Summary of Contents for Rohde & Schwarz R&S FSP Series

Page 1 R&S ® Spectrum Analyzer Operating Manual 1164.4556.12 – 06...
Page 2 ® The Operating Manual describes the following R&S FSP models and options: R&S FSP3 (1164.4391K03) R&S FSP7 (1164.4391K07) R&S FSP13 (1164.4391K13) R&S FSP30 (1164.4391K30) R&S FSP30 (1164.4391K39) R&S FSP31 (1164.4391K31) R&S FSP40 (1164.4391K40) R&S FSP-B6 (1129.8594.02) R&S FSP-B9 (1129.6991.02) R&S FSP-B10 (1129.8042.03) R&S FSP-B16 (1129.8042.03) R&S FSP-B21 (1155.1758.03) R&S FSP-B28 (1162.9915.02)
Page 3 Basic Safety Instructions Always read through and comply with the following safety instructions! All plants and locations of the Rohde & Schwarz group of companies make every effort to keep the safety standards of our products up to date and to offer our customers the highest possible degree of safety. Our products and the auxiliary equipment they require are designed, built and tested in accordance with the safety standards that apply in each case.
Page 4 Basic Safety Instructions Tags and their meaning The following signal words are used in the product documentation in order to warn the reader about risks and dangers. indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Page 5 Basic Safety Instructions Electrical safety If the information on electrical safety is not observed either at all to the extent necessary, electric shock, fire and/or serious personal injury or death may occur. 1. Prior to switching on the product, always ensure that the nominal voltage setting on the product matches the nominal voltage of the AC supply network.
Page 6 Basic Safety Instructions 14. Use suitable overvoltage protection to ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the product. Otherwise, the person operating the product will be exposed to the danger of an electric shock. 15.
Page 7 Basic Safety Instructions Repair and service 1. The product may be opened only by authorized, specially trained personnel. Before any work is performed on the product or before the product is opened, it must be disconnected from the AC supply network.
Page 8 Informaciones elementales de seguridad 2. Handles on the products are designed exclusively to enable personnel to transport the product. It is therefore not permissible to use handles to fasten the product to or on transport equipment such as cranes, fork lifts, wagons, etc. The user is responsible for securely fastening the products to or on the means of transport or lifting.
Page 9 Informaciones elementales de seguridad Se parte del uso correcto del producto para los fines definidos si el producto es utilizado conforme a las indicaciones de la correspondiente documentación del producto y dentro del margen de rendimiento definido (ver hoja de datos, documentación, informaciones de seguridad que siguen). El uso del producto hace necesarios conocimientos técnicos y ciertos conocimientos del idioma inglés.
Page 10 Informaciones elementales de seguridad Palabras de señal y su significado En la documentación del producto se utilizan las siguientes palabras de señal con el fin de advertir contra riesgos y peligros. PELIGRO identifica un peligro inminente con riesgo elevado que provocará...
Page 11 Informaciones elementales de seguridad Seguridad eléctrica Si no se siguen (o se siguen de modo insuficiente) las indicaciones del fabricante en cuanto a seguridad eléctrica, pueden producirse choques eléctricos, incendios y/o lesiones graves con posible consecuencia de muerte. 1. Antes de la puesta en marcha del producto se deberá comprobar siempre que la tensión preseleccionada en el producto coincida con la de la red de alimentación eléctrica.
Page 12 Informaciones elementales de seguridad 12. Si un producto se instala en un lugar fijo, se deberá primero conectar el conductor de protección fijo con el conductor de protección del producto antes de hacer cualquier otra conexión. La instalación y la conexión deberán ser efectuadas por un electricista especializado. 13.
Page 13 Informaciones elementales de seguridad 5. Ciertos productos, como p. ej. las instalaciones de radiocomunicación RF, pueden a causa de su función natural, emitir una radiación electromagnética aumentada. Deben tomarse todas las medidas necesarias para la protección de las mujeres embarazadas. También las personas con marcapasos pueden correr peligro a causa de la radiación electromagnética.
Page 14 Informaciones elementales de seguridad 6. En caso de falta de estanqueidad de una celda, el líquido vertido no debe entrar en contacto con la piel ni los ojos. Si se produce contacto, lavar con agua abundante la zona afectada y avisar a un médico.
Page 15 Sicherheitshinweise Kundeninformation zur Batterieverordnung (BattV) Dieses Gerät enthält eine schadstoffhaltige Batterie. Diese darf nicht mit dem Hausmüll entsorgt werden. Nach Ende der Lebensdauer darf die Entsorgung nur über eine Rohde&Schwarz-Kundendienststelle oder eine geeig- nete Sammelstelle erfolgen. Safety Regulations for Batteries (according to BattV) This equipment houses a battery containing harmful sub- stances that must not be disposed of as normal household...
Page 16 Customer Information Regarding Product Disposal The German Electrical and Electronic Equipment (ElektroG) Act is an implementation of the following EC directives: • 2002/96/EC on waste electrical and electronic equipment (WEEE) and • 2002/95/EC on the restriction of the use of certain hazardous substances in e lectrical and electronic equipment (RoHS).
Page 17 Qualitätszertifikat Certified Quality System ISO 9001 Certificate of quality Certified Environmental System Certificat de qualité ISO 14001 Sehr geehrter Kunde, Dear Customer, Cher client, Sie haben sich für den Kauf eines You have decided to buy a Vous avez choisi d’acheter un pro- Rohde &...
Page 18 Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support Centers. A team of highly qualified engineers provides telephone support and will work with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
Page 19 R&S FSP Documentation Overview Tabbed Divider Overview Safety Instructions are provided on the CD-ROM Tabbed Divider Documentation Overview Chapter 1: Putting into Operation Chapter 2: Getting Started Chapter 3: Manual Operation Chapter 4: Instrument Functions Chapter 5: Remote Control – Basics Chapter 6: Remote Control –...
Page 20 R&S FSP Documentation Overview Documentation Overview The documentation of the R&S FSP consists of base unit manuals and option man- uals. All manuals are provided in PDF format on the CD-ROM delivered with the instrument. Each software option available for the instrument is described in a sepa- rate software manual.
Page 21: Table Of Contents
R&S FSP Documentation Overview Quick Start Guide This manual is delivered with the instrument in printed form and in PDF format on the CD-ROM. It provides the information needed to set up and start working with the instrument. Basic operations and basic measurements are described. Also a brief introduction to remote control is given.
Page 22 R&S FSP Documentation Overview Service Manual This manual is available in PDF format on the CD-ROM delivered with the instru- ment. It informs on how to check compliance with rated specifications, on instrument function, repair, troubleshooting and fault elimination. It contains all information required for repairing the R&S FSP by the replacement of modules.
Page 23: Front And Rear Panel
R&S FSP Putting into Operation 1 Putting into Operation For details refer to the Quick Start Guide chapter 1, “Front and Rear Panel” and chapter 2, “ Preparing for Use”. Operating Manual 1164.4556.12 - 06...
Page 24 R&S FSP Putting into Operation Operating Manual 1164.4556.12 - 06...
Page 25 R&S FSP Getting Started 2 Getting Started 2.1 Introduction ..........2.2 2.2 Measuring the Spectra of Complex Signals .
Page 26: Introduction
R&S FSP Getting Started Introduction 2.1 Introduction This chapter explains how to operate the R&S FSP using typical measurements as examples. The basic operating steps such as selecting the menus and setting parameters are described in the Quick Start Guide, chapter 4, "Basic Operation". Furthermore, the screen structure and displayed function indicators are explained in this chapter.
Page 27 R&S FSP Getting Started Measuring the Spectra of Complex Signals Example: = 100 MHz, f = 100.03 MHz = 2 × f – f = 2 × 100 MHz – 100.03 MHz = 99.97 MHz = 2 × f – f = 2 ×...
Page 28: Measuring The Spectra Of Complex Signals
R&S FSP Getting Started Measuring the Spectra of Complex Signals With an intermodulation distance of 60 dB and an input level, Pw, of –20 dBm, the following 3 order intercept is obtained: TOI = 60 dBm / 2 + (-20 dBm) = 10 dBm. 2.2.2 Measurement Example –...
Page 29 R&S FSP Getting Started Measuring the Spectra of Complex Signals Press the RES BW MANUAL softkey and enter 10 kHz. By reducing the bandwidth, the noise is further reduced and the intermodulation products can be clearly seen. 5. Measuring intermodulation by means of the 3 order intercept measurement function Press the MEAS key.
Page 30 R&S FSP Getting Started Measuring the Spectra of Complex Signals Fig. 2-2 If the RF attenuation is increased, the R&S FSP’s intrinsic intermodulation products disappear below the noise floor. Calculation method: The method used by the R&S FSP to calculate the intercept point takes the average useful signal level P in dBm and calculates the intermodulation d in dB as a func-...
Page 31 R&S FSP Getting Started Measuring the Spectra of Complex Signals Distortion free Dynamic Range (1 MHz carrier offset RBW = 10 T.O.I. RBW = 1 RBW = 100 RBW = 10 Thermal Noise -100 -110 -120 Mixer level /dBm Fig. 2.11 Intermodulation-free range of the FSP3 as a function of level at the input mixer and the set resolution bandwidth (useful signal offset = 1 MHz, DANL = -155 dBm /Hz, TOI = 12 dBm;...
Page 32: Measuring Signals In The Vicinity Of Noise
R&S FSP Getting Started Measuring Signals in the Vicinity of Noise If the intermodulation products of a DUT with a very high dynamic range are to be measured and the resolution bandwidth to be used is therefore very small, it is best to measure the levels of the useful signals and those of the intermodulation products separately using a small span.
Page 33 R&S FSP Getting Started Measuring Signals in the Vicinity of Noise RBW = 10 kHz RBW = 300 kHz Reference level /dBm Fig. 2.13 Change in displayed noise as a function of the selected reference level at bandwidths of 10 kHz and 300 kHz (-30 dBm reference level) Impact of the resolution bandwidth The sensitivity of a Spectrum Analyzer also directly depends on the selected band- width.
Page 34 R&S FSP Getting Started Measuring Signals in the Vicinity of Noise Impact of the video bandwidth The displayed noise of a Spectrum Analyzer is also influenced by the selected video bandwidth. If the video bandwidth is considerably smaller than the resolution band- width, noise spikes are suppressed, i.e.
Page 35: 1Measurement Example - Measuring The Level Of The Internal Reference Generator At Low S/N Ratios
R&S FSP Getting Started Measuring Signals in the Vicinity of Noise RMS detector For each pixel of the trace, the RMS detector outputs the RMS value of the IF enve- lope for the frequency range assigned to each test point. It therefore measures noise power.
Page 36 R&S FSP Getting Started Measuring Signals in the Vicinity of Noise Press the RF ATTEN MANUAL softkey and enter 60 dB. The RF attenuation indicator is marked with an asterisk (*Att 60 dB) to show that it is no longer coupled to the reference level. The high input attenuation reduces the reference signal which can no longer be detected in noise.
Page 37 R&S FSP Getting Started Measuring Signals in the Vicinity of Noise Press the VIDEO BW MANUAL softkey and enter 10 kHz. The RF signal can be more clearly distinguished from noise. Fig. 2-3 RF sinewave signal with low S/N ratio if a smaller video bandwidth is selected.
Page 38: Noise Measurements
R&S FSP Getting Started Noise Measurements 2.4 Noise Measurements Noise measurements play an important role in spectrum analysis. Noise e.g. affects the sensitivity of radio communication systems and their components. Noise power is specified either as the total power in the transmission channel or as the power referred to a bandwidth of 1 Hz.
Page 39 R&S FSP Getting Started Noise Measurements Conversion to other reference bandwidths The result of the noise measurement can be referred to other bandwidths by simple conversion. This is done by adding 10 · log (BW) to the measurement result, BW being the new reference bandwidth.
Page 40 R&S FSP Getting Started Noise Measurements Determining the noise figure: The noise figure of amplifiers or of the R&S FSP alone can be obtained from the noise power display. Based on the known thermal noise power of a 50 Ω resistor at room temperature (-174 dBm (1Hz)) and the measured noise power P the noise noise...
Page 41: Measurement Of Noise Power Within A Transmission Channel
R&S FSP Getting Started Noise Measurements 2.4.2 Measurement of Noise Power within a Transmission Channel Noise in any bandwidth can be measured with the channel power measurement functions. Thus the noise power in a communication channel can be determined, for example.
Page 42 R&S FSP Getting Started Noise Measurements Fig. 2-1 Measurement of the R&S FSP’s intrinsic noise power in a 1.23 MHz channel bandwidth. 5. Stabilizing the measurement result by increasing the sweep time Press the SWEEP TIME softkey and enter 1 s. By increasing the sweep time to 1 s, the trace becomes much smoother thanks to the RMS detector and the channel power measurement display is much more stable.
Page 43 R&S FSP Getting Started Noise Measurements • The linear power of all the trace pixels within the channel is calculated. (Li/10) = 10 where = power of the trace pixel i = displayed level of trace point i • The powers of all trace pixels within the channel are summed up and the sum is divided by the number of trace pixels in the channel.
Page 44 R&S FSP Getting Started Noise Measurements With the RMS detector, the whole IF envelope is used to calculate the power for each trace pixel. The IF envelope is digitized using a sampling frequency which is at least five times the resolution bandwidth which has been selected. Based on the sample values, the power is calculated for each trace pixel using the following for- mula: ∑...
Page 45 R&S FSP Getting Started Noise Measurements max. error/dB 95 % Confidence level 99 % Confidence level 1000 10000 100000 Number of samples Fig. 2.17 Repeatability of channel power measurements as a function of the number of samples used for power calculation The curves in Fig.
Page 46: Measuring Phase Noise
R&S FSP Getting Started Noise Measurements 2.4.3 Measuring Phase Noise The R&S FSP has an easy-to-use marker function for phase noise measurements. This marker function indicates the phase noise of an RF oscillator at any carrier in dBc in a bandwidth of 1 Hz. 2.4.3.1 Measurement Example –...
Page 47: Measurements On Modulated Signals
R&S FSP Getting Started Measurements on Modulated Signals 6. Stabilize the measurement result by activating trace averaging. Press the TRACE key. Press the AVERAGE softkey. Fig. 2-1 Measuring phase noise with the phase-noise marker function The frequency offset can be varied by moving the marker with the spinwheel or by entering a new frequency offset as a number.
Page 48: 1Measurement Example 1 - Displaying The Af Of An Am Signal In The Time Domain
R&S FSP Getting Started Measurements on Modulated Signals 2.5.1.1 Measurement Example 1 – Displaying the AF of an AM signal in the time domain Test setup: Signal generator Settings on the signal generator (e.g. R&S SMIQ): Frequency: 100 MHz Level: 0 dBm Modulation: 50 % AM, 1 kHz AF...
Page 49: 2Measurement Example 2 - Measuring The Modulation Depth Of An Am Carrier In The Frequency Domain
R&S FSP Getting Started Measurements on Modulated Signals Fig. 2-2 Measuring the AF signal from a 1 kHz AM carrier If the R&S FSP is equipped with the AM/FM Demodulator option (R&S FSP- B3), the AF can be monitored on the built-in loudspeaker. 5.
Page 50: Measurements On Fm Signals
R&S FSP Getting Started Measurements on Modulated Signals Press the SPAN key and enter 5 kHz. 3. Activate the marker function for AM depth measurement Press the MEAS key. Press the MODULATION DEPTH softkey. The R&S FSP automatically positions a marker on the carrier signal in the middle of the graph and one delta marker on each of the lower and upper AM sidebands.
Page 51: 1Measurement Example - Displaying The Af Of An Fm Carrier
R&S FSP Getting Started Measurements on Modulated Signals 2.5.2.1 Measurement Example – Displaying the AF of an FM carrier Test setup: Signal generator Settings on the signal generator (e.g. R&S SMIQ): Frequency: 100 MHz Level: -30 dBm Modulation: FM 0 kHz deviation (i.e., FM = off), 1 kHz AF Measurement with the R&S FSP: 1.
Page 52 R&S FSP Getting Started Measurements on Modulated Signals Fig. 2-4 Filter edge of a 300 kHz filter used as an FM-discriminator characteristic 5. Set an FM deviation of 100 kHz and an AF of 1 kHz on the signal generator 6.
Page 53: Measuring Channel Power And Adjacent Channel Power
R&S FSP Getting Started Measurements on Modulated Signals 2.5.3 Measuring Channel Power and Adjacent Channel Power Measuring channel power and adjacent channel power is one of the most important tasks in the field of digital transmission for a Spectrum Analyzer with the necessary test routines.
Page 54: Cdma Signal
R&S FSP Getting Started Measurements on Modulated Signals 2.5.3.1 Measurement Example 1 – ACPR measurement on an IS95 CDMA Signal Test setup: Signal generator Settings on the signal generator (e.g. R&S SMIQ): Frequency: 850 MHz Level: 0 dBm Modulation: CDMA IS 95 Measurement with the R&S FSP: 1.
Page 55 R&S FSP Getting Started Measurements on Modulated Signals 5. Set the optimal reference level and RF attenuation for the applied signal level. Press the ADJUST REF LVL softkey. The R&S FSP sets the optimal RF attenuation and the reference level based on the transmission channel power to obtain the maximum dynamic range.
Page 56 R&S FSP Getting Started Measurements on Modulated Signals ACPR Repeatability IS95 IBW Method Adjacent channels Alternate channels Tx channel 1000 Sweep time/ms Fig. 2-2 Repeatability of adjacent channel power measurement on IS95-standard signals if the integration bandwidth method is used 6.
Page 57 R&S FSP Getting Started Measurements on Modulated Signals ACPR IS95 Repeatability 0,35 0,25 Adjacent channels 0,15 Tx channel Alternate channels 0,05 1000 Sweep time/ms Fig. 2-4 Repeatability of adjacent channel power measurements on IS95 signals in the Fast ACP mode Note on adjacent channel power measurements on IS95 base-station sig- nals: When measuring the adjacent channel power of IS95 base-station signals, the...
Page 58: Power Of An Is136 Tdma Signal
R&S FSP Getting Started Measurements on Modulated Signals 2.5.3.2 Measurement Example 2 – Measuring the adjacent channel power of an IS136 TDMA signal Test setup: RF Inp Signal generator Ext Ref IN Ext Ref Out As the modulation spectrum of the IS136 signal leaks into the adjacent channel, it makes a contribution to the power in the adjacent channel.
Page 59 R&S FSP Getting Started Measurements on Modulated Signals 5. Setting the optimum reference level and RF attenuation for the measurement Press the ADJUST REF LEVEL softkey. The R&S FSP sets the optimum RF attenuation and the optimum reference level on the basis of the measured channel power. Fig.
Page 60 R&S FSP Getting Started Measurements on Modulated Signals Fig. 2-2 Measuring adjacent channel power in time domain (Fast ACP) As the resolution bandwidth is much wider than the one used for the integration method, the results are much more stable when compared at the same sweep time.
Page 61: 3Measurement Example 3 - Measuring The Modulation Spectrum In Burst Mode With The Gated Sweep Function
R&S FSP Getting Started Measurements on Modulated Signals 2.5.3.3 Measurement Example 3 – Measuring the Modulation Spectrum in Burst Mode with the Gated Sweep Function Since transmission systems compliant to IS136 use a TDMA method, the adjacent channel power must also be measured in burst mode. An IS136 TDMA frame is divided into 6 time slots.
Page 62 R&S FSP Getting Started Measurements on Modulated Signals Keep turning the spinwheel until SAVE/RECALL FRAME appears in the list and select the menu item SAVE/RECALL FRAME using the SELECT key. The cursor is set to GET PREDEFINED FRAME. Press the SELECT key. Select UP1TCH using the spinwheel and press the SELECT key.
Page 63: 4Measurement Example 4 - Measuring The Transient Spectrum In Burst Mode With The Fast Acp Function
R&S FSP Getting Started Measurements on Modulated Signals The selected sweep time is the net sweep time, i.e. the time during which the R&S FSP is actually measuring. The complete frame of an IS136 signal takes 40 ms. In the above example, measurement only takes place for 2x5 ms within a frame.
Page 64 R&S FSP Getting Started Measurements on Modulated Signals Press the CP/ACP STANDARD softkey. Select NADC IS136 from the list of standards and press ENTER. Press the CP/ACP CONFIG ! softkey. Set the FAST ACP softkey to ON. The R&S FSP performs the power measurement in 5 channels (in the useful channel and in the two upper and lower adjacent channels).
Page 65: 5Measurement Example 5 - Measuring Adjacent Channel Power Of A W-Cdma Uplink Signal
R&S FSP Getting Started Measurements on Modulated Signals 2.5.3.5 Measurement Example 5 – Measuring adjacent channel power of a W-CDMA uplink signal Test setup: Signal generator Settings on the signal generator (e.g. R&S SMIQ): Frequency: 1950 MHz Level: 4 dBm Modulation: 3 GPP W-CDMA Reverse Link Measurement with the R&S FSP:...
Page 66 R&S FSP Getting Started Measurements on Modulated Signals Fig. 2-6 Measuring the relative adjacent channel power on a W-CDMA uplink signal 5. Measuring adjacent channel power with the Fast ACP method. Press the CP/ACP CONFIG ! softkey. Set FAST ACP softkey to ON. Press the ADJUST REF LVL softkey.
Page 67 R&S FSP Getting Started Measurements on Modulated Signals Optimum Level Setting for ACP Measurements on W-CDMA Signals The dynamic range for ACPR measurements is limited by the thermal noise floor, the phase noise and the intermodulation (spectral regrowth) of the R&S FSP. The power values produced by the R&S FSP due to these factors accumulate linearly.
Page 68: Amplitude Distribution Measurements
R&S FSP Getting Started Measurements on Modulated Signals To measure the R&S FSP’s intrinsic dynamic range for W-CDMA adjacent chan- nel power measurements, a filter which suppresses the adjacent channel power is required at the output of the transmitter. A SAW filter with a bandwidth of 4 MHz, for example, can be used.
Page 69 R&S FSP Getting Started Measurements on Modulated Signals Set the APD softkey to ON. The R&S FSP sets the frequency span to 0 Hz and measures the amplitude probability distribution (APD). The number of uncorrelated level measurements used for the measurement is 100000. The mean power and the peak power are displayed in dBm.
Page 70 R&S FSP Getting Started Measurements on Modulated Signals 4. Bandwidth selection If the amplitude distribution is measured, the resolution bandwidth must be set in a way that the complete spectrum of the signal to be measured falls within the bandwidth. This is the only way of ensuring that all the amplitudes will pass through the IF filter without being distorted.
Page 71 R&S FSP Manual Operation 3 Manual Operation For details refer to the Quick Start Guide chapter 4, “Basic Operation”. Operating Manual 1164.4556.12 - 06...
Page 72 R&S FSP Manual Operation Operating Manual 1164.4556.12 - 06...
Page 73 R&S FSP Instrument Functions 4 Instrument Functions 4.1 Introduction ..........4.4 4.2 R&S FSP Initial Configuration –...
Page 74 R&S FSP Instrument Functions 4.5.13 Power Measurements – MEAS Key ......4.75 4.5.13.1Power Measurement in Time Domain ..... 4.76 4.5.13.2Channel and Adjacent-Channel Power Measurements .
Page 75 R&S FSP Instrument Functions 4.8.7 Power Offset of the Tracking Generator ..... . . 4.225 4.9 External Generator Control – Option R&S FSP-B10 ....4.226 4.9.1 External Generator Settings .
Page 76: Instrument Functions
R&S FSP Instrument Functions Introduction 4.1 Introduction All functions of the R&S FSP and their application are explained in detail in this chapter. The sequence of the described menu groups depends on the procedure selected for the configuration and start of a measurement: 1.
Page 77: R&S Fsp Initial Configuration - Preset Key
R&S FSP Instrument Functions R&S FSP Initial Configuration – PRESET Key 4.2 R&S FSP Initial Configuration – PRESET Key PRESET Using the PRESET key, the R&S FSP can be set to a predefined initial state. The settings are selected in a way that the RF input is always protected against overload, provided that the applied signal levels are in the allowed range for the instrument.
Page 78 R&S FSP Instrument Functions R&S FSP Initial Configuration – PRESET Key Table 4-1 Initial State of R&S FSP Parameter Settings Mode Spectrum Center frequency 1,5 GHz / 3,5 GHz / 6,8 GHz / 15 GHz / 20 GHz (R&S FSP-3/-7/-13/-30/-40) Center frequency step size 0.1 * center frequency Span...
Page 79: Mode Selection - Hotkey Bar
R&S FSP Instrument Functions Mode Selection – Hotkey Bar 4.3 Mode Selection – Hotkey Bar For fast mode selection the R&S FSP has keys located under the measurement screen, the so-called hotkeys. These hotkeys are displayed depending on the options installed on the instrument. According to the selected mode, the correspond- ing softkey menus are displayed (on the right side of the measurement screen).
Page 80: Return To Manual Operation - Local Menu
R&S FSP Instrument Functions Return to Manual Operation – LOCAL Menu 4.4 Return to Manual Operation – LOCAL Menu LOCAL The LOCAL menu is displayed on switching the instrument to remote control mode. At the same time, the hotkey bar is blanked out and all keys are disabled except the PRESET key.
Page 81: Analyzer Mode
R&S FSP Instrument Functions Analyzer Mode 4.5 Analyzer Mode The analyzer mode is activated by pressing the SPECTRUM hotkey (see also sec- tion “Mode Selection – Hotkey Bar” on page 4.7) SPECTRUM The SPECTRUM hotkey selects the mode for spectrum analysis, the so-called ana- lyzer mode.
Page 82 R&S FSP Instrument Functions Analyzer Mode EXTERNAL MIXER (option B21) CENTER The CENTER softkey opens the window for manually entering the center frequency. The allowed range of values for the center frequency is: • for the frequency domain (span >0): minspan / 2 ≤...
Page 83 R&S FSP Instrument Functions Analyzer Mode = MARKER The = MARKER softkey sets the step size coupling to MANUAL and the step size to the value of the marker. This function is especially useful during measurements of the signal harmonic content at the marker position because by entering the center frequency each stroke of the STEP key selects the center frequency of another har- monic.
Page 84 R&S FSP Instrument Functions Analyzer Mode START The START softkey activates the window for manually entering the start frequency. The allowed range of values for the start frequency is: 0 Hz ≤ f ≤ f - minspan start start frequency start minspan smallest selectable span (10 Hz) max.
Page 85: Setting The Frequency Span - Span Key
R&S FSP Instrument Functions Analyzer Mode TRACK BW The TRACK BW softkey defines the search bandwidth for signal tracking. The fre- quency range is symmetrical with respect to the center frequency. Remote command: CALC:MARK:FUNC:STR:BAND 10KHZ TRACK The TRACK THRESHOLD softkey defines the threshold value for signal detection. THRESHOLD The value is always entered as an absolute level value.
Page 86: Level Display Setting And Rf Input Configuration - Ampt Key
R&S FSP Instrument Functions Analyzer Mode FULL SPAN The FULL SPAN softkey sets the span to the full frequency range of R&S FSP. Remote command: FREQ:SPAN:FULL ZERO SPAN The ZERO SPAN softkey sets the span to 0 Hz. The x-axis becomes the time axis with the grid lines corresponding to 1/10 of the current sweep time (SWT).
Page 87 R&S FSP Instrument Functions Analyzer Mode RF ATTEN AUTO MIXER MIXER LOW NOISE Side menu REF LEVEL POSITION REF LEVEL OFFSET GRID (ABS REL) EL ATTEN AUTO (option B25) EL ATTEN MANUAL (option B25) EL ATTEN OFF (option B25) RF INPUT (50W 75W) REF LEVEL The REF LEVEL softkey allows the reference level to be input in the currently active unit (dBm, dBµV, etc.)
Page 88 R&S FSP Instrument Functions Analyzer Mode UNIT dBmV dBµV dBµΑ dBµW VOLT AMPERE WATT The UNIT softkey opens a submenu to select the unit for the level axis. The default setting is dBm. In general, the R&S FSP measures the signal voltage at the RF input. The level dis- play is calibrated in rms values of an unmodulated sinewave signal.
Page 89: 1Electronic Attenuator
R&S FSP Instrument Functions Analyzer Mode MIXER LOW The MIXER LOW NOISE softkey changes the operating point of the input mixer so NOISE that (with the RF attenuation remaining the same) the inherent noise of the R&S FSP is reduced compared to the default setup. If the softkey is enabled, the R&S FSP has an improved dynamic range above 3 GHz.
Page 90: Setting The Bandwidths And Sweep Time - Bw Key
R&S FSP Instrument Functions Analyzer Mode The attenuation can be varied in 5 dB steps from 0 to 30 dB. Other entries are rounded to the next lower integer value. If the defined reference level cannot be set for the given RF attenuation, the refer- ence level will be adjusted accordingly and the warning "Limit reached"...
Page 91 R&S FSP Instrument Functions Analyzer Mode Bandwidths above 100 kHz are realized using decoupled 4-circuit LC filters. As an alternative to the analog filters, FFT filters are available for the bandwidths between 1 Hz and 30 kHz. When working with bandwidths up to 30 kHz, the FFT algorithm offers considerably higher measurement speeds with all the other settings remaining the same.
Page 92 R&S FSP Instrument Functions Analyzer Mode The …BW MANUAL softkeys allow a parameter to be entered. This parameter is not coupled to the other parameters. With the …BW AUTO softkeys the resolution bandwidth, the video bandwidth and the sweep time can be entered separately for the frequency domain (span > 0 Hz) and the time domain (span = 0 Hz).
Page 93 R&S FSP Instrument Functions Analyzer Mode In time domain (span = 0 Hz), the range of sweep times is 1 µs to 16000 s is select- able in steps of max. 5% of the sweep time. For numeric inputs, rounding is made to the nearest possible sweep time.
Page 94 R&S FSP Instrument Functions Analyzer Mode Band A Band B Band C/D Frequency range < 150 kHz 150 kHz to 30 MHz > 30 MHz IF bandwidth 200 Hz 9 kHz 120 kHz Frequency scan rate 20 s/kHz 200 s/MHz 20 s/MHz The SWEEPTIME AUTO function is designed for detectors like sample, max peak or average.
Page 95 R&S FSP Instrument Functions Analyzer Mode This coupling ratio is recommended whenever the amplitudes of pulsed signals are to be measured correctly. The IF filter is exclusively responsible for pulse shaping. No additional evaluation is performed by the video filter. Remote command: BAND:VID:RAT 10 This setting is only effective for the VBW AUTO selection in the main menu.
Page 96: 1Filter Types
R&S FSP Instrument Functions Analyzer Mode 4.5.4.1 Filter Types • NORMAL (3dB): The resolution bandwidths are implemented by Gaussian filters with the set 3 dB bandwidth and correspond approximately to the noise bandwidth. For bandwidths up to 100 kHz, digital bandpass filters are used. •...
Page 97: 2List Of Available Channel Filters
R&S FSP Instrument Functions Analyzer Mode 4.5.4.2 List of Available Channel Filters The channel filters included in the following table can be activated via the FILTER TYPE softkey and are then available as resolution filters (softkey RES BW) They are available for firmware version 1.10 or higher. For filters of type RRC (Root Raised Cosine), the filter bandwidth indicated describes the sampling rate of the filter.
Page 98 R&S FSP Instrument Functions Analyzer Mode Filter Bandwidth Filter Type Application 1.0 MHz CFILter CDMAone 1.2288 MHz CFILter CDMAone 1.5 MHz CFILter 2.0 MHz *) CFILter 3.0 MHz *) CFILter 3.84 MHz, a=0.22 *) W-CDMA 3GPP 4.096 MHz, a=0.22 *) W-CDMA NTT DOCoMo 5.0 MHz *) CFILter...
Page 99: Sweep Settings - Sweep Key
R&S FSP Instrument Functions Analyzer Mode Fig. 4.2 Reponses of the linear and the logarithmic average detectors as a function of pulse repetition frequency (PRF) for pulse-modulated signals with pulse durations of 400 ns and 1 ms. Resolution bandwidth is 1 MHz. Remote command: BAND:VID:TYPE LIN 4.5.5...
Page 100 R&S FSP Instrument Functions Analyzer Mode SINGLE The SINGLE SWEEP softkey starts n sweeps after triggering. The number of SWEEP sweeps is determined by the SWEEP COUNT softkey. When working in the split-screen mode, the frequency ranges of the two windows are swept one after the other.
Page 101: Triggering The Sweep - Trig Key
R&S FSP Instrument Functions Analyzer Mode The number of sweeps set in the TRACE menu is the same as that in the SWEEP menu. If SINGLE SWEEP is selected, the measurement stops after the selected number of sweeps has been performed. Remote command: SWE:COUN 64 SWEEP...
Page 102 R&S FSP Instrument Functions Analyzer Mode GATE SETTINGS GATE MODE (LEVEL EDGE) POLARITY (POS NEG) GATE DELAY GATE LENGTH SWEEPTIME Side menu TV TRIGGER TV TRIGGER ON | OFF SETTINGS VERT SYNC VERT SYNC ODD FIELD / VERT SYNC EVEN FIELD HOR SYNC VIDEO POL POS | NEG LINES 625 | 525...
Page 103 R&S FSP Instrument Functions Analyzer Mode For this purpose, the R&S FSP uses a level detector at the second intermediate fre- quency. The detector threshold can be selected in a range between –30 dBm and - 10 dBm at the input mixer. The resulting trigger level at the RF input is calculated via the following formula: ≤...
Page 104 R&S FSP Instrument Functions Analyzer Mode Fig. 4.3 Pulsed signal GATE OFF Fig. 4.4 TDMA signal with GATE ON The gated-sweep mode is activated by the GATED TRIGGER softkey. The setting of the mode takes place in the GATE SETTINGS submenu. GATED The GATED TRIGGER softkey switches the sweep mode with gate on and off.
Page 105 R&S FSP Instrument Functions Analyzer Mode The length of the gate signal defines when the sweep is to be interrupted. Here a dif- ferentiation is made between edge-triggered and level-triggered modes: in case of edge triggering the gate length can be set via the GATE LENGTH softkey, while in case of level triggering the gate length depends on the length of the gate signal.
Page 106 R&S FSP Instrument Functions Analyzer Mode When quitting the submenu, the program will return to the frequency domain pro- vided it was active before. The original span is restored so the desired measurement can now be performed with the accurately set gate. Remote command: GATE MODE The GATE MODE (LEVEL EDGE) softkey selects the trigger mode.
Page 107 R&S FSP Instrument Functions Analyzer Mode Measurement example The modulation spectrum of a GSM 900 signal is to be measured using the gated- sweep function. The signal is generated by a Signal Generator whose RF output is directly connected to the RF input of R&S FSP. Settings on the Signal Generator: FREQ: 802 MHz...
Page 108 R&S FSP Instrument Functions Analyzer Mode Fig. 4.6 Setting GATE DELAY and GATE LENGTH in time domain by means of lines GD and GL On quitting the GATE SETTINGS menu, R&S FSP returns to the previous screen. TV TRIGGER The TV and RF Trigger softkey is available with option R&S FSP-B6 and offers the SETTINGS following submenu.
Page 109: Selection And Setting Of Traces - Trace Key
R&S FSP Instrument Functions Analyzer Mode 4.5.7 Selection and Setting of Traces – TRACE Key The R&S FSP is capable of displaying up to three different traces at a time in a dia- gram. A trace consists of a maximum of 501 pixels on the horizontal axis (frequency or time).
Page 110 R&S FSP Instrument Functions Analyzer Mode VIEW BLANK SWEEP COUNT DETECTOR AUTO SELECT DETECTOR AUTO PEAK DETECTOR MAX PEAK DETECTOR MIN PEAK DETECTOR SAMPLE DETECTOR RMS DETECTOR AVERAGE DETECTOR QPK TRACE MATH T1-T2->T1 | T1-T3->T1 TRACE POSITION TRACE MATH OFF Side menu MIN HOLD HOLD CONT (ON OFF)
Page 111 R&S FSP Instrument Functions Analyzer Mode Pressing the MAX HOLD softkey again clears the trace memory and restarts the max hold mode. Remote command: DISP:WIND:TRAC:MODE MAXH AVERAGE The AVERAGE softkey activates the trace averaging function. The average is formed over several sweeps. Averaging can be performed with any of the detectors available.
Page 112 R&S FSP Instrument Functions Analyzer Mode ) Trace ⋅ – MeasValue -------------------------------------------------------------------------------- - Trace where Trace = new trace Trace = old trace = SWEEP COUNT The display "Sweep N of N" does not change any more until a new start is triggered. In the SINGLE SWEEP mode, the number of sweeps is triggered with SWEEP START.
Page 113 R&S FSP Instrument Functions Analyzer Mode TRACE MATH See following section “Mathematical Functions for Traces” on page 4.48. MIN HOLD The MIN HOLD softkey activates the min peak detector. R&S FSP saves for each sweep the smallest of the previously stored/currently measured values in the trace memory.
Page 114 R&S FSP Instrument Functions Analyzer Mode This low average value is usually corrected in noise power measurements by a 2.5 dB factor. Therefore the R&S FSP offers the selection of linear averaging. The trace data are delogarithmized prior to averaging, then averaged and logarithmized again for display on the screen.
Page 115 R&S FSP Instrument Functions Analyzer Mode Different language versions of evaluation programs may require a different han- dling of the decimal point. It is therefore possible to select between separators '.' (decimal point) and ',' (comma) using the DECIM SEP softkey. Example - file header File contents Description...
Page 116: 1Selection Of Detector
R&S FSP Instrument Functions Analyzer Mode Example - data section of the file File contents Description Trace 1:;; Selected trace x-Unit;Hz; Unit of x values: Hz with span > 0; s with span = 0; dBm/dB with statistics measurements y-Unit;dBm; Unit of y values: dB*/V/A/Ω...
Page 117 R&S FSP Instrument Functions Analyzer Mode Each of the 625 pixels of the display thus represents 1/625 of the sweep range and contains all single measurements (frequency samples) in this subrange in com- pressed form. For each trace display mode an optimized detector is selected auto- matically.
Page 118 R&S FSP Instrument Functions Analyzer Mode Average detector The average detector forms the average value of the measured values within a pixel. To this effect, R&S FSP uses the linear voltage after envelope detection. The sam- pled linear values are summed up and the sum is divided by the number of samples (= linear average value).
Page 119 R&S FSP Instrument Functions Analyzer Mode AUTO SELECT The AUTO SELECT softkey (= default setting) selects the optimum detector for the set display mode of the trace (Clear/Write, Max Hold and Min Hold) and the selected filter mode (bandpass/FFT). Trace display Detector (bandpass) Detector (FFT) Clear/Write...
Page 120: 2Mathematical Functions For Traces
R&S FSP Instrument Functions Analyzer Mode The rms detector supplies the power of the signal independent of the waveform. For this effect the root mean square of all sampled level values is formed during the sweep of a pixel. The sweep time thus determines the number of averaged values and with increasing sweep time better averaging is obtained.
Page 121: Recording The Correction Data - Cal Key
R&S FSP Instrument Functions Analyzer Mode TRACE The TRACE POSITION softkey activates the entry of the trace position for 0 differ- POSITION ence. The position is stated in % of the diagram height. The range of values extends from -100% to +200% Remote command: CALC:MATH:POS 50PCT TRACE MATH...
Page 122 R&S FSP Instrument Functions Analyzer Mode CAL CORR The CAL CORR (ON OFF) softkey switches the calibration data on/off. (ON OFF) • ON: The status message depends upon the results of the total calibration. • OFF: The message UNCAL appears in the status line. Remote command: CAL:STAT ON YIG CORR...
Page 123: Markers And Delta Markers - Mkr Key
R&S FSP Instrument Functions Analyzer Mode Remote command: CAL:RES? PAGE UP | The softkeys PAGE UP and PAGE DOWN scroll one page forward or backward in PAGE DOWN the CALIBRATION RESULTS table. They have no function when the table is closed. Remote command: 4.5.10 Markers and Delta Markers –...
Page 124 R&S FSP Instrument Functions Analyzer Mode The MKR key calls a menu that contains all marker and delta marker standard func- tions. If no marker is active, MARKER 1 will be enabled and a peak search on the trace carried out. Otherwise, the data entry for the marker activated last is opened. MARKER (1 2 3 4) / MARKER (NORM DELTA) SIGNAL COUNT...
Page 125: 1Frequency Measurement With The Frequency Counter
R&S FSP Instrument Functions Analyzer Mode Example [PRESET] R&S FSP is set to the default setting. [MKR] On calling the menu, MARKER 1 is switched on ('1' highlighted in the softkey) and positioned on the maximum value of the trace. It is a normal marker and the MARKER NORMAL softkey is high- lighted.
Page 126 R&S FSP Instrument Functions Analyzer Mode • The marker measures only the position of the pixel on the trace and infers the frequency of the signal from this value. The trace, however, contains only a limited number of pixels. Depending upon the selected span, each pixel may contain many measurement values, which therefore limits the frequency resolution.
Page 127 R&S FSP Instrument Functions Analyzer Mode Additionally, the REFERENCE FIXED softkey opens the submenu where it is possi- ble to determine manually a reference point with level and frequency, time or x-axis level, to define a level offset or deactivate the reference point. The REFERENCE FIXED function is useful for the measurement of the harmonic suppression at small span (fundamental not represented).
Page 128 R&S FSP Instrument Functions Analyzer Mode [MKR] MARKER 1 is switched on ('1' highlighted in the softkey) and set to the signal peak. [MARKER 2] MARKER 2 is switched on and automatically defined as the delta marker (DELTA is highlighted on MARKER NORM DELTA softkey).
Page 129 R&S FSP Instrument Functions Analyzer Mode Example Three traces are presented on the screen. The marker is always on trace 1 when switching on. [MKR ->TRACE] "2"<ENTER> The marker jumps to trace 2 but remains on the previous frequency or time. [MKR ->TRACE] "3"<ENTER>...
Page 130: Marker Functions - Mkr Fctn Key
R&S FSP Instrument Functions Analyzer Mode [SIGNAL COUNT] The frequency counter is switched on. R&S FSP counts the frequency of the signal at the marker position with a resolu- tion of 1 kHz. The counted frequency is indicated in the marker info field.
Page 131: 1Activating The Markers
R&S FSP Instrument Functions Analyzer Mode MKR FCTN SELECT MARKER PEAK NOISE MEAS PHASE NOISE PH NOISE (ON OFF) REF POINT LEVEL REF POINT LVL OFFSET REF POINT FREQUENCY PEAK SEARCH AUTO PEAK SEARCH N DB DOWN PEAK LIST NEW SEARCH SORT MODE (FREQ LEVEL) PEAK EXCURSION LEFT LIMIT | RIGHT LIMIT...
Page 132 R&S FSP Instrument Functions Analyzer Mode 4.5.11.2 Measurement of Noise Density NOISE MEAS The NOISE MEAS softkey switches the noise measurement for the active marker on or off. The corresponding marker becomes the NORMAL marker. During noise measurement, the noise power density is measured at the position of the marker.
Page 133: 3Phase Noise Measurement
R&S FSP Instrument Functions Analyzer Mode In time domain mode, the measured values are averaged versus time (after a sweep). Remote command: CALC:MARK:FUNC:NOIS ON; CALC:MARK:FUNC:NOIS:RES? Example: Measurement of inherent R&S FSP noise [PRESET] The R&S FSP is set to default setting. [MARKER] Marker 1 is switched on and set to the maximum value of the dis- played spectrum.
Page 134 R&S FSP Instrument Functions Analyzer Mode No marker enabled: [MKR FCTN] MARKER 1 is enabled and set to peak. [PHASE NOISE] MARKER 1 becomes the reference marker, MARKER 2 the delta marker; frequency = frequency of the reference marker. The delta marker is the active marker, i.e.
Page 135 R&S FSP Instrument Functions Analyzer Mode REF POINT The REF POINT LEVEL softkey activates an entry box for the input of a reference LEVEL level other than the reference marker level. The function is identical to that of the softkey with the same name in the MARKER menu (MKR). Remote command: CALC:DELT1:FUNC:FIX:RPO:Y -10dB REF POINT LVL...
Page 136: 4Measurement Of The Filter Or Signal Bandwidth
R&S FSP Instrument Functions Analyzer Mode 4.5.11.4 Measurement of the Filter or Signal Bandwidth N DB DOWN The N DB DOWN softkey activates the temporary markers T1 and T2 which are n dB below the active reference marker. Marker T1 is placed to the left and marker T2 at the right of the reference marker.
Page 137 R&S FSP Instrument Functions Analyzer Mode • LEVEL: sorting according to level The search range can be restricted by means of the LEFT LIMIT, RIGHT LIMIT and THRESHOLD softkeys. The definition of the peak values can be modified using the PEAK EXCURSION softkey.
Page 138: 6Af Demodulation
R&S FSP Instrument Functions Analyzer Mode LEFT LIMIT | The LEFT LIMIT and RIGHT LIMIT softkeys define the vertical lines F1/F2 in the fre- RIGHT LIMIT quency domain (span > 0) and T1/T2 in the time domain (span = 0) between which the search is carried out.
Page 139: 7Selecting The Trace
R&S FSP Instrument Functions Analyzer Mode The MARKER DEMOD softkey switches on the audio demodulator and calls a sub- menu in which the demodulation mode and the duration of the demodulation can be selected. Remote command: CALC:MARK1:FUNC:DEM ON MKR DEMOD The MKR DEMOD (ON OFF) softkey switches the demodulation on/off.
Page 140: Change Of Settings Via Markers - Mkr-> Key
R&S FSP Instrument Functions Analyzer Mode Example Three traces are displayed on the screen. The marker is always on Trace 1 on switching on. [MKR ->TRACE] "1" The marker jumps to Trace 2, but remains at the previous frequency or time. [MKR ->TRACE] "3"...
Page 141 R&S FSP Instrument Functions Analyzer Mode SELECT The SELECT MARKER softkey activates the numerical selection of the marker in MARKER the data entry field. Delta marker 1 is selected by input of ' 0 '. Remote command: CALC:MARK1 ON CALC:MARK1:X <value> CALC:MARK1:Y? PEAK The PEAK softkey sets the active marker/delta marker to the peak of the trace.
Page 142 R&S FSP Instrument Functions Analyzer Mode [REF LEVEL = MKR LVL] The reference level is set to the measured marker level. [SPAN] The span can, for example, be reduced using the rotary knob. NEXT PEAK The NEXT PEAK softkey sets the active marker/delta marker to the next lower max- imum of the selected trace.
Page 143 R&S FSP Instrument Functions Analyzer Mode SEARCH LIMIT The SEARCH LIMIT OFF softkey disables all limits of the search range. Remote command: CALC:MARK:X:SLIM OFF CALC:THR OFF MKR->TRACE The function of this softkey is identical to that of the MKR->TRACE softkey in the MKR menu (see “MKR->TRACE”...
Page 144 R&S FSP Instrument Functions Analyzer Mode NEXT MIN The NEXT MIN RIGHT softkey sets the active marker/delta marker to the next RIGHT higher minimum right of the current marker position on the selected trace. Remote command: CALC:MARK:MIN:RIGH CALC:DELT:MIN:RIGH NEXT MIN The NEXT MIN LEFT softkey sets the active marker/delta marker to the next higher LEFT minimum left of the current marker position on the selected trace.
Page 145 R&S FSP Instrument Functions Analyzer Mode Fig. 4.8 Examples of level measurement with different settings of PEAK EXCURSION The following table lists the signals as indicated by marker numbers in the diagram above, as well as the minimum of the amplitude decrease to both sides of the signal: signal # min.
Page 146 R&S FSP Instrument Functions Analyzer Mode Order of signals detected: PEAK: Signal 1 NEXT PEAK: Signal 2 NEXT PEAK: Signal 2 (no further signal detected) PEAK: Signal 1 NEXT PEAK LEFT: Signal 1 (no further signal detected) NEXT PEAK RIGHT: Signal 2 NEXT PEAK RIGHT: Signal 2 (no further signal detected) With 6 dB peak excursion, all signals will be detected with NEXT PEAK and NEXT PEAK RIGHT / NEXT PEAK LEFT.
Page 147: Power Measurements - Meas Key
R&S FSP Instrument Functions Analyzer Mode 4.5.13 Power Measurements – MEAS Key With its power measurement functions the R&S FSP is able to measure all the nec- essary parameters with high accuracy in a wide dynamic range. A modulated carrier is almost always used (except e.g. SSB-AM) for high-frequency transmission of information.
Page 148: 1Power Measurement In Time Domain
R&S FSP Instrument Functions Analyzer Mode • Spurious emissions (“SPURIOUS EMISSIONS” on page 4.122) • Spectrum Emission Mask (“SPECTRUM EMISSION MASK” on page 4.140) • order intercept (“TOI” on page 4.119) • Harmonic distortion (“HARMONIC DISTOR” on page 4.120) The above measurements are carried out alternatively. 4.5.13.1 Power Measurement in Time Domain With the aid of the power measurement function, the R&S FSP determines the...
Page 149 R&S FSP Instrument Functions Analyzer Mode MAX HOLD (ON OFF) AVERAGE (ON OFF) NUMBER OF SWEEPS The TIME DOM POWER softkey activates the power measurement in the time domain and opens a submenu for configuration of the power measurement. The submenu allows selection of the type of power measurement (rms or mean power), the settings for max hold and averaging as well as the definition of limits.
Page 150 R&S FSP Instrument Functions Analyzer Mode The number of sweeps over which the average or the maximum value is calculated is set with the NUMBER OF SWEEPS softkey. Remote command: CALC:MARK:FUNC:SUMM:RMS ON CALC:MARK:FUNC:SUMM:RMS:RES? MEAN The MEAN softkey switches on the calculation of the mean value from the points of the displayed trace or a segment of it.
Page 151 R&S FSP Instrument Functions Analyzer Mode STOP LIMIT The STOP LIMIT softkey activates the entry of the upper limit of the evaluation range. Remote command: CALC:MARK:X:SLIM:RIGH <value> The SET REFERENCE softkey sets the power values currently measured as refer- REFERENCE ence values for the calculation of the mean value (MEAN) and the rms value (RMS).
Page 152 R&S FSP Instrument Functions Analyzer Mode NUMBER OF The NUMBER OF SWEEPS softkey activates the entry of the number of sweeps for SWEEPS maximum or average value calculation. SINGLE SWEEP mode The R&S FSP performs sweeps until the selected number of sweeps is reached and stops then.
Page 153: 2Channel And Adjacent-Channel Power Measurements
R&S FSP Instrument Functions Analyzer Mode [TIME DOM POWER] Select power measurement in the time domain. The R&S FSP calculates the mean power from the points of the whole trace. The submenu for configuration of the power measurement is opened. MEAN is already switched on.
Page 154 R&S FSP Instrument Functions Analyzer Mode For some standards, the channel power and the adjacent-channel power are to be weighted by means of a root-raised cosine filter corresponding to a receive filter. This type of filtering is switched on automatically for both methods on selecting the standard (e.g.
Page 155 R&S FSP Instrument Functions Analyzer Mode Fig. 4.9 Screen display of adjacent-channel power measurement using the IBW method Fig. 4.10 Screen display of adjacent-channel power measurement using the time-domain method Limit values for the adjacent-channel power can be defined for the measurement. If limit checking is switched on, a pass/fail information indicating that the power has been exceeded is displayed during the measurement in the table in the lower half of the screen.
Page 156 R&S FSP Instrument Functions Analyzer Mode With the CP/ACP measurement switched on the functions SPLIT SCREEN and FULL SCREEN are inhibited. The channel configuration is defined in the MEAS - CHAN PWR ACP or the MEAS - MULT CARR ACP menu. CHAN PWR CP/ACP (ON OFF) MULT CARR...
Page 157 R&S FSP Instrument Functions Analyzer Mode ment configuration. In addition, they open a submenu for defining the parameters for channel power measurement. The softkey selected is shown in color to indicate that a channel or adjacent-channel power measurement is active. The softkeys are available only for measurements in the frequency domain (span >...
Page 158 R&S FSP Instrument Functions Analyzer Mode CDMA2000 MC3 TD-SCDMA WLAN 802.11a WLAN 802.11b WIMAX WIBRO USER () NADC IS136 TETRA CDPD For the R&S FSP, the channel spacing is defined as the distance between the center frequency of the adjacent channel and the center frequency of the transmis- sion channel.
Page 159 R&S FSP Instrument Functions Analyzer Mode As of firmware version 4.4x it is possible to customize ACP User Standards. The user defined ACP standard can be activated via the entry USER in the standard selection list. The related configuration file is displayed in brackets. To select another user defined standard, use the softkey SELECT USER STD.
Page 160 R&S FSP Instrument Functions Analyzer Mode The RMS detector is used for obtaining correct power measurement results. There- fore this requires no software correction factors. Measured values are output as a list. The powers of the transmission channels are output in dBm, the powers of the adjacent channels in dBm (CP/ACP ABS) or dB (CP/ACP REL).
Page 161 R&S FSP Instrument Functions Analyzer Mode Resolution bandwidth (RBW) To ensure both an acceptable measurement speed and the required selection (to suppress spectral components outside the channel to be measured, especially of the adjacent channels), the resolution bandwidth must not be selected too small or too large.
Page 162 R&S FSP Instrument Functions Analyzer Mode SELECT USER The softkey SELECT USER STD selects and activates a user defined ACP stan- dard. After selecting the standard, the user defined atndard becomes available for selec- tion in the ACP standard list (USER list item). The corresponding filename is shown in brackets.
Page 163: 3Setting The Channel Configuration
R&S FSP Instrument Functions Analyzer Mode 4.5.13.3 Setting the Channel Configuration CP/ACP NO. OF ADJ CHAN CONFIG NO. OF TX CHAN CHANNEL BANDWIDTH CHANNEL SPACING ACP REF SETTINGS CP/ACP (ABS REL) CHAN PWR / HZ POWER MODE CLEAR/WRITE MAX HOLD ADJUST SETTINGS Side menu ACP LIMIT CHECK...
Page 164 R&S FSP Instrument Functions Analyzer Mode With higher numbers the procedure is expanded accordingly. Remote command: SENS:POW:ACH:ACP 1 This increased number of adjacent channels is realized for all the relevant settings like: ACLR LIMIT CHECK :CALC:LIM:ACP:ACH:RES? :CALC:LIM:ACP:ALT1..11:RES? EDIT ACLR LIMITS :CALC:LIM:ACP:ACH:STAT ON :CALC:LIM:ACP:ACH:ABS –10dBm,-10dBm :CALC:LIM:ACP:ACH:ABS:STAT ON...
Page 165 R&S FSP Instrument Functions Analyzer Mode Measurements in the time domain (FAST ACP ON) are performed in the zero span mode. The channel limits are indicated by vertical lines. For measurements requiring channel bandwidths deviating from those defined in the selected standard the IBW method is to be used.
Page 166 R&S FSP Instrument Functions Analyzer Mode • Even number of TX channels: The two TX channels in the middle are used to calculate the frequency between those two channels. This frequency is aligned to the center frequency. Adjacent channels Since all the adjacent channels often have the same distance to each other, the entry of the adjacent-channel spacing (ADJ) causes channel spacing ALT1 to be set to twice and channel spacing ALT2 to three times the adjacent-channel spacing (and so on).
Page 167 R&S FSP Instrument Functions Analyzer Mode ACP REF The ACP REF SETTINGS softkey opens a table for selecting the transmission chan- SETTINGS nel to which the adjacent-channel relative power values should be referenced. A C P R E F E R E N C E C H A N N E L T X C H A N N E L 1 T X C H A N N E L 2 T X C H A N N E L 3...
Page 168 R&S FSP Instrument Functions Analyzer Mode CP/ACP The CP ACP (ABS REL) softkey (channel power absolute/relative) switches (ABS REL) between absolute and relative power measurement in the channel. CP/ACP ABS The absolute power in the transmission channel and in the adjacent channels is displayed in the unit of the y-axis, e.g.
Page 169 R&S FSP Instrument Functions Analyzer Mode ADJUST The ADJUST SETTINGS softkey automatically optimizes the instrument settings for SETTINGS the selected power measurement (see below). All instrument settings relevant for a power measurement within a specific frequency range (channel bandwidth) are optimized for the selected channel configuration (channel bandwidth, channel spacing): •...
Page 170 R&S FSP Instrument Functions Analyzer Mode EDIT ACP The EDIT ACP LIMITS softkey opens a table for defining the limits for the ACP mea- LIMITS surement. The following rules apply for the limits: • A separate limit can be defined for each adjacent channel. The limit applies to both the upper and the lower adjacent channel.
Page 171 R&S FSP Instrument Functions Analyzer Mode The weighting filter parameters can be manually controlled for NORMAL ACP, if no predefined standard is selected (standard NONE or USER). The softkey is not avail- able for FAST ACP. The dialog box contains the following paramaters: •...
Page 172 R&S FSP Instrument Functions Analyzer Mode Select the user standard you just created with SELECT USER STD Change the offset Save the user standard again to keep the current settings. Remote command: POW:ACH:PRES:RLEV:OFFS 10dB SELECT TRACE The SELECT TRACE softkey selects the trace on which the CP/ACP measurement is to be performed.
Page 173 R&S FSP Instrument Functions Analyzer Mode Measurement with user-specific channel configuration: Measurement of the adjacent-channel power ratio (ACPR) of an IS95 CDMA signal at 800 MHz, level 0 dBm. Similar to example 1, the setting can be simplified by using CP/ACP STANDARD.
Page 174 R&S FSP Instrument Functions Analyzer Mode Measurement of signal/noise power density (C/No) of an IS95 CDMA signal (frequency 800 MHz, level 0 dBm) [PRESET] Set the R&S FSP to the default setting. [FREQ: CENTER: Set the center frequency to 800 MHz. 800 MHz] [AMPT: 0 dBm] Set the reference level to 0 dBm.
Page 175 R&S FSP Instrument Functions Analyzer Mode Measurement of Occupied Bandwidth An important characteristics of a modulated signal is its occupied bandwidth. In a radio communications system for instance the occupied bandwidth must be limited to enable distortion-free transmission in adjacent channels. The occupied bandwidth is defined as the bandwidth containing a defined percentage of the total transmitted power.
Page 176 R&S FSP Instrument Functions Analyzer Mode ADJUST REF The ADJUST REF LVL softkey adjusts the reference level of the R&S FSP to the measured total power of the signal. The softkey is activated after the first sweep with the measurement of the occupied bandwidth has been completed and the total power of the signal is thus known.
Page 177 R&S FSP Instrument Functions Analyzer Mode Some of the measurement specifications (e.g. PDC, RCR STD-27B) require mea- surement of the occupied bandwidth using a peak detector. The detector setting of the R&S FSP has to be changed accordingly then. Example Measurement of occupied bandwidth of a PDC signal at 800 MHz, level 0 dBm [PRESET] Set the R&S FSP to the default setting.
Page 178: 4Measurement Of Signal Amplitude Statistics
R&S FSP Instrument Functions Analyzer Mode 4.5.13.4 Measurement of Signal Amplitude Statistics Digital modulated signals are similar to white noise within the transmit channel, but are different in their amplitude distribution. In order to transmit the modulated signal without distortion all amplitudes of the signal have to be transmitted linearly, e.g. from the output power amplifier.
Page 179 R&S FSP Instrument Functions Analyzer Mode Fig. 4.13 Display of the complementary cumulative distribution function (CCDF) Alternate to the histogram display of the APD the Complementary Cumulative Distri- bution Function (CCDF) can be displayed. It shows the probability of an amplitude exceeding a specific value.
Page 180 R&S FSP Instrument Functions Analyzer Mode SIGNAL The SIGNAL STATISTIC softkey opens a submenu for measurement of signal STATISTIC statistics. APD (ON OFF) CCDF (ON OFF) PERCENT MARKER RES BW NO OF SAMPLES SCALING X-AXIS REF LEVEL X-AXIS RANGE Y-UNIT (% ABS) Y-AXIS MAX VALUE Y-AXIS MIN VALUE ADJUST SETTINGS...
Page 181 R&S FSP Instrument Functions Analyzer Mode PERCENT If the CCDF function is active, the PERCENT MARKER softkey allows to position MARKER marker 1 by entering a probability value. Thus, the power which is exceeded with a given probability can be determined very easily. If marker 1 is in the switched-off state, it will be switched on automatically.
Page 182 R&S FSP Instrument Functions Analyzer Mode X-AXIS RANGE The X-AXIS RANGE softkey changes the level range to be covered by the statistics measurement selected. The function is identical to softkey RANGE LOG MANUAL in AMPT menu. Remote command: CALC:STAT:SCAL:X:RANG <value> Y-UNIT (% ABS) The softkey Y-UNIT (% ABS) defines the scaling type on the y-axis.
Page 183 R&S FSP Instrument Functions Analyzer Mode • y-axis lower limit: 1E-6 Remote command: CALC:STAT:PRES MEAN PWR Defines the relative X position of the mean power value for the CCDF measurement. POSITION The default position is 0% (left corner of the grid). This softkey is available if the CCDF measurement is switched on.
Page 184 R&S FSP Instrument Functions Analyzer Mode [CCDF ON /OFF] Switch on measurement of the complementary cumulative distribution function. The R&S FSP switches to zero span mode. The power of the signal and the CCDF is calculated for the number of samples selected. With the CCDF func- tion sample detector and video bandwidth are set auto- matically.
Page 185 R&S FSP Instrument Functions Analyzer Mode The I/Q data capturing is repeated until the configured number of valid samples is reached. If the active gate period is outside the I/Q capture buffer or the resulting gate time is zero the measurement will not reach its end. In this case, the range start and stop values have to be checked.
Page 186: 5Measurement Of Carrier/Noise Ratio C/N And C/No
R&S FSP Instrument Functions Analyzer Mode Gated statistics configuration example: A statistics evaluation has to be done over the useful part of the signal between t3 and t4. The period of the GSM signal is 4.61536 ms External positive trigger slope Begin of burst (after 25 µs) Begin of useful part, to be used for statistics (after 40 µs) End of useful part, to be used for statistics (after 578 µs)
Page 187 R&S FSP Instrument Functions Analyzer Mode 2. The carrier is inside the channel examined: In this case, the measurement must be performed in two steps. First, the reference measurement is performed with the carrier being active. This is done by switching on either the C/N or the C/No measurement and waiting for the end of the next measurement run.
Page 188: 6Measurement Of The Am Modulation Depth
R&S FSP Instrument Functions Analyzer Mode CHANNEL The CHANNEL BANDWIDTH softkey opens a window for selecting the measure- BANDWIDTH ment channel bandwidth. The default setting is 14 kHz. The specified channel bandwidth allows the optimal setting of the measurement parameters of the R&S FSP using ADJUST SETTINGS. Remote command: SENS:POW:ACH:BWID 14kHz ADJUST...
Page 189 R&S FSP Instrument Functions Analyzer Mode Measurement example The AM modulation depth of a carrier modulated with 1 kHz is to be measured at 100 MHz. [PRESET] The R&S FSP is set to the default setting. [CENTER: 100 MHz] The center frequency is set to 100 MHz. [SPAN: 5 kHz] The span is set to 5 kHz.
Page 190 R&S FSP Instrument Functions Analyzer Mode Level a D3 P I2 P I1 f ∆ f ∆ f ∆ Frequency Fig. 4.14 Intermodulation products P and P The intermodulation product at f is generated by mixing the 2nd harmonic of useful signal P and signal P , the intermodulation product at f...
Page 191 R&S FSP Instrument Functions Analyzer Mode The intercept point is the fictitious level where the two lines intersect. It cannot be measured directly since the useful level is previously limited by the maximum two port output power. It can be calculated from the known line slopes and the measured spacing a at a given level according to the following formula.
Page 192: 8Harmonic Measurement
R&S FSP Instrument Functions Analyzer Mode TOI MKR CALC The TOI measurement is based on positioning the markers 3 and 4 onto the position SRCH of the calculated intermodulation products. The accuracy of these frequency calcula- tions depend on the precision of the two carrier frequencies found with peak search. The softkey TOI MKR CALC SRCH allows to switch between the calculated marker position (CALC) and perfoming a local peak search near the expected frequencies (SRCH) instead of the faster position calculation.
Page 193 R&S FSP Instrument Functions Analyzer Mode Trace read out via the normal trace subsystem. The first harmonic frequency can be read out via the center frequency command. THD value comma separated in % and dB: Remote command: CALC:MARK:FUNC:HARM:DIST? TOT Comma separated list of harmonic levels, for each harmonic one value: Remote command: CALC:MARK:FUNC:HARM:LIST? NO.
Page 194: 9Measuring Spurious Emissions
R&S FSP Instrument Functions Analyzer Mode 4.5.13.9 Measuring Spurious Emissions All real amplifiers also generate unwanted RF products outside the assigned fre- quency band. These spurious emissions are usually measured across a wide fre- quency range, for example from 9 kHz to 7 GHz. The analyzer settings are specified for each frequency range.
Page 195 R&S FSP Instrument Functions Analyzer Mode The frequency range where measurements are actually performed is set by the start and stop frequency parameters of the R&S FSP; these parameters are independent of the sweep ranges. It is thus possible to define sweep ranges for a measurement task that can be stored and reloaded and to quickly and easily set the frequency range to be actually measured by means of two parameters;...
Page 196 R&S FSP Instrument Functions Analyzer Mode In the SWEEP LIST table, the individual sweep ranges are set. Range Start: Start frequency of the range Range Stop: Stop frequency of the range Filter Type: NORMAL (3dB), EMI (6dB), CHANNEL, RRC RBW: Resolution filter bandwidth VBW: Video filter bandwidth...
Page 197 R&S FSP Instrument Functions Analyzer Mode DELETE The DELETE RANGE softkey deletes the current range. All higher ranges are set RANGE back by one. Remote command: LIST:RANGe<1…20>:DELete NEXT RANGES The NEXT RANGES softkey activates the displays of the next higher subranges, i.e. 6 to 10, 11 to 15 or 16 to 20.
Page 198 R&S FSP Instrument Functions Analyzer Mode LIST The LIST EVALUATION softkey activates or deactivates the spurious emission mea- EVALUATION surement LIST EVALUATION. The peak search evaluation is automatically done during measurement and the results are displayed in a table in the lower part of the screen.
Page 199 R&S FSP Instrument Functions Analyzer Mode MARGIN The MARGIN softkey activates entry of the margin, i.e. the acceptance threshold for determining the peak list. The limit line is shifted by this value when the maximums are determined. The value range extends from -200 dB to 200 dB. The default value is 6 dB.
Page 200 R&S FSP Instrument Functions Analyzer Mode Table 4-1 Example: ASCII export table - file header File contents Explanation Type;R&S FSP; Model Version;3.90; Firmware version Date;02.Aug 2006; Storage date of data set Mode;ANALYZER; SPURIOUS; Operating mode of the device Start;9000.000000;Hz Start/stop of the span Stop;7000000000.000000;Hz Unit: Hz x-Axis;LIN;...
Page 201 R&S FSP Instrument Functions Analyzer Mode DECIM SEP In the case of floating-point numbers, use the DECIM SEP softkey to select between '.' (decimal point) and ',' (comma) as the decimal delimiter for the ASCII FILE EXPORT function. By selecting the decimal delimiter, various language versions of evaluation pro- grams (e.g.
Page 202 R&S FSP Instrument Functions Analyzer Mode 4.130 Operating Manual 1164.4556.12 - 06...
Page 203 R&S FSP Instrument Functions Analyzer Mode Operating Manual 1164.4556.12 - 06 4.131...
Page 204 R&S FSP Instrument Functions Analyzer Mode 4.132 Operating Manual 1164.4556.12 - 06...
Page 205 R&S FSP Instrument Functions Analyzer Mode Operating Manual 1164.4556.12 - 06 4.133...
Page 206 R&S FSP Instrument Functions Analyzer Mode Format Description of Spectrum Emission Mask XML files The files for importing range settings are in XML format and therefore obey the rules of the XML standard. Below, the child nodes, attributes, and structure defined for the data import is described.
Page 207 R&S FSP Instrument Functions Analyzer Mode • The third element is the Range element, which in turn is embedded in the PowerClass element. It carries the settings information of the range. There have to be at least three defined ranges: one reference range and at least one range to either side of the reference range.
Page 208 R&S FSP Instrument Functions Analyzer Mode • The PowerClass element is structered as follows: <PowerClass Index="n"> <StartPower Unit="dBm" InclusiveFlag="true" Value="StartPowerValue"/> <StopPower Unit="dBm" InclusiveFlag="false" Value="StopPowerValue"/> <DefaultLimitFailMode>Limit Fail Mode</DefaultLimitFailMode> <Range Index="n">  ...
Page 209 R&S FSP Instrument Functions Analyzer Mode <Amplitude> <ReferenceLevel Unit="dBm" Value="Value"/> <RFAttenuation Mode="Auto" Unit="dB" Value="Value"/> <Preamplifier State="State"/> </Amplitude> </Range> Table 4-3 Attributes and child nodes of the BaseFormat element Child Node Attribute Value Parameter Mandator Description FileFormatVersion 1.0.0.0 Date "YYYY-MM-DD HH:MM:SS" Date in ISO 8601 format Name <string>...
Page 210 R&S FSP Instrument Functions Analyzer Mode Child Node Attribute Value Parameter Mandatory Description DefaultLimitFailMode Absolute | Relative | Absolute and Relative | Absolute or Relative Table 4-5 Attributes and child nodes of the Range element (normal ranges) Child Node Attribute Value Parameter Mandatory...
Page 211 R&S FSP Instrument Functions Analyzer Mode Child Node Attribute Value Parameter Mandatory Description Bandwidth <bandwidth in Hz> Type NORMal | PULSe | CFILter | RRC | FFT Bandwidth <bandwidth in Hz> Detector NEG | POS | SAMP | RMS | No (if specified, it has AVER to be equal in all...
Page 212 R&S FSP Instrument Functions Analyzer Mode SPECTRUM The softkey menu of the Spectrum Emission Mask measurement contains the fol- EMISSION lowing softkeys. MASK SPEC EM (ON OFF) SWEEP LIST EDIT SWEEP LIST INS BEFORE RANGE INS AFTER RANGE DELETE RANGE NEXT RANGES PREVIOUS RANGES REFERENCE RANGE...
Page 213 R&S FSP Instrument Functions Analyzer Mode TX BANDWIDTH RRC FILT (ON OFF) ALPHA BT START MEAS STOP MEAS EDIT SWEEP Configures the sweep list. LIST SWEEP LIST RANGE 1 RANGE 2 Ref RANGE 3 RANGE 4 RANGE 5 Range Start -250 MHz -2.52 MHz 2.52 MHz...
Page 214 R&S FSP Instrument Functions Analyzer Mode • Sweep Time Mode AUTO, MANUAL Remote command: ESP:RANG1:SWE:TIME:AUTO ON • Sweep Time Shows the current sweep time. The R&S FSP automatically calculates the sweep time if AUTO mode is selected and displays the corresponding value in this field. If the field is edited, the sweep time mode is automatically set to MANUAL.
Page 215 R&S FSP Instrument Functions Analyzer Mode • Limit Check Sets the type of limit check for all ranges. ABSOLUTE: Checks only the defined absolute limits. RELATIVE: Checks only the relative limits. Relative limits are defined as relative to the measured power in the reference range. ABS &...
Page 216 R&S FSP Instrument Functions Analyzer Mode NEXT RANGES Scrolls through the sweep list in forward direction if more than 5 ranges are defined. The first page shows Range 1 through 5, the second page shows Range 6 to 11 etc. PREVIOUS Scrolls through the sweep list in backwards direction if more than 5 ranges are RANGES...
Page 217 R&S FSP Instrument Functions Analyzer Mode LIST EVAL Activates or deactivates the list evaluation. (ON OFF) A peak search evaluation is performed automatically during the measurement. The results are displayed in a table below the measurement diagram. By default, the list evaluation is active. The evaluation table shows the following results: •...
Page 218: Basic Settings
R&S FSP Instrument Functions Basic Settings 4.6 Basic Settings In this section, the general settings, printout, and instrument settings are described in detail. 4.6.1 Setup of Limit Lines and Display Lines – LINES Key Limit lines are used to define amplitude curves or spectral distribution boundaries on the display screen which are not to be exceeded.
Page 219: 1Selection Of Limit Lines
R&S FSP Instrument Functions Basic Settings Display lines are exclusively used to optically mark relevant frequencies or points in time (span = 0) as well as constant level values. It is not possible to check automati- cally whether the marked level values have been underranged or exceeded. 4.6.1.1 Selection of Limit Lines LINES...
Page 220 R&S FSP Instrument Functions Basic Settings The SELECTED LIMIT LINE display field provides information concerning the char- acteristics of the marked limit lines. In the LIMIT LINES table, the limit lines compatible to the settings of the active screen can be enabled. New limit lines can be specified and edited in the NEW LIMIT LINE and EDIT LIMIT LINE submenus, respectively.
Page 221 R&S FSP Instrument Functions Basic Settings Compatible Indicates if the limit line is compatible with the measurement window of the given trace. Limit Check Activate automatic violation check for upper/lower limits. Trace Select the measurement curve to which the limit is assigned. Margin Define margin.
Page 222 R&S FSP Instrument Functions Basic Settings Trace - Select the measurement curve to which the limit line is assigned. The selection of the measurement curve (trace) takes place in an entry window. Allowed are the integer entries 1, 2 or 3. The default setting is trace 1. If the selected limit line is not compatible with the assigned measurement curve, then the limit line is disabled (display and limit check).
Page 223: 2Entry And Editing Of Limit Lines
R&S FSP Instrument Functions Basic Settings 4.6.1.2 Entry and Editing of Limit Lines A limit line is characterized by • its name • the assignment of domain (frequency or time) • the scaling in absolute or relative times or frequencies •...
Page 224 R&S FSP Instrument Functions Basic Settings EDIT LIMIT NAME LINE / NEW LIMIT VALUES LINE INSERT VALUE DELETE VALUE SHIFT X LIMIT LINE SHIFT Y LIMIT LINE SAVE LIMIT LINE The EDIT LIMIT LINE and NEW LIMIT LINE softkeys both call the EDIT LIMIT LINE submenu used for editing limit lines.
Page 225 R&S FSP Instrument Functions Basic Settings A change in domain (frequency/time) is only permitted when the data point table is empty. Remote command: CALC:LIM3:CONT:DOM FREQ X-Axis - Select interpolation Linear or logarithmic interpolation can be carried out between the frequency refer- ence points of the table.
Page 226 R&S FSP Instrument Functions Basic Settings Margin - Setting a margin. The margin is defined as the signal-level distance to the limit line. When the limit line is defined as an upper limit, the margin means that the level is below the limit line. When the limit line is defined as a lower limit, the margin means that the level is above the limit line.
Page 227 R&S FSP Instrument Functions Basic Settings INSERT VALUE The INSERT VALUE softkey creates an empty line above the current cursor position where a new data point may be entered. However, during the entry of new values, it is necessary to observe an ascending order for frequency/time. Remote command: DELETE VALUE The DELETE VALUE softkey erases the data point (complete line) at the cursor...
Page 228 R&S FSP Instrument Functions Basic Settings Each line is identified by one of the following abbreviations: Display Line 1 Display Line 2 Frequency Line 1 Frequency Line 2 Time Line 1 Time Line 2 The level lines are continuous horizontal lines across the entire width of a diagram and can be shifted in y direction.
Page 229: Configuration Of Screen Display - Disp Key
R&S FSP Instrument Functions Basic Settings DISPLAY LINE 1 The DISPLAY LINE 1/2 softkeys enable or disable the level lines and allow the user / DISPLAY to enter the position of the lines. LINE 2 The level lines mark the selected level in the measurement window. These softkeys are only available in the time domain (span = 0).
Page 230 R&S FSP Instrument Functions Basic Settings However, specific settings of the two windows (reference level, center frequency) can be coupled, if required, so that with CENTER B = MARKER A for example, the shift of the marker in diagram A causes the frequency range (zoomed in some cases) to be shifted along diagram B.
Page 231 R&S FSP Instrument Functions Basic Settings SELECT OBJECT BRIGHTNESS TINT SATURATION PREDEFINED COLORS FULL SCREEN The FULL SCREEN softkey selects the display of one diagram. This corresponds to the default setting of R&S FSP. In the FULL SCREEN mode, it is possible to switch between two different device settings by selecting the active window (screen A or screen B).
Page 232 R&S FSP Instrument Functions Basic Settings CONFIG SCREEN TITLE DISPLAY TIME+DATE (ON OFF) LOGO (ON OFF) ANNOTATION (ON OFF) DATA ENTRY OPAQUE DEFAULT COLORS 1/ DEFAULT COLORS 2 DISPLAY PWR SAVE Side menu SELECT OBJECT BRIGHTNESS TINT SATURATION PREDEFINED COLORS The CONFIG DISPLAY softkey opens a submenu allowing additional display items to be added to the screen.
Page 233 R&S FSP Instrument Functions Basic Settings DEFAULT The DEFAULT COLORS 1/2 softkeys restores the default settings for brightness, COLORS 1/ color tint and color saturation for all display screen elements. DEFAULT The color schemes have been selected to give optimum visibility of all picture ele- COLORS 2 ments at an angle of vision from above or below.
Page 234 R&S FSP Instrument Functions Basic Settings BRIGHTNESS The BRIGHTNESS softkey activates entry of the brightness of the selected graphics element. Values between 0 and 100% can be entered. Remote command: DISP:CMAP3:HSL< hue>,<sat>,<lum> TINT The TINT softkey activates the entry of the color tint of the selected element. The entered value is related to a continuous color spectrum ranging from red (0%) to blue (100%).
Page 235: Instrument Setup And Interface Configuration - Setup Key
R&S FSP Instrument Functions Basic Settings PREDEFINED The PREDEFINED COLORS softkey activates a table, with which the predefined COLORS colors for the display screen elements can be selected. Remote command: DISP:CMAP1 to 26:PDEF <color> 4.6.3 Instrument Setup and Interface Configuration – SETUP Key The SETUP key opens the menu for configuration of the R&S FSP: SETUP REFERENCE FREQUENCY...
Page 236 R&S FSP Instrument Functions Basic Settings GPIB LANGUAGE IF GAIN (NORM PULS) SWEEP REP (ON OFF) COUPLING (FSP HP) COM INTERFACE TIME+DATE CONFIGURE NETWORK COMPUTER NAME IP ADDRESS SUBNET MASK DHCP (ON OFF) CONFIGURE NETWORK SHOW CONFIG NETWORK LOGIN OPTIONS INSTALL OPTION REMOVE OPTION Side menu...
Page 237: 1External Reference
R&S FSP Instrument Functions Basic Settings EXPORT / IMPORT DEV DATA Side menu FIRMWARE UPDATE FIRMWARE UPDATE RESTORE FIRMWARE UPDATE PATH OPEN START MENU POWER METER The following settings can be modified here: • The REFERENCE INT/EXT softkey determines the source of the reference. For details refer to section “External Reference”...
Page 238 R&S FSP Instrument Functions Basic Settings In the setting REFERENCE EXT, the connector REF IN is used as input connector for an external frequency standard. In this case all internal oscillators of the R&S FSP are synchronized to the external reference frequency. REFERENCE As of firmware version 4.4x, the firmware provides the REFERENCE FREQUENCY FREQUENCY...
Page 239: 3Rf Preamplifier
R&S FSP Instrument Functions Basic Settings 4.6.3.2 External Noise Source NOISE SRC The NOISE SRC (ON OFF) softkey switches on or off the supply voltage for an (ON OFF) external noise source which is connected to the NOISE SOURCE connector on the rear panel of the instrument.
Page 240 R&S FSP Instrument Functions Basic Settings NEW FACTOR / TRD FACTOR NAME EDIT TRD FACTOR TRD FACTOR UNIT TRD FACTOR VALUES INSERT LINE DELETE LINE SAVE TRD FACTOR DELETE FACTOR VIEW TRANSDUCER REFLVL ADJ AUTO MAN PAGE UP PAGE DOWN A table with the available factors is displayed, and the active transducer can be selected from this list.
Page 241 R&S FSP Instrument Functions Basic Settings Remote command: CORR:TRAN DEL VIEW The VIEW TRANSDUCER softkey activates the display of the active transducer fac- TRANSDUCER tor or set. During the measurement, the interpolated characteristic of the active transducer factor or set is shown in the diagram instead of the measured values. Remote command: CORR:TRAN:VIEW ON REFLVL ADJ...
Page 242 R&S FSP Instrument Functions Basic Settings The softkeys in the UNIT submenu of the AMPT key cannot be operated if the transducer is on. The NEW FACTOR and EDIT TRD FACTOR softkeys give access to the submenu FACTOR / for editing and generating transducer factors. EDIT TRD FAC TRD FACTOR NAME TRD FACTOR UNIT...
Page 243 R&S FSP Instrument Functions Basic Settings Name - Entry of name TRD FACTOR The TRD FACTOR NAME softkey is used to enter the name of the transducer factor. NAME A maximum of 8 characters is permissible for the name. The characters have to comply with the convention of DOS file names.
Page 244: 5Programming The Interface Configuration And Time Setup
R&S FSP Instrument Functions Basic Settings Fig. 4.17 Linear frequency axis and linear interpolation Fig. 4.18 Logarithmic frequency axis and interpolation Comment - Entry of comment Any comment with a maximum length of 50 characters can be entered. Remote command: CORR:TRAN:COMM <string>...
Page 245 R&S FSP Instrument Functions Basic Settings GENERAL GPIB GPIB ADDRESS SETUP ID STRING FACTORY ID STRING USER GPIB LANGUAGE IF GAIN (NORM PULS) SWEEP REP (ON OFF) COUPLING (FSP HP) COM INTERFACE TIME+DATE CONFIGURE COMPUTER NAME NETWORK IP ADDRESS SUBNET MASK DHCP (ON OFF) CONFIGURE NETWORK...
Page 246 R&S FSP Instrument Functions Basic Settings Selecting the GPIB Address GPIB The GPIB softkey opens a submenu for setting the parameters of the remote-control interface. Remote command: GPIB ADDRESS The GPIB ADDRESS softkey enables the entry of the GPIB address. Valid addresses are 0 through 30.
Page 247 R&S FSP Instrument Functions Basic Settings For 8566A/B, 8568A/B and 8594E, command sets A and B are available. Com- mand sets A and B differ in the rules regarding the command structure from the command structure of “SCPI”. Therefore, correct recognition of SCPI commands is not ensured in these operating modes.
Page 248 R&S FSP Instrument Functions Basic Settings Remote command: SYST:LANG "SCPI" | "8560E" | "8561E" | "8562E" | "8563E" | "8564E" | "8565E" | "8566A" | "8566B" | "8568A" | "8568A_DC" | "8568B" | "8568B_DC" | "8591E" | "8594E" | "71100C" | "71200C" | "71209A"...
Page 249 R&S FSP Instrument Functions Basic Settings Serial Interface Configuration The COM INTERFACE softkey activates the COM INTERFACE table for entry of the INTERFACE serial interface parameters. The following parameters can be configured in the table: Baud rate data transmission rate Bits number of data bits Parity...
Page 250 R&S FSP Instrument Functions Basic Settings Parity – Bit parity check NONE no parity check (default setting) EVEN even parity check odd parity check Remote command: SYST:COMM:SER:PAR NONE Stop bits – Number of stop bits Available are 1 and 2. The default setting is 1 stop bit. Remote command: SYST:COMM:SER:SBIT 1 HW-Handshake –...
Page 251 R&S FSP Instrument Functions Basic Settings Default setting is NONE. Remote command: SYST:COMM:SER:PACE NONE Owner – Assignment of the interface The serial interface can be assigned alternatively to the measuring instrument sec- tion or to the computer section. If the interface is assigned to one section of the instrument, it is not available to the other section.
Page 252 R&S FSP Instrument Functions Basic Settings CONFIGURE The CONFIGURE NETWORK softkey opens the following submenu: NETWORK COMPUTER NAME IP ADDRESS SUBNET MASK DHCP (ON OFF) CONFIGURE NETWORK SHOW CONFIG The Network Configuration softkeys above are available from firmware Version 4.3x. Instruments shipped with Windows XP Service Pack1 require an additional instal- lation package (LXI installer) if the softkeys are not visible.
Page 253 R&S FSP Instrument Functions Basic Settings CONFIGURE The CONFIGURE NETWORK softkey opens the dialog box with the network set- NETWORK tings. The softkey is used to modify an existing network configuration after the correspond- ing tabs are selected (see the Quick Start Guide 6, “...
Page 254 R&S FSP Instrument Functions Basic Settings With the 'Auto Login' option active, an automatic registration is performed during booting with the specified user name and password. Otherwise the Windows XP login request is displayed during booting. A PC keyboard with trackball (or mouse instead) is required for the installation/ configuration of the network support.
Page 255 R&S FSP Instrument Functions Basic Settings • Check whether the application with the maximum MAX MEM value is still required. Disable this application if it is not required to reduce the worst case memory allocation. • Reduce the base memory allocation by reducing the number of enabled applications with a MIN MEM value unequal to 0.
Page 256 R&S FSP Instrument Functions Basic Settings Display resolution When the display of the front-panel keys is switched on, the screen resolution of the instrument changes to 1024x768 pixels. Only a section of the total screen is then displayed on the LC display, which will automatically be shifted on mouse moves. In order to obtain a complete display of the user interface, an external monitor is to be plugged into the corresponding connector at the rear panel.
Page 257 R&S FSP Instrument Functions Basic Settings The LXI softkey opens a submenu to configure LXI. DISPLAY (ON OFF) INFO PASSWORD DESC LAN RESET LXI Activation The LXI has to be activated after the firmware update. 1. Connect the R&S FSP to the LAN. 2.
Page 258: 6System Information
R&S FSP Instrument Functions Basic Settings DESC The DESC softkey opens a dialog box to view or change the LXI instrument descrip- tion. This description is used on some of the LXI web sites. Remote command: SYST:LXI:MDES <string> LAN RESET The LAN RESET softkey resets the LAN configuration to a state required by the LXI standard.
Page 259 R&S FSP Instrument Functions Basic Settings The screenshot lists the components of an R&S FSP7 with options R&S FSP-B3 (AF demodulator) and R&S FSP-B16 (LAN interface). Display of Device Statistics STATISTICS The STATISTICS softkey opens the table STATISTICS. This table contains the model information, serial number, firmware version, and specifications version of the basic device.
Page 260: 7Service Menu
R&S FSP Instrument Functions Basic Settings Messages that have occurred since the last call to the SYSTEM MESSAGES menu are marked with an asterisk '*'. The CLEAR ALL MESSAGES softkey is activated and allows clearing of the error buffer. If the number of error messages exceeds the capacity of the error buffer, the mes- sage appearing first is "Message buffer overflow".
Page 261 R&S FSP Instrument Functions Basic Settings EXPORT / IMPORT DEV DATA The SERVICE softkey opens a submenu for selection of the service function. The INPUT RF and INPUT CAL softkeys are mutually exclusive selection switches. Only one switch can be active at any one time. General Service Functions INPUT RF The INPUT RF softkey switches the input of the R&S FSP to the input connector...
Page 262 R&S FSP Instrument Functions Basic Settings COMMAND The COMMAND TRACKING softkey activates or deactivates the SCPI error log TRACKING function. All remote control commands received by the R&S FSP are recorded in the following log file: D:\R_S\instr\log\IEC_CMDS.LOG Logging the commands may be extremely useful for debug purposes, e.g. in order to find misspelled keywords in control programs.
Page 263 R&S FSP Instrument Functions Basic Settings Selftest SELFTEST The SELFTEST softkey initiates the selftest of the instrument modules. With this function the instrument is capable of identifying a defective module in case of failure. During the selftest a message box appears in which the current test and its result is shown.
Page 264: 8Firmware Update
R&S FSP Instrument Functions Basic Settings 4.6.3.8 Firmware Update For the latest firmware version refer to the Rohde & Schwarz internet site and down- load the most up-to-date firmware. A detailed description about performing the firmware update in the intrument is given in the release note, provided on this CD.
Page 265: Saving And Recalling Data Sets - File Key
R&S FSP Instrument Functions Basic Settings Remote command: SYST:APPL:SREC ON OPEN START The OPEN START MENU softkey opens the windows XP start menu and therefore MENU provides an easy access to standard windows functions if a mouse is connect. POWER The POWER METER softkey opens a submenu for measurements with power sen- METER sors.
Page 266 R&S FSP Instrument Functions Basic Settings EDIT COMMENT SELECT ITEMS SELECT ITEMS ENABLE ALL ITEMS DISABLE ALL ITEMS DELETE FILE NEW FOLDER STARTUP RECALL FILE MANAGER EDIT PATH NEW FOLDER PASTE SORT MODE NAME DATE EXTENSION SIZE 2 FILE LISTS Side menu FORMAT DISK For details on storing and loading instrument settings refer to the Quick Start Guide,...
Page 267 R&S FSP Instrument Functions Basic Settings The SAVE / RECALL table contains the entry fields for editing the data set. Path Directory in which the data set is stored. Files List of data sets already stored. File Name Name of data set. The name can be entered with or without drive name and directory;...
Page 268 R&S FSP Instrument Functions Basic Settings SELECT ITEMS The SELECT ITEMS softkey moves the selection bar to the first line, left column of the Items field. An entry is selected. Position the entry focus to the corresponding partial data set using the cursor keys and then press the ENTER key in the desired line.
Page 269 R&S FSP Instrument Functions Basic Settings SELECT ITEMS The SELECT ITEMS softkey sets the focus on the Items field to select the appropri- ate item to be stored. ENABLE ALL The ENABLE ALL ITEMS softkey marks all partial data sets. ITEMS Remote command: MMEM:SEL:ALL...
Page 270: 2Operating Concept Of File Managers
R&S FSP Instrument Functions Basic Settings 4.6.4.2 Operating Concept of File Managers FILE The FILE MANAGER softkey opens a menu for managing storage media and files. MANAGER The designation and the letter of the current drive are displayed in the upper left cor- ner of the File Manager dialog.
Page 271 R&S FSP Instrument Functions Basic Settings EDIT PATH The EDIT PATH softkey activates the input of the directory which will be used in sub- sequent file operations. Use CURSOR UP / DOWN to select a drive and confirm your selection with ENTER. Open subdirectories by using CURSOR RIGHT, and use CURSOR LEFT to close them again.
Page 272 R&S FSP Instrument Functions Basic Settings COPY The COPY softkey opens the help line editor to enter the target directory for a copy- ing process. The file is also copied into the clipboard and can be copied into a differ- ent directory at a later time by means of PASTE.
Page 273 R&S FSP Instrument Functions Basic Settings DELETE The DELETE softkey deletes the selected file. A confirmation query is displayed to avoid unintentional deletion of files. Remote command: MMEM:DEL "test01.hcp" MMEM:RDIR "D:\user\test" SORT MODE NAME DATE EXTENSION SIZE The SORT MODE softkey opens the submenu to select the sorting mode for the dis- played files.
Page 274: Measurement Documentation - Hcopy Key
R&S FSP Instrument Functions Basic Settings SIZE The SIZE softkey sorts the file list by size Remote command: 2 FILE LISTS The 2 FILE LISTS softkey opens a second window for the File Manager. The entry focus can be moved between the two windows by means of SCREEN A and SCREEN B hotkeys.
Page 275 R&S FSP Instrument Functions Basic Settings Pressing one of the softkeys PRINT SCREEN, PRINT TRACE or PRINT TABLE in the HCOPY menu initiates the print job. The printer parameters defined in the DEVICE SETTINGS menu are used for setting up the printer configuration. All of the display items to be printed are written to the printer buffer.
Page 276 R&S FSP Instrument Functions Basic Settings PRINT TRACE The PRINT TRACE softkey starts the output of all curves visible on the display screen without auxiliary information. Specifically, no markers or display lines are printed. Remote command: HCOP:ITEM:WIND:TRAC:STAT ON HCOP:IMM PRINT TABLE The PRINT TABLE softkey starts the output of all tables and info lists visible on the display screen without the measurement diagrams and other information lying behind.
Page 277: 1Selecting Printer Colors
R&S FSP Instrument Functions Basic Settings The COMMENT softkey opens the auxiliary line editor where the desired letters can be entered in the text field by means of rotary knob and cursor keys. After clicking the COMMENT softkey, the auxiliary line editor can be reached with d key.
Page 278 R&S FSP Instrument Functions Basic Settings The COLORS softkey gives access to the submenu where the colors for the printout can be selected. To facilitate color selection, the selected color combination is dis- played when the menu is entered. The previous colors are restored when the menu is exited.
Page 279 R&S FSP Instrument Functions Basic Settings SELECT The SELECT OBJECT softkey allows picture elements to be selected to change OBJECT their color setting. After selection, the PREDEFINED COLORS, BRIGHTNESS, TINT and SATURATION softkeys enable the user to change the colors or bright- ness, the hue and the color saturation of the element selected.
Page 280 R&S FSP Instrument Functions Basic Settings PREDEFINED The PREDEFINED COLORS softkey opens a list from which predefined colors for COLORS the displayed elements can be selected: Remote command: HCOP:CMAP1 ... 26:PDEF <color> SET TO The SET TO DEFAULT softkey reactivates the default color setting (= OPTIMIZED DEFAULT COLOR SET).
Page 281: Tv And Rf Trigger - Option R&S Fsp-B6
R&S FSP Instrument Functions TV and RF Trigger – Option R&S FSP-B6 4.7 TV and RF Trigger – Option R&S FSP-B6 The option TV and RF Trigger, R&S FSP-B6, enables the R&S FSP to trigger on TV signals or on the presence of a RF carrier outside the resolution bandwidth. For this purpose, the hardware board is equipped with a TV demodulator, which pro- duces the trigger signals necessary for the analysis of TV signals.
Page 282 R&S FSP Instrument Functions TV and RF Trigger – Option R&S FSP-B6 The configuration menu for TV trigger settings can be reached with key sequence TRIG – NEXT – TV TRIG SETTINGS. The TRIG menu is described in section “Trig- gering the Sweep –...
Page 283 R&S FSP Instrument Functions TV and RF Trigger – Option R&S FSP-B6 VIDEO POL The VIDEO POL POS / NEG softkey selects the polarity of the video signal. POS / NEG Positive video polarity is to be selected e.g. for standard L signals, negative video polarity for signals according to the standards B/G/I/M (colour standard PAL or NTSC).
Page 284: Tracking Generator - Option R&S Fsp-B9
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8 Tracking Generator – Option R&S FSP-B9 During normal operation (without a frequency offset), the tracking generator emits a signal exactly at the input frequency of the R&S FSP. For frequency-converting measurements it is possible to set a constant frequency offset of ±150 MHz between the receive frequency of the R&S FSP and the output signal of the tracking generator.
Page 285 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 MODULATION OFF POWER SWEEP POWER SWP ON/OFF START POWER STOP POWER Additional softkeys are available in the displayed menus for controlling an external generator if option External Generator Control R&S FSP-B10 is fitted. For detailed information see section “External Generator Control –...
Page 286: Transmission Measurement
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 The permissible setting range is -200 dB to +200 dB in steps of 0.1 dB. Positive off- sets apply to an amplifier and negative offsets to an attenuator subsequent to the tracking generator.
Page 287 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 information calibration reflection measurement (CAL REFL SHORT and CAL REFL OPEN) and its mechanisms, refer to section “Calibration of Reflection Measurement” on page 4.220. To carry out a calibration for transmission measurements the whole test setup is through-connected (THRU).
Page 288: 2Normalization
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8.2.2 Normalization NORMALIZE The NORMALIZE softkey switches the normalization on or off. The softkey is only available if the memory contains a correction trace. It is possible to shift the relative reference point within the grid using the REF VALUE POSITION softkey.
Page 289 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 Fig. 4.22 Normalized measurement, shifted with REF VALUE POSITION 50% Remote command: DISP:WIND:TRAC:Y:RPOS 10PCT REF VALUE The REF VALUE softkey activates the input of a value which is assigned to the ref- erence line.
Page 290 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 Fig. 4.23 Measurement with REF VALUE -10 dB and REF VALUE POSITION 50% After the reference line has been moved by entering a REF VALUE of –10 dB the deviation from the nominal power level can be displayed with high resolution (e.g. 1 dB/div).
Page 291: Reflection Measurement
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 RECALL The RECALL softkey restores the R&S FSP settings that were used during source calibration. This can be useful if device settings were changed after calibration (e.g. center fre- quency, frequency deviation, reference level, etc.). The softkey is only available if: •...
Page 292: 1Calibration Of Reflection Measurement
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8.3.1 Calibration of Reflection Measurement The calibration mechanism for reflection measurement is basically the same as the one used for transmission measurement. CAL REFL The CAL REFL SHORT softkey starts the short-circuit calibration. SHORT If both calibrations (open circuit, short circuit) are carried out, the calibration curve is calculated by averaging the two measurements and stored in the memory.
Page 293 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 Table 4-6 Measurement accuracy levels Accuracy Enhancement Reason/Limitation label High No difference between reference setting and measurement Medium Change of the following settings: (approximation) • coupling (RBW, VBW, SWT) • reference level, RF attenuation •...
Page 294: Frequency-Converting Measurements
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8.5 Frequency-Converting Measurements For frequency-converting measurements (e.g. on converter units) the tracking gen- erator is able to set a constant frequency offset between the output frequency of the tracking generator and the receive frequency of the R&S FSP. Up to an output frequency of 150 MHz the measurement can be carried out in both inverted and normal positions.
Page 295: External Modulation Of The Tracking Generator
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8.6 External Modulation of the Tracking Generator MODULATION EXT AM EXT FM EXT I/Q MODULATION OFF The MODULATION softkey opens a submenu for selecting different modulation modes. The time characteristics of the tracking generator output signal can be influenced by means of external signals (input voltage range -1 V to +1 V).
Page 296 R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 The modulation signal is applied to the TG IN Q / FM connector. Switching on an external FM disables the active I/Q modulation. Remote command: SOUR:FM:STAT ON SOUR:FM:DEV 10MHz EXT I/Q The EXT I/Q softkey activates the external I/Q modulation of the tracking generator.
Page 297: Power Offset Of The Tracking Generator
R&S FSP Instrument Functions Tracking Generator – Option R&S FSP-B9 4.8.7 Power Offset of the Tracking Generator POWER POWER SWP ON/OFF SWEEP START POWER STOP POWER The POWER SWEEP softkey opens a submenu for activates or deactivates the power sweep. POWER SWP The POWER SWP ON/OFF softkey activates or deactivates the power sweep.
Page 298: External Generator Control - Option R&S Fsp-B10
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9 External Generator Control – Option R&S FSP-B10 The external generator control option permits to operate a number of commercially available generators as tracking generator on the R&S FSP. Thus, scalar network analysis with the R&S FSP is also possible outside the frequency range of the inter- nal tracking generator when the appropriate generators are used.
Page 299: External Generator Settings
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.1 External Generator Settings NETWORK The NETWORK hotkey opens the menu for setting the functions of the external gen- erator. SOURCE POWER POWER OFFSET SOURCE CAL CAL TRANS CAL REFL SHORT CAL REFL OPEN NORMALIZE REF VALUE POSITION...
Page 300: Transmission Measurement
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.2 Transmission Measurement The transmission characteristic of a two-port network is measured. The external generator serves as a signal source. It is connected to the input connector of the DUT.
Page 301 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 CAL TRANS The CAL TRANS softkey triggers the calibration of the transmission measurement. It starts a sweep that records a reference trace. This trace is then used to obtain the differences to the normalized values.
Page 302: 2Normalization
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.2.2 Normalization NORMALIZE The NORMALIZE softkey switches normalization on or off. The softkey is only avail- able if the memory contains a correction trace. It is possible to shift the relative reference point within the grid using the REF VALUE POSITION softkey.
Page 303 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 Fig. 4.31 Normalized measurement, shifted with REF VALUE POSITION 50% Remote command: DISP:WIND:TRAC:Y:RPOS 10PCT REF VALUE The REF VALUE softkey activates the input of a level difference which is assigned to the reference line.
Page 304 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 Fig. 4.32 Measurement with REF VALUE -10dB and REF VALUE POSITION 50% After the reference line has been shifted by entering REF VALUE –10 dB, depar- tures from the nominal value can be displayed with high resolution (e.g. 1 dB / Div.). The absolute measured values are still displayed, in the above example, 1 dB below nominal value (reference line) = 11 dB attenuation.
Page 305: Reflection Measurement
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 RECALL The RECALL softkey restores the instrument setting with which the calibration was carried out. This can be useful if the device setting was changed after calibration (e.g. center fre- quency setting, frequency deviation, reference level, etc.).
Page 306: 1Calibration Of Reflection Measurement
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.3.1 Calibration of Reflection Measurement The calibration mechanism essentially corresponds to that of the transmission mea- surement. CAL REFL The CAL REFL SHORT softkey starts the short-circuit calibration. SHORT If both calibrations (open circuit, short circuit) are carried out, the calibration curve is formed by averaging the two measurements and stored in the memory.
Page 307 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 Table 4-8 Measurement accuracy levels Accuracy Enhancement Reason/Limitation label High No difference between reference setting and measurement Medium Change of the following settings: (approximation) • coupling (RBW, VBW, SWT) •...
Page 308: Frequency-Converting Measurements
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.5 Frequency-Converting Measurements For frequency-converting measurements (e.g. on converters) the external generator is able to set a constant frequency offset between the output frequency of the gener- ator and the receive frequency of the R&S FSP and, in addition, the generator fre- quency as a multiple of the R&S FSP.
Page 309: Configuration Of An External Generator
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.6 Configuration of an External Generator EXT SOURCE EXT SRC ON / OFF SELECT GENERATOR FREQUENCY SWEEP GEN REF INT / EXT The EXT SOURCE softkey opens a submenu for configuration of the external gen- erator.
Page 310 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 EXT SRC ON / The EXT SRC ON / OFF softkey switches the external generator on or off. It can only be switched on successfully if the generator has been selected by means of SELECT GENERATOR and configured correctly by means of FREQUENCY SWEEP.
Page 311 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 • TYPE The field opens the list with the available generators: After completion of the selection, the remaining fields of the table are filled with the generator characteristics. A list of generator types supported by the R&S FSP is to be found in section “List of Generator Types Supported by the R&S FSP”...
Page 312: List Of Generator Types Supported By The R&S Fsp
R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 4.9.7 List of Generator Types Supported by the R&S FSP The R&S SMA and R&S SMU require the following firmware versions: • R&S SMA: V2.10.x or higher • R&S SMU: V1.10 or higher Generator Interface Generator...
Page 313 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 Generator Interface Generator Generator Generator Generator Type Min Freq Max Freq Min Power Max Power SMR60 1 GHz 60 GHz -130 SMR60B11 10 MHz 60 GHz -130 SMP02 10 MHz 20 GHz -130 SMP03...
Page 314 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 FREQUENCY The FREQUENCY SWEEP softkey opens a table for setting the generator level as SWEEP well as the multiplier and the offset used to derive the generator frequency from the analyzer frequency.
Page 315 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 – In the time domain (Span = 0 Hz) the generator frequency is derived from the set receive frequency of the R&S FSP using the calculation formula. For the sake of clarity, the formula is also displayed in the table. The offset setting can be used to sweep in the reverse direction.
Page 316 R&S FSP Instrument Functions External Generator Control – Option R&S FSP-B10 GEN REF INT / The GEN REF INT / EXT softkey switches over the reference oscillator of the gener- ator (switch over between internal and external reference source). Selection EXT allows connecting the external generator to an external reference frequency source.
Page 317: Lan Interface - Option R&S Fsp-B16
R&S FSP Instrument Functions LAN Interface - Option R&S FSP-B16 4.10 LAN Interface - Option R&S FSP-B16 The instrument can be connected to an Ethernet LAN (local area network) using the LAN interface connector on the rear panel. This makes it possible to transfer data over the network and to use network printers.
Page 318 R&S FSP Instrument Functions LAN Interface - Option R&S FSP-B16 If the TCP/IP services are installed, a terminal connection is possible using Start - Programs - Accessories - Telnet or a data transfer via FTP by means of Start - Run ftp - OK.
Page 319: Rsib Protocol
R&S FSP Instrument Functions RSIB Protocol 4.11 RSIB Protocol The instrument is equipped with an RSIB protocol as standard, which allows the instrument to be controlled by means of Visual C++ and Visual Basic programs, but also by means of the Windows applications WinWord and Excel as well as National Instruments LabView, LabWindows/CVI and Agilent VEE.
Page 320: 2Unix Environment
R&S FSP Instrument Functions RSIB Protocol 4.11.1.2 UNIX Environment To access the measuring equipment via the RSIB interface, copy the librsib.so.X.Y file to a directory for which the control application has read rights. X.Y in the file name indicates the version number of the library, for example 1.0.
Page 321: Rsib Interface Functions
R&S FSP Instrument Functions RSIB Interface Functions 4.12 RSIB Interface Functions This section lists all functions of the DLL "RSIB.DLL" or "RSIB32.DLL" or "librsib.so", which allow control applications to be produced. 4.12.1 Overview of Interface Functions The library functions are adapted to the interface functions of National Instruments for GPIB programming.
Page 322 R&S FSP Instrument Functions RSIB Interface Functions 4.12.1.1 Variables ibsta, iberr, ibcntl As with the National Instrument interface, the successful execution of a command can be checked by means of the variables ibsta, iberr and ibcntl. For this pur- pose, all RSIB functions are assigned references to these three variables. Status word - ibsta The status word ibsta provides information on the status of the RSIB interface.
Page 323: 2Description Of Interface Functions
R&S FSP Instrument Functions RSIB Interface Functions 4.12.1.2 Description of Interface Functions RSDLLibfind() The function provides a handle for access to the device with the name udName. VB format: Function RSDLLibfind (ByVal udName$, ibsta%, iberr%, ibcntl&) As Integer C format: short WINAPI RSDLLibfind( char far *udName, short far *ibsta, short far *iberr, unsigned long far *ibcntl)
Page 324 R&S FSP Instrument Functions RSIB Interface Functions C format (UNIX): short RSDLLilwrt( short ud, char *Wrt, unsigned long Cnt, short *ibsta, short *iberr, unsigned long *ibcntl) Parameters: Device handle String sent to the GPIB parser. Number of bytes sent to the device. Example: RSDLLilwrt (ud, '..', 100, ibsta, iberr, ibcntl)
Page 325 R&S FSP Instrument Functions RSIB Interface Functions This function fetches the responses of the GPIB parser to a query. In the case of Visual Basic programming, a string of sufficient length must be gener- ated beforehand. This can be done during the definition of the string or using the command Space$().
Page 326 R&S FSP Instrument Functions RSIB Interface Functions The file name may as well include a drive or path specification. RSDLLibtmo This function defines the time-out for a device. The default value for the time-out is set to 5 seconds. VB format: Function RSDLLibtmo (ByVal ud%, ByVal tmo%, ibsta%, iberr%, ibcntl&) As Integer C format:...
Page 327 R&S FSP Instrument Functions RSIB Interface Functions After switch over to LOCAL state, the instrument can be manually operated via the front panel. On the next access to the instrument by means of one of the functions of the library, the instrument is switched again to the REMOTE state. RSDLLibeot This function enables or disables the END message after write operations.
Page 328 R&S FSP Instrument Functions RSIB Interface Functions RSDLLibonl This function switches the device to 'online' or 'offline' mode. When it is switched to ‘offline’ mode, the interface is released and the device handle becomes invalid. By calling RSDLLibfind again, the communication is set up again. VB format: Function RSDLLibonl (ByVal ud%, ByVal v%, ibsta%, iberr%, ibcntl&) As Integer...
Page 329 R&S FSP Instrument Functions RSIB Interface Functions RSDLLWaitSrq This function waits until the device triggers an SRQ with the handle ud. VB format: Function RSDLLWaitSrq (ByVal ud%, Result%, ibsta%, iberr%, ibcntl&) As Integer C format: void WINAPI RSDLLWaitSrq( short ud, short far *result, short far *ibsta, short far *iberr, unsigned long far *ibcntl) C format (UNIX):...
Page 330: Programming Via The Rsib Protocol
R&S FSP Instrument Functions RSIB Interface Functions Different types of processor architecture store data in different byte sequences. For example, Intel processors store data in the reverse order of Motorola processors. Comparison of byte sequences: Byte sequence Use in Display in memory Description Big Endian Motorola processors,...
Page 331 R&S FSP Instrument Functions RSIB Interface Functions 2004 Length of data, e.g. Prefix for Number of digits of 501 pixels binary data the following length 4 bytes/pixel indication In order to enable the trace data to be directly read into a float array, a special func- tion declaration must be created.
Page 332 R&S FSP Instrument Functions RSIB Interface Functions 'and store ' Read out trace data Call RSDLLilrdTraceReal(ud, TraceData(0), TraceBytes, ibsta, iberr,ibcntl) Programming examples In this example, the start frequency of the instrument is queried. Dim ibsta As Integer ' Status variable Dim iberr As Integer ' Error variable Dim ibcntl As Long...
Page 333 R&S FSP Instrument Functions RSIB Interface Functions ' Set up connection to measuring instrument ud = RSDLLibfind("89.10.38.97", ibsta, iberr, ibcntl) If (ud < 0) Then ' Error treatment End If ' Request instrument settings Cmd = "SYST:SET?" Call RSDLLibwrt(ud, Cmd, ibsta, iberr, ibcntl) ' Store instrument response in file Call RSDLLibrdf(ud, "C:\db.sav", ibsta, iberr, ibcntl) ' Reset instrument...
Page 334 R&S FSP Instrument Functions RSIB Interface Functions ' Set up connection to measuring instrument ud = RSDLLibfind("89.10.38.97", ibsta, iberr, ibcntl) If (ud < 0) Then Call MsgBox("Device with address 89.10.38.97 could" & _ "not be found", vbExclamation) End If ' Determine maximum peak in the range 1-2MHZ Call RSDLLibwrt(ud, "*RST", ibsta, iberr, ibcntl) Call RSDLLibwrt(ud, "INIT:CONT OFF", ibsta, iberr, ibcntl) Call RSDLLibwrt(ud, "FREQ:START 1MHZ", ibsta, iberr, ibcntl)
Page 335 R&S FSP Instrument Functions RSIB Interface Functions When import libraries are used, the DLL is automatically loaded immediately before the application is started. At the end of the program, the DLL is unloaded again unless it is still used by other applications. Access to librsib.so functions (UNIX platforms) The functions of librsib.so are declared in the header file RSIB.H.
Page 336 R&S FSP Instrument Functions RSIB Interface Functions // Activate SRQ generation via event status register (ESR) // and enable ESB bit in SRE register RSDLLibwrt( ud, "*ESE 1;*SRE 32", &ibsta, &iberr, &ibcntl ); // Set single sweep, trigger sweep and use "*OPC" to cause // the generation of a service request at the end of the sweep RSDLLibwrt( ud, "INIT:CONT off;INIT;*OPC", &ibsta, &iberr, &ibcntl );...
Page 337: Lo/If Ports For External Mixers - Option R&S Fsp-B21
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 4.13 LO/IF ports for external mixers - Option R&S FSP- 4.13.1 Connecting an External Mixer To increase the frequency range, the FSP 40 can be operated with external mixers. Both two-port and three-port mixers can be used.
Page 338: Manual Operation
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Two-port mixer: S P E C T R U M A N A L Y Z E R 9 k H z . .. 3 G H z F S P 1 0 9 3 .4 4 9 5 .
Page 339 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Frequency range The frequency of the input signal can be expressed as a function of the LO fre- quency and the selected harmonic of the 1st LO as follows: = n * f where: frequency of input signal...
Page 340 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 The table contains the following parameters for each band: BAND - Designation of waveguide band Remote command: MIX:HARM:BAND E RANGE - Frequency range The frequency range of the waveguide band or the frequency range which is cov- ered by the selected harmonic is shown in this field.
Page 341 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Within the band USER this field is not editable. Remote command: MIX:HARM:TYPE EODD PORTS - Type of mixer Defines if a two- or three-port mixer is used. PORTS Remote command: MIX:PORT 3...
Page 342 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 SELECT <NONE> Band_A_4 Mixer_4 After selection of a file the parameters BIAS for the SELECT BAND table are taken from that file. The selected mixer type must correspond to the file entry PORTS. It is not possible to modify these parameters during operation.
Page 343: Conversion Loss Tables
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 The current is defined in the SELECT BAND table or set to the value of the Conver- sion Loss table. Fig. 4.36 Bias circuit of the R&S FSP The voltage U at the output of the operational amplifier can be set in the range –2.0 to +2.0 V An open-circuit voltage V...
Page 344 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 PREVIEW Name: RS_Band_U_4 Mixer: FS_Z60 Band: S/N: 12345678 Harmonic#: Ports: Bias: 0.00 mA Comment: Freq. range: 40.000 GHz to 60.000 GHz TABLES Band_A_2 Band_A_4 Band_Q_4 RS_Band_U_4 Band_W_8 Press ENTER to edit table The PREVIEW window shows the information characterizing the marked file: Name...
Page 345 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 TABLES ON DISK Band_A_2 Band_A_4 Band_Q_4 RS_Band_U_4 Band_W_8 Press ENTER to load table Remote command: This function is needed, for example, for the initial loading of correction data of a new mixer to the hard disk of the R&S FSP.
Page 346 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 DELETE TABLE The DELETE TABLE softkey deletes the selected file from the hard disk of the R&S FSP. If the key is pressed, a window opens in which the user is prompted to confirm or abort deleting.
Page 347 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Data and type designation of the mixer can be entered into the header of the table.The columns contain the frequencies and the corresponding conversion losses. Name - File name The name of the table is identical with the name of the file (without extension) in which the table is stored.
Page 348 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Remote command: CORR:CVL:BIAS 7mA See section “Bias Current” on page 4.270. Comment The comment can be freely defined by the user. It may consist of a maximum of 60 characters.
Page 349: Signal Identification
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 PAGE UP / The PAGE UP / PAGE DOWN softkeys allow to scroll through the selection list. PAGE DOWN Remote command: With the PREV hardkey, an edited table can be accepted, checked for consistency with permissible values and stored on the hard disk under the specified table name.
Page 350: 1Remarks Concerning Signal Identification With Auto Id
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 The reference sweep is performed using a LO setting shifted downwards by 2*IF/ Harmonic#. Input signals in the wanted sideband that are converted by means of the set harmonic are displayed in both traces at the same position on the frequency axis.
Page 351 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Tolerance for the comparison of test sweep and reference Since the LO frequency is displaced downwards in the reference sweep, the conver- sion loss of the mixer may differ from that of the test sweep. The reasons for this are the LO output power of the R&S FSP varying with the frequency and the non-ideal characteristics of the mixer.
Page 352 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 sured at a frequency too. As a result, the criterion for detecting unwanted signals is not fulfilled. To blank out unwanted signals permanently an almost constant noise indication is therefore required.
Page 353 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 If unwanted mixer products represented at frequencies which slightly differ from each other occur in the test sweep and reference sweep, the two mixer products from the test sweep and the reference sweep are displayed by the same sweep point.
Page 354 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 Display of mixer products at the same frequency If the input signal consists of a very large number of spectral components, it will become more and more probable that two different unwanted mixer products will be displayed at the same frequency in the test sweep and reference sweep.
Page 355: Introductory Example Of Operation
R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 R B W 3 0 k H z V B W 1 0 0 k H z R e f - 3 0 d B m S W T 2 0 m s - 3 0 - 4 0 1 S A...
Page 356 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 The example of operation is described in the following steps: Test setup Activating the external mixing and selecting the mode Default setting Level correction Frequency-dependent level correction Level correction with average value Taking into account the cable loss in the IF path Functions for signal identification...
Page 357 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 4. Level correction The conversion loss of the mixer can be taken into account both as a function of frequency and with an average value. The frequency-dependent level correction is used in this example for obtaining a higher precision.
Page 358 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 R B W 3 M H z M a r k e r 1 [ T 1 ] V B W 1 M H z - 3 6 . 0 7 d B m R e f - 2 0 d B m S W T 5 0 m s 5 8 .
Page 359 R&S FSP Instrument Functions LO/IF ports for external mixers - Option R&S FSP-B21 For frequency-dependent level correction, increase every reference value by the insertion loss to the same extent. For this the cable loss can be entered via a transducer table. Such a table should only contain two reference values (band start and end) for which a is specified.
Page 360: Trigger Port - Option R&S Fsp-B28
R&S FSP Instrument Functions Trigger Port – Option R&S FSP-B28 4.14 Trigger Port – Option R&S FSP-B28 An essential performance criterion to be met by automatic test systems is to mini- mize the time overhead of the entire test relative to the net measurement time. A typical test comprises the following steps: 1.
Page 361 R&S FSP Instrument Functions Trigger Port – Option R&S FSP-B28 Analyzer Setup Analyzer Settling Time DUT Output Signal Data Acquisition Analyzer not ready for trigger valid Trigger Start Signal Measurement Fig. 4.44 Test with single trigger pulse A particularly difficult aspect of this problem is the variable settling times, which are unavoidable in practice.
Page 362 R&S FSP Instrument Functions Trigger Port – Option R&S FSP-B28 4.290 Operating Manual 1164.4556.12 - 06...
Page 363 R&S FSP Remote Control – Basics 5 Remote Control – Basics 5.1 Overview ........... . 5.3 5.2 Introduction .
Page 364 R&S FSP Remote Control – Basics 5.7.3 Description of the Status Registers ......5.22 5.7.3.1Status Byte (STB) and Service Request Enable Register (SRE) .
Page 365: Overview
R&S FSP Remote Control – Basics Overview 5.1 Overview This chapter contains the following: • instructions on how to put the R&S FSP into operation via remote control, • a general introduction to remote control of programmable instruments. This includes the description of the command structure and syntax according to the SCPI standard, the description of command execution and of the status registers, •...
Page 366: Getting Started
R&S FSP Remote Control – Basics Getting Started 5.3 Getting Started The short and simple operating sequence provided below enables you to quickly put the instrument into operation and set its basic functions. As a prerequisite, the GPIB address, which is factory-set to 20, must remain unchanged. 1.
Page 367: Remote Control Via Gpib
R&S FSP Remote Control – Basics Starting Remote Control During program execution it is recommended to activate the display of results by means of "SYSTem:DISPlay:UPDate ON" so that it is possible to follow the changes in the device settings and the recorded measurement curves on the screen.
Page 368: Remote Control Via Rs-232-Interface
R&S FSP Remote Control – Basics Starting Remote Control • Before the transition, command processing must be completed as otherwise transition to GPIB is performed immediately. • The keys can be disabled by the universal command LLO (see chapter “Maintenance and Instrument Interfaces”, section “Interface Messages”...
Page 369: 3Restrictions
R&S FSP Remote Control – Basics Starting Remote Control • Before the transition, command processing must be completed as otherwise transition to remote control is performed immediately • The keys can be enabled again by sending the control string "@LOC" via RS- 232 (see chapter “Maintenance and Instrument Interfaces”, section...
Page 370: 2Return To Manual Operation
R&S FSP Remote Control – Basics Messages 5.4.4.2 Return to Manual Operation Return to manual operation can be made manually via the front panel or remotely via the RSIB interface. Manually: Press LOCAL softkey or PRESET key. Make sure that the execution of commands is completed prior to switch over since otherwise the instrument will switch back to remote control immediately.
Page 371: Structure And Syntax Of The Device Messages
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages • According to the effect they have on the instrument: Setting commands cause instrument settings such as reset of the instrument or setting the center frequency. Queries cause data to be provided for output on the GPIB, e.g. for identification of the device or polling the marker.
Page 372 R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages The commands used in the following examples are not in every case implemented in the instrument. Common commands Common commands consist of a header preceded by an asterisk "*" and one or several parameters, if any.
Page 373 R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages Some key words occur in several levels within one command system. Their effect depends on the structure of the command, that is to say, at which position in the header of a command they are inserted.
Page 374: Structure Of A Command Line
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages SENSe:FREQuency:STOP? MAXimum This query requests the maximal value for the stop frequency. Response: 3.5E9 Numeric suffix If a device features several functions or features of the same kind, e.g. inputs, the desired function can be selected by a suffix added to the command.
Page 375: Responses To Queries
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages 5.6.4 Responses to Queries A query is defined for each setting command unless explicitly specified otherwise. It is formed by adding a question mark to the associated setting command. According to SCPI, the responses to queries are partly subject to stricter rules than in standard IEEE 488.2.
Page 376 R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages Special numerical The texts MINimum, MAXimum, DEFault, UP and DOWN are interpreted as values special numerical values. In the case of a query, the numerical value is provided. Example: Setting command: SENSe:FREQuency:STOP MAXimum Query: SENSe:FREQuency:STOP?
Page 377: Overview Of Syntax Elements
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages Strings Strings must always be entered in quotation marks (' or "). Example: SYSTem:LANGuage "SCPI" SYSTem:LANGuage 'SCPI' Block data Block data is a transmission format which is suitable for the transmission of large amounts of data.
Page 378: Instrument Model And Command Processing
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages 5.6.7 Instrument Model and Command Processing The instrument model shown in Fig. 5.2 has been made viewed from the standpoint of the servicing of remote commands. The individual components work indepen- dently of each other and simultaneously.
Page 379: Instrument Data Base And Instrument Hardware
R&S FSP Remote Control – Basics Structure and Syntax of the Device Messages If the command recognition recognizes a delimiter (<PROGRAM MESSAGE SEPA- RATOR> or <PROGRAM MESSAGE TERMINATOR>) or a DCL, it requests the instrument data base to set the commands in the instrument hardware as well now. Subsequently it is immediately prepared to process commands again.
Page 380: Status Reporting System
R&S FSP Remote Control – Basics Status Reporting System Command Action after the hardware has settled Programming the controller *OPC Setting the operation-complete bit in the ESR - Setting bit 0 in the ESE - Setting bit 5 in the SRE - Waiting for service request (SRQ) *OPC? Writing a "1"...
Page 381: Structure Of An Scpi Status Register
R&S FSP Remote Control – Basics Status Reporting System 5.7.1 Structure of an SCPI Status Register Each SCPI register consists of 5 parts which each have a width of 16 bits and have different functions (cf. Fig. 5.3). The individual bits are independent of each other, i.e.
Page 382 R&S FSP Remote Control – Basics Status Reporting System With these two edge register parts the user can define which state transition of the condition part (none, 0 to 1, 1 to 0 or both) is stored in the EVENt part. EVENt part The EVENt part indicates whether an event has occurred since the last reading, it is the "memory"...
Page 383: Overview Of The Status Registers
R&S FSP Remote Control – Basics Status Reporting System 5.7.2 Overview of the Status Registers The following figure shows the status registers used by the R&S FSP base unit. The status registers used by the R&S FSP options are described in the separate soft- ware manuals.
Page 384: Description Of The Status Registers
R&S FSP Remote Control – Basics Status Reporting System 5.7.3 Description of the Status Registers 5.7.3.1 Status Byte (STB) and Service Request Enable Register (SRE) The STB is already defined in IEEE 488.2. It provides a rough overview of the instru- ment status by collecting the pieces of information of the lower registers.
Page 385 R&S FSP Remote Control – Basics Status Reporting System 5.7.3.2 IST Flag and Parallel Poll Enable Register (PPE) By analogy with the SRQ, the IST flag combines the entire status information in a single bit. It can be queried by means of a parallel poll (cf. section “Parallel Poll”...
Page 386: Register (Ese)
R&S FSP Remote Control – Basics Status Reporting System 5.7.3.4 STATus:OPERation Register In the CONDition part, this register contains information on which actions the instrument is being executing or, in the EVENt part, information on which actions the instrument has executed since the last reading. It can be read using commands "STATus:OPERation:CONDition?"...
Page 387: 6Status:questionable:acplimit Register
R&S FSP Remote Control – Basics Status Reporting System Meaning LMARgin This bit is set if a margin is violated (see also section “STATus:QUEStionable:LMARgin<1|2> Register” on page 5.28) This bit is not used ACPLimit This bit is set if a limit for the adjacent channel power measurement is violated (see also section “STATus:QUEStionable:ACPLimit Register”...
Page 388: 7Status:questionable:frequency Register
R&S FSP Remote Control – Basics Status Reporting System Meaning ALT2 UPPer FAIL (Screen B) This bit is set if in screen B the limit is exceeded in the upper 2nd alternate channel. ALT2 LOWer FAIL (Screen B) This bit is set if in screen B the limit is exceeded in the lower 2nd alternate channel. This bit is not used.
Page 389: 8Status:questionable:limit<1|2> Register
R&S FSP Remote Control – Basics Status Reporting System 5.7.3.8 STATus:QUEStionable:LIMit<1|2> Register This register comprises information about the observance of limit lines in the corre- sponding measurement window (LIMit 1 corresponds to Screen A, LIMit 2 to Screen B). It can be queried with commands STATus:QUEStionable:LIMit<1|2>: CONDition? and STATus:QUEStionable:LIMit<1|2>[:EVENt]?.
Page 390: 9Status:questionable:lmargin<1|2> Register
R&S FSP Remote Control – Basics Status Reporting System 5.7.3.9 STATus:QUEStionable:LMARgin<1|2> Register This register comprises information about the observance of limit margins in the cor- responding measurement window (LMARgin1 corresponds to Screen A, LMARgin2 corresponds to Screen B). It can be queried with commands STATus:QUEStion- "STATus:QUEStionable:LMAR- able:LMARgin<1|2>:CONDition? gin<1|2>[:EVENt]?.
Page 391 R&S FSP Remote Control – Basics Status Reporting System 5.7.3.10 STATus:QUEStionable:POWer Register This register comprises all information about possible overloads of the unit. It can be queried with commands STATus:QUEStionable:POWer:CONDition? and STATus:QUEStionable:POWer[:EVENt]?. Meaning OVERload (Screen A) This bit is set if the RF input is overloaded. 'OVLD' will then be displayed. UNDerload (Screen A) This bit is set if the RF input is underloaded.
Page 392: Application Of The Status Reporting Systems
R&S FSP Remote Control – Basics Status Reporting System 5.7.4 Application of the Status Reporting Systems In order to be able to effectively use the status reporting system, the information contained there must be transmitted to the controller and further processed there. There are several methods which are represented in the following.
Page 393: 4Query By Means Of Commands
R&S FSP Remote Control – Basics Status Reporting System The instrument first has to be set for the parallel poll using quick-BASIC command "IBPPC()". This command allocates a data line to the instrument and determines whether the response is to be inverted. The parallel poll itself is executed using "IBRPP()".
Page 394: Resetting Values Of The Status Reporting System
R&S FSP Remote Control – Basics Status Reporting System 5.7.5 Resetting Values of the Status Reporting System The table below comprises the different commands and events causing the status reporting system to be reset. None of the commands, except for *RST and SYSTem: PRESet influences the functional instrument settings.
Page 395 R&S FSP Remote Control – Description of Commands 6 Remote Control – Description of Commands 6.1 Introduction ..........6.4 6.2 Notation .
Page 396 R&S FSP Remote Control – Description of Commands 6.13 INSTrument Subsystem ........6.127 6.14 MMEMory Subsystem .
Page 397 R&S FSP Remote Control – Description of Commands 6.23.4 856x: Emulation of the Spurious Response Measurement Utility 85672A ........... . . 6.272 6.23.4.1General commands for Spurious .
Page 398 R&S FSP Remote Control – Description of Commands Introduction 6.1 Introduction This chapter describes all remote control commands of the R&S FSP in detail. For details on the notation of the remote control commands refer to “Notation” on page 6.5. Before sending a command sequence consisting of commands described in chapter 6, please make sure that the analyzer mode is active, by one of the following actions: •...
Page 399 R&S FSP Remote Control – Description of Commands Notation 6.2 Notation In the following sections, all commands implemented in the instrument are first listed in tables and then described in detail, arranged according to the command subsystems. The notation is adapted to the SCPI standard.
Page 400 R&S FSP Remote Control – Description of Commands Notation Upper/lower case Upper/lower case letters are used to mark the long or short form of the key words notation of a command in the description (see chapter “Remote Control – Basics”). The instrument itself does not distinguish between upper and lower case letters.
Page 401 R&S FSP Remote Control – Description of Commands Notation <numeric_value> These key words mark parameters which may be entered as numeric values or be <num> set using specific key words (character data). The following key words given below are permitted: –...
Page 402 R&S FSP Remote Control – Description of Commands Common Commands 6.3 Common Commands The common commands are taken from the IEEE 488.2 (IEC 625-2) standard. A particular command has the same effect on different devices. The headers of these commands consist of an asterisk "*" fol- lowed by three letters.
Page 403 R&S FSP Remote Control – Description of Commands Common Commands *IDN? IDENTIFICATION QUERY queries the instrument identification. Example: "Rohde&Schwarz, FSP-3, 123456/789, 4.31" FSP-3 = Device name 123456/789 = Serial number of the instrument 4.31 = Firmware version number *IST? INDIVIDUAL STATUS QUERY returns the contents of the IST flag in decimal form (0 | 1). The IST flag is the status bit which is sent during a parallel poll (cf.
Page 404 R&S FSP Remote Control – Description of Commands Common Commands Position Option R&S FS-K76 TD SCDMA BTS reserved R&S FS-K30 Noise Figure and Gain Measurments R&S FS-K40 Phase Noise Tests R&S FS-K5 GSM-GSM/EDGE R&S FS-K77 TD SCDMA UE R&S FS-K7 FM Demodulator R&S FS-K8 Application Firmware Bluetooth®...
Page 405 R&S FSP Remote Control – Description of Commands Common Commands The query form *PSC? reads out the contents of the power-on-status-clear flag. The response can be 0 or 1. *RST RESET sets the instrument to a defined default status. The command essentially corresponds to pressing the PRESET key.
Page 406 R&S FSP Remote Control – Description of Commands ABORt Subsystem 6.4 ABORt Subsystem The ABORt subsystem contains the commands for aborting triggered actions. An action can be triggered again immediately after being aborted. All commands trigger events, and therefore they have no *RST value.
Page 407 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5 CALCulate Subsystem The CALCulate subsystem contains commands for converting instrument data, transforming and carry- ing out corrections. These functions are carried out subsequent to data acquisition, i.e. following the SENSe subsystem.
Page 408 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.1 CALCulate:DELTamarker Subsystem The CALCulate:DELTamarker subsystem controls the delta-marker functions in the instrument. The measurement windows are selected via CALCulate1 (screen A) or 2 (screen B). CALCulate<1|2>:DELTamarker<1...4>:AOFF This command switches off all active delta markers. The measurement windows are selected via CALCulate1 (screen A) or 2 (screen B).
Page 409 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:FUNCtion:FIXed:RPOint:Y <numeric_value> This command defines a new reference point level for all delta markers in the selected measurement window for a measurement with fixed reference point. (CALCulate:DELTamarker:FUNCtion: FIXed:STATe ON). For phase noise measurements (CALCulate:DELTamarker:FUNCtion:PNOise:STATe ON), the command defines a new reference point level for delta marker 2 in the selected measurement window.
Page 410 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:FUNCtion:PNOise:AUTO ON | OFF This command adds an automatic peak search action for the reference fixed marker 1 at the end of each particular sweep. This function may be used for tracking of a drifting source whilst phase noise measurement.
Page 411 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:LINK ON | OFF This command switches on and off a link of delta marker 1 to marker 1. If the link is switched on and the x-axis value of the marker 1 is changed, the delta marker 1 will follow on the same x-position. The suffix at DELTamarker can only be 1 or not present, because the functionality is only available for marker 1 and delta marker 1.
Page 412 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:MAXimum:RIGHt This command positions the specified delta marker to the next smaller maximum value to the right of the current value (i.e. ascending X values). The corresponding delta marker is activated first, if necessary.
Page 413 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:MINimum:RIGHt This command positions the specified delta marker to the next higher minimum value to the right of the current value (i.e. ascending X values). The corresponding delta marker will be activated first, if necessary.
Page 414 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:TRACe 1 to 3 This command assigns the selected delta marker to the indicated measurement curve. The selected measurement curve must be active, i.e. its state must be different from "BLANK". The measurement windows are selected via CALCulate1 (screen A) or 2 (screen B).
Page 415 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:DELTamarker<1...4>:Y? This command queries the measured value of the selected delta marker in the indicated measurement window. The corresponding delta marker will be activated, if necessary. The output is always a relative value referred to marker 1 or to the reference position (reference fixed active).
Page 416 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.2 CALCulate:DLINe Subsystem The CALCulate:DLINe subsystem controls the settings for the display lines. The measurement windows are selected by CALCulate 1 (screen A) or 2 (screen B). CALCulate<1|2>:DLINe<1|2> MINimum .. MAXimum (depending on current unit) This command defines the position of Display Line 1 or 2.
Page 417 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.3 CALCulate:ESPectrum Subsystem The following chapter describes remote control commands that configure the list evaluation for the Spec- trum Emission Mask measurement. CALCulate<1|2>:ESPectrum:PSEarch | PEAKsearch:AUTO ON | OFF This command activates or deactivates the list evaluation of the Spectrum Emission Mask measurement.
Page 418 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.4 CALCulate:FLINe Subsystem The CALCulate:FLINe subsystem controls the settings for the frequency limit lines. The measurement windows are selected by CALCulate 1 (screen A) or 2 (screen B). CALCulate<1|2>:FLINe<1|2> 0 to f This command defines the position of the frequency lines.
Page 419 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.5 CALCulate:LIMit Subsystem The CALCulate:LIMit subsystem consists of the limit lines and the corresponding limit checks. Limit lines can be defined as upper or lower limit lines. The individual Y values of the limit lines correspond to the values of the x-axis (CONTrol).
Page 420 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Switching on and evaluating the line in screen A (example for analyzer mode): 1. Switching on the line in screen A: CALC1:LIM5:UPP:STAT ON 2. Switching on the limit check in screen A: CALC1:LIM5:STAT ON 3.
Page 421 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:CLEar[:IMMediate] This command deletes the result of the current limit check for all limit lines. Up to 8 limit lines can be defined at the same time. The numeric suffixes <1|2> of CALCulate indicate the measurement window.
Page 422 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:DELete This command deletes the selected limit line. Up to 8 limit lines can be defined at the same time. The command is independent of the measurement window. Example: "CALC:LIM1:DEL" 'Deletes limit line 1.
Page 423 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:STATe ON | OFF This command switches on or off the limit check for the selected limit line. The result of the limit check can be queried with CALCulate<1|2>:LIMit<1...8>:CLEar[:IMMediate]. Up to 8 limit lines can be defined at the same time. The numeric suffixes <1|2> of CALCulate indicate the measurement window.
Page 424 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.5.2 CALCulate:LIMit:ACPower Subsystem The CALCulate:LIMit:ACPower subsystem defines the limit check for adjacent channel power measure- ment. CALCulate<1|2>:LIMit<1...8>:ACPower:ACHannel:ABSolute -200DBM to 200DBM, -200 to 200DBM This command defines the absolute limit value for the lower/upper adjacent channel during adjacent channel power measurement (Adjacent Channel Power) in the selected measurement window.
Page 425 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "CALC:LIM:ACP:ACH 30DB, 30DB" 'Sets the relative limit value in screen A for the power in the lower and upper adjacent channel to 30 dB below the channel power. "CALC:LIM:ACP:ACH:ABS -35DBM, -35DBM" 'Sets the absolute limit value in screen A for the power in the lower and upper adjacent channel to -35 dBm.
Page 426 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:ACPower:ACHannel[:RELative]:STATe ON | OFF This command activates the limit check for the relative limit value of the adjacent channel when adjacent channel power measurement is performed. Before the command, the limit check must be activated using CALCulate:LIMit:ACPower:STATe ON.
Page 427 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "CALC:LIM:ACP:ACH 30DB, 30DB" 'Sets the relative limit value in screen A for the power in the lower and upper adjacent channel to 30 dB below the channel power. "CALC:LIM:ACP:ACH:ABS -35DBM, -35DBM" 'Sets the absolute limit value in screen A for the power in the lower and upper adjacent channel to -35 dB.
Page 428 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:ACPower:ALTernate<1...11>:ABSolute:STATe ON | OFF This command activates the limit check for the alternate adjacent channels in the selected measurement window for adjacent channel power measurement (Adjacent Channel Power). Before the command, the limit check must be globally switched on for the channel/adjacent channel power with the command CALCulate:LIMit:ACPower:STATe ON.
Page 429 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Parameter: The first value is the limit for the lower and the upper alternate adjacent channel. The second limit value is ignored but must be indicated for reasons of compatibility with the FSE family.
Page 430 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:ACPower:ALTernate<1...11>:RESult? This command queries the result of the limit check for the alternate adjacent channels in the selected measurement window for adjacent channel power measurements. The numeric suffix after ALTernate<1...11> denotes the alternate channel. The numeric suffixes <1...8>...
Page 431 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.5.3 CALCulate:LIMit:CONTrol Subsystem The CALCulate:LIMit:CONTrol subsystem defines the x-axis (CONTrol-axis). CALCulate<1|2>:LIMit<1...8>:CONTrol[:DATA] <numeric_value>,<numeric_value>. This command defines the x-axis values (frequencies or times) of the upper or lower limit lines. The values are defined independently of the measurement window. The number of values for the CONTrol axis and for the corresponding UPPer and/or LOWer limit lines have to be identical.
Page 432 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Characteristics: *RST value: 0 SCPI: device-specific Mode: CALCulate<1|2>:LIMit<1...8>:CONTrol:SHIFt <numeric_value> This command moves a limit line by the indicated value in x direction. In contrast to CALC:LIM:CONT: OFFS, the line is shifted by modifying the individual x values and not by means of an additive offset. The shift is independent of the measurement window.
Page 433 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.5.4 CALCulate:LIMit:LOWer Subsystem The CALCulate:LIMit:LOWer subsystem defines the lower limit line. CALCulate<1|2>:LIMit<1...8>:LOWer[:DATA] <numeric_value>,<numeric_value>... This command defines the values for the selected lower limit line. Up to 8 limit lines can be defined at the same time. This command is independent of the measurement window.
Page 434 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:LOWer:OFFSet <numeric_value> This command defines an offset for the y-axis of the selected relative lower limit line. In contrast to CALC:LIM:LOW:SHIFt, the line is not shifted by modifying the individual Y values but by means of an additive offset.
Page 435 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:LOWer:THReshold <numeric_value> This command defines an absolute threshold value for limit lines with relative y-axis scaling independently of the measurement window. The absolute threshold value is used in the limit check as soon as it exceeds the relative limit value.
Page 436 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.5.5 CALCulate:LIMit:UPPer Subsystem The CALCulate:LIMit:UPPer subsystem defines the upper limit line. CALCulate<1|2>:LIMit<1...8>:UPPer[:DATA] <numeric_value>,<numeric_value>... This command defines the values for the upper limit lines. Up to 8 limit lines can be defined at the same time. This command is independent of the measurement window.
Page 437 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:UPPer:OFFSet <numeric_value> This command defines an offset for the y-axis of the selected relative upper limit line. In contrast to CALC:LIM:UPP:SHIFt, the line is not shifted by modifying the individual Y values but by means of an additive offset.
Page 438 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:LIMit<1...8>:UPPer:THReshold <numeric_value> This command defines an absolute threshold value for limit lines with relative y-axis scaling independently of the measurement window. The absolute threshold value is used in the limit check as soon as it exceeds the relative limit value.
Page 439 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6 CALCulate:MARKer Subsystem The CALCulate:MARKer subsystem checks the marker functions in the instrument. The measurement windows are selected via CALCulate1 (screen A) or 2 (screen B). The subsystem is divided into the description of the general marker commands (“General CALCulate: MARKer:...
Page 440 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:COUNt:FREQuency? This command queries the result of the frequency counter for marker 1 in the selected measurement window. Before the command, the frequency counter should be switched on and a complete measurement performed to obtain a valid count result.
Page 441 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:MAXimum:AUTO ON | OFF This command switches an automatic maximum peak search for marker 1 at the end of each particular sweep on and off. The current marker search limit settings (LEFT LIMIT, RIGHT LIMIT, THRESHOLD, EXCLUDE LO) are taken into account.
Page 442 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:MAXimum[:PEAK] This command positions the specified marker to the current maximum value of the corresponding trace. The corresponding marker is activated first or switched to the marker mode. If no maximum value is found on the trace (level spacing to adjacent values < peak excursion), an execution error (error code: -200) is produced.
Page 443 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:MINimum:LEFT This command positions the specified marker to the next higher minimum value to the left of the current value (i.e. in descending X direction) on the corresponding trace. If no next higher minimum value is found on the trace (level spacing to adjacent values <...
Page 444 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:MINimum:RIGHt This command positions the specified marker to the next higher minimum value to the right of the current value (i.e. in ascending X direction) on the corresponding trace. If no next higher minimum value is found on the trace (level spacing to adjacent values <...
Page 445 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "CALC:MARK3:TRAC 2" 'Assigns marker 3 in screen A to trace 2. "CALC2:MARK:TRAC 3" 'Assigns marker 1 in screen B to trace 3. Characteristics: *RST value: - SCPI: device-specific Mode: CALCulate<1|2>:MARKer<1...4>:X 0 to MAX (frequency | sweep time) This command positions the selected marker to the indicated : •...
Page 446 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:X:SLIMits:RIGHt 0 to MAX (frequency | sweep time) This command sets the right limit of the search range for markers and delta markers in the selected measurement window. Depending on the x-axis domain the indicated value defines a frequency (span >...
Page 447 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:Y? This command queries the measured value of the selected marker in the indicated measurement window. The corresponding marker is activated before or switched to marker mode, if necessary. To obtain a valid query result, a complete sweep with synchronization to the sweep end must be performed between the activation of the marker and the query of the y value.
Page 448 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6.2 CALCulate:MARKer:FUNCtion Subsystem The measurement window is selected by CALCulate 1 (screen A) or 2 (screen B). CALCulate<1|2>:MARKer<1...4>:FUNCtion:CENTer This command sets the center frequency of the selected measurement window equal to the frequency of the indicated marker.
Page 449 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:HOLDoff 10ms to 1000s This command defines the hold time at the marker position for the demodulation in the frequency domain (span > 0). The setting is independent of the measurement window and the selected marker, i.e.
Page 450 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation[:STATe] ON | OFF This command switches on or off the audio demodulator when the indicated marker is reached in the selected measurement window. In the frequency domain (span > 0) the hold time can be defined at the corresponding marker position with CALCulate:MARKer:FUNCtion: DEModulation:HOLD.
Page 451 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "INIT:CONT OFF" 'switches to single-sweep mode "INIT;*WAI" 'starts measurement and synchronizes to end "CALC:MARK:TRAC 1" 'sets marker 1 in screen A to trace 1 "CALC:MARK:FUNC:FPE:SORT X" 'sets the sort mode to increasing X values "CALC:MARK:FUNC:FPE 3"...
Page 452 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Return value: "107.5E6,153.8E6,187.9E6" 'frequencies in increasing order "2.05E-3,2.37E-3, 3.71e-3" 'times in increasing order Characteristics: *RST value: -- SCPI: device-specific Mode: CALCulate<1|2>:MARKer<1...4>:FUNCtion:FPEaks:Y? This query reads out the list of X values of the maxima found. The number of available values can be queried with CALC:MARK:FUNC:FPEaks:COUNt?.
Page 453 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Characteristics: *RST value: - SCPI: device-specific Mode: This command is only a query and therefore has no *RST value. CALCulate<1|2>:MARKer<1...4>:FUNCtion:MDEPth[:STATe] This command switches on the measurement of the AM modulation depth. An AM-modulated carrier is required on the screen for correct operation.
Page 454 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Measurement Measurement Measurement Time Time Time Period Period Time offset of first pulse Trace start TRACE 1 of the selected screen is always used by the function. The suffix of MARKer will be ignored. Example: "DISP:WIND:TRAC:Y:RLEV –10dBm"...
Page 455 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:NDBDown <numeric_value> This command defines the level spacing of the two delta markers to the right and left of marker 1 in the selected measurement window. Marker 1 is always used as the reference marker. The numeric suffix <1...4>...
Page 456 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "INIT:CONT OFF" 'Switches to single-sweep mode. "CALC:MARK:FUNC:NDBD ON" 'Switches on the n-dB-down function in screen A. "INIT;*WAI" 'Starts a sweep and waits for the end. "CALC:MARK:FUNC:NDBD:RES?" 'Outputs the measured value of screen A. Characteristics: *RST value: - SCPI: device-specific Mode:...
Page 457 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:NOISe:RESult? This command queries the result of the noise measurement. A complete sweep with synchronization to the sweep end must be performed between switching on the function and querying the measured value in order to obtain a valid query result. This is only possible in single-sweep mode.
Page 458 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:TOI:MARKer CALCulate | SEARch This command controls the positioning of the intercept markers 3 and 4 for TOI measurement, based on the two carrier signals. • CALCulate: Calculates the intermodulation product frequencies. •...
Page 459 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "CALC:MARK:FUNC:TOI ON" 'Switches on the measurement of the third-order intercept in screen A. Characteristics: *RST value: OFF SCPI: device-specific Mode: CALCulate<1|2>:MARKer<1...4>:FUNCtion:ZOOM <numeric_value> This command defines the range to be zoomed around marker 1 in the selected measurement window. Marker 1 is activated first, if necessary.
Page 460 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6.3 CALCulate:MARKer:FUNCtion:HARMonics Subsystem The CALCulate:MARKer:FUNCtion:HARMonics subsystem contains the commands for Harmonic Dis- tortion measurement CALCulate<1|2>:MARKer<1...4>:FUNCtion:HARMonics:BANDwidth:AUTO ON | OFF This command specifies whether the resolution bandwidth of the 2 to the n harmonic should be identical to the bandwidth of the first harmonic (OFF) or to the next largest bandwidth (corresponding to the harmonic) of the multiple of the bandwidth of the first harmonic (ON).
Page 461 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:HARMonics:LIST? This command reads out the list of harmonics. The first value is the absolute power of the first harmonic in the unit set via UNIT. The other values are relative to the carrier signal and are output in dB.
Page 462 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:HARMonics:PRESet This command optimizes the device settings depending on the mode in which the harmonic measurement was started: If the harmonic measurement was started in the frequency domain (span > 0), the frequency and the level of the first harmonic are calculated, from which the measurement list is set up.
Page 463 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6.4 CALCulate:MARKer:FUNCtion:POWer Subsystem The CALCulate:MARKer:FUNCtion:POWER subsystem contains the commands for control of power measurement. CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:MODE WRITe | MAXHold This command selects the Clear Write or Maxhold for Channel Power values. Example: "CALC:MARK:FUNC:POW:MODE MAXH"...
Page 464 R&S FSP Remote Control – Description of Commands CALCulate Subsystem WIBro WiMAX WiBro (Wireless Broadband) IEEE 802.16-2004/Cor1-2005 EUTRa E-UTRA/LTE Square Use this standard setting to measure the assumed adjacent channel carrier configuration, E-UTRA of same BW. In this mode, on all channels a square filter is applied. REUTra E-UTRA/LTE Square/RRC Use this standard setting to measure the assumed adjacent channel carrier configuration, 1.28, 3.84, 7.68,...
Page 465 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:RESult:PHZ ON | OFF This command switches the query response of the power measurement results in the indicated measurement window between output of absolute values (OFF) and output referred to the measurement bandwidth (ON).
Page 466 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:RESult? ACPower | AOBandwidth | AOBWidth | CPOWer | MCACpower | OBANdwidth | OBWidth | CN | CN0 This command queries the result of the power measurement performed in the selected window. If necessary, the measurement is switched on prior to the query.
Page 467 R&S FSP Remote Control – Description of Commands CALCulate Subsystem MCACpower: Channel/adjacent channel power measurement with several carrier signals Results are output in the following sequence, separated by commas: 1. Power of carrier signal 1 2. Power of carrier signal 2 3.
Page 468 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example of channel/adjacent channel power measurement: 'Sets the number of adjacent/alternate channels in "SENS2:POW:ACH:ACP 3" screen B to 3. 'Sets the bandwidth of the transmission channel to "SENS2:POW:ACH:BAND 30KHZ" 30 kHz. 'Sets the bandwidth of each adjacent channel to 40 kHz.
Page 469 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:SELect ACPower | CPOWer | MCACpower | OBANdwidth | OBWidth | CN | CN0 This command selects – and switches on – one of the above types of power measurement in the selected measurement window.
Page 470 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:STANdard:CATalog? This command returns all predefine ACP standards and all user standards. The numeric suffixes at MARKer are irrelevant for this command. Example: "CALC:MARK:FUNC:POW:STAN:CAT?” 'get all available ACP standards Characteristics: *RST value:- SCPI: device-specific Mode: CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer:STANdard:DELete <name>...
Page 471 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:POWer[:STATe] OFF This command switches off the power measurement in the selected measurement window. Example: "CALC:MARK:FUNC:POW OFF" 'Switches off the power measurement in screen A. Characteristics: *RST value: - SCPI: device-specific Mode: This command is an event and therefore has no *RST value.
Page 472 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6.5 CALCulate:MARKer:FUNCtion:STRack Subsystem The CALCulate:MARKer:FUNCtion:STRack subsystem defines the settings of the signal track. CALCulate<1|2>:MARKer<1...4>:FUNCtion:STRack:BANDwidth|BWIDth 10Hz to MAX(SPAN) These commands have the same function. For the selected measurement window they define the bandwidth around the center frequency within which the largest signal is searched.
Page 473 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:STRack:THReshold -330dBm to +30dBm This command defines the threshold above which the largest signal is searched for in the selected measurement window. The function is independent of the selected marker, i.e. the numeric suffix <1...4>...
Page 474 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.6.6 CALCulate:MARKer:FUNCtion:SUMMary Subsystem This subsystem contains the commands for controlling the time domain power functions. These are pro- vided in the marker subsystem for reasons of compatibility with the FSE family. CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:AOFF This command switches off all time domain measurements in the selected measurement window.
Page 475 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "INIT:CONT OFF" 'Switches to single-sweep mode. "CALC:MARK:FUNC:SUMM:MEAN ON" 'Switches on the function in screen A. "CALC:MARK:FUNC:SUMM:AVER ON" 'Switches on the average value calculation in screen A. "INIT;*WAI" 'Starts a sweep and waits for the end. "CALC:MARK:FUNC:SUMM:MEAN:AVER:RES?"...
Page 476 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:MEAN:RESult? This command queries the result of the measurement of the mean value in the selected measurement window. The function is independent of the marker selection, i.e. the numeric suffix <1...4> of :MARKer is irrelevant.
Page 477 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Characteristics: *RST value: ABSolute SCPI: device-specific Mode: CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:PHOLd ON | OFF This command switches on or off the peak-hold function for the active time domain power measurement in the indicated measurement window. The function is independent of the marker selection, i.e.
Page 478 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:PPEak:PHOLd:RESult? This command is used to query the result of the measurement of the positive peak value with active peak hold function. The query is only possible if the peak hold function has been activated previously using CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:PHOLd.
Page 479 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:PPEak[:STATe] ON | OFF This command switches on or off the measurement of the positive peak value in the selected measurement window. The function is independent of the marker selection, i.e. the numeric suffix <1...4> of MARKer is irrelevant.
Page 480 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "INIT:CONT OFF" 'Switches to single-sweep mode. "CALC:MARK:FUNC:SUMM:RMS ON" 'Switches on the function in screen A. "CALC:MARK:FUNC:SUMM:AVER ON" Switches on the average value calculation in screen A. "INIT;*WAI" 'Starts a sweep and waits for the end. "CALC:MARK:FUNC:SUMM:RMS:AVER:RES?"...
Page 481 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:RMS:RESult? This command queries the result of the measurement of the RMS power value in the selected measurement window. The function is independent of the marker selection, i.e. the numeric suffix <1...4> of :MARKer is irrelevant.
Page 482 R&S FSP Remote Control – Description of Commands CALCulate Subsystem Example: "INIT:CONT OFF" 'Switches to single-sweep mode. "CALC:MARK:FUNC:SUMM:SDEV ON" 'Switches on the function in screen A. "CALC:MARK:FUNC:SUMM:AVER ON" 'Switches on the calculation of average in screen A. "INIT;*WAI" 'Starts a sweep and waits for the end. "CALC:MARK:FUNC:SUMM:MEAN:SDEV:RES?"...
Page 483 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:SDEViation:RESult? This command queries the results of the standard deviation measurement. The function is independent of the marker selection, i.e. the numeric suffix <1...4> of :MARKer is irrelevant. It is only available in the time domain (span = 0).
Page 484 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.7 CALCulate:MATH Subsystem The CALCulate:MATH subsystem allows to process data from the SENSe-subsystem in numeric expres- sions. The measurement windows are selected by CALCulate1 (screen A) and CALCulate2 (screen B). CALCulate<1|2>:MATH[:EXPression][:DEFine] (<expr>) This command defines the mathematical expression for relating traces to trace1.
Page 485 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:MATH:STATe ON | OFF This command switches the mathematical relation of traces on or off. The measurement windows are selected via CALCulate1 (screen A) or 2 (screen B). Example: "CALC:MATH:STAT ON" 'Switches on the trace mathematics in screen A.
Page 486 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.8 CALCulate:PEAKsearch I PSEarch Subsystem CALCulate<1|2>:PEAKsearch|PSEarch:AUTO ON | OFF By using this command, the peak list in the spurious measurement is calculated automatically after a measurement. For each range, exactly one peak value is calculated. The SENSe suffix is unused.
Page 487 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.9 CALCulate:STATistics Subsystem The CALCulate:STATistics subsystem controls the statistical measurement functions in the instrument. The measurement window cannot be selected with these functions. The numeric suffix <1|2> in CALCu- late is therefore ignored. CALCulate<1|2>:STATistics:APD[:STATe] ON | OFF This command switches on or off the measurement of amplitude distribution (APD).
Page 488 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:STATistics:NSAMples 100 to 1E9 This command sets the number of measurement points to be acquired for the statistical measurement functions. Example: "CALC:STAT:NSAM 500" 'Sets the number of measurement points to be acquired to 500. Characteristics: *RST value: 100000 SCPI: device-specific Mode:...
Page 489 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:STATistics:SCALe:AUTO ONCE This command optimizes the level setting of the instrument depending on the measured peak power, in order to obtain maximum instrument sensitivity. To obtain maximum resolution, the level range is set as a function of the measured spacing between peak power and the minimum power for the APD measurement and of the spacing between peak power and mean power for the CCDF measurement.
Page 490 R&S FSP Remote Control – Description of Commands CALCulate Subsystem CALCulate<1|2>:STATistics:SCALe:X:RLEVel -130dBm to 30dBm This command defines the reference level for the x-axis of the measurement diagram. The setting is identical to the reference level setting using the command DISPlay:WINDow:TRACe:Y:RLEVel. With the reference level offset <>...
Page 491 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.10 CALCulate:THReshold Subsystem The CALCulate:THReshold subsystem controls the threshold value for the maximum/minimum search of markers. The measurement windows are selected by CALCulate 1 (screen A) or 2 (screen B). CALCulate<1|2>:THReshold MINimum to MAXimum (depending on current unit) This command defines the threshold value for the maximum/minimum search of markers with marker search functions MAX PEAK, NEXT PEAK, etc.
Page 492 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.11 CALCulate:TLINe Subsystem The CALCulate:TLINe subsystem controls the settings for the time lines. The measurement windows are selected by CALCulate 1 (screen A) or 2 (screen B). CALCulate<1|2>:TLINe<1|2> 0 to 1000s This command defines the position of the time lines.
Page 493 R&S FSP Remote Control – Description of Commands CALCulate Subsystem 6.5.12 CALCulate:UNIT Subsystem The CALCulate:Unit subsystem defines the units for power measurement settings. CALCulate<1|2>:UNIT:POWer DBM | V | A | W | DBPW | WATT | DBUV | DBMV | VOLT | DBUA | AMPere | DBPT | DBUV_M | DBUA_M This command selects the unit for power in the selected measurement window.
Page 494 R&S FSP Remote Control – Description of Commands CALibration Subsystem 6.6 CALibration Subsystem The commands of the CALibration subsystem determine the data for system error correction in the instrument. CALibration:ABORt This command aborts the acquisition of correction data and restores the last complete correction data set.
Page 495 R&S FSP Remote Control – Description of Commands CALibration Subsystem Characteristics: *RST value: -- SCPI: device-specific Mode: CALibration:STATe ON | OFF This command determines whether the current calibration data are taken into account by the instrument (ON) or not (OFF). Example: "CAL:STAT OFF"...
Page 496 R&S FSP Remote Control – Description of Commands DIAGnostic Subsystem 6.7 DIAGnostic Subsystem The DIAGnostic subsystem contains the commands which support instrument diagnostics for mainte- nance, service and repair. In accordance with the SCPI standard, all of these commands are device-spe- cific.
Page 497 R&S FSP Remote Control – Description of Commands DIAGnostic Subsystem DIAGnostic<1|2>:SERVice:INPut:PULSed[:STATe] ON | OFF This command toggles the calibration signal in the selected measurement window between pulsed and non-pulsed. The selection takes effect only if the RF input has been set to the internal reference signal using the DIAGnostic<1|2>:SERVice:INPut[:SELect] command.
Page 498 R&S FSP Remote Control – Description of Commands DIAGnostic Subsystem DIAGnostic<1|2>:SERVice:INPut[:SELect] CALibration | RF This command toggles between the RF input on the front panel and the internal 128 MHz reference signal in the selected measurement window. The level of the 128-MHz signals can be selected by DIAGnostic<1|2>:SERVice:CSOource[:POWer] command.
Page 499 R&S FSP Remote Control – Description of Commands DIAGnostic Subsystem DIAGnostic<1|2>:SERVice:STESt:RESult? This command reads the results of the selftest out of the instrument. The lines of the result table are output as string data separated by commas: The numeric suffix <1|2> is ignored with this command. Parameter: "Total Selftest Status: PASSED","Date (dd/mm/yyyy): 09/07/ 2006...
Page 500 R&S FSP Remote Control – Description of Commands DISPlay Subsystem 6.8 DISPlay Subsystem The DISPLay subsystem controls the selection and presentation of textual and graphic information as well as of measurement data on the display. The measurement windows are selected by WINDow1 (screen A) or WINDow2 (screen B). DISPlay:ANNotation:FREQuency ON | OFF This command switches the x-axis annotation on or off.
Page 501 R&S FSP Remote Control – Description of Commands DISPlay Subsystem CMAP16 Table + softkey background CMAP17 Table selected field text CMAP18 Table selected field background CMAP19 Table + data entry field opaque title bar CMAP20 Data entry field opaque text CMAP21 Data entry field opaque background CMAP22...
Page 502 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay:FORMat SINGle | SPLit This command switches the measurement result display between FULL SCREEN and SPLIT SCREEN. The coupling of settings between screen A and screen B can be selected with the command INSTrument:COUPle.
Page 503 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay[:WINDow<1|2>]:ACTive? This command returns the active measurement window. The numeric response has following meaning: Screen A Screen B Screen C Screen D Example: "DISP:WIND:ACT?" returns the active window Characteristics: *RST value: -- SCPI: device-specific Mode: The numeric suffix at WINDow<1|2>...
Page 504 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay[:WINDow<1|2>]:TEXT[:DATA] <string> This command defines a comment (max. 20 characters) which can be displayed on the screen in the selected measurement window. Example: "DISP:WIND2:TEXT 'Noise Measurement'" 'Defines the title for screen B Characteristics: *RST value: ""...
Page 505 R&S FSP Remote Control – Description of Commands DISPlay Subsystem Example: "INIT:CONT OFF" 'Switching to single-sweep mode. "SWE:COUN 16" 'Sets the number of measurements to 16. "DISP:WIND1:TRAC3:MODE MAXH" 'Switches on the calculation of the for trace 3 in screen A. "INIT;*WAI"...
Page 506 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay[:WINDow<1|2>]:TRACe<1...3>:X:SPACing LINear | LOGarithmic This command toggles between linear and logarithmic display. Example: "DISP:TRAC:X:SPAC LIN" Characteristics: *RST value: LOGarithmic SCPI: conform Mode: The numeric suffix in TRACe<1...3> is irrelevant. DISPlay[:WINDow<1|2>]:TRACe<1...3>:Y[:SCALe] 10dB to 200dB This command defines the display range of the y-axis (level axis) in the selected measurement window with logarithmic scaling (DISPlay[:WINDow<1|2>]:TRACe<1...3>:Y[:SCALe]:RVALue).
Page 507 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay[:WINDow<1|2>]:TRACe<1...3>:Y[:SCALe]:RLEVel:OFFSet -200dB to 200dB This command defines the offset of the reference level in the selected measurement window. Depending on the coupling of the measurement windows, it is valid for both screens or only for the selected measurement window (INSTrument:COUPle).
Page 508 R&S FSP Remote Control – Description of Commands DISPlay Subsystem DISPlay[:WINDow<1|2>]:TRACe<1...3>:Y:SPACing LINear | LOGarithmic| LDB This command toggles between linear and logarithmic display in the selected measurement window. On a linear scale, switch over between the unit % (command DISP:WIND:TRAC:Y:SPAC LIN) and the unit dB (command DISP:WIND:TRAC:Y:SPAC LDB) is also possible.
Page 509 R&S FSP Remote Control – Description of Commands FORMat Subsystem 6.9 FORMat Subsystem The FORMat subsystem specifies the data format of the data transmitted from and to the instrument. FORMat[:DATA] ASCii | REAL | UINT [, 8 | 32] This command specifies the data format for the data transmitted from the instrument to the control PC. The format settings are valid for the binary transmission of trace data (see also TRACe[:DATA]).
Page 510 R&S FSP Remote Control – Description of Commands HCOPy Subsystem 6.10 HCOPy Subsystem The HCOPy subsystem controls the output of display information for documentation purposes on output devices or files. The instrument allows two independent printer configurations which can be set sepa- rately with the numeric suffix <1|2>.
Page 511 R&S FSP Remote Control – Description of Commands HCOPy Subsystem CMAP14 Limit check fail CMAP15 Table + softkey background CMAP16 Table + softkey text CMAP17 Table selected field text CMAP18 Table selected field background CMAP19 Table + data entry field opaque title bar CMAP20 Data entry field opaque text CMAP21...
Page 512 R&S FSP Remote Control – Description of Commands HCOPy Subsystem HCOPy:DESTination<1|2> <string> This command selects the printer output medium (Disk, Printer or Clipboard) associated with configuration 1 or 2. The type of instrument is selected with SYSTem:COMMunicate:PRINter: SELect, which will automatically select a default output medium. Therefore the command HCOPy:DESTination should always be sent after setting the device type.
Page 513 R&S FSP Remote Control – Description of Commands HCOPy Subsystem HCOPy:DEVice:LANGuage<1|2> GDI | WMF | EWMF | BMP This command determines the data format for the printed output. Parameter: GDI (Graphics Device Interface): Default format for output to a printer that has been configured under Windows.
Page 514 R&S FSP Remote Control – Description of Commands HCOPy Subsystem HCOPy:ITEM:WINDow<1|2>:TABle:STATe ON | OFF This command selects the output of the currently displayed tables. Example: "HCOP:ITEM:WIND:TABL:STAT ON" Characteristics: *RST value: OFF SCPI: device-specific Mode: The command HCOPy:DEVice:ITEM:WINDow<1|2>:TABle:STATe OFF as well as command HCOPy:DEVice:ITEM:ALL enables the output of the whole screen.
Page 515 R&S FSP Remote Control – Description of Commands INITiate Subsystem 6.11 INITiate Subsystem The INITiate subsystem controls the init-measurement function in the selected measurement window. The measurement windows are assigned to INITiate1 (screen A) and INITiate2 (screen B). INITiate<1|2>:CONMeas This command continues a stopped measurement at the current position in single-sweep mode. The function is useful especially for trace functions MAXHold, MINHold and AVERage if the previous results are not to be cleared with Sweep Count >...
Page 516 R&S FSP Remote Control – Description of Commands INITiate Subsystem INITiate<1|2>:DISPlay ON | OFF This command configures the behavior of the display during a single sweep. The numeric suffix of INITiate is irrelevant with this command. Parameter: OFF: the display is switched off during the measurement, ON: the display is switched on during the measurement.
Page 517 R&S FSP Remote Control – Description of Commands INITiate Subsystem Characteristics: *RST value: - SCPI: conform Mode: This command is an event and therefore has no *RST value and no query. INITiate<1|2>:SPURious This command starts a new spurious measurement. Example: "INIT:CONT OFF"...
Page 518 R&S FSP Remote Control – Description of Commands INPut Subsystem 6.12 INPut Subsystem The INPut subsystem controls the input characteristics of the RF inputs of the instrument. The measure- ment windows are assigned to INPut1 (screen A) and INPut2 (screen B). INPut<1|2>:ATTenuation 0 to 70/75dB This command programs the input attenuator.
Page 519 R&S FSP Remote Control – Description of Commands INPut Subsystem INPut<1|2>:EATT 0 to 30dB This command programs the attenuation of the electronic input attenuator. The attenuation can be varied in 5 dB steps from 0 to 30 dB. Other entries are rounded to the next lower integer value. If the attenuation is programmed directly, the coupling to the reference level is switched off.
Page 520 R&S FSP Remote Control – Description of Commands INPut Subsystem INPut<1|2>:GAIN:STATe ON | OFF This command switches the preamplifier for the instrument on or off. The switchable gain is fixed to 20 Example: "INP:GAIN:STAT ON" 'Switches the 20 dB preamplifier on. Characteristics: *RST value: OFF SCPI: conform Mode:...
Page 521 R&S FSP Remote Control – Description of Commands INSTrument Subsystem 6.13 INSTrument Subsystem The INSTrument subsystem selects the operating mode of the unit either via text parameters or fixed numbers. Only operating modes available for the base unit and the models and the options described in this manual (see “Documentation Overview”...
Page 522 R&S FSP Remote Control – Description of Commands INSTrument Subsystem INSTrument[:SELect] SANalyzer | ADEMod | BTOoth This command enables you to switch between modes by entering the mode designation. Parameter: SANalyzer: spectrum analyzer ADEMod: FM demodulator BTOoth: BLUETOOTH Example: "INST SAN" 'Switches the instrument to SPECTRUM.
Page 523 R&S FSP Remote Control – Description of Commands MMEMory Subsystem 6.14 MMEMory Subsystem The MMEMory (mass memory) subsystem provides commands which allow for access to the storage media of the instrument and for storing and loading various instrument settings. The various drives can be addressed via the "mass storage unit specifier" <msus> using the conven- tional DOS syntax.
Page 524 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:CATalog? <path> This command reads the indicated directory. According to DOS convention, wild card characters can be entered in order to query e.g. a list of all files of a certain type. The path name should be in conformance with DOS conventions and may also include the drive name.
Page 525 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:CLEar:STATe 1,<file_name> This command deletes the instrument setting selected by <file_name>. All associated files on the mass memory storage are cleared. A list of the extensions used is included under MMEMory:LOAD: STATe.
Page 526 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:DATA <file_name>[,<block data>] This command writes the block data contained in <block> into the file characterized by <file_name>. The GPIB delimiter must be set to EOI to obtain error-free data transfer. The associated query command reads the indicated file from the mass memory and transfers it to the control computer via the GPIB.
Page 527 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:DELete:IMMediate <file_name> This command deletes the indicated files. Any ’read only’ labels are ignored. The indication of the file name contains the path and, optionally, the drive name. Indication of the path complies with DOS conventions.
Page 528 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:LOAD:STATe 1,<file_name> This command loads device settings from data set files (*.FSP). The contents of the file are loaded and set as the new device state. Items can be individually deselected for the recall. The maximum items to be loaded are the maximum number of items stored in the data set file.
Page 529 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:MSIS <device> This command changes to the drive indicated. The drive may be the internal hard disk “D:”, a memory stick or the floppy disk drive “A:”. Example: "MMEM:MSIS 'D:'" Characteristics: *RST value: "D:' SCPI: conform Mode:...
Page 530 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:SELect[:ITEM]:ALL This command includes all data subsets in the list device settings to be stored/loaded. Example: "MMEM:SEL:ALL" Characteristics: *RST value: -- SCPI: device-specific Mode: This command is an event and therefore has no *RST value. MMEMory:SELect[:ITEM]:DEFault This command sets the default list of device settings to be stored/loaded.
Page 531 R&S FSP Remote Control – Description of Commands MMEMory Subsystem • the activated transducers: A data set may include 4 transducer factors at maximum. It comprises the activated factors and, if available, the de- activated factors last used. Therefore the combination of non-activated restored transducer factors depends on the sequence of use with the command MMEM:LOAD.
Page 532 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:SELect[:ITEM]:TRACe[:ACTive] ON | OFF This command adds the active traces to the list of data subsets of a save/recall device setting. Active traces are all traces whose state is not blank. Example: "MMEM:SEL:TRAC ON"...
Page 533 R&S FSP Remote Control – Description of Commands MMEMory Subsystem MMEMory:STORe<1|2>:SPURious <file_name> This command stores the peak list in an ASCII file to a file on a disk. The file has a header containing important parameters for scaling, several data sections containing the sweep settings per range and a data section containing the peak list.
Page 534 R&S FSP Remote Control – Description of Commands MMEMory Subsystem Parameter: 1 to 3 := selected measurement curve (trace) <file_name> := file name in compliance to DOS conventions, including indication of the path and the drive name Example: "MMEM:STOR2:TRAC 3,'A:\TEST.ASC'" 'Stores trace 3 from screen B in the file TEST.ASC on a disk.
Page 535 R&S FSP Remote Control – Description of Commands MMEMory Subsystem File contents Explanation File data section TRACE 1: Selected trace x-Unit;Hz; Unit of x values: y-Unit;dBm; Unit of y values: Values;2500; Number of measurement points 9000.000000;-99.619965; Measurement values: 9225.961538;-105.416908; <x value>; <y value> 9451.923077;-100.938057;...
Page 536 R&S FSP Remote Control – Description of Commands OUTPut Subsystem 6.15 OUTPut Subsystem The OUTPut subsystem controls the output features of the instrument. In conjunction with the tracking generator option, a distinction is made between OUTPut1 (screen A) and OUTPut2 (screen B). OUTPut<1|2>[:STATe] ON | OFF This command switches the tracking generator on or off.
Page 537 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16 SENSe Subsystem The SENSe subsystem is organized in several subsystems. The commands of these subsystems directly control device-specific settings, they do not refer to the signal characteristics of the measure- ment signal.
Page 538 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]AVERage[:STATe<1...3>] ON | OFF This command switches on or off the average calculation for the selected trace (STATe<1...3>) in the selected measurement window. Example: "AVER OFF" 'Switches off the average calculation for trace 1 in screen A. "SENS2:AVER:STAT3 ON"...
Page 539 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.2 SENSe:BANDwidth Subsystem This subsystem controls the setting of the instrument's filter bandwidths. Both groups of commands (BANDwidth and BWIDth) perform the same functions. The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B). [SENSe<1|2>:]BANDwidth|BWIDth:FFT WIDE | AUTO | NARROW This command allows to specify between the following three options for FFT filters.
Page 540 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]BANDwidth|BWIDth[:RESolution]:AUTO ON | OFF In analyzer mode, this command either automatically couples the resolution bandwidth of the instrument to the span or cancels the coupling. The automatic coupling adapts the resolution bandwidth to the currently set frequency span according to the relationship between frequency span and resolution bandwidth.
Page 541 R&S FSP Remote Control – Description of Commands SENSe Subsystem Example: "BAND:TYPE NORM" Characteristics: *RST value: NORMal SCPI: device-specific Mode: [SENSe<1|2>:]BANDwidth|BWIDth:VIDeo 1 Hz to 10 MHz This command defines the instrument's video bandwidth. Bandwidths from 1 Hz to 10 MHz in 1, 3, 10 steps are available.
Page 542 R&S FSP Remote Control – Description of Commands SENSe Subsystem Example: "BAND:VID:TYPE LIN" 'Video filter ahead of the logarithmic amplifier Characteristics: *RST value: LIN SCPI: device-specific Mode: This command is available from firmware version 1.40 or higher. 6.148 Operating Manual 1164.4556.12 - 06...
Page 543 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.3 SENSe:CORRection Subsystem This subsystem also controls calibration and normalization during operation with the external generator control option (B10). The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B).
Page 544 R&S FSP Remote Control – Description of Commands SENSe Subsystem Mode: This command is only available with the option R&S FSP-B21 (modell R&S FSP 40 only). [SENSe<1|2>:]CORRection:CVL:CATalog? This command queries all the names of the conversion loss tables saved on the hard disc. The syntax of the output is: <sum of file length of all following files>,<free spaces on hard disc>, <1...
Page 545 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]CORRection:CVL:DATA <freq>,<level>.. This command defines the reference values of the selected Conversion Loss Tables. The values are entered as a result of frequency/level pairs. The frequencies have to be sent in ascending order. A maximum of 50 pairs of frequency/level may be entered.
Page 546 R&S FSP Remote Control – Description of Commands SENSe Subsystem This command is only available with the option R&S FSP-B21 (modell R&S FSP 40 only). [SENSe<1|2>:]CORRection:CVL:SELect <file_name> This command selects the Conversion Loss Table designated with <file_name>. If <file_name> is not available, a new Conversion Loss Table will be created.
Page 547 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]CORRection:RECall This command restores the instrument setting that was valid for the measurement of the reference data, provided that the tracking generator is active. Example: "CORR:REC" Characteristics: *RST value: - SCPI: conform Mode: This command is an event and therefore has no *RST value and no query.
Page 548 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]CORRection:TRANsducer:CATalog? This command queries all the names of the transducer files saved on the hard disc. The syntax of the output is: <sum of file length of all following files>,<free spaces on hard disc>,<1 file name>,<1 file length>, <2...
Page 549 R&S FSP Remote Control – Description of Commands SENSe Subsystem This command is an event and therefore has no *RST value. [SENSe<1|2>:]CORRection:TRANsducer:GENerate <name> This command generates a transducer factor <name> using normalized trace data. The function is only available when normalization is switched on. Parameter: <name>::= Name of the transducer factors as string data with up to 8 characters.
Page 550 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]CORRection:TRANsducer[:STATe] ON | OFF This command switches the selected transducer factor on or off. Prior to this command, the command SENS:CORR:TRAN:SEL must be sent. Example: "CORR:TRAN:SEL 'FACTOR1'" "CORR:TRAN ON" Characteristics: *RST value: OFF SCPI: device-specific Mode: This command is available from firmware version 1.40 or higher.
Page 551 R&S FSP Remote Control – Description of Commands SENSe Subsystem Order No. SubRev ≥ 02 ≥ 01 1130.2396 ≥ 02 ≥ 01 1130.2544 ≥ 08 ≥ 01 1093.8249 ≥ 02 ≥ 01 1093.8584 ≥ 02 ≥ 01 1130.3240 Example: "CORR:YIG:TEMP OFF" 'Switches off automatic correction of the YIG filter frequency drift.
Page 552 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.4 SENSe:DETector Subsystem The SENSe:DETector subsystem controls the acquisition of measurement data via the selection of the detector for the corresponding trace. The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B).
Page 553 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.5 SENSe:ESPectrum Subsystem This chapter describes all remote control commands available to configure Spectrum Emission Mask measurements. [SENSe<1|2>:]ESPectrum:BWIDth numeric_value This command defines the bandwidth used for measuring the channel power in the Spectrum Emission Mask measurement.
Page 554 R&S FSP Remote Control – Description of Commands SENSe Subsystem Characteristics: *RST value:- SCPI: device-specific Mode: [SENSe<1|2>:]ESPectrum:PRESet[:STANdard] 'xml_file' This command selects the specified XML file under D:\r_s\instr\sem_std. If the file is stored in a subdirectory, include the relative path. The query returns information about the selected standard, the power class and the link direction. If no standard has been selected, the query returns ''.
Page 555 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ESPectrum:RANGe<1...20>:COUNt? This command indicates the number of defined ranges of the Spectrum Emission Mask measurement. The numeric suffixes <1|2> at SENSe and <1...20> at RANGe are irrelevant for this command. Example: "ESP:RANG:COUN?"...
Page 556 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ESPectrum:RANGe<1...20>[:FREQuency]:STOP <numeric_value> This command sets the relative stop frequency of a range in the Spectrum Emission Mask measurement. The numeric suffixes <1...20> specify the range. The numeric suffix at SENSe<1|2> is irrelevant. Example: "ESP:RANG2:STOP 2.52MHZ"...
Page 557 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ESPectrum:RANGe<1..20>:INSert AFTer | BEFore This command inserts a new range before or after the specified range. The range numbers are updated accordingly. The numeric suffix at RANGe<1...20> specify the range. The numeric suffixes <1...20>...
Page 558 R&S FSP Remote Control – Description of Commands SENSe Subsystem Characteristics: *RST value: depends on range SCPI: device-specific Mode: [SENSe<1|2>:]ESPectrum:RANGe<1..20>:LIMit:RELative:STOP <numeric_value> This command defines the relative limit at the stop frequency of the range for the Spectrum Emission Mask measurement. The numeric suffixes <1...20>...
Page 559 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ESPectrum:RANGe<1...20>:RLEVel <numeric_value> This command defines the reference level of a range in the Spectrum Emission Mask measurement. The numeric suffixes <1...20> specify the range. The numeric suffix at SENSe<1|2> is irrelevant. Example: "ESP:RANG2:RLEV -30"...
Page 560 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ESPectrum:RRANge? This command returns the numer of the reference range of the Spectrum Emission Mask measurement. The numeric suffixes <1...20> specify the range. The numeric suffix at SENSe<1|2> is irrelevant. Example: "ESP:RRAN?"...
Page 561 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.6 SENSe:FREQuency Subsystem The SENSe:FREQuency subsystem defines the frequency axis of the active display. The frequency axis can either be defined via the start/stop frequency or via the center frequency and span. The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B).
Page 562 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]FREQuency:MODE CW | FIXed | SWEep In analyzer mode, this command switches between frequency domain (SWEep) and time domain (CW | FIXed). For CW and FIXed, the frequency setting is via command FREQuency:CENTer. In the SWEep mode, the setting is via commands FREQuency:STARt, STOP, CENTer and SPAN.
Page 563 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]FREQuency:STOP 0 to f This command defines the stop frequency of the R&S FSP. This command is only available in the frequency domain (span >0). Example: "FREQ:STOP 20MHz" Characteristics: *RST value: f SCPI: conform Mode: Operating Manual 1164.4556.12 - 06...
Page 564 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.7 SENSe:LIST Subsystem The commands of this subsystem are used for measuring the power at a list of frequency points with dif- ferent device settings. The measurement is always performed in the time domain (span = 0 Hz). A new trigger event is required for each test point (exception: Trigger FREE RUN).
Page 565 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:POWer:RESult? This command queries the result of a previous list measurement as configured and initiated with SENSe:LIST:POWer[:SEQuence]. The measured results are output in a list of floating point values separated by commas. The unit of the results depends on the setting made with the CALC:UNIT command.
Page 566 R&S FSP Remote Control – Description of Commands SENSe Subsystem Parameter: <analyzer freq>: Receive frequency for the signal to be measured (= center frequency in manual operation) Range of values: 0 Hz to max. frequency, depending on the instrument model. <ref level>: Reference level Range of values:...
Page 567 R&S FSP Remote Control – Description of Commands SENSe Subsystem Command "SENSe:LIST:POWer? 935.2MHz,-20dBm,10dB,OFF,NORM,1MHz,3MHz,434us,0, 935.4MHz,-20dBm,10dB,10dB,NORM,30kHz,100kHz,434us,0, 935.6MHz,-20dBm,10dB,20dB,NORM,30kHz,100kHz,434us,0" thus returns the following list, for example: -28.3,-30.6,-38.1 If the command sequence is extended to "SENSe:LIST:POWer:SET ON,ON,ON,IMM,POS,0,0" "SENSe:LIST:POWer? 935.2MHz,-20dBm,10dB,OFF,NORM,1MHz,3MHz,434us,0, 935.4MHz,-20dBm,10dB,10dB,NORM,30kHz,100kHz,434us,0, 935.6MHz,-20dBm,10dB,20dB,NORM,30kHz,100kHz,434us,0" the result list is extended to 3 results per frequency point (peak, RMS and average): -28.3, -29.6, 1.5, -30.6, -31.9, 0.9, -38.1, -40.0, 2.3 Example: "SENSe:LIST:POWer...
Page 568 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:POWer:SET <PEAK meas>,<RMS meas>,<AVG meas>,<trigger mode>,<trigger slope>,<trigger offset>, <gate length> This command defines the constant settings for the list during multiple power measurement. Parameters <PEAK meas>, <RMS meas> and <AVG meas> define, which measurements are to be performed at the same time at the frequency point.
Page 569 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:POWer:SET:AVERage:TYPE LINear | LOGarithmic With this command the average type of the sense list measurement can be set either to linear (default) or logarithmic. In linear mode voltages are averaged in logarithmic mode levels. Example: "LIST:POW:SET:AVER LOG"...
Page 570 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:RANGe<1...20>:COUNt? This command indicates the number of defined ranges of the spurious measurement. The numeric suffix <1...20> with RANGe is not relevant for this command. Example: "LIST:RANG:COUN?" 'Indicates the number of ranges Characteristics: *RST value: -- SCPI: device-specific Mode:...
Page 571 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:RANGe<1...20>[:FREQuency]:STOP <numeric_value> This command sets the stop frequency of a range in the spurious measurement. Example: "LIST:RANG2:STOP 2GHZ" 'Stop frequency of range 2 to 2 GHz Characteristics: *RST value: -- SCPI: device-specific Mode: [SENSe<1|2>:]LIST:RANGe<1...20>:INPut:ATTenuation <numeric_value>...
Page 572 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:RANGe<1...20>:LIMit:STATe ON | OFF This command activates/deactivates the limit checking for the spurious emission measurement LIST EVALUATION (for details on this measurement see page 220). The numeric suffix at SENSe<1|2> and the numeric suffix at RANGe1...20> are irrelevant. Example: "LIST:RANG5:LIM -40"...
Page 573 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]LIST:RANGe<1...20>:SWEep:TIME:AUTO ON | OFF This command controls the automatic coupling of the sweep duration on the frequency span and the bandwidth settings in a spurious measurement range. Example: "LIST:RANG2:SWE:TIME:AUTO ON" 'Activates the coupling of frequency range and bandwidths in range 2 Characteristics: *RST value: ON SCPI: device-specific...
Page 574 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.8 SENSe:MIXer Subsystem The SENSe:MIXer subsystem controls the settings of the external mixer. It is only active if option R&S FSP-B21 is installed. [SENSe<1|2>:]MIXer:BIAS:HIGH <numeric_value> This command sets the bias current of the mixer for higher harmonics in bands with two harmonics. Example: "MIX ON"...
Page 575 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]MIXer:HARMonic:BAND A|Q|U|V|E|W|F|D|G|Y|J|USER This command sets the active band. Example: "MIX ON" "MIX:HARM:BAND E" Characteristics: *RST value: U SCPI: device-specific Mode: This command is only available for model R&S FSP 40 with option R&S FSP-B21 and external mixer activated.
Page 576 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]MIXer:LOSS[:LOW] <numeric_value> This command sets the conversion loss of the mixer. If two harmonics are used for the band, it is set for the lower harmonic. Example: "MIX ON" "MIX:LOSS -12DB" Characteristics: *RST value: 0 dB SCPI: conform Mode:...
Page 577 R&S FSP Remote Control – Description of Commands SENSe Subsystem This command is only available for model R&S FSP 40 with option R&S FSP-B21 and external mixer activated. [SENSe<1|2>:]MIXer:SIGNal ON | OFF | AUTO | ALL In analyzer mode, this command activates the Signal ID (ON) or Auto ID (AUTO) mode or both (ALL). Example: "MIX ON"...
Page 578 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.9 SENSe:MPOWer Subsystem The commands of this subsystem are used to determine the mean burst power or peak burst power for a given number of signal bursts, and for outputting the results in a list. Since all the settings required for a measurement are combined in a single command, the measurement speed is considerably higher than when using individual commands.
Page 579 R&S FSP Remote Control – Description of Commands SENSe Subsystem 1. Setting up the instrument and at the same time querying the result list: This method ensures the smallest delay between measurement and the output of the measured values, but requires the control computer to wait actively for the response of the instrument. 2.
Page 580 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]MPOWer:RESult:MIN? This command queries the minimum power value in a multiple burst power measurement as configured and initiated with SENSe:MPOWer[:SEQuence]. The unit used for the return values is always dBm. If no measurement result is available, the command will return a query error.
Page 581 R&S FSP Remote Control – Description of Commands SENSe Subsystem Parameter: <analyzer freq> Receive frequency for the burst signals to be measured (= center frequency in manual operation) The range is 0 Hz to max. frequency, depending on instrument model <rbw>...
Page 582 R&S FSP Remote Control – Description of Commands SENSe Subsystem To properly use this command, you have to specify the unit of the trigger level (DBM or PCT). <trigger offset> Offset between the detection of the trigger signal and the start of the measurement. The range is from 125 ns to 100s <type of meas>...
Page 583 R&S FSP Remote Control – Description of Commands SENSe Subsystem The measurement function always uses trace 1 in the selected screen, and acti- vates the selected screen. Repeated use of the command without changes to its parameters (i.e. using the same settings again) will speed up the measurement since the previous hardware settings will be cached and therefore additional hardware settling times will be avoided.
Page 584 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.10 SENSe:POWer Subsystem This subsystem controls the setting of the instrument's channel and adjacent channel power measure- ments. The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B). [SENSe<1|2>:]POWer:ACHannel:ACPairs 0 to 12 This command sets the number of adjacent channels (upper and lower channel in pairs).
Page 585 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:BANDwidth|BWIDth[:CHANnel] 100 Hz to 1000 MHz This command sets the channel bandwidth of the radio communication system. The bandwidths of adjacent channels are not influenced by this modification (in contrast to the FSE family). With SENS:POW:HSP ON the steep-edged channel filters from the table "List of available channel filters"...
Page 586 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:FILTer:ALPHa:CHANnel<1...12> 0…1 This command sets the rolloff factor of the RRC weighting filter for the TX channel. It is only available if Fast ACP is not active and no predefine standard is selected. Example: "POW:ACH:FILT:ALPH:CHAN 0.26"...
Page 587 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:FILTer:STATe:CHANnel<1...12> ON | OFF This command switches the weigthing filter state for the TX channel on or off. It is only available if Fast ACP is not active and no predefine standard is selected. This command changes the setting for the TX channel.
Page 588 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:PRESet:RLEVel This command adapts the reference level to the measured channel power and – if required - switches on previously the adjacent channel power measurement. This ensures that the signal path of the instrument is not overloaded.
Page 589 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:REFerence:TXCHannel:AUTO MINimum | MAXimum | LHIGhest | This command activates or deactivates the automatic selection of a transmission channel to be used as a reference channel in relative adjacent channel power measurements. The transmission channel with the highest power, the transmission channel with the lowest power, or the transmission channel nearest to the adjacent channels can be defined as a reference channel.
Page 590 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:ACHannel:SPACing:ALTernate<1...11> 100 Hz to 2000 MHz This command defines the spacing between the alternate adjacent channels and the TX channel. If the spacing to an alternate adjacent channel ALTernate<k> is modified, the spacing to all the following alternate adjacent channels ALTernate<n>...
Page 591 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:BANDwidth|BWIDth 10 to 99.9PCT This command defines the percentage of the power with respect to the total power. This value is the basis for the occupied bandwidth measurement (command: POWer:ACHannel:PRESet OBW). The command is only available in the frequency domain (span >...
Page 592 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]POWer:TRACe 1 to 3 This command assigns the channel/adjacent channel power measurement to the indicated trace in the selected measurement window. The corresponding trace must be active, i.e. its state must be different from blank.
Page 593 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.11 SENSe:ROSCillator Subsystem This subsystem controls the reference oscillator. The numeric suffix in SENSe is irrelevant for the com- mands of this subsystem. [SENSe<1|2>:]ROSCillator:EXTernal:FREQuency 1MHz to 20MHz This command informs the instrument on the frequency of the external reference oscillator. This frequency is used as starting point for the synchronization of the internal reference frequencies.
Page 594 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]ROSCillator[:INTernal]:TUNE:SAVE This command saves the new value for the tuning of the internal reference oscillator. The factory-set value in the EEPROM is overwritten. This command is only available at service level 1. Example: "ROSC:TUN:SAV"...
Page 595 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.12 SENSe:SWEep Subsystem This subsystem controls the sweep parameters. The measurement windows are selected by SENSe1 (screen A) and SENSe2 (screen B). [SENSe<1|2>:]SWEep:COUNt 0 to 32767 This command defines the number of sweeps started with single sweep, which are used for calculating the average or maximum value.
Page 596 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]SWEep:EGATe ON | OFF This command switches on/off the sweep control by an external gate signal. If the external gate is selected the trigger source is automatically switched to EXTernal as well. In case of measurement with external gate, the measured values are recorded as long as the gate is opened.
Page 597 R&S FSP Remote Control – Description of Commands SENSe Subsystem [SENSe<1|2>:]SWEep:EGATe:LENGth 0 to 100 s In case of edge triggering, this command determines the time interval during which the instrument sweeps. Example: "SWE:EGAT:LENG 10ms" Characteristics: *RST value: 0s SCPI: device-specific Mode: [SENSe<1|2>:]SWEep:EGATe:POLarity POSitive | NEGative This command determines the polarity of the external gate signal.
Page 598 R&S FSP Remote Control – Description of Commands SENSe Subsystem Mode: [SENSe<1|2>:]SWEep:EGATe:TRACe<1..3>STARt<1..3> | STOP<1..3> <value> Sets the start or stop value of a gate range in the gate range table. The suffix after TRACe indicates the trace. The suffix after STARt | STOP indicates the range. Example: "SWE:EGAT:TRAC1:STAR2 5us"...
Page 599 R&S FSP Remote Control – Description of Commands SENSe Subsystem Characteristics: *RST value: AUTO SCPI: device-specific Mode: [SENSe<1|2>:]SWEep:POINts 125, 251, 501, 1001, 2001, 4001, 8001 This command defines the number of measurement points for one sweep run. Example: "SWE:POIN 251" Characteristics: *RST value: 501 SCPI: conform Mode:...
Page 600 R&S FSP Remote Control – Description of Commands SENSe Subsystem 6.16.13 SENSe:TV Subsystem This subsystem controls the TV trigger part of option R&S FSP-B6 (TV and RF trigger). The setup of the individual trigger parameters is included in subsystem TRIGger. [SENSe<1|2>:]TV:CCVS INTernal | EXTernal This command selects between an internal and an external CCVS signal as TV demodulator input signal.
Page 601 R&S FSP Remote Control – Description of Commands SOURce Subsystem 6.17 SOURce Subsystem The SOURce subsystem controls the output signals of the instrument if the options tracking generator (B9) or External Generator Control (B10) are installed. The measurement window is selected by SOURce1 (screen A) and SOURce2 (screen B).
Page 602 R&S FSP Remote Control – Description of Commands SOURce Subsystem SOURce<1|2>:FM:STATe ON | OFF This command switches on or off the external frequency modulation of the tracking generator in the selected measurement window. External I/Q modulation is switched off, if active. This command is only valid in conjunction with the tracking generator option B9.
Page 603 R&S FSP Remote Control – Description of Commands SOURce Subsystem SOURce<1|2>:POWer[:LEVel][:IMMediate]:OFFSet -200dB to +200dB This command defines a level offset for the tracking generator level. Thus, for example, attenuators or amplifiers at the output of the tracking generator can be taken into account for the setting. This command is only valid in conjunction with the tracking generator option R&S FSP-B9.
Page 604 R&S FSP Remote Control – Description of Commands SOURce Subsystem 6.17.2 SOURce:EXTernal Subsystem The SOURce:EXTernal subsystem controls the operation of the unit with option Ext. Generator Control (B10). The commands are only valid for the selected window, with SOURce1 changing the setting in screen A and SOURce2 the setting in screen B.
Page 605 R&S FSP Remote Control – Description of Commands SOURce Subsystem Example: "SOUR:EXT:FREQ:NUM 4" "SOUR:EXT:FREQ:DEN 3" 'Sets a multiplication factor of 4/3, i.e. the transmit frequency of the generator is 4/ 3 times the analyzer frequency. Characteristics: *RST value: 1 SCPI: device-specific Mode: SOURce<1|2>:EXTernal<1|2>:FREQuency:OFFSet <numeric_value>...
Page 606 R&S FSP Remote Control – Description of Commands SOURce Subsystem Mode: SOURce<1|2>:EXTernal<1|2>:ROSCillator[:SOURce] INTernal | EXTernal This command switches between external and internal reference oscillator for the frequency processing of external generator 1 and 2. The command always works on both generators. Therefore, the numeric suffix in EXTernal<1|2> is not significant.
Page 607 R&S FSP Remote Control – Description of Commands STATus Subsystem 6.18 STATus Subsystem The STATus subsystem contains the commands for the status reporting system (see chapter “Remote Control – Basics”, section “Status Reporting System” on page 5.18). *RST does not influence the status registers.
Page 608 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:OPERation:PTRansition 0 to 65535 This command sets the edge detectors of all bits of the STATus:OPERation register from 0 to 1 for the transitions of the CONDition bit. Example: "STAT:OPER:PTR 65535" Characteristics: *RST value: –...
Page 609 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:ACPLimit:NTRansition 0 to 65535 This command sets the edge detectors of all bits of the STATus:QUEStionable:ACPLimit register from 1 to 0 for the transitions of the CONDition bit. Example: "STAT:QUES:ACPL:NTR 65535" Characteristics: *RST value: –...
Page 610 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:FREQuency:CONDition? This command queries the contents of the CONDition section of the STATus:QUEStionable: FREQuency register. Readout does not delete the contents of the CONDition section. Example: "STAT:QUES:FREQ:COND?" Characteristics: *RST value: – SCPI: device-specific Mode: STATus:QUEStionable:FREQuency:ENABle 0 to 65535...
Page 611 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:LIMit<1|2>:CONDition? This command queries the contents of the CONDition section of the STATus:QUEStionable:LIMit register. Readout does not delete the contents of the CONDition section. Example: "STAT:QUES:LIM:COND?" Characteristics: *RST value: – SCPI: device-specific Mode: STATus:QUEStionable:LIMit<1|2>:ENABle 0 to 65535...
Page 612 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:LMARgin<1|2>:CONDition? This command queries the contents of the CONDition section of the STATus:QUEStionable:LMARgin register. Readout does not delete the contents of the CONDition section. Example: "STAT:QUES:LMAR:COND?" Characteristics: *RST value: – SCPI: device-specific Mode: STATus:QUEStionable:LMARgin<1|2>:ENABle 0 to 65535...
Page 613 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:NTRansition 0 to 65535 This command sets the edge detectors of all bits of the STATus:QUEStionable register from 1 to 0 for the transitions of the CONDition bit. Example: "STAT:QUES:NTR 65535" Characteristics: *RST value: –...
Page 614 R&S FSP Remote Control – Description of Commands STATus Subsystem STATus:QUEStionable:POWer:PTRansition 0 to 65535 This command sets the edge detectors of all bits of the STATus:QUEStionable:POWer register from 0 to 1 for the transitions of the CONDition bit. Example: "STAT:QUES:POW:PTR 65535" Characteristics: *RST value: –...
Page 615 R&S FSP Remote Control – Description of Commands SYSTem Subsystem 6.19 SYSTem Subsystem This subsystem contains a series of commands for general functions. SYSTem:APPLication:SRECovery[:STATe] ON | OFF This command controls the instrument behaviour when changing the active application, e.g from SPECTRUM to FM DEMOD and back from FM DEMOD to SPECTRUM.
Page 616 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:COMMunicate:GPIB:RDEVice:GENerator<1|2>:ADDRess 0 to 30 This command changes the GPIB address of the device selected as external generator 1 or 2. If two generators are connected at the same time to IECBUS 2 their addresses must be different.
Page 617 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:COMMunicate:PRINter:ENUMerate:FIRSt? This command queries the name of the first printer (in the list of printers) available under Windows NT. The names of other installed printers can be queried with command SYSTem:COMMunicate: PRINter:ENUMerate:NEXT?.
Page 618 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:COMMunicate:RDEVice:GENerator<1|2>:LINK GPIB | TTL This command selects the interface type of the external generator 1 or 2. The following types are available • GPIB alone (= GPIB, for all the generators of other manufacturers and some Rohde & Schwarz units) •...
Page 619 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:COMMunicate:SERial:CONTrol:RTS IBFull | OFF These commands switch the hardware handshake procedure for the serial interface off (OFF) or on (IBFull). The two commands are equivalent. Example: "SYST:COMM:SER:CONT:DTR OFF" "SYST:COMM:SER:CONT:RTS IBF" Characteristics: *RST value: -- (no influence on this parameter, factory default OFF) SCPI: conform Mode:...
Page 620 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:COMMunicate:SERial[:RECeive]:SBITs 1|2 This command defines the number of stop bits per data word for the serial interface (COM). Example: "SYST:COMM:SER:SBITs 2" Characteristics: *RST value: -- (no influence on this parameter, factory default 1) SCPI: conform Mode: SYSTem:DATE 1980 to 2099, 1 to 12, 1 to 31...
Page 621 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:DISPlay:UPDate ON | OFF This command switches on or off the update of all display elements during remote control. The best performance is obtained when the display output is switched off during remote control.
Page 622 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:FIRMware:UPDate <path> As of firmware version 4.5x it is possible to update base system and applications in one single step. The structure of the update folder has to look like: Extract the ZIP file containg the files needed for an update including the folder structure.
Page 623 R&S FSP Remote Control – Description of Commands SYSTem Subsystem Characteristics: *RST value: FSP SCPI: device-specific Mode: SYSTem:IDENtify:FACTory This command resets the *IDN string to the factory default. Return value: "1" for the factory default state "0" for a changed *IDN string Example: "SYST:IDEN:FACT"...
Page 624 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:LANGuage <language> This command activates the emulation of various analyzers. The analyzer default command set is SCPI. The following remote-control languages are available: SCPI, 71100C, 71200C, 71209A, 8560E, 8561E, 8562E, 8563E, 8564E, 8565E, 8566A, 8566B, 8568A, 8568A_DC, 8568B, 8568B_DC, 8591E, 8594E •...
Page 625 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:LXI:INFO? This command queries the current parameters of the LXI class C. Return value: <current version> | <LXI class> | <Computername> | <MAC adress> | <IP adress> | <Auto MDIX> Example: "SYST:LXI:INFO?"...
Page 626 R&S FSP Remote Control – Description of Commands SYSTem Subsystem SYSTem:LXI:PASSword <password> This command shows or changes the LXI password. The default password is 'LxiWebIfc'. Example: "SYST:LXI:PASS '123456'" ’Sets a new password (123456). Characteristics: *RST value: - SCPI: device-specific Mode: SYSTem:MSIZe? MBOard This command outputs the memory size of the mainboard.
Page 627 R&S FSP Remote Control – Description of Commands SYSTem Subsystem Characteristics: *RST value: -- SCPI: device-specific Mode: SYSTem:SHUTdown This command shuts down the instrument. This command is an event and therefore has no query and no *RST value. Example: "SYST:SHUT" Characteristics: *RST value: - SCPI: device- specific Mode:...
Page 628 R&S FSP Remote Control – Description of Commands TRACe Subsystem 6.20 TRACe Subsystem The TRACe subsystem controls access to the instrument's internal trace memory. 6.20.1 General Trace Commands TRACe<1|2>:COPY TRACE1| TRACE2| TRACE3 , TRACE1| TRACE2| TRACE3 This command copies data from one trace to another. The second operand describes the source, the first operand the destination of the data to be copied.
Page 629 R&S FSP Remote Control – Description of Commands TRACe Subsystem These values are defined via the [SENSe<1|2>:]LIST:RANGe<1...20> subsystem. SPURious reads the peak list in the spurious measurement. As results a list of frequency, level and delta to limit line values is returned. A delta limit of +200dB indicates no limit check is active.
Page 630 R&S FSP Remote Control – Description of Commands TRACe Subsystem – <meas value x>: 4 byte floating point measurement values Saving and recalling: Saving and recalling trace data together with the device settings to/from the device-internal hard disk or to/from a memory stick/floppy is controlled via the commands MMEMory:STORe:STATe and MMEMory:LOAD:STATe respectively.
Page 631 R&S FSP Remote Control – Description of Commands TRACe Subsystem TRACe<1|2>:IMMediate:LEVel? This query returns the current Y results of the sweep. During a sweep the last measured value is read out. Example: "INIT:CONT OFF" 'switches to single-sweep mode "INIT" 'starts a sweep (without waiting for the sweep end!) "TRAC1:IMM:LEV?"...
Page 632 R&S FSP Remote Control – Description of Commands TRACe Subsystem 6.20.3 TRACe:IQ Subsystem The commands of this subsystem are used for collection and output of measured IQ data. A special memory is therefore available in the instrument with 128k words for the I and Q data. The measurement is always performed in the time domain (span = 0 Hz) at the selected center frequency.
Page 633 R&S FSP Remote Control – Description of Commands TRACe Subsystem Fig. 6.1 shows the analyzer hardware from the IF section to the processor. The IF filter is the resolution filter of the R&S FSP with bandwidths selectable from 300 kHz to 10 MHz. The A/D converter samples the IF signal (20.4 MHz) at a rate of 32 MHz.
Page 634 R&S FSP Remote Control – Description of Commands TRACe Subsystem TRACe<1|2>:IQ:AVERage:COUNt 0 .. 32767 This command defines the number of I/Q data sets that are to serve as a basis for averaging. Example: TRAC:IQ ON 'Switches on acquisition of I/Q data. TRAC:IQ:SYNC ON 'Switches on synchronization of the aquision of I/Q measurement data with the trigger time.
Page 635 R&S FSP Remote Control – Description of Commands TRACe Subsystem Example: TRAC:IQ ON 'Switches on acquisition of I/Q data. TRAC:IQ:SYNC ON 'Switches on synchronization of the aquision of I/Q measurement data with the trigger time. TRAC:IQ:SET NORM,10MHz,32MHz,EXT,POS,0,2048 'Reads 2048 I/Q values starting at the time of trigger. 'Filter type: NORMAL (analogue) 'RBW: 10 MHz 'Sample Rate: 32 MHz...
Page 636 R&S FSP Remote Control – Description of Commands TRACe Subsystem Parameter: <offset samples>: Offset of the values to be output, referenced to the start of the sampled data. Value range: 0 ... <# of samples> - 1, where <# of samples> is the value specified with the TRACe:IQ:SET command <# of samples>: Value range: 1 ...
Page 637 R&S FSP Remote Control – Description of Commands TRACe Subsystem TRACe<1|2>:IQ:DATA? This command starts a measurement with the settings defined via TRACe:IQ:SET and returns the list of measurement results immediately after they are corrected in terms of frequency response. The number of measurement results depends on the settings defined with TRACe:IQ:SET, the output format depends on the settings of the FORMat –...
Page 638 R&S FSP Remote Control – Description of Commands TRACe Subsystem # of I-data = # of Q-data = (# of DataBytes) / 8 The offset of Q-data in the output buffer can be calculated as follows: Q-data offset = (# of DataBytes) / 2 + LengthIndicatiorDigit with LengthIndicatorDigits being the number of digits of the length indicator including the '#'.
Page 639 R&S FSP Remote Control – Description of Commands TRACe Subsystem RFPower requires the TV and RF Trigger option R&S FSP-B6. After selecting IFPower and RFPower, the trigger threshold can be set with com- mand TRIG:LEV:IFP or TRIG:LEV:RFP. <trigger slope>: Used trigger slope. Values: POSitive | NEGative <pretrigger samples>: Number of measurement values to be recorded before the trigger point.
Page 640 R&S FSP Remote Control – Description of Commands TRACe Subsystem TRACe<1|2>:IQ:SRATe 15.625 kHz to 32 MHz This command sets the sampling rate for the I/Q data acquisition. Thus the sample rate can be modified without affecting the other settings. Return value: 15.625 kHz, 31.25 kHz, 62.5 kHz, 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz, 16 MHz, 32 MHz Example:...
Page 641 R&S FSP Remote Control – Description of Commands TRACe Subsystem Example: "TRAC:IQ ON" 'Switches on I/Q data acquisition "TRAC:IQ:SYNC ON ON" 'Switches on synchronization of I/Q data acquisition to the trigger event "TRAC:IQ:SET NORM,10MHz,32MHz,EXT,POS,0,2048" 'Reads 2048 I/Q-values starting at the trigger point. 'Filtertype: NORMAL (analog) 'RBW: 10 MHz 'Sample Rate: 32 MHz...
Page 642 R&S FSP Remote Control – Description of Commands TRIGger Subsystem 6.21 TRIGger Subsystem The TRIGger subsystem is used to synchronize instrument actions with events. It is thus possible to con- trol and synchronize the start of a sweep. An external trigger signal can be applied to the connector at the rear panel of the instrument.
Page 643 R&S FSP Remote Control – Description of Commands TRIGger Subsystem TRIGger<1|2>[:SEQuence]:LEVel:RFPower -50 to –10 dBm This command sets the level of the RF power trigger source. Example: "TRIG:LEV:RFP –20DBM" Characteristics: *RST value: -20 dBm SCPI: device-specific Mode: This command is only available with option R&S FSP-B6 (TV and RF Trigger). TRIGger<1|2>[:SEQuence]:LEVel:VIDeo 0 to 100PCT This command sets the level of the video trigger source.
Page 644 R&S FSP Remote Control – Description of Commands TRIGger Subsystem IFPower The next measurement is triggered by the detection of a signal at the instrument IF (10 MHz bandwidth) RFPower The next measurement is triggered by the detection of a signal at the instrument RF (80 MHz bandwidth) The next measurement is triggered by the detection of a TV signal according to the settings of the TRIGger:SEQuence:VIDeo-...
Page 645 R&S FSP Remote Control – Description of Commands TRIGger Subsystem TRIGger<1|2>[:SEQuence]:VIDeo:SSIGnal:POLarity NEGative | POSitive With active TV trigger this command selects the polarity of the video sync signal. Example: "TRIG:VID:SSIG:POL NEG" Characteristics: *RST value: SCPI: conform Mode: This command is only available with option R&S FSP-B6 (TV and RF Trigger). Operating Manual 1164.4556.12 - 06 6.251...
Page 646 R&S FSP Remote Control – Description of Commands UNIT Subsystem 6.22 UNIT Subsystem The UNIT subsystem is used to switch the base unit of setting parameters. The numeric suffix at UNIT<1|2> selects the measurement window. UNIT<1|2>:POWer DBM | DBPW | WATT | DBUV | DBMV | VOLT | DBUA | AMPere | V | A | W | DB | DBPT | PCT | UNITLESS | DBUV_MHZ | DBMV_MHZ | DBUA_MHZ | DBUV_M | DBUA_M | DBUV_MMHZ | DBUA_MMHZ This command selects the unit for power for the selected measurement window.
Page 647 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23 GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.1 Introduction The R&S FSP analyzer family supports a subset of the GPIB commands of HP models 8560E, 8561E, 8562E, 8563E, 8564E, 8565E, 8566A, 8566B, 8568A, 8568B and 8594E.
Page 648 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models ADJALL ADJALL Adjust all HP 856xE / available in V3.2x and above HP 8566B / HP 8568B / HP 8594E ADJCRT...
Page 649 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Blank B HP 8566A/ available HP 8568A Trace B - HP 8566A/ available in V3.3x and above Display Line ->...
Page 650 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models CONTS CONTS HP 856xE / available HP 8566B / HP 8568B / HP 8594E COUPLE COUPLE AC|DC Input coupling HP 856xE /...
Page 651 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models DLE ON|OFF Display Line HP 856xE / available in V3.3x and above enable HP 8566B / HP 8568B / HP 8594E DONE...
Page 652 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models FOFFSET FOFFSET <numeric_value> Frequency HP 856xE / available HZ|KHZ|MHZ|GHZ Offset HP 8566B / FOFFSET? HP 8568B / HP 8594E FREF FREF INT|EXT...
Page 653 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models INZ 75 Input HP 856xE / available INZ 50 Impedance HP 8566B / INZ? HP 8568B / HP 8594E Instrument HP 8566A/...
Page 654 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models KSP <numeric_value> HPIB address HP 8566A/ available HP 8568A Band lock off HP 8566A/ available in V3.2x and above HP 8568A Fast Preset HP 8566A/...
Page 655 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Signal ident on HP 8566A/ available in V3.2x and above HP 8568A Display line off HP 8566A/ available in V3.2x and above HP 8568A...
Page 656 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Marker Normal HP 8566A/ available M2 <numeric_value> HP 8568A HZ|KHZ|MHZ|GHZ M2 DN M2 UP Delta Marker HP 8566A/ available M3 <numeric_value>...
Page 657 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Delta Marker HP 856xE / available MKD <numeric_value> HZ|KHZ| HP 8566B / MHZ|GHZ HP 8568B / MKD DN HP 8594E MKD UP...
Page 658 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models MKPK MKPK Marker Search HP 856xE / available MKPK HI HP 8566B / MKPK NH HP 8568B / MKPK NR HP 8594E...
Page 659 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Marker Track HP 8566A/ available HP 8568A MXMH MXMH TRA|TRB Maximum Hold HP 856xE / available HP 8566B / HP 8568B /...
Page 660 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models PRINT PRINT Hardcopy HP 856xE / available PRINT 1|0 HP 8566B / HP 8568B / HP 8594E PSDAC PSDAC <numeric_value>...
Page 661 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models RL <numeric_value> DB|DM Reference HP 856xE / available RL DN Level HP 8566B / RL UP HP 8568B / HP 8594E RLCAL...
Page 662 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models SNGLS SNGLS Single Sweep HP 856xE / available HP 8566B / HP 8568B / HP 8594E SQUELCH SQUELCH <numeric_value>...
Page 663 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models Subtract HP 8566B / available in V4.1x and above HP 8568B / HP 8594E sum of trace HP 8566B / available in V4.3x and above amplitudes...
Page 664 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models TDF P Trace Data HP 856xE / available TDF M Format HP 8566B / TDF B HP 8568B / TDF A HP 8594E...
Page 665 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Supported subset Function Corresponding Status HP-Models VB <numeric_value> Video HP 856xE / available HZ|KHZ|MHZ|GHZ Bandwidth HP 8566B / VB DN HP 8568B / VB UP HP 8594E VB AUTO...
Page 666: 856X: Emulation Of The Spurious Response Measurement Utility
R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.4 856x: Emulation of the Spurious Response Measurement Utility 85672A 6.23.4.1 General commands for Spurious Command Supported subset Function Corresponding Status HP-Models SP_OK A value of 1 denotes a HP 856xE...
Page 667 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.4.3 Commands for Harmonic Distortion Command Supported subset Function Corresponding Status HP-Models SP_HARM Executes harmonis distortion HP 856xE available in V4.1x and measurement above SP_H_MAX...
Page 668 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.4.4 Commands for Spurious Command Supported subset Function Corresponding Status HP-Models SP_TIME Calculates an estimated time for HP 856xE available in V4.1x and the spurious search above SP_GEN...
Page 669: 856X: Emulation Of The Phase Noise Utility 85671A
R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.5 856x: Emulation of the Phase Noise Utility 85671A The following commands require option FS-K40 installed and enabled. Command Supported subset Function Corresponding Status HP-Models...
Page 670: Special Behavior Of Commands
R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.6 Special Behavior of Commands Command Known Differences ABORT Does not automatically set the command complete bit (bit 4) in the status byte. An additional DONE is required for that purpose.
Page 671 R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E Command Known Differences Supported bits: 1 (Units key pressed) 2 (End of Sweep) 3 (Device error) 4 (Command complete) 5 (Illegal command) SRCNORM Requires option R&S FSP-B9 or R&S FSP-B10 SRCPWR...
Page 672: Model-Dependent Default Settings
R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E 6.23.7 Model-Dependent Default Settings If the GPIB language is switched over to an 85xx model, the GPIB address will automatically be switched over to 18 provided that the default address of the R&S FSP (20) is still set.
Page 673: Trace Data Output Formats
R&S FSP Remote Control – Description of Commands GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E REMOTE state, the R&S FSP is reconfigured such that the number of test points (trace points) corre- sponds to that of the 85xx families (1001 for 8566A/B and 8568A/B, 601 for 8560E to 8565E, 401 for 8594E).
Page 674: Differences In Gpib Behavior Between The Fsp And The Fse Families Of Instruments
R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments 6.24 Differences in GPIB Behavior between the FSP and the FSE Families of Instruments The following list of commands contains the differences in syntax and behavior between the GPIB command set of the FSP and the FSE families of instruments.
Page 675 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 2 of 47) Parameter Notes R&S *TRG R&S FSP starts measurement in active screen FSE: starts measurement in both screens (split screen mode)
Page 676 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 3 of 47) Parameter Notes R&S CALCulate<1|2>:DELTamarker<1...4>:FUNCtion: <numeric_value> R&S FSP: marker 1 can FIXed:RPOint:X be moved independently from the reference point FSE: the marker and the reference point are...
Page 677 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 4 of 47) Parameter Notes R&S CALCulate<1|2>:DELTamarker<1...4>:TRACe 1 to 3 R&S FSP: 3 traces are available per screen; FSE: 4 traces are available in full screen mode and 2 traces per...
Page 678 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 5 of 47) Parameter Notes R&S CALCulate<1|2>:LIMit<1...8>:ACPower: -200 to 200 DBM, new function for ACHannel:ABSolute -200 to 200 DBM R&S FSP R&S CALCulate<1|2>:LIMit<1...8>:ACPower:...
Page 679 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 6 of 47) Parameter Notes CALCulate<1|2>:LIMit<1...8>:BURSt:POWer? not available for R&S FSP, FSET and ESIB CALCulate<1|2>:LIMit<1...8>:BURSt:PTEMplate? not available for R&S FSP, FSET and ESIB CALCulate:LIMit:CATalog?
Page 680 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 7 of 47) Parameter Notes R&S CALCulate<1|2>:LIMit<1...8>:LOWer[:DATA] <numeric value> CALCulate<1|2>:LIMit<1...8>:MARGin 0 to 100DB not available for R&S FSP, FSET and ESIB R&S...
Page 681 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 8 of 47) Parameter Notes FSET/ CALCulate<1|2>:LIMit<1...8>:UNIT DBM | DBPW | WATT | only the following units ESIB DBUV | DBMV | VOLT | are available for the...
Page 682 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 9 of 47) Parameter Notes CALCulate<1|2>:MARKer<1...4>:FUNCtion: not available for ADEMod:SINad:RESult? R&S FSP and FSET CALCulate<1|2>:MARKer<1...4>:FUNCtion: ON | OFF not available for ADEMod:SINad[:STATe] R&S FSP and FSET...
Page 683 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 10 of 47) Parameter Notes R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: NDBDown:RESult? R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: ON | OFF NDBDown:STATe R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: NOISe:RESult? R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion:...
Page 684 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 11 of 47) Parameter Notes R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: -330 to +30 dBm new function for STRack:THReshold R&S FSP R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: 1 to 3...
Page 685 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 12 of 47) Parameter Notes R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: SUMMary:PPEak: AVERage:RESult? R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: SUMMary:PPEak:PHOLd:RESult? R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: SUMMary:PPEak:RESult? R&S CALCulate<1|2>:MARKer<1...4>:FUNCtion: ON | OFF SUMMary:PPEak[:STATe]...
Page 686 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 13 of 47) Parameter Notes R&S CALCulate<1|2>:MARKer<1...4>:MAXimum: RIGHt R&S CALCulate<1|2>:MARKer<1...4>:MAXimum[: PEAK] R&S CALCulate<1|2>:MARKer<1...4>:MINimum:LEFT R&S CALCulate<1|2>:MARKer<1...4>:MINimum:NEXT R&S CALCulate<1|2>:MARKer<1...4>:MINimum:RIGHt R&S CALCulate<1|2>:MARKer<1...4>:MINimum[:...
Page 687 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 14 of 47) Parameter Notes R&S CALCulate<1|2>:MATH:MODE LINear | LOGarithmic affects all traces on the R&S FSP; therefore the numeric suffix : MATH<1...4>...
Page 688 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 15 of 47) Parameter Notes FSET/ CALCulate<1|2>:UNIT:POWer DBM | V | W | DB | PCT the R&S FSP supports ESIB | UNITLESS | DBPW |...
Page 689 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 16 of 47) Parameter Notes CONFigure:BURSt:POWer:COUNt 1 to 1000 not available for R&S FSP and FSET CONFigure:BURSt:POWer[IMMediate] not available for R&S FSP and FSET...
Page 690 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 17 of 47) Parameter Notes CONFigure[:BTS]:CHANnel:SLOT 0 to 7 not available for R&S FSP and FSET CONFigure[:BTS]:CHANnel:SLOT:AUTO ONCE not available for...
Page 691 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 18 of 47) Parameter Notes CONFigure[:BTS]MEASurement? not available for R&S FSP and FSET CONFigure[:MS]:ARFCn <numeric_value> not available for R&S FSP and FSET CONFigure[:MS]:ARFCn:AUTO ONCE...
Page 692 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 19 of 47) Parameter Notes CONFigure[:MS]MEASurement? not available for R&S FSP and FSET FSET DIAGnostic:INFO:CCOunt:ATTenuation? not available for R&S FSP DIAGnostic:INFO:CCOunt:ATTenuation<1 | 10>? not available for...
Page 693 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 20 of 47) Parameter Notes R&S DISPlay:CMAP<1...26>:HSL 0 to 1,0 to 1,0 to 1 larger selection of independently configurable items (1 to R&S...
Page 694 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 21 of 47) Parameter Notes DISPlay[:WINDow<1|2>]:TRACe<1...4>:X: LINear | LOGarithmic not available for SPACing R&S FSP DISPlay[:WINDow<1|2>]:TRACe<1...4>:X[: <numeric_value>...
Page 695 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 22 of 47) Parameter Notes R&S DISPlay[:WINDow<1|2>]:TRACe<1...3>[:STATe] ON | OFF R&S FSP: TRACe<1...3> FSE: TRACE<1...4> FETCh:BURSt:FERRor:AVERage? not available for R&S FSP and FSET FETCh:BURSt:FERRor:MAXimum?
Page 696 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 23 of 47) Parameter Notes FORMat[:DATA] ASCii | REAL | UINT UINT is not available for [,32] R&S FSP R&S...
Page 697 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 24 of 47) Parameter Notes HCOPy:ITEM:WINDow<1|2>:TRACe: ON | OFF not available for CAINcrement R&S FSP R&S HCOPy:ITEM:WINDow<1|2>:TRACe:STATe ON | OFF HCOPy:PAGE:DIMensions:FULL...
Page 698 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 25 of 47) Parameter Notes R&S INPut<1|2>:ATTenuation:AUTO:MODE NORMal | LNOise | not available for models LDIStorsion 3 and 7;...
Page 699 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 26 of 47) Parameter Notes FSET INPut<1|2>:PRESelection:COUPling:LOW: 10Hz to 5MHz not available for FREQuency R&S FSP FSET INPut<1|2>:PRESelection:COUPling:LOW:SET 'name of preselector set...
Page 700 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 27 of 47) Parameter Notes FSE/ INSTrument<1|2>[:SELect] SANalyzer | DDEMod | 5 parameters are FSIQ ADEMod | BGSM | available.
Page 701 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 28 of 47) Parameter Notes MMEMory:SELect[:ITEM]:CVL[:ACTive] ON | OFF not available for R&S FSP and FSET R&S MMEMory:SELect[:ITEM]:DEFault MMEMory:SELect[:ITEM]:GSETup...
Page 702 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 29 of 47) Parameter Notes READ:BURSt:FERRor:MAXimum? not available for R&S FSP and FSET READ:BURSt:FERRor:STATus? not available for R&S FSP and FSET READ:BURSt:PERRor:PEAK:AVERage? not available for...
Page 703 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 30 of 47) Parameter Notes [SENSe<1|2>:]AVERage:AUTO ON | OFF not available for R&S FSP R&S [SENSe<1|2>:]AVERage:COUNt 0 to 32767 [SENSe<1|2>:]AVERage:COUNt 0 to 32767...
Page 704 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 31 of 47) Parameter Notes R&S [SENSe<1|2>:]BANDwidth|BWIDth[:RESolution]: ON | OFF old command that is still MODE:FFT supported, but has been replaced on the R&S FSP by...
Page 705 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 32 of 47) Parameter Notes R&S [SENSe<1|2>:]CORRection:TRANsducer:ACTive? R&S [SENSe<1|2>:]CORRection:TRANsducer: CATalog? R&S [SENSe<1|2>:]CORRection:TRANsducer: <string> COMMent R&S [SENSe<1|2>:]CORRection:TRANsducer:DATA <freq>,<level>...
Page 706 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 33 of 47) Parameter Notes [SENSe<1|2>:]DDEMod:FILTer:REFerence RCOSine | RRCosine | not available for GAUSsian | B22 | B25 | R&S FSP B44 | QFM | QFR | QRM | QRR | A25Fm | EMES |...
Page 707 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 34 of 47) Parameter Notes [SENSe<1|2>:]DDEMod:PSK:NSTate 2 | 8 not available for R&S FSP [SENSe<1|2>:]DDEMod:QAM:NSTate not available for R&S FSP [SENSe<1|2>:]DDEMod:QPSK:FORMat NORMal | DIFFerential |...
Page 708 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 35 of 47) Parameter Notes R&S [SENSe<1|2>:]DETector<1...3>[:FUNCtion] APEak |NEGative | R&S FSP: number of POSitive | SAMPle | traces restricted to 3;...
Page 709 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 36 of 47) Parameter Notes R&S [SENSe<1|2>:]FREQuency:CENTer 0 to f frequency ranges are different for R&S FSP and FSE [SENSe<1|2>:]FREQuency:CENTer:LINK STARt | STOP | SPAN...
Page 710 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 37 of 47) Parameter Notes R&S [SENSe<1|2>:]LIST:POWer[:SEQuence] <analyzer freq>, new function for <ref level>, R&S FSP <rf att>, <el att>, <filter type>,...
Page 711 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 38 of 47) Parameter Notes R&S [SENSe<1|2>:]MPOWer[:SEQuence] <analyzer freq>, new function for <rbw>, R&S FSP <meas time>, <trigger source>, <trigger level>, <trigger offset>,...
Page 712 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 39 of 47) Parameter Notes R&S [SENSe<1|2>:]POWer:ACHannel:REFerence: ONCE AUTO R&S [SENSe<1|2>:]POWer:ACHannel:SPACing[: 100Hz to 2000MHz different parameter ACHannel] range R&S...
Page 713 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 40 of 47) Parameter Notes ESIB [SENSe<1|2>:]SCAN<1...10>:INPut:GAIN[: ON | OFF not available for STATE] R&S FSP ESIB [SENSe<1|2>:]SCAN<1...10>:INPut:TYPE INPUT1 | INPUT2...
Page 714 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 41 of 47) Parameter Notes R&S [SENSe<1|2>:]SWEep:TIME 2.5ms to 1000s | 1µs to different parameter 16000s ranges for R&S FSP and R&S [SENSe<1|2>:]SWEep:TIME:AUTO...
Page 715 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 42 of 47) Parameter Notes R&S STATus:OPERation:PTRansition 0 to 65535 R&S STATus:OPERation[:EVENt?] R&S STATus:PRESet R&S STATus:QUEStionable:ACPLimit:CONDition? R&S STATus:QUEStionable:ACPLimit:ENABle 0 to 65535...
Page 716 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 43 of 47) Parameter Notes R&S STATus:QUEStionable:LMARgin<1|2>:ENABle 0 to 65535 R&S FSP: individual registers for screen A and B R&S STATus:QUEStionable:LMARgin<1|2>:...
Page 717 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 44 of 47) Parameter Notes R&S STATus:QUEue[:NEXT?] SYSTem:BINFo? not available for R&S FSP R&S SYSTem:COMMunicate:GPIB:RDEVice: 0 to 30 new command for GENerator<1|2>:ADDRess R&S FSP...
Page 718 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 45 of 47) Parameter Notes R&S SYSTem:ERRor[:NEXT]? new function for R&S FSP, but compatible to SYSTem: ERRor? on the FSE R&S SYSTem:ERRor:LIST?
Page 719 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 46 of 47) Parameter Notes R&S TRACe:IQ:SET <filter type>, new function for <rbw>, R&S FSP <sample rate>, <trigger source>, <trigger slope>, <pretrigger samples>,...
Page 720 R&S FSP Remote Control – Description of Commands Differences in GPIB Behavior between the FSP and the FSE Families of Instruments Devices Command (Sheet 47 of 47) Parameter Notes FSE/ TRIGger<1|2>[:SEQuence]:SYNChronize:ADJust: 0 to 100s not available for ESIB FRAMe R&S FSP TRIGger<1|2>[:SEQuence]:SYNChronize:ADJust: ONCE not available for...
Page 721 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands 6.25 Alphabetical List of Remote Commands Command Parameter Page CALCulate<1|2>:DELTamarker<1...4>: 6.14 AOFF CALCulate<1|2>:DELTamarker<1...4>: 6.17 MAXimum:NEXT CALCulate<1|2>:DELTamarker<1...4>[: 6.19 STATe] *CAL? *CLS *ESE 0 to 255 *ESR? *IDN? *IST? *OPC *OPC? *OPT?
Page 722 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page CALCulate<1|2>:ESPectrum:PSEarch | PEAKsearch:MARGin -200dB … +200dB 6.23 CALCulate<1|2>:FLINe<1|2> 0 to fmax 6.24 CALCulate<1|2>:FLINe<1|2>:STATe ON | OFF 6.24 CALCulate<1|2>:LIMit<1...8>:ACPower:ACHannel:ABSolute -200DBM to 200DBM, -200 to 200DBM 6.30 CALCulate<1|2>:LIMit<1...8>:ACPower:ACHannel:ABSolute:STATe ON | OFF...
Page 723 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page CALCulate<1|2>:MARKer<1...4>:FUNCtion:CENTer 6.54 CALCulate<1|2>:MARKer<1...4>:FUNCtion:CSTep 6.54 CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:CONTinuous ON | OFF 6.54 CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:HOLDoff 10ms to 1000s 6.55 CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:SELect AM | FM 6.55 CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:SQUelch: 0 to 100 PCT 6.55 LEVel CALCulate<1|2>:MARKer<1...4>:FUNCtion:DEModulation:SQUelch[:...
Page 724 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page CALCulate<1|2>:MARKer<1...4>:FUNCtion:STRack[:STATe] ON | OFF 6.78 CALCulate<1|2>:MARKer<1...4>:FUNCtion:STRack:THReshold -330dBm to +30dBm 6.79 CALCulate<1|2>:MARKer<1...4>:FUNCtion:STRack:TRACe 1 to 3 6.79 CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:AOFF 6.80 CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:AVERage ON | OFF 6.80 CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:MEAN:AVERage: 6.80 RESult? CALCulate<1|2>:MARKer<1...4>:FUNCtion:SUMMary:MEAN:PHOLd: 6.81...
Page 725 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page CALCulate<1|2>:MARKer<1...4>:X:SLIMits[:STATe] ON | OFF 6.52 CALCulate<1|2>:MARKer<1...4>:Y:PERCent 0 to100% 6.52 CALCulate<1|2>:MARKer<1...4>:Y? 6.53 CALCulate<1|2>:MATH[:EXPression][:DEFine] (<expr>) 6.90 CALCulate<1|2>:MATH:MODE LINear | LOGarithmic | POWer 6.90 CALCulate<1|2>:MATH:POSition -100PCT to 200PCT 6.90 CALCulate<1|2>:MATH:STATe ON | OFF...
Page 726 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page DISPlay:PSAVe[:STATe] ON | OFF 6.108 DISPlay[:WINDow<1|2>]:ACTive? 6.109 DISPlay[:WINDow<1|2>]:SELect 6.109 DISPlay[:WINDow<1|2>]:SIZE LARGe | SMALl 6.109 DISPlay[:WINDow<1|2>]:TEXT[:DATA] <string> 6.110 DISPlay[:WINDow<1|2>]:TEXT:STATe ON | OFF 6.110 DISPlay[:WINDow<1|2>]:TIME ON | OFF 6.110 DISPlay[:WINDow<1|2>]:TRACe<1...3>:MODE WRITe | VIEW | AVERage | MAXHold |...
Page 727 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page INSTrument[:SELect] SANalyzer | ADEMod | BTOoth 6.128 MMEMory:CATalog:LONG? <path> 6.129 MMEMory:CATalog? <path> 6.130 MMEMory:CDIRectory <directory_name> 6.130 MMEMory:CLEar:ALL 6.130 MMEMory:CLEar:STATe 1,<file_name> 6.131 MMEMory:COMMent <string> 6.131 MMEMory:COPY <file_source>,<file_destination>...
Page 728 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page [SENSe<1|2>:]CORRection:CVL:SELect <file_name> 6.152 [SENSe<1|2>:]CORRection:CVL:SNUMber <string> 6.152 [SENSe<1|2>:]CORRection:METHod TRANsmission | REFLection 6.152 [SENSe<1|2>:]CORRection:RECall 6.153 [SENSe<1|2>:]CORRection[:STATe] ON | OFF 6.153 [SENSe<1|2>:]CORRection:TRANsducer:ACTive? 6.153 [SENSe<1|2>:]CORRection:TRANsducer:ADJust:RLEVel[:STATe] ON | OFF 6.153 [SENSe<1|2>:]CORRection:TRANsducer:CATalog? 6.154...
Page 729 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page [SENSe<1|2>:]FREQuency:SPAN:FULL 6.168 [SENSe<1|2>:]FREQuency:STARt 0 to fmax 6.168 [SENSe<1|2>:]FREQuency:STOP 0 to fmax 6.169 [SENSe<1|2>:]LIST:POWer:RESult? 6.171 [SENSe<1|2>:]LIST:POWer[:SEQuence] <analyzer freq>,<ref level>,<rf att>,<el 6.171 att>, <filter type>, <rbw>, <vbw>, <meas time>,<trigger level>...
Page 730 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page [SENSe<1|2>:]POWer:ACHannel:FILTer:ALPHa:ACHannel 0…1 6.191 [SENSe<1|2>:]POWer:ACHannel:FILTer:ALPHa:ALL 0…1 6.191 [SENSe<1|2>:]POWer:ACHannel:FILTer:ALPHa:ALTernate<1...11> 0…1 6.191 [SENSe<1|2>:]POWer:ACHannel:FILTer:ALPHa:CHANnel<1...12> 0…1 6.192 [SENSe<1|2>:]POWer:ACHannel:FILTer:STATe:ACHannel ON | OFF 6.192 [SENSe<1|2>:]POWer:ACHannel:FILTer:STATe:ALL ON | OFF 6.192 [SENSe<1|2>:]POWer:ACHannel:FILTer:STATe:ALTernate<1...11> ON | OFF 6.192 [SENSe<1|2>:]POWer:ACHannel:FILTer:STATe:CHANnel<1...12>...
Page 731 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page SOURce<1|2>:EXTernal<1|2>:POWer[:LEVel] <numeric_value> 6.211 SOURce<1|2>:EXTernal<1|2>:ROSCillator[:SOURce] INTernal | EXTernal 6.212 SOURce<1|2>:EXTernal<1|2>[:STATe] ON | OFF 6.212 SOURce<1|2>:FM:DEViation 100Hz to 10MHz 6.207 SOURce<1|2>:FM:STATe ON | OFF 6.208 SOURce<1|2>:FREQuency:OFFSet -150MHz to 150MHz 6.208 SOURce<1|2>:POWer[:LEVel][:IMMediate][:AMPLitude]...
Page 732 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page SYSTem:COMMunicate:PRINter:SELect <1|2> <printer_name> 6.223 SYSTem:COMMunicate:RDEVice:GENerator<1|2>:LINK GPIB | TTL 6.224 SYSTem:COMMunicate:RDEVice:GENerator<1|2>:TYPE <name> 6.224 SYSTem:COMMunicate:SERial:CONTrol:RTS IBFull | OFF 6.225 SYSTem:COMMunicate:SERial[:RECeive]:BAUD 110 | 300 | 600 | 1200 | 2400 | 9600 | 19200 6.225 | 38400 | 57600 | 115200 | 128000 SYSTem:COMMunicate:SERial[:RECeive]:BITS...
Page 733 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands Command Parameter Page TRIGger<1|2>[:SEQuence]:LEVel[:EXTernal] 0.5 to +3.5 V 6.248 TRIGger<1|2>[:SEQuence]:LEVel:IFPower -30 to –10 dBm 6.248 TRIGger<1|2>[:SEQuence]:LEVel:RFPower -50 to –10 dBm 6.249 TRIGger<1|2>[:SEQuence]:LEVel:VIDeo 0 to 100PCT 6.249 TRIGger<1|2>[:SEQuence]:SLOPe POSitive | NEGative 6.249 TRIGger<1|2>[:SEQuence]:SOURce...
Page 734 R&S FSP Remote Control – Description of Commands Alphabetical List of Remote Commands 6.340 Operating Manual 1164.4556.12 - 06...
Page 735 R&S FSP Remote Control – Programming Examples 7 Remote Control – Programming Examples 7.1 Introduction ..........7.2 7.2 Basic Programming Steps for the VISA Interface .
Page 736: Remote Control - Programming Examples
R&S FSP Remote Control – Programming Examples Introduction 7.1 Introduction The following programming examples have a hierarchical structure, i.e. subsequent examples are based on previous ones. It is thus possible to compile very easily an operational program from the modules of the given examples. VISUAL BASIC has been used as programming language.
Page 737 R&S FSP Remote Control – Programming Examples Basic Programming Steps for the VISA Interface 7.2.1.1 Initiate Service Request REM ---- Example of initialization of the SRQ in the case of errors -------- PUBLIC SUB SetupSRQ() status = viWrite(analyzer, "*CLS", 4, retCnt) ’Reset status reporting system status = viWrite(analyzer, "*SRE 168", 8, retCnt) 'Permit service request for STAT:OPER,STAT:QUES and ESR registe...
Page 738 R&S FSP Remote Control – Programming Examples Basic Programming Steps for the VISA Interface Non-blocking (user inputs possible) This method is recommended if the waiting time until the event to be signalled by an SRQ is long (longer than the selected time-out), and user inputs should be possible during the waiting time, or if the event is not certain to occur.
Page 739 R&S FSP Remote Control – Programming Examples Basic Programming Steps for the VISA Interface The following programming example describes the Hold() function, which returns control to the operating system for the period of the waiting time selectable in milli- seconds. Rem ********************************************************************** Rem The waiting function below expects the transfer of the desired Rem waiting time in milliseconds.
Page 740 R&S FSP Remote Control – Programming Examples Basic Programming Steps for the VISA Interface 7.2.1.5 Evaluation of SCPI Status Registers REM ------ Subroutine for evaluating Questionable Status Register --------- Public SUB Questionablestatus() Ques$ = SPACE$(20) 'Preallocate blanks to text variable status = viWrite(analyzer, "STATus:QUEStionable:EVENt?", 26, retCnt) status = viRead(analyzer, Ques$, 20, retCnt) PRINT "Questionable Status: ";...
Page 741: More Complex Programming Examples
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3 More Complex Programming Examples In this section, the more advanced programming examples are included: • “Using Marker and Delta Marker” on page 7.7 • “Limit Lines and Limit Test” on page 7.12 •...
Page 742 R&S FSP Remote Control – Programming Examples More Complex Programming Examples status = viWrite(analyzer, "CALC:MARK:X:SLIM:LEFT 99.6MHz;RIGHt 100.4MHz", 44, retCnt) 'Activate search limit and set to ±400 kHz about center frequency status = viWrite(analyzer, "CALC:THR:STAT ON", 16, retCnt) status = viWrite(analyzer, "CALC:THR -60DBM", 15, retCnt) 'Activate threshold and set to –60 dBm '--------- Activate search for spurious --------------------- status = viWrite(analyzer, "CALC:MARK:FUNC:FPE:SORT X", 25, retCnt)
Page 743 R&S FSP Remote Control – Programming Examples More Complex Programming Examples 'Single sweep '--------- Set frequency ------------------------------------ status = viWrite(analyzer, "FREQ:SPAN 1MHz", 14, retCnt) 'Span status = viWrite(analyzer, "BAND:RES 30kHz", 14, retCnt) 'Resolution bandwidth status = viWrite(analyzer, "INIT;*WAI", 9, retCnt) 'Perform sweep with sync '--------- Measure 60 dB value ------------------------------ status = viWrite(analyzer, "CALC:MARK:PEXC 6DB", 18, retCnt)
Page 744 R&S FSP Remote Control – Programming Examples More Complex Programming Examples The following example is based on two adjacent signals with a level of –30 dBm at 100 MHz and 110 MHz. The intermodulation products lie at 90 MHz and 120 MHz according to the above formula.
Page 745 R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.1.4 Measuring the AM Modulation Depth The example below is based on an AM-modulated signal at 100 MHz with the fol- lowing characteristics: • Carrier signal level: –30 dBm •...
Page 746: Limit Lines And Limit Test
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.2 Limit Lines and Limit Test The example below shows the definition and use of a new limit line 5 for trace 1 on screen A and trace 2 on screen B with the following characteristics: •...
Page 747 R&S FSP Remote Control – Programming Examples More Complex Programming Examples '--------- Definition of data points and threshold ---------- xlimit$ = "CALC:LIM5:CONT 120MHZ,126MHZ,127MHZ,128MHZ,129MHZ,130MHz,136MHz" status = viWrite(analyzer, xlimit$, 63, retCnt) 'Set values for x-axis status = viWrite(analyzer, "CALC:LIM5:UPP -70,-40,-40,-20,-40,-40,-70", 41, retCnt) 'Set values for y-axis status = viWrite(analyzer, "CALC:LIM5:UPP:THR -75DBM", 24, retCnt) 'Set y threshold (only possible for relative y-axis)
Page 748: Measuring The Channel And Adjacent Channel Power
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.3 Measuring the Channel and Adjacent Channel Power In the following example, the channel and adjacent channel power is first measured on a signal with a level of 0 dBm at 800 MHz to IS95. Then the channel and adjacent channel power is measured on a GSM signal at 935.2 MHz with fast ACP measure- ment (FAST ACP).
Page 749 R&S FSP Remote Control – Programming Examples More Complex Programming Examples '--------- Read out result ---------------------------------- Print "Result (CP, ACP low, ACP up, Alt low, Alt up): " Print result$ '--------- Example 2: Configure CP/ACP manually for GSM ---- result$ = Space$(100) status = viWrite(analyzer, "FREQ:CENT 935.2MHz", 18, retCnt) 'Set frequency status = viWrite(analyzer, "CALC:MARK:FUNC:POW:SEL ACP", 26, retCnt)
Page 750: Occupied Bandwidth Measurement
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 'Query result of status = viRead(analyzer, result$, 100, retCnt) 'limit check '--------- Read out result --------------------------------- Print "Result Limit Check: "; result$ END SUB REM ************************************************************************ 7.3.4 Occupied Bandwidth Measurement In the following example, the bandwidth is to be found in which 95% of the power of a GSM signal is contained.
Page 751: Time Domain Power Measurement
R&S FSP Remote Control – Programming Examples More Complex Programming Examples status = viRead(analyzer, result$, 100, retCnt) Print result$ END SUB REM ************************************************************************ 7.3.5 Time Domain Power Measurement In the following example, the mean carrier power of a signal with 300 kHz bandwidth at 100 MHz is to be determined.
Page 752: Fast Power Measurement On Power Ramps
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 'RMS measurement query$ = query$ + ":CALC:MARK:FUNC:SUMM:SDEV:RES?" 'Standard deviation status = viWrite(analyzer, query$, 120, retCnt) status = viRead(analyzer, result$, 100, retCnt) Print result$ END SUB REM ************************************************************************ 7.3.6 Fast Power Measurement on Power Ramps A frequent task in mobile radio tests is measurement of a DUT at various power con- trol levels at the highest possible speed.
Page 753 R&S FSP Remote Control – Programming Examples More Complex Programming Examples REM ************************************************************************ Public Sub MultiSumMarker() result$ = Space$(200) '--------- R&S FSP default setting--------------------------- CALL SetupStatusReg 'Configure status register status = viWrite(analyzer, "*RST", 4, retCnt 'Reset instrument status = viWrite(analyzer, "INIT:CONT OFF", 13, retCnt) 'Single sweep mode status = viWrite(analyzer, "SYST:DISP:UPD ON", 16, retCnt) 'ON:...
Page 754 R&S FSP Remote Control – Programming Examples More Complex Programming Examples REM ************************************************************************ 7.3.6.2 Multi-Burst Power Measurement The multi-burst power measurement function is suitable for measuring the power of a sequence of pulses with the following characteristics: • The pulses occur at variable time intervals. •...
Page 755 R&S FSP Remote Control – Programming Examples More Complex Programming Examples During the measurement, each pulse is mapped into a pixel of the screen, i.e. any change of the trace can be detected only at the left-hand edge of the screen. Maxi- mum measurement speed is as usual achieved with the display switched off.
Page 756: Fast Level Measurement Using Frequency Lists
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.7 Fast Level Measurement Using Frequency Lists A typical task for the R&S FSP is power measurement at a number of frequency points, e.g. at multiples of the fundamental (harmonics measurement), or at frequen- cies defined by a mobile radio standard (e.g.
Page 757 R&S FSP Remote Control – Programming Examples More Complex Programming Examples REM ************************************************************************ Public Sub FrequencyList() result$ = Space$(500) '--------- R&S FSP default setting ------------------------- CALL SetupStatusReg 'Configure status register status = viWrite(analyzer, "*RST", 4, retCnt) 'Reset instrument status = viWrite(analyzer, "INIT:CONT OFF", 13, retCnt) 'Single sweep mode status = viWrite(analyzer, "SYST:DISP:UPD OFF", 17, retCnt) 'Display off...
Page 758: Level Correction Of Transducers (Definition Of Transducer Factors)
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.8 Level Correction of Transducers (Definition of Transducer Fac- tors) In more complex test systems, the frequency response of the test setup must be taken into account in all power measurements to avoid any measurement errors being introduced from sources other than the DUT.
Page 759: Measuring The Magnitude And Phase Of A Signal (I/Q Data Acquisition)
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.9 Measuring the Magnitude and Phase of a Signal (I/Q Data Acquisition) Due to the R&S FSP's internal architecture, it is capable of measuring and output- ting the magnitude and phase of a signal in addition to its power values. This opens up a variety of possibilities for more in-depth analysis (FFT, demodulation, etc.).
Page 760 R&S FSP Remote Control – Programming Examples More Complex Programming Examples '(= 25*2*1024 bytes) result$ = Space$(100) 'Buffer for simple results '--------- R&S FSP default setting --------------------------------------- CALL SetupInstrument 'Default setting status = viWrite(analyzer, "TRAC:IQ:STAT ON", 15, retCnt) 'Activate I/Q data acquisition mode; must be done before 'TRAC:IQ:SET ! 'Select number of test points (= 128 * 1024 –...
Page 761: Averaging I/Q Data
R&S FSP Remote Control – Programming Examples More Complex Programming Examples status = viRead(analyzer, result$, 6553600, retCnt) status = viWrite(analyzer, "TRAC:IQ:STAT OFF", 16, retCnt) 'Stop I/Q data aquisition mode if no further measurements are 'to be done END SUB REM ************************************************************************ 7.3.10 Averaging I/Q Data ---''''''''...
Page 762: Reading And Writing Files
R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.11 Reading and Writing Files 7.3.11.1 Reading a File from the Instrument In the following example, file TEST1.SET stored under D:\USER\DATA is read from the instrument and stored in the controller. REM ************************************************************************ Public Sub ReadFile() '--------- Generate variables ------------------------------...
Page 763 R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.3.11.2 Creating a File on the Instrument In the following example, the TEST1.SET file available on the controller is stored in the instrument under D:\USER\DATA\DUPLICAT.SET. REM ************************************************************************ Public Sub WriteFile() '--------- Generate variables ------------------------------- FileBuffer$ = Space$(100000) 'Buffer for file...
Page 764 R&S FSP Remote Control – Programming Examples More Complex Programming Examples 7.30 Operating Manual 1164.4556.12 - 06...
Page 765: Maintenance And Instrument Interfaces
R&S FSP Maintenance and Instrument Interfaces Introduction 8 Maintenance and Instrument Inter- faces 8.1 Introduction ..........8.1 8.2 Maintenance .
Page 766: Maintenance
R&S FSP Maintenance and Instrument Interfaces Maintenance 8.2 Maintenance 8.2.1 Storing and Packing For the storage temperature range of the R&S FSP, see the instrument specifica- tions. When stored for an extended period of time the instrument should be pro- tected against dust.
Page 767: 1Interface Characteristics
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces 8.3.1.1 Interface Characteristics • 8-bit parallel data transfer • bi-directional data transfer • three-line handshake • high data transfer rate • up to 15 instruments can be connected • maximal length of the interconnecting cables 15 m (single connection, 2m) •...
Page 768: 3Interface Functions
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces Handshake bus with three lines. DAV (Data Valid), active low signals a valid data byte on the data bus. NRFD (Not Ready For Data), active low signals that one of the devices connected is not ready for data transfer. NDAC (Not Data Accepted), active low as long as the device connected is accepting the data present on the data bus.
Page 769: Printer Interface (Lpt)
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces Command QuickBASIC command Effect on the instrument DCL (Device Clear) IBCMD (controller%, CHR$(20)) Aborts the processing of the commands just received and sets the command processing software to a defined initial state. Does not change the instrument settings.
Page 770 R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces Signal Input (I) Description Output (O) STROBE Pulse for transmitting a data byte, min. 1µs pulse width (active LOW) Data Line 0 Data Line 1 Data Line 2 Data Line 3 Data Line 4 Data Line 5 Data Line 6 Data Line 7...
Page 771: Rs-232-C Interface (Com)
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces 8.3.3 RS-232-C Interface (COM) The standard R&S FSP is equipped with a RS-232-C serial interface. The interface can be set up and activated manually in the SETUP-GENERAL SETUP menu in the COM INTERFACE table (selection OWNER = INSTRUMENT) for remote control. For details on the connector refer to the Quick Start Guide, chapter 1.
Page 772: 3Transmission Parameters
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces • Interface ground, connected to instrument ground • DSR (Data Set Ready) Input, active LOW, Indicates that the remote station is ready to receive data. • RTS (Request To Send) Output, active LOW. Indicates that the local terminal wants to transmit data.
Page 773: 4Control Characters
R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces 8.3.3.4 Control Characters For interface control, several strings are defined and control characters are reserved which are based upon GPIB control. Control string or character Function '@REM' Switch over to remote '@LOC' Switch over to local '@SRQ' Service Request SRQ (SRQ is sent by the instrument)
Page 774 R&S FSP Maintenance and Instrument Interfaces Instrument Interfaces Hardware handshake For hardware handshake, the instrument indicates that it is ready to receive data via the lines DTR and RTS. A logic '0' on both lines means 'ready' and a logic '1' means 'not ready'.
Page 775: Error Messages
R&S FSP Error Messages 9 Error Messages 9.1 Introduction ..........9.2 9.2 SCPI-Specific Error Messages .
Page 776: Introduction
R&S FSP Error Messages Introduction 9.1 Introduction Error messages are entered in the error/event queue of the status reporting system in the remote control mode and can be queried with the command SYSTem: ERRor?. The answer format of R&S FSP to the command is as follows: <error code>, "<error text with queue query>;...
Page 777 R&S FSP Error Messages SCPI-Specific Error Messages 9.2 SCPI-Specific Error Messages Error code Error text in the case of queue poll Error explanation No error This message is output if the error queue does not contain any entries. Error code Error text in the case of queue poll Error explanation -100...
Page 778 R&S FSP Error Messages SCPI-Specific Error Messages Error code Error text in the case of queue poll Error explanation -114 Header suffix out of range The header contains an invalid numeric suffix. Example: SENSe3 does not exist in the instrument. -120 Numeric data error The command contains a faulty numeric parameter.
Page 779 R&S FSP Error Messages SCPI-Specific Error Messages Error code Error text in the case of queue poll Error explanation -158 String data not allowed The command contains a valid string at a position which is not allowed. Example: A text parameter is set in quotation marks, INPut:COUPling "DC" -160 Block data error The command contains faulty block data.
Page 780 R&S FSP Error Messages SCPI-Specific Error Messages Error code Error text in the case of queue poll Error explanation -214 Trigger deadlock The trigger source for the initiation of measurement is set to GET and subsequent measurement is received. The measurement cannot be started until a GET is received, but the GET would cause an interrupted-error) -215 Arm deadlock...
Page 781 R&S FSP Error Messages SCPI-Specific Error Messages Error code Error text in the case of queue poll Error explanation -254 Media full The media is full. Example: There is no space on the floppy. -255 Directory full The media directory is full. -256 File name not found The file name cannot be found on the media.
Page 782 R&S FSP Error Messages Device-Specific Messages Error code Error text in the case of queue poll Error explanation -420 Query UNTERMINATED The query is incomplete. Example: The instrument is addressed as a talker and receives incomplete data. -430 Query DEADLOCKED The query cannot be processed.
Page 783 R&S FSP Index Index Symbols bandwidth ..4.92, 4.103, 4.116 number ....4.91, 4.92 * (enhancement label) ... . . 4.40 power .
Page 784 R&S FSP Index resolution bandwidth ... 4.21 External Generator (R&S FSP-B10 option) sweep time....4.21 4.226 video bandwidth .
Page 785 R&S FSP Index measurement ....4.120 ACP measurement ... . . 4.97 Header ......5.10 Limit line Horizontal sync signal .
Page 786 R&S FSP Index signal/noise power density (C/No) of an service functions....4.189 IS95 CDMA signal ... . 4.102 Path.
Page 787 R&S FSP Index Reflection measurement ..4.219, 4.233 Setup......4.163 Remote commands general .
Page 788 R&S FSP Index CAL RESULTS... 4.50, 6.100 DELETE VALUE ....4.155 CAL TOTAL ... . . 4.49, 6.100 DESC .
Page 789 R&S FSP Index GEN REF INT/EXT ... 4.244 MIXER LOW NOISE... . 4.17 GENERAL SETUP... . 4.172 MKR DEMOD ON/OFF.
Page 790 R&S FSP Index POWER OFFSET . 4.213, 4.227, 6.209 SCREEN COLORS ... 4.206 POWER ON/OFF 4.77, 6.80, 6.82, 6.85, SCREEN TITLE ..4.160, 6.110 6.87, 6.89 SEARCH LIMIT OFF .
Page 791 R&S FSP Index SWEEP COUNT ..4.28, 4.40, 6.201 Y OFFSET ..4.150, 6.40, 6.43 SWEEP LIST4.123, 4.140, 6.175, 6.176, Y-AXIS MAX VALUE..4.110, 6.96 6.177, 6.178, 6.179 Y-AXIS MIN VALUE .
Page 792 R&S FSP Index gated ....4.31, 4.32 max hold ..... 4.38 range .
Page 793 R&S FSP Index Operating Manual 1164.4556.12 - 06 4.11...
Page 794 R&S FSP 4.12 Operating Manual 1164.4556.12 - 06...
Page 795 R&S FSP Operating Manual 1164.4556.12 - 06 4.13...
Page 796 R&S FSP 4.14 Operating Manual 1164.4556.12 - 06...

This manual is also suitable for:

R&s fsp31 R&s fsp40 R&s fsp-b6 R&s fsp3 R&s fsp-b9 R&s fsp-b10 ... Show all

Save PDF
