APPENDIX A
Table A–1: FLEXANALOG PARAMETERS (Sheet 3 of 4)
SETTING
DISPLAY TEXT
6763
SRC 2 V_2 Angle
7168
SRC 1 P
7170
SRC 1 Pa
7172
SRC 1 Pb
7174
SRC 1 Pc
7176
SRC 1 Q
7178
SRC 1 Qa
7180
SRC 1 Qb
7182
SRC 1 Qc
7184
SRC 1 S
7186
SRC 1 Sa
7188
SRC 1 Sb
7190
SRC 1 Sc
7192
SRC 1 PF
7193
SRC 1 Phase A PF
7194
SRC 1 Phase B PF
7195
SRC 1 Phase C PF
7200
SRC 2 P
7202
SRC 2 Pa
7204
SRC 2 Pb
7206
SRC 2 Pc
7208
SRC 2 Q
7210
SRC 2 Qa
7212
SRC 2 Qb
7214
SRC 2 Qc
7216
SRC 2 S
7218
SRC 2 Sa
7220
SRC 2 Sb
7222
SRC 2 Sc
7224
SRC 2 PF
7225
SRC 2 Phase A PF
7226
SRC 2 Phase B PF
7227
SRC 2 Phase C PF
7552
SRC 1 Frequency
7553
SRC 2 Frequency
8704
Brk 1 Arc Amp A
8706
Brk 1 Arc Amp B
8708
Brk 1 Arc Amp C
8710
Brk 2 Arc Amp A
8712
Brk 2 Arc Amp B
8714
Brk 2 Arc Amp C
9216
Synchchk 1 Delta V
9218
Synchchk 1 Delta F
9219
Synchchk 1 Delta Phs
9220
Synchchk 2 Delta V
9222
Synchchk 2 Delta F
9223
Synchchk 2 Delta Phs
9248
1 S1 S2 Angle
9344
Local IA Mag
9346
Local IB Mag
9348
Local IC Mag
GE Power Management
DESCRIPTION
SRC 2 Negative Sequence Voltage Angle (°)
SRC 1 Three Phase Real Power (W)
SRC 1 Phase A Real Power (W)
SRC 1 Phase B Real Power (W)
SRC 1 Phase C Real Power (W)
SRC 1 Three Phase Reactive Power (var)
SRC 1 Phase A Reactive Power (var)
SRC 1 Phase B Reactive Power (var)
SRC 1 Phase C Reactive Power (var)
SRC 1 Three Phase Apparent Power (VA)
SRC 1 Phase A Apparent Power (VA)
SRC 1 Phase B Apparent Power (VA)
SRC 1 Phase C Apparent Power (VA)
SRC 1 Three Phase Power Factor
SRC 1 Phase A Power Factor
SRC 1 Phase B Power Factor
SRC 1 Phase C Power Factor
SRC 2 Three Phase Real Power (W)
SRC 2 Phase A Real Power (W)
SRC 2 Phase B Real Power (W)
SRC 2 Phase C Real Power (W)
SRC 2 Three Phase Reactive Power (var)
SRC 2 Phase A Reactive Power (var)
SRC 2 Phase B Reactive Power (var)
SRC 2 Phase C Reactive Power (var)
SRC 2 Three Phase Apparent Power (VA)
SRC 2 Phase A Apparent Power (VA)
SRC 2 Phase B Apparent Power (VA)
SRC 2 Phase C Apparent Power (VA)
SRC 2 Three Phase Power Factor
SRC 2 Phase A Power Factor
SRC 2 Phase B Power Factor
SRC 2 Phase C Power Factor
SRC 1 Frequency (Hz)
SRC 2 Frequency (Hz)
Breaker 1 Arcing Amp Phase A (kA2-cyc)
Breaker 1 Arcing Amp Phase B (kA2-cyc)
Breaker 1 Arcing Amp Phase C (kA2-cyc)
Breaker 2 Arcing Amp Phase A (kA2-cyc)
Breaker 2 Arcing Amp Phase B (kA2-cyc)
Breaker 2 Arcing Amp Phase C (kA2-cyc)
Synchrocheck 1 Delta Voltage (V)
Synchrocheck 1 Delta Frequency (Hz)
Synchrocheck 1 Delta Phase (°)
Synchrocheck 2 Delta Voltage (V)
Synchrocheck 2 Delta Frequency (Hz)
Synchrocheck 2 Delta Phase (°)
Power Swing S1 S2 Angle (°)
Local IA Magnitude (A)
Local IB Magnitude (A)
Local IC Magnitude (A)
L90 Line Differential Relay
A.1 PARAMETER LIST
A-3
A
