  • Page 1 User Guide English Stratasys P750K 3D Printer System...
  • Page 3 The text and drawings herein are for illustration and reference only. The specifications on which they are based are subject to change. Stratasys Ltd. may, at any time and without notice, make changes to this document. Stratasys Ltd., for itself and on behalf of its subsidiaries, assumes no liability for...
  • Page 4 This product is covered by one or more of the following U.S. patents: 5,386,500 6,259,962 6,569,373 6,658,314 6,850,334 7,183,335 7,209,797 7,225,045 7,364,686 7,369,915 7,479,510 7,500,846 7,604,768 7,628,857 7,658,976 7,725,209 Stratasys Ltd. http://www.stratasys.com DOC 08010 Revision A (DRAFT 1a) June 2015...

  • Page 5: Table Of Contents

    Converting CAD Files to SLC Format ..................... 3–8 Objet Studio Software ........................3–9 4 Installing Objet Software How to Install Software for the Stratasys 3D Printing System ........... 4–2 How to Uninstall Objet Studio......................4–6 DOC08010 Rev. A (DRAFT 1)
  • Page 6 Stratasys P750K User Guide 5 Using Objet Studio Launching Objet Studio ........................5–3 Windows® 7 Security Warning......................5–3 Objet Studio Interface ......................... 5–4 Ribbon Commands..........................5–6 Objet Studio Commands Menu......................5–8 Model Tree Pane ..........................5–8 Preparing Models for Production....................5–9 OBJDF Files: Overview ........................
  • Page 7 Job Manager Commands ......................... 5–73 Configuring User Alerts........................5–76 Printing the Tray ..........................5–77 Additional Server Features......................5–77 6 Operating & Maintaining the Stratasys P750K 3D Printer Starting the Printer ..........................6–2 Loading Model and Support Cartridges ..................6–4 Producing Models..........................6–5 Preparing the Printer ..........................
  • Page 8 Stratasys P750K User Guide Post Printing Treatment for Models Printed with Objet VeroClear........... 7–4 Photo Bleaching Instructions......................7–4 Storing Models ........................... 7–5 viii...

  • Page 9: About This Guide

    About This Guide Using This Guide................. 2 For More Information ................. 2 Terms Used in This Guide..............3 1–1 DOC08010 Rev. A (DRAFT 1)

  • Page 10: Using This Guide

    Visit http://www.stratasys.com/ for more details about Objet printer technology, products and consumables, and for service and support contacts. For other documents that relate to Stratasys P750K 3D printing systems, and for this document in other languages, contact your regional Stratasys Customer Support office.

  • Page 11: Terms Used In This Guide

    Connex™ The technology of printing models by jetting multiple materials simultaneously from the print heads. This technology enables Stratasys P750K printers to print in Digital Material mode. Digital Material™ Combinations of model materials fabricated in the printer from the two basic model materials installed.
  • Page 12 The base substance from which photopolymer printing materials are made for use in Stratasys printers. In Objet Studio and printer application screens, “resin” refers to cartridges of model and support materials. A file type used with Objet software. (These files are bitmaps of individual slices of the object.

  • Page 13: Safety

    Safety Safety Features..................... 2 Symbols and Warning Labels ..............3 Safety Guidelines..................4 Printer Installation ..................4 Printer Operation ................... 4 UV Radiation ....................4 Printer Maintenance ..................4 Model and Support Materials ..............5 UV Lamps......................5 First Aid for Working with Printing Materials ........6 Waste Disposal.....................

  • Page 14: Safety Features

    UV screen If the Stratasys 3D printing system is not used as specified in this guide, the safety features may not provide adequate protection. 2–2 DOC08010 Rev. A (DRAFT 1)

  • Page 15: Symbols And Warning Labels

    Stratasys P750K User Guide Symbols and Warning Labels This following table lists the warning labels located on or in Stratasys printers. Warning Meaning Location Comments Symbol Hazard On the name plate Read the instructions (general) on the back of the in this document printer.

  • Page 16: Safety Guidelines

    The UV lamps used in the printer emit dangerous radiation. If the UV lamps remain on when the printer is open, do not stare directly at the UV light. Shut down the printer and call your Stratasys service provider. Printer...

  • Page 17: Model And Support Materials

    Materials model and support materials used by the Stratasys system are handled in sealed cartridges. Normally, operators of the printer should never be directly exposed to hazardous materials. In the unlikely event of a leak or spill, follow the instructions that are included with the printing material cartridge used.

  • Page 18: First Aid For Working With Printing Materials

    Safety First Aid for Working with Printing Materials In general, try to avoid direct contact with uncured printing material. If skin or eyes come into contact with it, wash the area immediately and thoroughly with water, and follow these first aid instructions. The Material Safety Data Sheet (MSDS) that accompanies printing materials contains important safety information.

  • Page 19: Waste Disposal

    However, special care is required when handling printer waste (uncured printing material). Printing Materials When removing the waste container from the Stratasys printer, wear neoprene or nitrile gloves. To prevent liquid waste from splashing into the eyes, wear safety goggles.
  • Page 20 Safety 2–8 DOC08010 Rev. A (DRAFT 1)

  • Page 21: Introducing The Stratasys P750K 3D Printing System

    Introducing the Stratasys P750K 3D Printing System Welcome to Connex ..................2 Work Configurations .................. 2 Source Files....................3 STL Files ......................3 SLC Files ......................3 Connex Workflows..................4 Printing Materials..................5 Storage ......................5 Shelf Life ......................5 Exposure to Light ...................

  • Page 22: Welcome To Connex

    Figure 3-1: The Stratasys P750K 3D Printer Work Configurations The Stratasys 3D printing system can be set up as a single station system or as a multi station system. When connected to a local computer network, the system can serve multiple users. In such configurations, each user workstation (client) prepares files with Objet Studio software for production.

  • Page 23: Source Files

    The result is that high quality object descriptions mean very heavy files. Most CAD software can export STL files. The Stratasys system utilizes these files for building models (rapid prototyping), and also for directly making molds for mass producing items.

  • Page 24: Connex Workflows

    Introducing the Stratasys P750K 3D Printing System Connex Workflows With Connex 3D printing systems, you have great flexibility in preparing model files and printing them. Below are the major workflows you can use. Detailed instructions for implementing the listed tasks are in chapter 5 (“Using Objet Studio”).

  • Page 25: Printing Materials

    For up-to-date information about PolyJet printing materials and their properties, go to http://www.stratasys.com/materials/polyjet. Storage Materials used for printing models with Stratasys printers are made of resins, which are composed of reactive monomers and oligomers. Although printing materials are supplied in sealed, UV proof cartridges, care must be taken when storing and handling them.

  • Page 26: Safety Considerations

    Work Environment Extreme heat and humidity conditions can adversely affect the operation of the Stratasys 3D printer. Use ventilation or air conditioning systems, if necessary, to keep the work area within the following ranges: • 18 –25 C (64 –77 F) •...

  • Page 27: Workstation Requirements

    2. A 64 bit operating system is recommended, to utilize 8 GB of memory. Objet Studio running on a 32 bit application can utilize only 4 GB of memory. 3. The following graphics cards were tested in Stratasys labs: ® ®...

  • Page 28: Preparing Files For Use With Objet 3D Printing Systems

    Introducing the Stratasys P750K 3D Printing System Preparing Files for Use with Objet 3D Printing Systems Before using files with Stratasys 3D printing systems, you need to convert them in your CAD program to a file format supported by Objet Studio. (For an explanation of these file formats, see “Source Files”...

  • Page 29: Objet Studio Software

    Stratasys P750K User Guide Objet Studio Software Objet Studio software for the Stratasys 3D printing system consists of two main screens: • Tray Settings / Model Settings • Job Manager Tray Settings / Model Settings In the Tray Settings and Model Settings screens, you prepare source files for production in Stratasys 3D printers.
  • Page 30 Introducing the Stratasys P750K 3D Printing System 3–10 DOC08010 Rev. A (DRAFT 1)

  • Page 31: Installing Objet Software

    Installing Objet Software How to Install Software for the Stratasys 3D Printing System..... 2 4–1 DOC08010 Rev. A (DRAFT 1)

  • Page 32: How To Install Software For The Stratasys 3D Printing System

    Installing Objet Software How to Install Software for the Stratasys 3D Printing System The Objet Studio setup wizard guides you when installing this software. Objet Studio is installed on the printer server (“host”) computer, but it can also be installed on remote, “client” computers and on computers used to prepare files for printing models, or for training and demonstration purposes.
  • Page 33 Select Objet Studio for a server computer • if you are installing Objet Studio on the server (“host”) computer— the computer directly connected to an Stratasys printer. • if you are installing Objet Studio on a standalone (off line) computer.
  • Page 34 Installing Objet Software 8. In the Select Installation Folder screen, verify the destination folder and click Next It is recommended that you do not change the default destination folder. Click to check the space in the destination folder. Disk Space Figure 4-4: Objet Studio installation-folder selection 9.
  • Page 35 Stratasys P750K User Guide Installation begins and a progress bar appears, showing the progress of the installation process. Figure 4-6: Installation progress bar When the Objet program installation is complete, the final InstallShield wizard screen appears. Figure 4-7: Final installation screen 11.

  • Page 36: How To Uninstall Objet Studio

    Installing Objet Software How to Uninstall Objet Studio If there is ever a need to uninstall the Objet Studio software, do not attempt to do so from the Windows Control Panel. (This does not completely remove all software components.) Instead— From the Start menu, select All Programs >...

  • Page 37: Using Objet Studio

    Using Objet Studio Launching Objet Studio..............3 Windows® 7 Security Warning............3 Objet Studio Interface ................4 Ribbon Commands ................6 Objet Studio Commands Menu ............8 Model Tree Pane ..................8 Preparing Models for Production ............. 9 OBJDF Files: Overview................. 9 Model Files .....................
  • Page 38 Handling Completed Trays ............. 45 Tray Validation ..................45 Production Estimates................46 Printing Modes ..................47 E mailing Objet Digital Files ............. 48 Printing the Tray File ................48 Applying Additional Objet Studio Features ......... 51 Dividing Objects.................. 51 Choosing the Support Strength............52 “Hollow”—...

  • Page 39: Launching Objet Studio

    Stratasys P750K User Guide Launching Objet Studio After you install Objet Studio, a launch icon appears on the Windows desktop. Open the application by double clicking this icon, or by selecting Objet Studio from the menu. Start ® Windows ®...

  • Page 40: Objet Studio Interface

    Using Objet Studio 4. In the following dialog box, click Figure 5-3: Confirming the change in the User Account Control settings Objet Studio When Objet Studio opens, the Tray Settings screen appears, showing an Interface empty build tray. Figure 5-4: Objet Studio opening screen The Objet Studio interface consists of two main screens: •...
  • Page 41 Stratasys P750K User Guide The ribbon, colors used, and several other interface features can be customized. How to change the appearance of the interface is explained in “Customizing Objet Studio” on page 57. Instructions for using the commands for preparing models for production and sending jobs to the printer, appear later in this chapter.

  • Page 42: Ribbon Commands

    Using Objet Studio Ribbon The following table lists the Tray Settings and Model Settings ribbon Commands command groups, and shows when they are enabled, and where they appear. Group Purpose When Tray Model enabled Settings Settings Ribbon Ribbon Setting display Always.
  • Page 43 Stratasys P750K User Guide Group Purpose When Tray Model enabled Settings Settings Ribbon Ribbon Placing model Always. files on the build tray Pre build/build Models are on commands. the build tray. Setting model A model is dimensions. selected. Cutting, A model is copying, pasting selected.

  • Page 44: Objet Studio Commands Menu

    Using Objet Studio Objet Studio Clicking the icon in the upper left corner opens the Objet Studio Commands Commands menu. This menu displays basic application commands and Menu options. Figure 5-7: Objet Studio Commands menu The Options button opens a dialog box for customizing Objet Studio. Figure 5-8: Options dialog box Model Tree The Model Tree pane lists the objects placed on the build tray in a parent...

  • Page 45: Preparing Models For Production

    2. If necessary, manipulate the object’s orientation and position. 3. Select the materials and model finish. Just as Stratasys printers can produce different models on the build tray using different materials, you can produce components of a model with different materials. To do this, each part of the model must be a separate stl file.

  • Page 46: Placing Objects On The Build Tray

    Using Objet Studio Placing To place an object on the build tray: Objects on the 1. Open the Insert dialog box— Build Tray • From the Object menu, select Insert or— • On the Tray Settings ribbon, click or— • Right click on the build tray, and select from the context Insert...
  • Page 47 Stratasys P750K User Guide Figure 5-10: Assembly check box selected—stl files are placed as an assembly Figure 5-11: Assembly check box not selected—stl files are placed as parts The Model Settings ribbon is displayed when objects are placed on the build tray.
  • Page 48 Using Objet Studio Note: The Extents values displayed in the Coordinates section of the Insert dialog box, represent the maximum dimensions of the object on each axis. These dimensions correspond to the virtual “bounding box” surrounding the object see figure 5-50 on page 38). 6.
  • Page 49 Stratasys P750K User Guide Opening objdf Files Before placing objdf files on the build tray, Objet Studio must extract the component stl files together with information about their relative position and model materials. To do this, Objet Studio creates a folder with the same name as the objdf file, in the same location.

  • Page 50: Opening Objet Tray Files

    Using Objet Studio Opening Objet You can open trays that were saved as objtf files. This is useful, for example, Tray Files if you saved a tray after preparing it for printing, and now you want to make changes before printing it. To place an object saved as an Objet Tray File (objtf) file on the build tray: 1.
  • Page 51 Stratasys P750K User Guide STL file loading If there are identically named stl files in more than one location, you need preference to ensure that the correct component stl files are linked to the objtf file. For example, if there are identically named stl files on one drive and on a flash drive (this can occur if you copy the original files to a working folder), you can set the default location from which files are loaded.

  • Page 52: Quick Access Model Commands

    Using Objet Studio Quick-Access You can access common commands for working with objects on the build Model tray with the convenient Model Toolbar and context menus. Commands Model Toolbar Select an object in the tray to display the Model Toolbar that contains icons to perform common tasks.

  • Page 53: Copying And Pasting Objects

    Stratasys P750K User Guide Copying and If you need to duplicate objects on the build tray, you can insert the same Pasting object from its file more than once. An easier way, however, is to copy and Objects paste the object. You can copy objects from the build tray or the model tree—individual or multiple parts or assemblies.

  • Page 54: Selecting Objects

    Using Objet Studio Selecting To manipulate an object on the build tray or assign characteristics to it Objects (model material, building style etc.), you must first select the object. You select an object by clicking it, either on the tray or in the model tree. Its image on the build tray changes color (to light blue, by default) and its name is highlighted in the model tree.

  • Page 55: Splitting Objects Into Components

    Stratasys P750K User Guide Splitting You can convert a complex object to an assembly of component parts. To do Objects into so, you split the stl file that represents the object into a group of separate stl Components files, each one representing a component. (This is referred to in the Objet Studio interface as separating the object into shells.) You can then assign a...

  • Page 56: Model Material Settings

    Using Objet Studio The object appears—on the build tray and in the model tree—as an assembly of parts (“shells”). You can assign each part a different model material (This is explained in “Model Material Settings” on page 20). Figure 5-23: Object after being converted to an assembly of component parts Model-Material Before placing objects on the build tray in Objet Studio, you should pay Settings...

  • Page 57: Changing The Model Material

    Stratasys P750K User Guide 3. Change the material selection settings on the Tray Settings ribbon to those used on the other build tray. 4. Assign materials to the object (see “Assigning a Model Material to Objects” on page 22). 5. Select the object and copy it.

  • Page 58: Assigning A Model Material To Objects

    Using Objet Studio Assigning a You can assign any of the available to objects on the build tray. Model Material To assign a model material to objects: to Objects 1. Select an object on the build tray (see “Selecting Objects” on page 18). When an object is selected, its properties—including model materials—...

  • Page 59: Surface Finish

    Stratasys P750K User Guide Surface Finish Models can be printed with a matte or glossy surface finish. To create a matte finish, the printer surrounds models with a thin layer of support material. To set the model finish: 1. Select the model.

  • Page 60: Assigning Properties To Hidden Objects

    Using Objet Studio To inspect, modify or remove the coating applied to an object: 1. On the Model Toolbar or the Model Settings ribbon, click The Coat with dialog box opens. 2. Perform one of the following actions— • Change the coating settings, and click Apply •...

  • Page 61: Positioning Objects On The Build Tray

    Stratasys P750K User Guide Positioning Objects on the Build Tray To produce models efficiently and with the required finish, it is important to carefully position objects on the build tray. Objet Studio supports the automatic positioning of objects. However, you should check to make sure that the objects are orientated optimally for your needs, according to the considerations explained in “Model Orientation”...

  • Page 62: Automatic Placement

    Using Objet Studio Automatic After placing several objects on the build tray, you can let Objet Studio Placement arrange them before printing. This ensures that the objects are positioned properly, and that they will be printed in the shortest time and with a minimum of material.

  • Page 63: Manipulating Objects On The Build Tray

    If you do not insert objects with automatic positioning, they often appear either above or below the tray. In practice, the Stratasys system prints all models on the build tray on a one- millimeter bed of support material. The importance of positioning objects directly on the build tray with Objet Studio is to correctly display the objects on the screen.

  • Page 64: Valid Object Placement

    Using Objet Studio To ensure that objects are always positioned directly on the tray: 1. From the Tools menu, select , and display the Settings tab. Options Figure 5-34: Options dialog box, Settings tab 2. In the Automatic Lay On (Gravity) section, select Always Other Z-axis options (in the Automatic Lay On section): •...
  • Page 65 Stratasys P750K User Guide 2. Select to identify— Dynamic check • invalid object placement while placing objects—On Drop selected. • invalid object placement after moving objects—While Drag selected. • objects placed beyond the tray’s boundaries—Outside Tray selected. • objects that overlap—Object Collision selected.

  • Page 66: Using A Grid To Position Objects

    Using Objet Studio Using a Grid to Displaying a grid on the image of the build tray can be useful when Position positioning objects. To use the grid features, select the following menu Objects options. Menu Option Result Tools > Grid Displays a grid on the build tray.

  • Page 67: Measurement Units

    Stratasys P750K User Guide Measurement 3D files contain an object s proportions, but not its units of measure. Units Therefore, make sure to correctly select either millimeters or inches when inserting an object. Otherwise, the size of the object on the build tray will be either much too large or much too small.

  • Page 68: Setting Model Dimensions

    Using Objet Studio Setting Model You can change an object’s dimensions by changing its size on the X , Y , Dimensions and Z axes, from the Dimensions group on the Model Settings ribbon. Figure 5-40: Dimensions on the Model Settings ribbon •...
  • Page 69 Stratasys P750K User Guide 3. If you click on a corner of the frame, the cursor changes to indicate that the object can be rotated. Figure 5-42: Manually rotating an object 4. Manipulate the object with the arrow keys or with the mouse.

  • Page 70: Changing An Object's Orientation

    Using Objet Studio Changing an There are several methods for changing the orientation of objects on the Object’s build tray. Orientation To rotate an object: Select the object and use the Object menu options (see also “Repositioning Objects” on page 32). To re-align an object’s plane: 1.
  • Page 71 Stratasys P750K User Guide 3. On the Alignment toolbar, click an appropriate icon to change the alignment. or— From the Tools menu, select , and select an alignment Plane Alignment option. Figure 5-45: Tools menu, Plane Alignment options To cancel plane selection after re-aligning objects on the build tray: On the Tray Settings or Model Settings ribbon—...

  • Page 72: Grouping And Ungrouping Objects

    Using Objet Studio Grouping and You can manipulate two or more objects on the build tray, at the same time. Ungrouping • Selecting multiple objects Objects Manipulating done to one object affects all selected objects. For example, turning one object on its axis causes all selected objects to turn on their respective axes.

  • Page 73: Freezing Model Orientation

    Stratasys P750K User Guide Freezing Model If you manipulate an object on the build tray, you can freeze its orientation Orientation so that it does not change when you position it automatically (see “Automatic Placement” on page 26). To freeze an object: 1.
  • Page 74 Using Objet Studio To display objects as boxes, showing their maximum dimensions instead of their shape: From the View menu, select Display Bounding Box Figure 5-50: Model displayed with bounding box To display the area around objects needed for support material (to produce a matte finish): From the View menu, select Display Thickening Box...

  • Page 75: Screen Layout

    Stratasys P750K User Guide Screen Layout Objet Studio automatically adjusts the default screen layout to display the optimum views of the build tray and the model tree. You can view models from different perspectives by changing the screen layout. To change the screen layout:...
  • Page 76 Using Objet Studio Tray Positioning To view the tray and models from different directions, you can move the tray around the screen and change its display angle. To move the tray in the Objet Studio screen: Press the mouse wheel while moving the mouse. Figure 5-57: Tray after moving it in the Objet Studio display To manually rotate the tray: Press Alt and press the mouse wheel while moving the mouse.

  • Page 77: Setting Object Colors

    Stratasys P750K User Guide Setting Object The color of objects on the build tray can indicate how they are printed. Colors Objet Studio enables you to choose the color display so that you can easily see the material, surface and coating of objects.

  • Page 78: Large File Manipulation

    Using Objet Studio Large File If you need to work with a detailed model that is composed of a large Manipulation number of polygons, you can speed up its display and manipulation in Objet Studio by reducing the number of polygons on the screen. Although this may reduce the resolution on the screen, it has no affect on the printed models.
  • Page 79 Stratasys P750K User Guide 4. Select Polygon Reduction (Percent) 5. Enter the percentage of total polygons to display. When you click , the display changes. Apply Note: The setting affects the static display (when the object is not being moved).

  • Page 80: Zoom Options

    Using Objet Studio Zoom Options While manipulating objects, you often need to view them at different zoom levels. To change the zoom level: On the ribbon, open the Zoom flyout toolbar and select an option: Zoom Object Zoom Tray Zoom by Rectangle Figure 5-64: Zoom flyout toolbar Zoom Object focuses on the selected object.

  • Page 81: Handling Completed Trays

    Stratasys P750K User Guide Handling Completed Trays After you have properly placed all objects on the build tray, you save the tray as an objtf file, which is sent to the 3D printer for production. But before saving the tray, you can check that there would be no problem producing it.

  • Page 82: Production Estimates

    Using Objet Studio Production Objet Studio enables you to calculate the time and material resources Estimates needed for producing trays before sending them to the printer. The time it takes Objet Studio to perform this calculation depends on the number of objects on the tray and their complexity.

  • Page 83: Printing Modes

    Stratasys P750K User Guide Printing Modes Stratasys printers can build models using three possible printing modes. HQ (High Quality) Mode— • Models are printed in 16 micron layers, resulting in smooth surfaces, suitable for producing fine detailed and delicate items.

  • Page 84: E Mailing Objet Digital Files

    Using Objet Studio E-mailing ® ® You can easily e mail objdf files using Microsoft Office Outlook . Sending Objet Digital objdf files is recommended (instead of stl files) because the size of a file is Files typically reduced by more than half. An added benefit is that the objdf file contains the model material information for the object.
  • Page 85 Stratasys P750K User Guide This setting enables the Stratasys software to determine (just before printing) the most efficient way to print the tray. Digital Material mode is used if this removes the need to perform the Material Replacement procedure. Otherwise, High Speed mode is used.
  • Page 86 Using Objet Studio 4. Click Build If the build tray file has not been saved, the Save As dialog box opens for you to save it now. Objet Studio checks if there is a problem with the positioning of objects on the tray.

  • Page 87: Applying Additional Objet Studio Features

    Stratasys P750K User Guide Applying Additional Objet Studio Features Dividing You can use the Split Object feature to produce objects larger than the tray Objects area by dividing the model into separate parts. With this feature, you produce only a specific section of a model.

  • Page 88: Choosing The Support Strength

    Using Objet Studio Choosing the When producing models, support material fills some hollow and empty Support sections (see “Model Orientation” on page 26). Objet Studio allows you to Strength adjust the strength of the structure formed with the support material. This adjustment is useful when producing either large/massive models or small/ delicate models.

  • Page 89: Hollow"- Filling Models With Support Material

    Stratasys P750K User Guide “Hollow”— Many objects placed on the tray from stl files are “solid.” This means that, Filling Models when printed, the model will be completely filled with model material. with Support Often, especially with large objects, this is unnecessary. Instead, the model Material can be filled with support material, which is less costly.

  • Page 90: Displaying The Cross Section Of Objects

    Using Objet Studio Displaying the The Section feature enables you to view the interior of an object by “slicing” Cross Section it on any axis. You can then manipulate the object to inspect the interior of Objects from different angles. This may be important for deciding on the type of support necessary when producing the model (see “Choosing the Support Strength”...

  • Page 91: Saving The Screen Display As An Image File

    Stratasys P750K User Guide Saving the You can save the image displayed in the active viewing screen as a graphic Screen Display file. as an To save the screen display as an image: Image File 1. Press Ctrl+B or— From the Objet Studio Commands menu...

  • Page 92: Exporting And Importing Objet Build Trays

    When you save build trays in Objet Studio, they are saved as objtf files. Importing These files contain instructions to Objet Studio and to Stratasys printers for Objet Build displaying and producing the stl files used on the tray. To conveniently...

  • Page 93: Customizing Objet Studio

    Stratasys P750K User Guide Customizing Objet Studio You can customize Objet Studio to suit your particular working needs and preferences. Features that you can customize include: • Creating a quick access toolbar for frequently used commands. • Changing the position of the Quick Access toolbar.

  • Page 94: Hiding The Ribbon

    Using Objet Studio 3. To choose from a wider range of commands: • From the Customize Quick Access Toolbar menu (see figure 5 80 on page 57), select More Commands or— • Right click on the Objet Studio Commands icon , or elsewhere on the ribbon, and select Customize Quick Access Toolbar...

  • Page 95: Display Colors

    Stratasys P750K User Guide Display Colors You can customize some of the colors used for displaying Objet Studio screens and for displaying objects on the build tray. To change the colors used in Objet Studio screens: 1. From the Tools menu, select...

  • Page 96: Keyboard Shortcuts

    Using Objet Studio Changing Color Objet Studio offers a choice of four background color themes—blue, black, Themes silver and aqua. Figure 5-86: Background color themes To change the color theme: From the Style menu, select one of the options. Keyboard You can define shortcut keys for frequently used commands.

  • Page 97: Setting User Preferences

    Stratasys P750K User Guide 3. Click Customize The Customize Keyboard dialog box appears. Figure 5-88: Customize Keyboard dialog box 4. Select command Categories to display all the commands in that category, for example, all the Model Settings commands. Current shortcut keys are displayed.

  • Page 98: Professional Mode Features

    Using Objet Studio Professional Mode Features Some advanced features of Objet Studio are only accessible in Professional Mode. To see the current Objet Studio setting: Open the Tools menu. Figure 5-90: Tools menu, showing Professional Mode selected If Professional Mode is selected, advanced features are displayed. To change the Professional Mode setting: 1.

  • Page 99: Default Settings

    Stratasys P750K User Guide Default You can control the default settings of several Objet Studio features from Settings the Advanced tab of the Options dialog box. To display the Options dialog box From the Tools menu, select Options or— In the Objet Studio Commands menu...

  • Page 100: Opengl Driver Configuration

    Using Objet Studio OpenGL Driver The OpenGL driver displays 3D graphics on your screen. There is normally Configuration no reason to adjust its settings. If you suspect a problem with the way Objet Studio displays objects, you can use the OpenGL Driver Configuration tool to check and configure the driver settings.
  • Page 101 Stratasys P750K User Guide To perform a test of the driver configuration and enter the suggested pixel format ID: 1. Select Choose Format 2. Click Test Objet Studio returns the recommended pixel format ID. Figure 5-95: Recommended pixel format ID 3.

  • Page 102: Getting Additional Objet Studio Assistance

    Using Objet Studio Getting Additional Objet Studio Assistance Objet Studio Help provides on screen instructions and information, as you work. To view Objet Studio Help: On the standard toolbar, click and then click Objet Studio Help Figure 5-96: Help options You can also view information on the following subjects: •...
  • Page 103 Stratasys P750K User Guide Materials Module The Materials Module tab shows details of the material module installed. Figure 5-99: Materials Module tab • Module version If a Materials Module upgrade (patch) was installed, the new Materials Module version is displayed. If no patches were installed, the Module version is the same as the Objet Studio version.

  • Page 104: Monitoring And Managing Print Jobs

    Using Objet Studio Monitoring and Managing Print Jobs In the Job Manager screen of Objet Studio, you monitor and manage jobs sent to the printer. There are a few differences between Objet Studio on client workstations and on the computer connected directly to the 3D printer—the server workstation.
  • Page 105 Stratasys P750K User Guide Jobs Queue On the server, the Jobs Queue lists the last 15 jobs sent from client computers. On client workstations, the Jobs Queue lists jobs sent from that computer to the printer server. Information for each of the queued jobs is displayed, including the job status.

  • Page 106: Setting The Printer Connection

    Using Objet Studio Setting the When an Objet 3D printer is installed, the server computer is connected to Printer that printer. Normally, there should be no reason to change this connection. Connection Occasionally, however, you may need to reset the connection, to connect the server to another printer, or to use Objet Studio in off line mode (without a printer connection).

  • Page 107: Off Line Mode

    Stratasys P750K User Guide Off-line Mode You can use Objet Studio to prepare trays for printing in off line mode, on a remote computer or when the printer connection is not available. You also use off line mode to prepare trays for printing with other printers. In this case, if Objet Studio is currently connected to a printer, you must change to off line mode by removing this connection.
  • Page 108 Using Objet Studio To change the Objet Studio off-line configuration: 1. In the Set Printer dialog box, select a printer type. Figure 5-107: Off-line printer selection 2. Click (not “Connect”). 5–72 DOC08010 Rev. A (DRAFT 1)

  • Page 109: Setting The Remote Printer Connection (Client Mode)

    Stratasys P750K User Guide Setting the When you open Objet Studio for the first time in a client installation, you Remote Printer are prompted to connect to an Objet server computer that sends jobs to a 3D Connection printer. To do this, the server computer must be operating and connected to (Client Mode) the local network.
  • Page 110 Using Objet Studio The following operations are available on the Job Manager ribbon: Group Icon Purpose Client: Sets the server connection. See “Setting the Remote Printer Printer Connection (Client Mode)” on page 73. Server: Sets the printer connection. See “Setting the Printer Connection”...
  • Page 111 Stratasys P750K User Guide In addition to using ribbon command icons, you can use commands on context (pop up) toolbars and from the Job menu on the standard toolbar. Restart Delete Stop Resume Edit Schedule Export packed job Figure 5-110: Icons on pop-up toolbar (server)

  • Page 112: Configuring User Alerts

    Using Objet Studio Configuring Objet Studio can alert you (and others) to the status of jobs sent to the server User Alerts for printing. This is especially useful during long printing jobs, when the operator is away from the printer. The following events can be reported: •...

  • Page 113: Printing The Tray

    5. In the Notifications dialog box, click Printing the If there is a job in the Jobs Queue, it is sent automatically to the Stratasys Tray printer—as long as it is on, there is a connection to the printer, and the printer is on line.
  • Page 114 Using Objet Studio Extended Tray Preview In this window, you can view the tray from different angles and magnifications without leaving the Job Manager screen. In addition to displaying the selected job in the Tray Preview pane, you can open an enlarged build tray window.
  • Page 115 Stratasys P750K User Guide The Tray Settings screen opens, displaying the build tray. The status of the job in the Job Manager screen changes to “Editing.” 3. Edit the job. 4. On the Tray Settings ribbon, click The status of the job in the Job Manager screen changes back to “Waiting.”...
  • Page 116 Using Objet Studio Exporting Jobs (objzf) You can save print jobs as compressed files. For an explanation of objzf files, see “Exporting and Importing Objet Build Trays” on page 56. To export a print job: 1. Select a job. 2. On the pop up toolbar, click 3.

  • Page 117: Operating & Maintaining The Stratasys P750K 3D Printer

    Operating & Maintaining the Stratasys P750K 3D Printer Starting the Printer ................2 Loading Model and Support Cartridges.......... 4 Producing Models ................5 Preparing the Printer ................5 Printer Interface Color Key..............7 Printing Indicators ................8 Resuming Production After Printing has Stopped......9 Changing the Printing Material ............

  • Page 118: Starting The Printer

    Figure 6-1: The Stratasys P750K 3D Printer Starting the Printer CAUTION! Do not attempt to operate the Stratasys printer before being trained by a Stratasys customer-support representative. Observe all safety warnings and follow the safety guidelines described in chapter 2.
  • Page 119 Stratasys P750K User Guide 2. After the printer control computer boots, log in to Windows and launch the printer control program: • On the printer computer desktop, double click the Stratasys printer icon. or— • From the Start menu, select ( >...

  • Page 120: Loading Model And Support Cartridges

    Operating & Maintaining the Stratasys P750K 3D Printer Loading Model and Support Cartridges Stratasys P750K printers use up to 12 cartridges of Model material and four cartridges of Support material, each weighing 3.6 kilograms when full. A graphical representation of the cartridges loaded and their current weight appears in the printer interface (see figure 6 3).

  • Page 121: Producing Models

    Stratasys P750K User Guide Producing Models The Stratasys P750K printer produces models by printing tray files prepared in the Objet Studio application and sent to the printer from there. For information about preparing model files for printing, see “Using Objet Studio”...
  • Page 122 Support material in the supply cartridges, printing proceeds automatically until the job is finished. The Stratasys P750K printer uses up to six different Model material cartridges to produce models. In addition, two Support material cartridges are required. If additional cartridges are installed and they are not needed...

  • Page 123: Printer Interface Color Key

    Stratasys P750K User Guide Printer The background colors in the printer indicator fields tell you at a glance Interface whether or not the value or item is suitable or ready for printing. Color Key • Green—suitable/ready for printing For example, in figure 6 4: Heads (°C)—The heads have reached the temperature required for...

  • Page 124: Printing Indicators

    Operating & Maintaining the Stratasys P750K 3D Printer Printing The printer interface screen changes when you send a print job from Objet Indicators Studio to the printer, and the printer is on line (see figure 6 5): • The mode changes from Pre print to Printing.

  • Page 125: Resuming Production After Printing Has Stopped

    Stratasys P750K User Guide Resuming Production After Printing has Stopped If the printing process is interrupted, Objet Studio stops sending slices to the printer. This can happen, for example, if the printing material runs out in the middle of a print job, and you don’t replace the empty cartridge immediately.
  • Page 126 Operating & Maintaining the Stratasys P750K 3D Printer You cannot continue printing the model if: • The number of the last slice printed does not appear in the printer interface, even if the server computer displays the Continue from Slice confirmation dialog box.

  • Page 127: Changing The Printing Material

    Stratasys P750K User Guide Changing the Printing Material Before producing models using a different type of printing material than is currently installed, run the Material Replacement wizard to flush the print block and feed tubes. You should carefully plan printing models with different Model materials to avoid unnecessary waste of the materials currently loaded.
  • Page 128 Operating & Maintaining the Stratasys P750K 3D Printer 3. If the printer cover is not closed, a screen appears, prompting you to close the cover. Confirm that it is closed and click Next 4. Choose the configuration for producing models: •...
  • Page 129 Stratasys P750K User Guide 7. Choose how thoroughly you want to flush out material currently in the system: • Economy. This cycle can be used when replacing a light colored Model material with a darker material (such as TangoBlack™ or VeroBlack™), or if the exact color of the printed models (in the first...

  • Page 130: Advanced Settings

    Operating & Maintaining the Stratasys P750K 3D Printer 11. Read the warning message, and click If you continue, you must complete the material replacement process before you can produce models. To replace material at another time, click Cancel. If you continue (by clicking OK) and you do not complete the process, you will need to run the wizard again before producing models.
  • Page 131 Stratasys P750K User Guide Positioning By default, Automatic slot selection determines the best slot locations for the cartridges in the materials cabinet, based on materials currently in the system. This ensures minimum flushing of materials currently loaded. If there is a special need to load cartridges in certain slot locations, select...

  • Page 132: Keeping The Printer In Idle Mode

    Operating & Maintaining the Stratasys P750K 3D Printer Keeping the Printer in Idle Mode Between printing jobs, the Stratasys P750K printer can be kept on for up to one week. If the printer will not be used for more than a week, use the Shutdown wizard to automatically perform the procedures that must be done before turning off the printer (see “Shutting Down the Printer,”...

  • Page 133: Shutting Down The Printer

    Stratasys P750K User Guide Shutting Down the Printer You only need to shut down the Stratasys printer if it will not be used for a week or more. Otherwise, the printer can remain on, in Idle mode. The Shutdown process flushes printing materials from printer components.
  • Page 134 Operating & Maintaining the Stratasys P750K 3D Printer 3. Choose the appropriate option for the length of time that the printer will not be used—less or more than 30 days. Note: Before selecting More than days, make sure that cleaning-fluid are available.

  • Page 135: Maintaining The Printer

    Stratasys P750K User Guide Maintaining the Printer The performance of routine maintenance tasks is essential for getting satisfactory results from Stratasys 3D printers. Perform the tasks at specified intervals for optimum performance. Routine Maintenance Frequency Task For More Information Schedule...

  • Page 136: Uv Lamp Check

    Operating & Maintaining the Stratasys P750K 3D Printer UV Lamp A heat sensitive label is fixed to the UV lamp covers as a warning against Check overheating. Its center changes from white to black if the temperature of the cover reaches 65 °C (150 °F). If this occurs, do not use the printer, and call your service provider.
  • Page 137 Stratasys P750K User Guide 3. Follow the instructions on the wizard screens, and select the confirmation check boxes. Figure 6-18: Head cleaning procedure—wizard screen 4. Click Next The printer prepares for you to clean the print heads. 5. When the following screen appears, open the cover.
  • Page 138 Operating & Maintaining the Stratasys P750K 3D Printer 9. Clean the orifice plates, with a back and forth motion (see figure 6 20). Use the mirror to make sure that you have removed all of the residue material. Figure 6-20: Cleaning the heads 10.

  • Page 139: Cleaning And Replacing The Wiper

    Stratasys P750K User Guide Cleaning and A rubber wiper removes excess material from the print heads after the Replacing the purge sequence. This is done automatically before each print job, and Wiper performed manually during maintenance tasks. You should clean the wiper and surrounding area at least once a week.
  • Page 140 Operating & Maintaining the Stratasys P750K 3D Printer 5. When the following screen appears, open the cover. Figure 6-24: Wiper Cleaning wizard during steps 6–10 6. Put on the cleaning gloves. 7. Using a generous amount of alcohol on the cleaning cloth, remove any material remaining on the wiper and the surrounding area.

  • Page 141: Pattern Test

    Stratasys P750K User Guide 12. Confirm this in the wizard screen, and click Next Figure 6-26: Confirmation screen 13. Click to close the wizard. Done Pattern Test The pattern test is the basic verification of the printer’s ability to produce quality models, since it demonstrates the condition of the nozzles in the print heads.

  • Page 142: Improving Print Quality

    Operating & Maintaining the Stratasys P750K 3D Printer Figure 6-29: Sample Pattern Test 6. Carefully inspect the test paper to see if there are missing lines. Too many missing lines, especially if they are in the same area, indicates that the quality of printing when producing models will be poor.

  • Page 143: Cleaning The Roller Waste Collector And Inspecting The Roller Scraper

    Stratasys P750K User Guide Cleaning the The roller waste collector removes waste material scraped from the roller. Roller Waste Suction removes this waste to the printer’s waste container. Collector and This assembly should be cleaned weekly to prevent a blockage in the tubes...
  • Page 144 Operating & Maintaining the Stratasys P750K 3D Printer 4. Loosen the two screws securing the suction tube on the print block. Suction tube screws Figure 6-31: Lifting the suction tube 5. Lift the suction tube to secure it in a raised position.
  • Page 145 Stratasys P750K User Guide To check the effectiveness of the roller scraper: 1. Put on the cleaning gloves. 2. Wet a cloth with isopropanol. 3. Use the cloth to wet the bottom of the roller. 4. Turn the roller slowly with your hand. As the blade scrapes the roller, make sure the isopropanol is spread evenly over the entire length of the blade.

  • Page 146: Replacing The Roller Scraper

    Operating & Maintaining the Stratasys P750K 3D Printer Replacing the You should replace the roller scraper blade— Roller Scraper • after 1,000 hours of printing. • if it does not effectively keep the roller clean. You should periodically test the effectiveness of the roller scraper when you clean the roller waste collector.
  • Page 147 Stratasys P750K User Guide Figure 6-38: Removing the old roller scraper blade 5. Remove the scraper blade and discard it. 6. Place the new scraper blade onto the pins in the holder, as shown. Figure 6-39: Inserting the new roller scraper blade 7.

  • Page 148: Aligning The Print Heads

    Operating & Maintaining the Stratasys P750K 3D Printer 8. After tightening the screws, inspect the blade and make sure that it is straight. If necessary, loosen the screws and tighten them again, evenly. 9. Return the roller waste collector assembly and the right UV lamp to the print block.
  • Page 149 Stratasys P750K User Guide 8. When the following screen appears, remove the transparency. Figure 6-42: Head Alignment wizard—steps 8–10 The transparency sheet is printed with sets of vertical lines in seven columns, each showing the results from a different print head.
  • Page 150 Operating & Maintaining the Stratasys P750K 3D Printer Optimum head alignment is shown when the fourth lines in the upper and lower rows are aligned, as in figure 6 44. In the example shown, no change to the head alignment is necessary. If other lines in the set are aligned, you need to change the alignment of that head—in the next...

  • Page 151: Optimizing (Calibrating) Print Heads

    Stratasys P750K User Guide 13. Continue as follows: • To make the alignment changes in the printer, make sure that Yes is selected, and click Next • To recheck the alignment test results before making the alignment changes in the printer, click Previous •...
  • Page 152 Operating & Maintaining the Stratasys P750K 3D Printer Note: To accurately test and calibrate print heads, they must be clean. If necessary, run the Head Cleaning wizard before beginning this procedure. To test and calibrate the print heads: 1. Prepare—...
  • Page 153 Stratasys P750K User Guide 5. In the following screen, select if you Continue with Head optimization have recently cleaned the print heads. Otherwise, cancel the wizard and run the Head Cleaning wizard. Figure 6-49: Clean print heads screen 6. In the following screen, make sure Optimize all print heads is selected...
  • Page 154 Operating & Maintaining the Stratasys P750K 3D Printer 8. When the following screen appears, tape a sheet of pink paper to the surface left of the build tray, close the cover and click Next Figure 6-52: Preparations confirmation The printer prints a frame on the build tray and then prints the Pattern Test.
  • Page 155 Stratasys P750K User Guide 11. The wizard continues according the number of missing nozzles you entered. If there are too many missing nozzles for acceptable printing, the wizard instructs you to replace the defective print head(s). You can do this now, or abort the wizard.
  • Page 156 Operating & Maintaining the Stratasys P750K 3D Printer 13. After confirming all of the items listed in the wizard screen, click Next Printing material (resin) is jetted from each head and its weight is automatically recorded. This process is repeated for each printing mode, after which the following screen appears.
  • Page 157 Choose Replace defective head(s) if you are prepared to replace the print heads now (see below). or— Choose Abort wizard if you want to replace the print heads at another time. Replace print heads only after consulting with a Stratasys-authorized customer-support engineer. 6–41 DOC08010 Rev. A (DRAFT 1)

  • Page 158: Replacing Print Heads

    Operating & Maintaining the Stratasys P750K 3D Printer To replace print heads, you need these tools and materials: • replacement print head(s) • isopropanol (IPA—isopropyl alcohol) or ethanol (ethyl alcohol) • disposable cleaning gloves (supplied with the print head; or use any clean, powder free protective gloves) •...
  • Page 159 Stratasys P750K User Guide The Head Optimization wizard guides you through the procedure of replacing a print head and adjusts printer components to enable you to perform it. Only replace a print head with the aid of the wizard. The entire procedure takes about 45 minutes, and consists of the following phases: A.
  • Page 160 Operating & Maintaining the Stratasys P750K 3D Printer 5. In the following screen, select if you Continue with Head optimization have recently cleaned the print heads. Otherwise, cancel the wizard and run the Head Cleaning wizard. Figure 6-61: Clean print heads screen 6.
  • Page 161 Stratasys P750K User Guide The printer heats and empties the print block and prepares the printer. (This can take up to 15 minutes.) Figure 6-64: Printer preparation progress screen 8. The following screen appears when the printer is ready for you to replace print heads.
  • Page 162 Operating & Maintaining the Stratasys P750K 3D Printer Removing the 10. On the print block, release the upper and lower screws that secure the Defective Head print head in the block. (If necessary, you may use a screwdriver to loosen the screws.) Figure 6-66: Releasing the locking screws 11.
  • Page 163 Stratasys P750K User Guide 13. Pull the print head driver card out of its socket so that the head is free (A) and remove it from the bottom of the print block (B). Figure 6-69: Releasing the print-head driver card to remove the head 14.
  • Page 164 Operating & Maintaining the Stratasys P750K 3D Printer Installing the 15. Inspect the replacement head and make sure that the O ring seals are New Head in place (see figure 6 70). 16. Gently insert the replacement head into the vacant slot in the print block and push the print head driver card into its socket.
  • Page 165 Stratasys P750K User Guide 20. In the Replace print heads screen, select the check box to confirm that you have replaced the head(s) and click Next Figure 6-74: Head replacement confirmation 21. With your fingers, make sure that the new head is level and even with the other heads.
  • Page 166 Operating & Maintaining the Stratasys P750K 3D Printer 23. In the next wizard screen, confirm that you have removed all tools and objects from the printer. Figure 6-77: Cleared-tray confirmation screen 24. Close the printer cover. The wizard continues by heating the heads, then filling and purging them.
  • Page 167 Stratasys P750K User Guide Installation If the printer detects that there is a problem after you install print heads, Problems relevant warning screens appear. • If the printer software does not detect the replaced head, the following warning screen appears.
  • Page 168 Operating & Maintaining the Stratasys P750K 3D Printer • If the vacuum test is not successful, the replacement head was not sealed properly during installation, and the following warning screen appears. Figure 6-81: Vacuum-leakage warning screen If this happens: a. Click Next b.

  • Page 169: Testing And Calibrating The Uv Lamps

    UV radiation after every 300 hours of printing. You do this by running the UV Calibration Wizard. To measure the UV radiation, you need: • Stratasys TOL 03005 S (UV sensor and cable, supplied with the printer) or— • a stand alone UV radiation meter, approved for use with the printer The wizard compares the measured radiation to the recommended radiation level for each of the lamps, at each printing mode—High Speed,...
  • Page 170 Figure 6-83: UV device selection UV Measuring Device When you use the Stratasys UV sensor (TOL-03005-S), you connect it to the printer. The wizard automatically measures and calibrates the UV radiation. If you use a stand-alone UV radiation meter, you need to manually enter the readings from the meter in the wizard screens.
  • Page 171 Stratasys P750K User Guide The following steps apply when using the Stratasys UV sensor that you connect to the printer (TOL-03005-S). They do not apply when using a stand-alone UV radiation measuring device. UV sensor 1. Adjust the wizard for the sensitivity of the UV sensor by entering the connected to printer CF number that appears on the sensor’s label.
  • Page 172 Operating & Maintaining the Stratasys P750K 3D Printer 2. Connect the UV sensor cable to the connector in the printer. Figure 6-88: Sensor preparation 3. Confirm the items listed in the wizard screen and click Next Continue with “UV measurement” on page 58.
  • Page 173 External UV meter The following steps apply when using a stand-alone UV meter. They do not apply when using the Stratasys UV sensor connected to the printer. 1. When the following screen appears, open the printer and place the UV sensor at the rear edge of the tray, in the center.
  • Page 174 Operating & Maintaining the Stratasys P750K 3D Printer UV measurement The UV lamps power up and stabilize. (This takes several minutes.) Then, the print block passes over the sensor and the wizard compares the measured radiation to the recommended level for each UV lamp and printing mode.

  • Page 175: Calibrating The Load Cells

    Stratasys P750K User Guide After examining the UV calibration results: 1. Click Next 2. Remove the UV sensor and close the printer cover. After confirming the items listed in the wizard screen, click Next Figure 6-94: Final UV Calibration Wizard screen...
  • Page 176 Operating & Maintaining the Stratasys P750K 3D Printer 4. In the next wizard screen, observe the numbers and wait until the level is relatively stable—two units above or below the average level shown. Figure 6-96: Level stabilization 5. Select the check box, and click Next 6.

  • Page 177: Replacing The Odor Filter

    The UV lamps used for curing models have a long, but limited, working UV Lamps life. The Stratasys service engineer tests their effectiveness during regular maintenance checks, and replaces them, if necessary. You can test and adjust their effective power with the UV Calibration wizard (see “Testing and Calibrating the UV Lamps”...
  • Page 178 Operating & Maintaining the Stratasys P750K 3D Printer 4. Select the UV lamp(s) to be replaced and click Next Figure 6-100: UV lamp selection screen 5. Disconnect the UV lamp power connector and the UV heat fuse connector. Figure 6-101: Disconnecting the UV lamp Note: Do not disconnect the power connection to the cooling fans.
  • Page 179 Stratasys P750K User Guide 7. Pull the lamp reflector out of the print block. Figure 6-103: Removing the UV lamp reflector 8. Inspect the new lamp reflector, and make sure that a black strip is attached to the inside of it. If not, install one—on the side of the reflector opposite (not next to) the print block.
  • Page 180 Operating & Maintaining the Stratasys P750K 3D Printer 10. Insert the new UV lamp/reflector unit into the housing next to the print block. Figure 6-104: Print block and UV lamp assembly, showing correct placement of black strip 11. Replace the lamp cover by inserting it into the slot on the bottom of the housing, and tighten the securing screw on top.
  • Page 181 Stratasys P750K User Guide 13. In the wizard screen, confirm that you have replaced the lamp(s) and that the black strip is attached, then click Next Figure 6-107: UV-installation confirmation screen The wizard operates the lamps and checks if their power is within the acceptable range for each printing mode.

  • Page 182: Built In Tests

    You can configure basic communications and environment tests to run automatically, when the Stratasys software opens. In addition, you can run a more comprehensive set of tests before processing a print job, as a system check, to ensure optimum printing results.
  • Page 183 Stratasys P750K User Guide Test Interface The Built In Tests screen lists pre configured tests, grouped by component categories. In this screen, you select and run tests, and the results are displayed. Figure 6-111: Built In Tests screen Test Name Test List This column lists all of the tests, together with selection check boxes.
  • Page 184 Operating & Maintaining the Stratasys P750K 3D Printer Test Selection Area In the Test Selection area, at the bottom of the screen, you can quickly select or de select tests by their characteristics: Click to select all of the tests in the list.
  • Page 185 . By default, these files BITReport [date][time].htm are saved in the Stratasys installation folder, but you can save it in any other folder. View Click to display the latest test report that you saved. (You can view other test reports by opening the relevant files in your Web browser.
  • Page 186 Operating & Maintaining the Stratasys P750K 3D Printer Test Descriptions The following table lists the name of each test in the Built in Tests suite, together with its description and a possible reason for its failure. If you Troubleshooting need assistance, contact your Stratasys service provider.

  • Page 187: Replacing The Waste Container

    Stratasys P750K User Guide Replacing the Printer waste contains partially cured polymeric material, collected during Waste normal operation and maintenance of the printer. For safety and Container environmental reasons, this material is kept in a special leak proof, disposable container.
  • Page 188 Operating & Maintaining the Stratasys P750K 3D Printer Waste weight Display toggle button Figure 6-112: Printer interface, showing waste weight (red background indicates operator alert) The waste container consists of a plastic container inside a cardboard box. You typically dispose of the entire waste container—including the box.

  • Page 189: Cleaning The Exterior Panels

    Dispose of the full waste container in accordance with environmental and safety requirements. Cleaning the The painted exterior plastic panels of Stratasys 3D printers have a durable Exterior Panels finish, offering excellent chemical resistance to common cleaning materials. Follow the recommendations below when cleaning these areas of the printer.
  • Page 190 Operating & Maintaining the Stratasys P750K 3D Printer Unacceptable Materials • industrial solvents • cleaning agents containing hydrocarbons, ketones, esters and lacquer thinners • spray disinfectants • abrasives and agents which could wear away the panel finish 6–74 DOC08010 Rev. A (DRAFT 1)

  • Page 191: Handling Printed Models

    Handling Printed Models Removing Models After Printing.............. 2 Removing the Support Material..............2 Post Printing Treatment for Models Printed with Objet VeroClear..4 Storing Models..................... 5 7–1 DOC08010 Rev. A (DRAFT 1)

  • Page 192: Removing Models After Printing

    For most models, the most efficient way to remove support material is by Material with Water using a high pressure water jet. One suitable system is the Balco WaterJet cleaning unit. This device is marketed by Stratasys. Pressure 7–2 DOC08010 Rev. A (DRAFT 1)
  • Page 193 Stratasys P750K User Guide Figure 7-1: Balco WaterJet Cleaning Unit To clean a model using this device, you place it in the chamber, and you manipulate it and the jet using the built in, waterproof sleeves. A pump turns ordinary tap water into a high pressure jet, and a wiper keeps the window clear.

  • Page 194: Post Printing Treatment For Models Printed With Objet Veroclear

    For parts with a glossy finish, continue the photobleaching treatment for up to 18 hours more. In Stratasys laboratories, there was a tint reduction of approximately 70% within six hours. After 24 hours, tint was reduced by approximately 90%.

  • Page 195: Storing Models

    Stratasys P750K User Guide Storing Models Models are cured as they are printed, making them safe and stable for a long time. However, proper storage conditions are necessary to prevent deforming. • Keep printed models at room temperature and in a low humidity environment.
  • Page 196 Handling Printed Models 7–6 DOC08010 Rev. A (DRAFT 1)

Table of Contents
