6 ACTUAL VALUES

6.2 STATUS

For status reporting, 'On' represents Logic 1 and 'Off' represents Logic 0.
NOTE
Ö
PATH: ACTUAL VALUES STATUS
T T

CONTACT INPUTS

„
MESSAGE
The present status of the contact inputs is shown here. The first line of a message display indicates the ID of the contact
input. For example, 'Cont Ip 1' refers to the contact input in terms of the default name-array index. The second line of the
display indicates the logic state of the contact input.
Ö
PATH: ACTUAL VALUES STATUS
„

VIRTUAL INPUTS

„
MESSAGE
The present status of the 32 virtual inputs is shown here. The first line of a message display indicates the ID of the virtual
input. For example, 'Virt Ip 1' refers to the virtual input in terms of the default name-array index. The second line of the dis-
play indicates the logic state of the virtual input.
Ö
PATH: ACTUAL VALUES STATUS
„

REMOTE INPUTS

„
MESSAGE
The present state of the 32 remote inputs is shown here.
The state displayed will be that of the remote point unless the remote device has been established to be "Offline" in which
case the value shown is the programmed default state for the remote input.
GE Power Management
Ö
CONTACT INPUTS
Cont Ip 1
Off
↓
↓
Cont Ip xx
Off
ÖØ
VIRTUAL INPUTS
Virt Ip 1
Off
↓
↓
Virt Ip 32
Off
ÖØ
REMOTE INPUTS
REMOTE INPUT 1
STATUS: Off
↓
↓
REMOTE INPUT 32
STATUS: Off
L90 Line Differential Relay
6.2.1 CONTACT INPUTS
6.2.2 VIRTUAL INPUTS
6.2.3 REMOTE INPUTS
Range: On, Off
Range: On, Off
6.2 STATUS
6
6-3
