B.4 MEMORY MAPPING
F400
UR_UINT16 CT/VT BANK SELECTION
bitmask
bank selection
0
Card 1 Contact 1 to 4
1
Card 1 Contact 5 to 8
B
2
Card 2 Contact 1 to 4
3
Card 2 Contact 5 to 8
4
Card 3 Contact 1 to 4
5
Card 3 Contact 5 to 8
F500
UR_UINT16 PACKED BITFIELD
First register indicates I/O state with bits 0(MSB)-15(LSB) corre-
sponding to I/0 state 1-16. The second register indicates I/O state
with bits 0-15 corresponding to I/0 state 17-32 (if required) The
third register indicates I/O state with bits 0-15 corresponding to I/0
state 33-48 (if required). The fourth register indicates I/O state with
bits 0-15 corresponding to I/0 state 49-64 (if required).
The number of registers required is determined by the specific
data item. A bit value of 0 = Off, 1 = On
F501
UR_UINT16 LED STATUS
Low byte of register indicates LED status with bit 0 representing
the top LED and bit 7 the bottom LED. A bit value of 1 indicates
the LED is on, 0 indicates the LED is off.
F502
BITFIELD ELEMENT OPERATE STATES
Each bit contains the operate state for an element. See the F124
format code for a list of element IDs. The operate bit for element ID
X is bit [X mod 16] in register [X/16].
F504
BITFIELD 3 PHASE ELEMENT STATE
bitmask
element state
0
Pickup
1
Operate
2
Pickup Phase A
3
Pickup Phase B
4
Pickup Phase C
5
Operate Phase A
6
Operate Phase B
7
Operate Phase C
F505
BITFIELD CONTACT OUTPUT STATE
0 = Contact State, 1 = Voltage Detected, 2 = Current Detected
B-56
F506|
BITFIELD 1 PHASE ELEMENT STATE
0 = Pickup, 1 = Operate
F507
BITFIELD COUNTER ELEMENT STATE
0 = Count Greater Than, 1 = Count Equal To, 2 = Count Less Than
F509
BITFIELD SIMPLE ELEMENT STATE
0 = Operate
F510
BITFIELD 87L ELEMENT STATE
bitmask
87L Element State
0
Operate A
1
Operate B
2
Operate C
3
Received DTT
4
Operate
5
Key DTT
6
PFLL FAIL
7
PFLL OK
8
Channel 1 FAIL
9
Channel 2 FAIL
10
Channel 1 Lost Packet
11
Channel 2 Lost Packet
12
Channel 1 CRC Fail
13
Channel 2 CRC Fail
F511
BITFIELD 3 PHASE SIMPLE ELEMENT STATE
0 = Operate, 1 = Operate A, 2 = Operate B, 3 = Operate C
F513
ENUMERATION POWER SWING MODE
0 = Two Step, 1 = Three Step
F514
ENUMERATION POWER SWING TRIP MODE
0 = Delayed, 1 = Early
L90 Line Differential Relay
