38 Operation
2. Release the modeling base retainers and pull the plastic
modeling base (substrate) towards you, out of the tray
guides.
3. Close the modeling chamber door.
4. After you have opened and closed the door, the panel
displays Part Removed? Only after removing the part,
press Yes.
After you press Yes, the panel displays the status as
Ready to Build for the next part in the queue, if there is
one.

To remove a completed part from the plastic modeling base:

1. After removing the base from the machine, firmly flex the
modeling base back and forth with your hands to loosen
the part. For best results, flex the modeling base
perpendicular to the first layer raster direction (front-right to
back-left).
2. Pull the part off the base or use a putty knife to pry the part
completely off.
Supports are much easier to remove when the plastic
modeling base is still warm.
For information on reusing a plastic modeling base, see
page 26.

WaterWorks

Prodigy Plus uses WaterWorks, a water-based solution designed
to simply wash away the support material. Your part is left smooth
and clean with the fine details intact. The soluble support material
Prodigy Plus User Guide
The machine can be damaged if the part
hasn't been removed!
Note
WARNING
