5 SETTINGS
Figure 5–16: FLEXELEMENT™ DIRECTION, PICKUP, AND HYSTERESIS
In conjunction with the
FLEXELEMENT 1 INPUT MODE
teristics as shown in the figure below.
GE Power Management
FLEXELEMENT 1 PKP
FLEXELEMENT
DIRECTION = Over
FLEXELEMENT 1 PKP
FLEXELEMENT
DIRECTION = Under
setting the element could be programmed to provide two extra charac-
FLEXELEMENT
DIRECTION = Over;
FLEXELEMENT COMP
MODE = Signed;
FLEXELEMENT
DIRECTION = Over;
FLEXELEMENT COMP
MODE = Absolute;
FLEXELEMENT
DIRECTION = Under;
FLEXELEMENT COMP
MODE = Signed;
FLEXELEMENT
DIRECTION = Under;
FLEXELEMENT COMP
MODE = Absolute;
Figure 5–17: FLEXELEMENT™ INPUT MODE SETTING
L90 Line Differential Relay
HYSTERESIS = % of PICKUP
FlexElement 1 OpSig
HYSTERESIS = % of PICKUP
FlexElement 1 OpSig
842705A1.CDR
FLEXELEMENT 1 PKP
FlexElement 1 OpSig
FLEXELEMENT 1 PKP
FlexElement 1 OpSig
FLEXELEMENT 1 PKP
FlexElement 1 OpSig
FLEXELEMENT 1 PKP
FlexElement 1 OpSig
842706A1.CDR
