Display Panel and Keypad
The main interface to Prodigy Plus is the Display Panel and
Keypad (see
Figure
Display Panel
Context-sensitive
displays
Figure 5: Prodigy Plus display panel and keypad
The display panel and keypad is very easy to use. It consists of a
larger multiple-line LCD display on top, and four single-line context-
sensitive displays, each with one button (or key). The top line in the
large display always reveals the machine status. The lower three
lines show details related to the current operation.
Normally there will be an item blinking in the lower (context-
sensitive) displays. This item is usually the most logical selection.
5).
Operation
Keypad
buttons
Prodigy Plus User Guide
