Clearing Drive Block Obstructions - Stratasys Prodigy Plus User Manual

60 Troubleshooting
b. Remove the support drive block first. Use a 7/64" Allen
wrench to remove the two screws securing the motor
assembly as shown in
Model drive
Drive Wheels
Figure 22: Removing the drive block assemblies to check for buildup
c. Set the drive block assembly on the material cartridge.
d. Remove the Model drive block assembly the same
way.
6. With the drive blocks removed, look through both filament
guide funnels for obstructions. If an obstruction is present
in either drive block, follow the procedure for clearing drive
block obstructions.

Clearing drive block obstructions:

a. Remove the filament guide.
b. Remove any excess material; use the needle-nose
c. Replace the filament guide.
Prodigy Plus User Guide
Support drive
Drive Wheels
Filament Guide Funnel and
Mounting Screw
Use the 7/64" Allen wrench provided in the Startup
Kit by removing the filament-guide mounting screw
as shown in Figure
pliers if necessary.
Figure 22.
Drive Block Assembly
Mounting Screws
22.
