B.4 MEMORY MAPPING
F186
ENUMERATION MEASUREMENT MODE
0 = Phase to Ground, 1 = Phase to Phase
F190
B
ENUMERATION Simulated Keypress
bitmask keypress
0
---
use between real
keys
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
0
11
Decimal Pt
12
Plus/Minus
F192
ENUMERATION ETHERNET OPERATION MODE
0 = Half-Duplex, 1 = Full-Duplex
F194
ENUMERATION DNP SCALE
A bitmask of 0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000
F195
ENUMERATION SINGLE POLE TRIP MODE
A bitmask of 0 = Disabled, 1 = 3 Pole Only, 2 = 3 Pole & 1 Pole
F196
ENUMERATION NEUTRAL DIR OC OPERATE CURRENT
0 = Calculated 3I0, 1 = Measured IG
B-54
bitmask
keypress
13
Value Up
14
Value Down
15
Message Up
16
Message Down
17
Message Left
18
Message Right
19
Menu
20
Help
21
Escape
22
Enter
23
Reset
24
User 1
25
User 2
26
User 3
L90 Line Differential Relay
F197
ENUMERATION DNP BINARY INPUT POINT BLOCK
bitmask
Input Point Block
0
Not Used
1
Virtual Inputs 1 to 16
2
Virtual Inputs 17 to 32
3
Virtual Outputs 1 to 16
4
Virtual Outputs 17 to 32
5
Virtual Outputs 33 to 48
6
Virtual Outputs 49 to 64
7
Contact Inputs 1 to 16
8
Contact Inputs 17 to 32
9
Contact Inputs 33 to 48
10
Contact Inputs 49 to 64
11
Contact Inputs 65 to 80
12
Contact Inputs 81 to 96
13
Contact Outputs 1 to 16
14
Contact Outputs 17 to 32
15
Contact Outputs 33 to 48
16
Contact Outputs 49 to 64
17
Remote Inputs 1 to 16
18
Remote Inputs 17 to 32
19
Remote Devs 1 to 16
20
Elements 1 to 16
21
Elements 17 to 32
22
Elements 33 to 48
23
Elements 49 to 64
24
Elements 65 to 80
25
Elements 81 to 96
26
Elements 97 to 112
27
Elements 113 to 128
28
Elements 129 to 144
29
Elements 145 to 160
30
Elements 161 to 176
31
Elements 177 to 192
32
Elements 193 to 208
33
Elements 209 to 224
34
Elements 225 to 240
35
Elements 241 to 256
36
Elements 257 to 272
37
Elements 273 to 288
38
Elements 289 to 304
39
Elements 305 to 320
40
Elements 321 to 336
41
Elements 337 to 352
42
Elements 353 to 368
43
Elements 369 to 384
44
Elements 385 to 400
45
Elements 401 to 406
APPENDIX B
GE Power Management
