APPENDIX B
bitmask
Input Point Block
46
Elements 417 to 432
47
Elements 433 to 448
48
Elements 449 to 464
49
Elements 465 to 480
50
Elements 481 to 496
51
Elements 497 to 512
52
Elements 513 to 528
53
Elements 529 to 544
54
Elements 545 to 560
55
LED States 1 to 16
56
LED States 17 to 32
57
Self Tests 1 to 16
58
Self Tests 17 to 32
F200
TEXT40 40 CHARACTER ASCII TEXT
20 registers, 16 Bits: 1st Char MSB, 2nd Char. LSB
F201
TEXT8 8 CHARACTER ASCII PASSCODE
4 registers, 16 Bits: 1st Char MSB, 2nd Char. LSB
F202
TEXT20 20 CHARACTER ASCII TEXT
10 registers, 16 Bits: 1st Char MSB, 2nd Char. LSB
F203
TEXT16 16 CHARACTER ASCII TEXT
F204
TEXT80 80 CHARACTER ASCII TEXT
F205
TEXT12 12 CHARACTER ASCII TEXT
F206
TEXT6 6 CHARACTER ASCII TEXT
F207
TEXT4 4 CHARACTER ASCII TEXT
F208
TEXT2 2 CHARACTER ASCII TEXT
GE Power Management
F222
ENUMERATION TEST ENUMERATION
0 = Test Enumeration 0, 1 = Test Enumeration 1
F230
ENUMERATION DIRECTIONAL POLARIZING
0 = Voltage, 1 = Current, 2 = Dual
F231
ENUMERATION POLARIZING VOLTAGE
0 = Calculated V0, 1 = Measured VX
F300
UR_UINT16 FLEXLOGIC BASE TYPE (6 bit type)
The FlexLogic™ BASE type is 6 bits and is combined with a 9 bit
descriptor and 1 bit for protection element to form a 16 bit value.
The combined bits are of the form: PTTTTTTDDDDDDDDD,
where P bit if set, indicates that the FlexLogic™ type is associated
with a protection element state and T represents bits for the BASE
type, and D represents bits for the descriptor.
The values in square brackets indicate the base type with P prefix
[PTTTTTT] and the values in round brackets indicate the descrip-
tor range.
[0] Off(0) this is boolean FALSE value
[0] On (1)This is boolean TRUE value
[2] CONTACT INPUTS (1 - 96)
[3] CONTACT INPUTS OFF (1-96)
[4] VIRTUAL INPUTS (1-64)
[6] VIRTUAL OUTPUTS (1-64)
[10] CONTACT OUTPUTS VOLTAGE DETECTED (1-64)
[11] CONTACT OUTPUTS VOLTAGE OFF DETECTED (1-64)
[12] CONTACT OUTPUTS CURRENT DETECTED (1-64)
[13] CONTACT OUTPUTS CURRENT OFF DETECTED (1-64)
[14] REMOTE INPUTS (1-32)
[28] INSERT (Via Keypad only)
[32] END
[34] NOT (1 INPUT)
[36] 2 INPUT XOR (0)
[38] LATCH SET/RESET (2 INPUTS)
[40] OR (2-16 INPUTS)
[42] AND (2-16 INPUTS)
[44] NOR (2-16 INPUTS)
[46] NAND (2-16 INPUTS)
[48] TIMER (1-32)
[50] ASSIGN VIRTUAL OUTPUT (1 - 64)
[52] SELF-TEST ERROR (See F141 for range)
[56] ACTIVE SETTING GROUP (1-8)
[62] MISCELLANEOUS EVENTS (See F146 for range)
[64-127] ELEMENT STATES
(Refer to Memory Map Element States Section)
L90 Line Differential Relay
B.4 MEMORY MAPPING
B-55
B
