation

    The G60 provides for any location of the VTs and CTs with respect to the involved power transformer and the direction of any given zone.
  • Page 292 ------ - V BC_21P – BC_21P – ------ - V CA_21P – CA_21P Dy11 – ------ - V AB_21P – AB_21P – ------ - V BC_21P – BC_21P – ------ - V CA_21P – CA_21P G60 Generator Management Relay GE Multilin...
  • Page 293 ------ - 2I – – BC_21P BC_21P ------ - 2I – – CA_21P CA_21P Yd11 – ------ - I – AB_21P AB_21P – ------ - I – BC_21P BC_21P ------ - I – – CA_21P CA_21P GE Multilin G60 Generator Management Relay...
  • Page 294: Example

    = 2.576 kA ∠–27.6° primary or 42.93 A ∠–27.6° secondary I = I – I And consequently it would see an apparent impedance of: = V / I = 30.05 Ω ∠85° primary or 0.687 Ω ∠85° secondary G60 Generator Management Relay GE Multilin...
  • Page 295 X, the relay shall be set to 0.687 Ω ∠85° secondary in order to reach to the fault shown in the figure. When installed at H, the relay shall be set to 2.569 Ω ∠88.4° to ensure exactly same coverage. See Chapter 9: Application of Settings for more information on setting calculations. GE Multilin G60 Generator Management Relay...
  • Page 296 8.1 PHASE DISTANCE THROUGH POWER TRANSFORMERS 8 THEORY OF OPERATION G60 Generator Management Relay GE Multilin...
  • Page 297: Application Of

    GE Multilin Generator Management Relay 830712A4.CDR Figure 9–1: G60 SAMPLE SYSTEM 9.1.2 SYSTEM SETUP Ideally, the CTs should be selected so the generator nominal current is 80 to 85% of CT primary. The following settings are entered for the example system. The M5 bank and the ground CT input on each of the groups are unused in this example.
  • Page 298: Power System

    Elements using the Auxiliary VT input are assigned to the “NEUTRL” source. Make the following changes through EnerVista UR Setup or through the !" !" SETTINGS SYSTEM SETUP SOURCE 1 !" !" menus: SETTINGS SYSTEM SETUP SOURCE 2 G60 Generator Management Relay GE Multilin...
  • Page 299: Stator Differential

    For the application example, the pickup setting is: × × Pickup 70% I capability 0.70 5.6% (EQ 9.3) The NEUTRL source will be chosen for this element. The settings are as follows: GE Multilin G60 Generator Management Relay...
  • Page 300: Loss Of Excitation

    (EQ 9.12) × × × Phase CT Primary Phase VT Ratio Phase VT Secondary × -- - × -------------------------------------------------------------------- - For the example system: 0.044 pu × × × 8000 A 157.5 66 V G60 Generator Management Relay GE Multilin...
  • Page 301: System Backup Overcurrent

    (EQ 9.17) Total Impedance 32.2 Fault Voltage 5.93 kV Pickup Reduction ----------------------------------------------------------------------- - ------------------- - 0.329 (EQ 9.18) Generator Nominal Voltage 18 kV The equation for an IEEE extremely inverse curve is as follows: GE Multilin G60 Generator Management Relay...
  • Page 302: Backup Distance

    (EQ 9.22) CT Ratio ⋅ ⋅ ---------------------- - Zone 1 Reach Transformer Impedance Line Impedance VT Ratio (EQ 9.23) 1600 ⋅ ⋅ -------------- - ∠ j0.162 0.255 j1.276 17.8 80° secondary ohms 157.5 G60 Generator Management Relay GE Multilin...
  • Page 303: Stator Ground Fault

    VT secondary ground faults. For the sample system a time delay of 1 second will be used. Make the following changes in EnerVista UR Setup or through the !" !" !" SETTINGS GROUPED ELEMENTS SETTING GROUP 1 VOLTAGE ELEMENTS menu: AUXILIARY OV1 GE Multilin G60 Generator Management Relay...
  • Page 304 -------------------- - 0.0045 pu (EQ 9.27) 66 V 66 V Make the following changes in EnerVista UR Setup or through the !" !" SETTINGS GROUPED ELEMENTS SETTING GROUP !" menu: STATOR GROUND 100% STATOR GROUND G60 Generator Management Relay GE Multilin...
  • Page 305 A time delay of 5 seconds will be applied. If required, the element may be blocked when the machine is offline. Make the following changes in EnerVista UR Setup or through the !" !" !" SETTINGS GROUPED ELEMENTS SETTING GROUP 1 STA- menu: TOR GROUND 3RD HARM NTRL UNDERVOLTAGE GE Multilin G60 Generator Management Relay...
  • Page 306: Overexcitation

    The Volts/Hz 1 pickup will be used to generate an alarm. Either source may be assigned in this example. Make the following changes in EnerVista UR Setup or through the !" !" !" SETTINGS GROUPED ELEMENTS SETTING GROUP 1 menus: VOLTAGE ELEMENTS VOLTS/HZ 1(2) 9-10 G60 Generator Management Relay GE Multilin...
  • Page 307: Frequency

    The UV pickup setting must be set above the maximum expected fault voltage. Make the following changes in EnerVista UR Setup or through the !" !" SETTINGS GROUPED ELEMENTS SETTING GROUP !" menu: ACCIDENTAL ENERGIZATION GE Multilin G60 Generator Management Relay 9-11...
  • Page 308: Inputs/outputs

    The following inputs and outputs will be used in this example. Make the following changes in EnerVista UR Setup or through the !" menus: SETTINGS INPUTS/OUTPUTS CONTACT INPUTS CONTACT INPUT H7a(H7c) Make the following changes in EnerVista UR Setup or through the !" !" SETTINGS INPUTS/OUTPUTS CONTACT OUTPUTS menus: CONTACT OUTPUT H1(H4) 9-12 G60 Generator Management Relay GE Multilin...
  • Page 309: Flexlogic

    AND(2) OR(6) = TURBINE TRIP (VO3) OVEREXCIT ON (VO7) AND(2) AND(2) = SEQ TRIP (VO9) AUX OV1 OP STATOR GND STG1 OP OR(6) 830716A1.CDR = TURBINE TRIP (VO3) Figure 9–5: APPLICATION EXAMPLE FLEXLOGIC™ GE Multilin G60 Generator Management Relay 9-13...
  • Page 310: Phase Distance Through Power Transformers

    APPLICATION DESCRIPTION Phase distance elements of the G60 could be set to respond to faults beyond any three-phase power transformer. The relay guarantees accurate reach and targeting for any phase fault. Moreover, the current and voltage transformers may be located independently on different sides of the transformer.
  • Page 311: Example

    × ------------ - ∠ 0.8011Ω 85° (EQ 9.36) 2625 "0.80" PHS DIST Z1 REACH: "85" PHS DIST Z1 RCA: "None" PHS DIST Z1 XMFR VOL CONNECTION: "Dy1" PHS DIST Z1 XMFR CUR CONNECTION: GE Multilin G60 Generator Management Relay 9-15...
  • Page 312 ---------- - ------------ - 2.601Ω 89.4° (EQ 9.37) 13.8 2625 "2.60" PHS DIST Z3 REACH: "89" PHS DIST Z3 RCA: "Yd11" PHS DIST Z3 XMFR VOL CONNECTION: "None" PHS DIST Z3 XMFR CUR CONNECTION: 9-16 G60 Generator Management Relay GE Multilin...
  • Page 313: Flexanalog Parameters

    SRC 1 Igd Mag 6338 SRC 4 Phase B Current RMS SRC 4 Ib RMS 6180 SRC 1 Diff. Gnd. Current Angle SRC 1 Igd Angle 6340 SRC 4 Phase C Current RMS SRC 4 Ic RMS GE Multilin G60 Generator Management Relay...
  • Page 314 SRC 2 Vag Mag 6850 SRC 4 Phase BG Voltage RMS SRC 4 Vbg RMS 6728 SRC 2 Phase AG Voltage Angle SRC 2 Vag Angle 6852 SRC 4 Phase CG Voltage RMS SRC 4 Vcg RMS G60 Generator Management Relay GE Multilin...
  • Page 315 SRC 2 Phase B Apparent Power SRC 2 Sb 7704 SRC 2 Demand Var SRC 2 Demand var 7222 SRC 2 Phase C Apparent Power SRC 2 Sc 7706 SRC 2 Demand Va SRC 2 Demand Va GE Multilin G60 Generator Management Relay...
  • Page 316 FlexElement 11 Value 13560 RTD Inputs 9 Value RTD Inputs 9 Value 39447 FlexElement 12 Actual FlexElement 12 Value 13561 RTD Inputs 10 Value RTD Inputs 10 Value 39449 FlexElement 13 Actual FlexElement 13 Value G60 Generator Management Relay GE Multilin...
  • Page 317 FlexElement 15 Actual FlexElement 15 Value 39455 FlexElement 16 Actual FlexElement 16 Value 40971 Current Setting Group Active Setting Group 43808 VHZ 1 Actual Volts Per Hertz 1 43809 VHZ 2 Actual Volts Per Hertz 2 GE Multilin G60 Generator Management Relay...
  • Page 318 A.1 PARAMETER LIST APPENDIX A G60 Generator Management Relay GE Multilin...
  • Page 319: Modbus Communications

    Broadcast mode is only recognized when associated with Function Code 05h. For any other function code, a packet with broadcast mode slave address 0 will be ignored. GE Multilin G60 Generator Management Relay...
  • Page 320: Algorithm

    No: go to 8; Yes: G (+) A --> A and continue. Is j = 8? No: go to 5; Yes: continue i + 1 --> i Is i = N? No: go to 3; Yes: continue A --> CRC G60 Generator Management Relay GE Multilin...
  • Page 321: Modbus Function Codes

    DATA #1 - low NUMBER OF REGISTERS - low DATA #2 - high CRC - low DATA #2 - low CRC - high DATA #3 - high DATA #3 - low CRC - low CRC - high GE Multilin G60 Generator Management Relay...
  • Page 322: Execute Operation (function Code 05h

    DATA STARTING ADDRESS - low DATA STARTING ADDRESS - low DATA - high DATA - high DATA - low DATA - low CRC - low CRC - low CRC - high CRC - high G60 Generator Management Relay GE Multilin...
  • Page 323: Store Multiple Settings (function Code 10h

    PACKET FORMAT EXAMPLE (HEX) SLAVE ADDRESS SLAVE ADDRESS FUNCTION CODE FUNCTION CODE CRC - low order byte ERROR CODE CRC - high order byte CRC - low order byte CRC - high order byte GE Multilin G60 Generator Management Relay...
  • Page 324: File Transfers

    Cleared Date to the present date and time. To read binary COMTRADE oscillography files, read the following filenames: OSCnnnn.CFG and OSCnnn.DAT Replace “nnn” with the desired oscillography trigger number. For ASCII format, use the following file names OSCAnnnn.CFG and OSCAnnn.DAT G60 Generator Management Relay GE Multilin...
  • Page 325: Modbus Password Operation

    COMMAND or SETTING password security access is restricted to the particular port or particular TCP/IP connection on which the entry was made. Passwords must be entered when accessing the relay through other ports or connections, and the passwords must be re-entered after disconnecting and re-connecting on TCP/IP. GE Multilin G60 Generator Management Relay...
  • Page 326: Memory Mapping

    0 (Off) 0419 Virtual Input 26 State 0 to 1 F108 0 (Off) 041A Virtual Input 27 State 0 to 1 F108 0 (Off) 041B Virtual Input 28 State 0 to 1 F108 0 (Off) G60 Generator Management Relay GE Multilin...
  • Page 327 ...Repeated for Remote Device 3 155D ...Repeated for Remote Device 4 1561 ...Repeated for Remote Device 5 1565 ...Repeated for Remote Device 6 1569 ...Repeated for Remote Device 7 156D ...Repeated for Remote Device 8 GE Multilin G60 Generator Management Relay...
  • Page 328 F002 16E1 Reserved (3 items) 0 to 65535 F001 16E4 ...Repeated for Frequency Rate of Change 2 16E8 ...Repeated for Frequency Rate of Change 3 16EC ...Repeated for Frequency Rate of Change 4 B-10 G60 Generator Management Relay GE Multilin...
  • Page 329 Source 1 Auxiliary Voltage Angle -359.9 to 0 degrees F002 1A23 Source 1 Zero Sequence Voltage Magnitude 0 to 999999.999 0.001 F060 1A25 Source 1 Zero Sequence Voltage Angle -359.9 to 0 degrees F002 GE Multilin G60 Generator Management Relay B-11...
  • Page 330 ...Repeated for Source 3 1D30 ...Repeated for Source 4 1D40 ...Repeated for Source 5 1D50 ...Repeated for Source 6 Energy Commands (Read/Write Command) 1D60 Energy Clear Command 0 to 1 F126 0 (No) B-12 G60 Generator Management Relay GE Multilin...
  • Page 331 Block of data from requested file (122 items) 0 to 65535 F001 Event Recorder (Read Only) 3400 Events Since Last Clear 0 to 4294967295 F003 3402 Number of Available Events 0 to 4294967295 F003 GE Multilin G60 Generator Management Relay B-13...
  • Page 332 -32768 to 32767 °C F002 3506 RTD Input 23 Value -32768 to 32767 °C F002 3507 RTD Input 24 Value -32768 to 32767 °C F002 3508 RTD Input 25 Value -32768 to 32767 °C F002 B-14 G60 Generator Management Relay GE Multilin...
  • Page 333 0.1 to 1 F001 Communications (Read/Write Setting) 407E COM1 minimum response time 0 to 1000 F001 407F COM2 minimum response time 0 to 1000 F001 4080 Modbus Slave Address 1 to 254 F001 GE Multilin G60 Generator Management Relay B-15...
  • Page 334 IEC 60870-5-104 Client Address (5 items) 0 to 4294967295 F003 40FE IEC 60870-5-104 Communications Reserved (2 items) 0 to 1 F001 4100 DNP Binary Input Block of 16 Points (58 items) 0 to 58 F197 0 (Not Used) B-16 G60 Generator Management Relay GE Multilin...
  • Page 335 ...Repeated for User-Programmable LED 12 4298 ...Repeated for User-Programmable LED 13 429A ...Repeated for User-Programmable LED 14 429C ...Repeated for User-Programmable LED 15 429E ...Repeated for User-Programmable LED 16 42A0 ...Repeated for User-Programmable LED 17 GE Multilin G60 Generator Management Relay B-17...
  • Page 336 0 (1 A) 4484 ...Repeated for CT Bank 2 4488 ...Repeated for CT Bank 3 448C ...Repeated for CT Bank 4 4490 ...Repeated for CT Bank 5 4494 ...Repeated for CT Bank 6 B-18 G60 Generator Management Relay GE Multilin...
  • Page 337 User-Definable Display 1 Bottom Line Text F202 ““ 4C14 Modbus Addresses of Display 1 Items (5 items) 0 to 65535 F001 4C19 Reserved (7 items) F001 4C20 ...Repeated for User-Definable Display 2 4C40 ...Repeated for User-Definable Display 3 GE Multilin G60 Generator Management Relay B-19...
  • Page 338 ...Repeated for FlexLogic™ Timer 10 5850 ...Repeated for FlexLogic™ Timer 11 5858 ...Repeated for FlexLogic™ Timer 12 5860 ...Repeated for FlexLogic™ Timer 13 5868 ...Repeated for FlexLogic™ Timer 14 5870 ...Repeated for FlexLogic™ Timer 15 B-20 G60 Generator Management Relay GE Multilin...
  • Page 339 ...Repeated for Phase Instantaneous Overcurrent 6 5A60 ...Repeated for Phase Instantaneous Overcurrent 7 5A70 ...Repeated for Phase Instantaneous Overcurrent 8 5A80 ...Repeated for Phase Instantaneous Overcurrent 9 5A90 ...Repeated for Phase Instantaneous Overcurrent 10 GE Multilin G60 Generator Management Relay B-21...
  • Page 340 Ground Time Overcurrent 1 Events 0 to 1 F102 0 (Disabled) 5D0A Reserved (6 items) 0 to 1 F001 5D10 ...Repeated for Ground Time Overcurrent 2 5D20 ...Repeated for Ground Time Overcurrent 3 B-22 G60 Generator Management Relay GE Multilin...
  • Page 341 0 to 65.535 0.001 F001 64D5 Overfrequency 1 Reset Delay 0 to 65.535 0.001 F001 64D6 Overfrequency 1 Target 0 to 2 F109 0 (Self-reset) 64D7 Overfrequency 1 Events 0 to 1 F102 0 (Disabled) GE Multilin G60 Generator Management Relay B-23...
  • Page 342 Loss Of Excitation Center 1 0.1 to 300 0.01 F001 1000 6683 Loss Of Excitation Radius 1 0.1 to 300 0.01 F001 6684 Loss Of Excitation UV Supervision Enable 1 0 to 1 F102 1 (Enabled) B-24 G60 Generator Management Relay GE Multilin...
  • Page 343 F001 Stator Ground Source (Read/Write Grouped Setting) 6750 Stator Ground Source 0 to 5 F167 0 (SRC 1) Stator Ground (Read/Write Grouped Setting) 6780 Stator Ground Function 0 to 1 F102 0 (Disabled) GE Multilin G60 Generator Management Relay B-25...
  • Page 344 0 to 65535 F300 7046 Phase Overvoltage 1 Target 0 to 2 F109 0 (Self-reset) 7047 Phase Overvoltage 1 Events 0 to 1 F102 0 (Disabled) 7048 Reserved (8 items) 0 to 1 F001 B-26 G60 Generator Management Relay GE Multilin...
  • Page 345 Neutral Directional Overcurrent 1 Block 0 to 65535 F300 728A Neutral Directional Overcurrent 1 Events 0 to 1 F102 0 (Disabled) 728B Neutral Directional Overcurrent 1 Polarizing Voltage 0 to 1 F231 0 (Calculated V0) GE Multilin G60 Generator Management Relay B-27...
  • Page 346 ...Repeated for dcmA Inputs 19 74C8 ...Repeated for dcmA Inputs 20 74E0 ...Repeated for dcmA Inputs 21 74F8 ...Repeated for dcmA Inputs 22 7510 ...Repeated for dcmA Inputs 23 7528 ...Repeated for dcmA Inputs 24 B-28 G60 Generator Management Relay GE Multilin...
  • Page 347 ...Repeated for RTD Input 43 77F0 ...Repeated for RTD Input 44 7800 ...Repeated for RTD Input 45 7810 ...Repeated for RTD Input 46 7820 ...Repeated for RTD Input 47 7830 ...Repeated for RTD Input 48 GE Multilin G60 Generator Management Relay B-29...
  • Page 348 0 (Self-reset) 7F68 Auxiliary Undervoltage 1 Events 0 to 1 F102 0 (Disabled) 7F69 Reserved (7 items) 0 to 65535 F001 7F70 ...Repeated for Auxiliary Undervoltage 2 7F80 ...Repeated for Auxiliary Undervoltage 3 B-30 G60 Generator Management Relay GE Multilin...
  • Page 349 ...Repeated for FlexElement™ 6 9078 ...Repeated for FlexElement™ 7 908C ...Repeated for FlexElement™ 8 90A0 ...Repeated for FlexElement™ 9 90B4 ...Repeated for FlexElement™ 10 90C8 ...Repeated for FlexElement™ 11 90DC ...Repeated for FlexElement™ 12 GE Multilin G60 Generator Management Relay B-31...
  • Page 350 F001 A001 Setting Groups Block 0 to 65535 F300 A002 FlexLogic to Activate Groups 2 through 8 (5 items) 0 to 65535 F300 A009 Setting Group Function 0 to 1 F102 0 (Disabled) B-32 G60 Generator Management Relay GE Multilin...
  • Page 351 0 to 65535 F300 AD03 Non-Volatile Latch 1 Reset 0 to 65535 F300 AD04 Non-Volatile Latch 1 Target 0 to 2 F109 0 (Self-reset) AD05 Non-Volatile Latch 1 Events 0 to 1 F102 0 (Disabled) GE Multilin G60 Generator Management Relay B-33...
  • Page 352 Digital Counter 1 Compare -2147483647 to 2147483647 F004 B311 Digital Counter 1 Reset 0 to 65535 F300 B312 Digital Counter 1 Freeze/Reset 0 to 65535 F300 B313 Digital Counter 1 Freeze/Count 0 to 65535 F300 B-34 G60 Generator Management Relay GE Multilin...
  • Page 353 0 to 65534 F206 (None) B88F IEC 61850 Logical Node XCBRx Name Prefix (2 items) 0 to 65534 F206 (None) B895 IEC 61850 Logical Node PTRCx Name Prefix (2 items) 0 to 65534 F206 (None) GE Multilin G60 Generator Management Relay B-35...
  • Page 354 IEC 61850 GGIO2.CF.SPCSO17.ctlModel Value 2 to 3 F001 BC11 IEC 61850 GGIO2.CF.SPCSO18.ctlModel Value 2 to 3 F001 BC12 IEC 61850 GGIO2.CF.SPCSO19.ctlModel Value 2 to 3 F001 BC13 IEC 61850 GGIO2.CF.SPCSO20.ctlModel Value 2 to 3 F001 B-36 G60 Generator Management Relay GE Multilin...
  • Page 355 ...Repeated for Contact Input 34 C110 ...Repeated for Contact Input 35 C118 ...Repeated for Contact Input 36 C120 ...Repeated for Contact Input 37 C128 ...Repeated for Contact Input 38 C130 ...Repeated for Contact Input 39 GE Multilin G60 Generator Management Relay B-37...
  • Page 356 ...Repeated for Contact Input 88 C2C0 ...Repeated for Contact Input 89 C2C8 ...Repeated for Contact Input 90 C2D0 ...Repeated for Contact Input 91 C2D8 ...Repeated for Contact Input 92 C2E0 ...Repeated for Contact Input 93 B-38 G60 Generator Management Relay GE Multilin...
  • Page 357 ...Repeated for Virtual Output 4 CCD0 ...Repeated for Virtual Output 5 CCE0 ...Repeated for Virtual Output 6 CCF0 ...Repeated for Virtual Output 7 CD00 ...Repeated for Virtual Output 8 CD10 ...Repeated for Virtual Output 9 GE Multilin G60 Generator Management Relay B-39...
  • Page 358 ...Repeated for Virtual Output 58 D030 ...Repeated for Virtual Output 59 D040 ...Repeated for Virtual Output 60 D050 ...Repeated for Virtual Output 61 D060 ...Repeated for Virtual Output 62 D070 ...Repeated for Virtual Output 63 B-40 G60 Generator Management Relay GE Multilin...
  • Page 359 ...Repeated for Contact Output 33 D4A0 ...Repeated for Contact Output 34 D4B0 ...Repeated for Contact Output 35 D4C0 ...Repeated for Contact Output 36 D4D0 ...Repeated for Contact Output 37 D4E0 ...Repeated for Contact Output 38 GE Multilin G60 Generator Management Relay B-41...
  • Page 360 DB40 Direct Device ID 1 to 16 F001 DB41 Direct I/O Channel 1 Ring Configuration Function 0 to 1 F126 0 (No) DB42 Platform Direct I/O Data Rate 64 to 128 kbps F001 B-42 G60 Generator Management Relay GE Multilin...
  • Page 361 ...Repeated for Direct Output 7 DD0E ...Repeated for Direct Output 8 DD10 ...Repeated for Direct Output 9 DD12 ...Repeated for Direct Output 10 DD14 ...Repeated for Direct Output 11 DD16 ...Repeated for Direct Output 12 GE Multilin G60 Generator Management Relay B-43...
  • Page 362 ...Repeated for Device 4 E030 ...Repeated for Device 5 E03C ...Repeated for Device 6 E048 ...Repeated for Device 7 E054 ...Repeated for Device 8 E060 ...Repeated for Device 9 E06C ...Repeated for Device 10 B-44 G60 Generator Management Relay GE Multilin...
  • Page 363 ...Repeated for Remote Input 39 E19C ...Repeated for Remote Input 40 E1A0 ...Repeated for Remote Input 41 E1A4 ...Repeated for Remote Input 42 E1A8 ...Repeated for Remote Input 43 E1AC ...Repeated for Remote Input 44 GE Multilin G60 Generator Management Relay B-45...
  • Page 364 ...Repeated for Remote Output 26 E668 ...Repeated for Remote Output 27 E66C ...Repeated for Remote Output 28 E670 ...Repeated for Remote Output 29 E674 ...Repeated for Remote Output 30 E678 ...Repeated for Remote Output 31 B-46 G60 Generator Management Relay GE Multilin...
  • Page 365 ...Repeated for Restricted Ground Fault 2 EF12 ...Repeated for Restricted Ground Fault 3 EF1B ...Repeated for Restricted Ground Fault 4 EF24 ...Repeated for Restricted Ground Fault 5 EF2D ...Repeated for Restricted Ground Fault 6 GE Multilin G60 Generator Management Relay B-47...
  • Page 366: Data Formats

    POWER_FACTOR (SIGNED 16 BIT INTEGER) 0 = Time-Out, 1 = Acknowledge Positive values indicate lagging power factor; negative values indicate leading. F084 ENUMERATION: SELECTOR POWER UP 0 = Restore, 1 = Synchronize, 2 = Sync/Restore B-48 G60 Generator Management Relay GE Multilin...
  • Page 367 0 = Instantaneous, 1 = Timed, 2 = Linear F118 F105 ENUMERATION: OSCILLOGRAPHY MODE ENUMERATION: LOGIC INPUT 0 = Automatic Overwrite, 1 = Protected 0 = Disabled, 1 = Input 1, 2 = Input 2 GE Multilin G60 Generator Management Relay B-49...
  • Page 368 Ground Instantaneous Overcurrent 1 0 = 1 A, 1 = 5 A Ground Instantaneous Overcurrent 2 Ground Instantaneous Overcurrent 3 Ground Instantaneous Overcurrent 4 Ground Instantaneous Overcurrent 5 Ground Instantaneous Overcurrent 6 Ground Instantaneous Overcurrent 7 B-50 G60 Generator Management Relay GE Multilin...
  • Page 369 Third Harmonic Neutral Undervoltage Non-volatile Latch 16 Setting Group Digital Element 1 Reset Digital Element 2 Overfrequency 1 Digital Element 3 Overfrequency 2 Digital Element 4 Overfrequency 3 Digital Element 5 Overfrequency 4 Digital Element 6 GE Multilin G60 Generator Management Relay B-51...
  • Page 370 F128 DSP Error ENUMERATION: CONTACT INPUT THRESHOLD No DSP Interrupts 0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC Unit Not Calibrated B-52 G60 Generator Management Relay GE Multilin...
  • Page 371 0 = Active Group, 1 = Group 1, 2 = Group 2, 3 = Group 3 4 = Group 4, 5 = Group 5, 6 = Group 6 F154 ENUMERATION: DISTANCE DIRECTION 0 = Forward, 1 = Reverse, 2 = Non-Directional GE Multilin G60 Generator Management Relay B-53...
  • Page 372 ENUMERATION: LOW/HIGH OFFSET and GAIN ENUMERATION: COMMUNICATION PORT TRANSDUCER INPUT/OUTPUT SELECTION 0 = None, 1 = COM1-RS485, 2 = COM2-RS485, 0 = LOW, 1 = HIGH 3 = Front Panel-RS232, 4 = Network B-54 G60 Generator Management Relay GE Multilin...
  • Page 373 A bitmask of 0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000, 6 = 10000, 7 = 100000, 8 = 0.001 F196 ENUMERATION: NEUTRAL DIRECTIONAL OVERCURRENT OPERATING CURRENT 0 = Calculated 3I0, 1 = Measured IG GE Multilin G60 Generator Management Relay B-55...
  • Page 374 TEXT2: 2-CHARACTER ASCII TEXT Elements 401 to 406 Elements 417 to 432 F222 Elements 433 to 448 ENUMERATION: TEST ENUMERATION Elements 449 to 464 0 = Test Enumeration 0, 1 = Test Enumeration 1 B-56 G60 Generator Management Relay GE Multilin...
  • Page 375 [6] VIRTUAL OUTPUTS (1-64) format code for a list of element IDs. The operate bit for element ID [10] CONTACT OUTPUTS VOLTAGE DETECTED (1-64) X is bit [X mod 16] in register [X/16]. GE Multilin G60 Generator Management Relay B-57...
  • Page 376 0 = –1 to 1 mA; 1 = 0 to 1 mA; 2 = 4 to 20 mA Operate IBC Operate ICA F523 ENUMERATION: DNP OBJECTS 20, 22, AND 23 DEFAULT VARIATION F509 BITFIELD: SIMPLE ELEMENT STATE bitmask Default Variation 0 = Operate B-58 G60 Generator Management Relay GE Multilin...
  • Page 377 UR_UINT16: FLEXANALOG PARAMETER Corresponds to the modbus address of the value used when this parameter is selected. Only certain values may be used as Flex- Analogs (basically all metering quantities used in protection) GE Multilin G60 Generator Management Relay B-59...
  • Page 378 B.4 MEMORY MAPPING APPENDIX B B-60 G60 Generator Management Relay GE Multilin...
  • Page 379: Iec 61850

    The G60 relay supports IEC 61850 server services over both TCP/IP and TP4/CLNP (OSI) communication protocol stacks. The TP4/CLNP profile requires the G60 to have a network address or Network Service Access Point (NSAP) to establish a communication link. The TCP/IP profile requires the G60 to have an IP address to establish communications. These addresses are located in the !"...
  • Page 380: Communication Software Utilities

    C.1.6 COMMUNICATION SOFTWARE UTILITIES The exact structure and values of the supported IEC 61850 logical nodes can be seen by connecting to a G60 relay with an MMS browser, such as the “MMS Object Explorer and AXS4-MMS” DDE/OPC server from Sisco Inc.
  • Page 381: Asci Conformance

    Setting group control REPORTING Buffered report control M7-1 sequence-number M7-2 report-time-stamp M7-3 reason-for-inclusion M7-4 data-set-name M7-5 data-reference M7-6 buffer-overflow M7-7 entryID M7-8 BufTm M7-9 IntgPd M7-10 Unbuffered report control M8-1 sequence-number M8-2 report-time-stamp M8-3 reason-for-inclusion GE Multilin G60 Generator Management Relay...
  • Page 382: Asci Services Conformance Statement

    AA: TP/MC SERVER/ UR FAMILY PUBLISHER SERVER (CLAUSE 6) ServerDirectory APPLICATION ASSOCIATION (CLAUSE 7) Associate Abort Release LOGICAL DEVICE (CLAUSE 8) LogicalDeviceDirectory LOGICAL NODE (CLAUSE 9) LogicalNodeDirectory GetAllDataValues DATA (CLAUSE 10) GetDataValues SetDataValues GetDataDirectory GetDataDefinition G60 Generator Management Relay GE Multilin...
  • Page 383 (qchg) S27-3 data-update (dupd) GetURCBValues SetURCBValues LOGGING (CLAUSE 14) LOG CONTROL BLOCK GetLCBValues SetLCBValues QueryLogByTime QueryLogByEntry GetLogStatusValues GENERIC SUBSTATION EVENT MODEL (GSE) (CLAUSE 14.3.5.3.4) GOOSE-CONTROL-BLOCK SendGOOSEMessage GetReference GetGOOSEElementNumber GetGoCBValues SetGoCBValues GSSE-CONTROL-BLOCK SendGSSEMessage GetReference GE Multilin G60 Generator Management Relay...
  • Page 384 (QueryLogByTime or QueryLogAfter) c8: shall declare support for at least one (SendGOOSEMessage or SendGSSEMessage) NOTE c9: shall declare support if TP association is available c10: shall declare support for at least one (SendMSVMessage or SendUSVMessage) G60 Generator Management Relay GE Multilin...
  • Page 385: Logical Nodes

    RDRS: Disturbance record handling XCBR: Circuit breaker RBRF: Breaker failure XSWI: Circuit switch RDIR: Directional element T: LOGICAL NODES FOR INSTRUMENT TRANSFORMERS RFLO: Fault locator TCTR: Current transformer RPSB: Power swing detection/blocking TVTR: Voltage transformer RREC: Autoreclosing GE Multilin G60 Generator Management Relay...
  • Page 386 ZCAP: Capacitor bank ZCON: Converter ZGEN: Generator ZGIL: Gas insulated line ZLIN: Power overhead line ZMOT: Motor ZREA: Reactor ZRRC: Rotating reactive component ZSAR: Surge arrestor ZTCF: Thyristor controlled frequency converter ZTRC: Thyristor controlled reactive component G60 Generator Management Relay GE Multilin...
  • Page 387: Iec 60870-5-104

    Address Field of the Link: Balanced Transmision Not Present (Balanced Transmission Only) Unbalanced Transmission One Octet Two Octets Structured Unstructured Frame Length (maximum length, number of octets): Not selectable in companion IEC 60870-5-104 standard GE Multilin G60 Generator Management Relay...
  • Page 388 <18> := Packed start events of protection equipment with time tag M_EP_TB_1 <19> := Packed output circuit information of protection equipment with time tag M_EP_TC_1 Ë <20> := Packed single-point information with status change detection M_SP_NA_1 G60 Generator Management Relay GE Multilin...
  • Page 389 <103> := Clock synchronization command (see Clause 7.6 in standard) C_CS_NA_1 <104> := Test command C_TS_NA_1 Ë <105> := Reset process command C_RP_NA_1 <106> := Delay acquisition command C_CD_NA_1 Ë <107> := Test command with time tag CP56Time2a C_TS_TA_1 GE Multilin G60 Generator Management Relay...
  • Page 390 Blank boxes indicate functions or ASDU not used. • ‘X’ if only used in the standard direction TYPE IDENTIFICATION CAUSE OF TRANSMISSION MNEMONIC <1> M_SP_NA_1 <2> M_SP_TA_1 <3> M_DP_NA_1 <4> M_DP_TA_1 <5> M_ST_NA_1 <6> M_ST_TA_1 <7> M_BO_NA_1 <8> M_BO_TA_1 G60 Generator Management Relay GE Multilin...
  • Page 391 <21> M_ME_ND_1 <30> M_SP_TB_1 <31> M_DP_TB_1 <32> M_ST_TB_1 <33> M_BO_TB_1 <34> M_ME_TD_1 <35> M_ME_TE_1 <36> M_ME_TF_1 <37> M_IT_TB_1 <38> M_EP_TD_1 <39> M_EP_TE_1 <40> M_EP_TF_1 <45> C_SC_NA_1 <46> C_DC_NA_1 <47> C_RC_NA_1 <48> C_SE_NA_1 <49> C_SE_NB_1 GE Multilin G60 Generator Management Relay...
  • Page 392 <102> C_RD_NA_1 <103> C_CS_NA_1 <104> C_TS_NA_1 <105> C_RP_NA_1 <106> C_CD_NA_1 <107> C_TS_TA_1 <110> P_ME_NA_1 <111> P_ME_NB_1 <112> P_ME_NC_1 <113> P_AC_NA_1 <120> F_FR_NA_1 <121> F_SR_NA_1 <122> F_SC_NA_1 <123> F_LS_NA_1 <124> F_AF_NA_1 <125> F_SG_NA_1 <126> F_DR_TA_1*) G60 Generator Management Relay GE Multilin...
  • Page 393 Long pulse duration (duration determined by a system parameter in the outstation) Ë Persistent output Ë Supervision of maximum delay in command direction of commands and setpoint commands Ë Maximum allowable delay of commands and setpoint commands: 10 s GE Multilin G60 Generator Management Relay...
  • Page 394 Transmission of sequences of events Transmission of sequences of recorded analog values Ë File transfer in control direction: Transparent file Ë Background scan: Background scan Ë Acquisition of transmission delay: Acquisition of transmission delay G60 Generator Management Relay GE Multilin...
  • Page 395 The suitable selection of documents from RFC 2200 defined in this standard for given projects has to be chosen by the user of this standard. Ethernet 802.3 Ë Serial X.21 interface Ë Ë Other selection(s) from RFC 2200 (list below if selected) GE Multilin G60 Generator Management Relay...
  • Page 396: Iec 60870-5-104 Point List

    RGF 4 Restricted Ground Current Magnitude 2043 SRC 1 Auxiliary Voltage Angle degrees 2089 RGF 5 Differential Ground Current Magnitude 2044 SRC 1 Zero Sequence Voltage Magnitude 2090 RGF 5 Restricted Ground Current Magnitude D-10 G60 Generator Management Relay GE Multilin...
  • Page 397 132 - 147 Virtual Output States[0] 148 - 163 Virtual Output States[1] 164 - 179 Virtual Output States[2] 180 - 195 Virtual Output States[3] 196 - 211 Contact Input States[0] 212 - 227 Contact Input States[1] GE Multilin G60 Generator Management Relay D-11...
  • Page 398 D.1 IEC 60870-5-104 APPENDIX D D-12 G60 Generator Management Relay GE Multilin...
  • Page 399: E.1.1 Device Profile Document

    2048 Maximum Data Link Re-tries: Maximum Application Layer Re-tries: None None Ë Ë Fixed at 2 Configurable Ë Ë Configurable Ë Requires Data Link Layer Confirmation: Ë Never Always Ë Sometimes Ë Configurable Ë GE Multilin G60 Generator Management Relay...
  • Page 400 FlexLogic™. The On/Off times and Count value are ignored. “Pulse Off” and “Latch Off” operations put the appropriate Virtual Input into the “Off” state. “Trip” and “Close” operations both put the appropriate Virtual Input into the “On” state. G60 Generator Management Relay GE Multilin...
  • Page 401: Counters

    Default Object: Ë 16 Bits (Counter 8) Default Variation: 1 32 Bits (Counters 0 to 7, 9) Ë Point-by-point list attached Ë Other Value: _____ Ë Point-by-point list attached Ë Sends Multi-Fragment Responses: Ë Ë GE Multilin G60 Generator Management Relay...
  • Page 402: E.1.2 Dnp Implementation

    Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the G60 is not restarted, but the DNP process is restarted. G60 Generator Management Relay GE Multilin...
  • Page 403 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the G60 is not restarted, but the DNP process is restarted. GE Multilin G60 Generator Management Relay...
  • Page 404 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the G60 is not restarted, but the DNP process is restarted. G60 Generator Management Relay GE Multilin...
  • Page 405 Otherwise, static object requests sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for change- event objects, qualifiers 17 or 28 are always responded.) Note 3: Cold restarts are implemented the same as warm restarts – the G60 is not restarted, but the DNP process is restarted. GE Multilin G60 Generator Management Relay...
  • Page 406: E.2.1 Binary Inputs

    Virtual Input 25 Virtual Output 23 Virtual Input 26 Virtual Output 24 Virtual Input 27 Virtual Output 25 Virtual Input 28 Virtual Output 26 Virtual Input 29 Virtual Output 27 Virtual Input 30 Virtual Output 28 G60 Generator Management Relay GE Multilin...
  • Page 407 Contact Input 6 Contact Input 53 Contact Input 7 Contact Input 54 Contact Input 8 Contact Input 55 Contact Input 9 Contact Input 56 Contact Input 10 Contact Input 57 Contact Input 11 Contact Input 58 GE Multilin G60 Generator Management Relay...
  • Page 408 Contact Output 51 Contact Output 5 Contact Output 52 Contact Output 6 Contact Output 53 Contact Output 7 Contact Output 54 Contact Output 8 Contact Output 55 Contact Output 9 Contact Output 56 E-10 G60 Generator Management Relay GE Multilin...
  • Page 409 Source 2 VT Fuse Failure Remote Device 3 Source 3 VT Fuse Failure Remote Device 4 Source 4 VT Fuse Failure Remote Device 5 Stator Differential Remote Device 6 Accidental Energization Remote Device 7 GE Multilin G60 Generator Management Relay E-11...
  • Page 410 Non-Volatile Latch 2 LED State 5 (ALARM) Non-Volatile Latch 3 LED State 6 (PICKUP) Non-Volatile Latch 4 LED State 9 (VOLTAGE) Non-Volatile Latch 5 LED State 10 (CURRENT) Non-Volatile Latch 6 LED State 11 (FREQUENCY) E-12 G60 Generator Management Relay GE Multilin...
  • Page 411 User-Programmable Pushbutton 2 User-Programmable Pushbutton 3 User-Programmable Pushbutton 4 User-Programmable Pushbutton 5 User-Programmable Pushbutton 6 User-Programmable Pushbutton 7 User-Programmable Pushbutton 8 User-Programmable Pushbutton 9 User-Programmable Pushbutton 10 User-Programmable Pushbutton 11 User-Programmable Pushbutton 12 GE Multilin G60 Generator Management Relay E-13...
  • Page 412: E.2.2 Binary And Control Relay Outputs

    Virtual Input 22 Virtual Input 23 Virtual Input 24 Virtual Input 25 Virtual Input 26 Virtual Input 27 Virtual Input 28 Virtual Input 29 Virtual Input 30 Virtual Input 31 Virtual Input 32 E-14 G60 Generator Management Relay GE Multilin...
  • Page 413: E.2.3 Counters

    Events Since Last Clear A counter freeze command has no meaning for counters 8 and 9. G60 Digital Counter values are represented as 32-bit integers. The DNP 3.0 protocol defines counters to be unsigned integers. Care should be taken when interpreting negative counter values.
  • Page 414: Analog Inputs

    Deadbands for individual Analog Input Points can be set using DNP Object 34. When using the G60 in DNP systems with limited memory, the Analog Input Points below may be replaced with a user- definable list. This user-definable list uses the same settings as the Modbus User Map and can be configured with the Mod- bus User Map settings.
  • Page 415 SRC 1 Phase C Real Power RTD Inputs 4 Value SRC 1 Three Phase Reactive Power Tracking Frequency SRC 1 Phase A Reactive Power FlexElement 1 Actual SRC 1 Phase B Reactive Power FlexElement 2 Actual GE Multilin G60 Generator Management Relay E-17...
  • Page 416 FlexElement 9 Actual FlexElement 10 Actual FlexElement 11 Actual FlexElement 12 Actual FlexElement 13 Actual FlexElement 14 Actual FlexElement 15 Actual FlexElement 16 Actual Current Setting Group VHZ 1 Actual VHZ 2 Actual E-18 G60 Generator Management Relay GE Multilin...
  • Page 417: Change Notes

    1601-0110-J1 4.4x 15 September 2004 URX-156 1601-0110-K1 4.6x 15 February 2005 URX-176 F.1.2 CHANGES TO THE G60 MANUAL Table F–2: MAJOR UPDATES FOR G60 MANUAL REVISION K1 (Sheet 1 of 2) PAGE PAGE CHANGE DESCRIPTION (J1) (K1) Title Title Update...
  • Page 418 F.1 CHANGE NOTES APPENDIX F Table F–2: MAJOR UPDATES FOR G60 MANUAL REVISION K1 (Sheet 2 of 2) PAGE PAGE CHANGE DESCRIPTION (J1) (K1) Update Updated MODBUS MEMORY MAP for firmware release 4.6x Added IEC 61850 COMMUNICATIONS appendix Update Updated DNP IMPLEMENTATION section Table F–3: MAJOR UPDATES FOR G60 MANUAL REVISION J1...
  • Page 419 APPENDIX F F.1 CHANGE NOTES Table F–7: MAJOR UPDATES FOR G60 MANUAL REVISION G1 PAGE PAGE CHANGE DESCRIPTION (F2) (G1) Title Title Update Manual part number to 1601-0110-G1 Update Updated G60 ORDER CODES table Update Updated ORDER CODES FOR REPLACEMENT MODULES table...
  • Page 420: Abbreviations

    FDH....Fault Detector high-set MVA ....MegaVolt-Ampere (total 3-phase) FDL ....Fault Detector low-set MVA_A ... MegaVolt-Ampere (phase A) FLA....Full Load Current MVA_B ... MegaVolt-Ampere (phase B) FO ....Fiber Optic MVA_C... MegaVolt-Ampere (phase C) G60 Generator Management Relay GE Multilin...
  • Page 421 ....With Option RST ....Reset WRT....With Respect To RSTR ..... Restrained RTD....Resistance Temperature Detector X .....Reactance RTU....Remote Terminal Unit XDUCER..Transducer RX (Rx) ..Receive, Receiver XFMR....Transformer s ..... second Z......Impedance, Zone S..... Sensitive GE Multilin G60 Generator Management Relay...
  • Page 422: Warranty

    24 months from date of shipment from factory. In the event of a failure covered by warranty, GE Multilin will undertake to repair or replace the relay providing the warrantor determined that it is defective and it is returned with all transportation charges prepaid to an authorized service centre or the factory.
  • Page 423: Index

    Modbus registers .......... B-9, B-13, B-41 BATTERY FAIL ..............7-4 module assignments ............3-11 BINARY INPUT POINTS ............. E-8 settings ............... 5-167 BINARY OUTPUT POINTS ..........E-14 wiring ................3-13 BLOCK DIAGRAM .............. 1-3 GE Multilin G60 Generator Management Relay...
  • Page 424 DIFFERENTIAL stator ............2-6, 5-86, 6-11 EGD PROTOCOL DIGITAL COUNTERS actual values ..............6-7 actual values ..............6-5 Modbus registers ............B-31 FlexLogic™ operands ............ 5-53 settings ................5-19 logic ................5-162 ELECTROSTATIC DISCHARGE ........2-14 G60 Generator Management Relay GE Multilin...
  • Page 425 FLASH MESSAGES ............5-8 FLEX STATE PARAMETERS actual values ............6-5, 6-14 G.703 ............ 3-24, 3-25, 3-26, 3-29 Modbus registers ..........B-13, B-31 GE TYPE IAC CURVES ............ 5-92 settings ................. 5-31 GENERATOR UNBALANCE specifications ..............2-9 FlexLogic™ operands ............. 5-54 FLEXANALOG PARAMETER LIST ........
  • Page 426 INSTANTANEOUS OVERCURRENT exception responses ............B-5 see PHASE, GROUND, and NEUTRAL IOC entries execute operation ............B-4 INSULATION RESISTANCE ..........2-14 flex state parameters ............5-31 INTELLIGENT ELECTRONIC DEVICE ......... 1-2 function code 03/04h ............B-3 G60 Generator Management Relay GE Multilin...
  • Page 427 ................5-101 settings ............... 5-151 Modbus registers ............B-22 specifications ..............2-8 settings ............... 5-101 OVERFRQUENCY specifications ..............2-6 Modbus registers ............B-23 NEUTRAL OVERVOLTAGE OVERVOLTAGE FlexLogic™ operands ............ 5-54 auxiliary ..............2-7, 5-128 GE Multilin G60 Generator Management Relay...
  • Page 428 UserSt-1 bit pair ............5-172 PHASE UNDERVOLTAGE REPLACEMENT MODULES ..........2-4 FlexLogic™ operands ............ 5-55 RESETTING ............5-57, 5-172 logic ................5-123 RESTRICTED GROUND FAULT Modbus registers ............B-26 actual values ..............6-16 settings ............... 5-123 FlexLogic™ operands .............5-56 G60 Generator Management Relay GE Multilin...
  • Page 429 ................ 6-11 force contact outputs ............ 5-183 SIGNAL TYPES ..............1-3 lamp test ................. 7-2 SINGLE LINE DIAGRAM ..........2-1, 2-2 self-test error messages ...........7-3 SITE LIST, CREATING ............4-1 THIRD HARMONIC NEUTRAL UNDERVOLTAGE GE Multilin G60 Generator Management Relay...
  • Page 430 ................. 5-22 WEB SERVER PROTOCOL ..........5-17 USER-PROGRAMMABLE LEDs WEBSITE ................1-1 custom labeling ............... 4-7 defaults ................4-6 description............... 4-6 Modbus registers ............B-17 settings ................. 5-27 ZERO SEQUENCE CORE BALANCE ........3-9 specifications..............2-9 viii G60 Generator Management Relay GE Multilin...

This manual is also suitable for:

Ur series

Comments to this Manuals

Symbols: 0
Latest comments:
