7. With the drive blocks removed, inspect the model liquefier
inlet tube and the inlet funnel covering the support liquefier
inlet tube (see
visible, proceed to the appropriate clearing liquefier inlet
tube procedure.
Figure 23: Inspecting the liquefier inlet tubes
Clearing the support liquefier inlet tube:
a. If material is extended out from the inlet funnel,
gently remove material with the bronze brush or
needle-nose pliers, if necessary.
b. If the material buildup in the inlet funnel is difficult
to remove, insert a 1/16" Allen wrench into the
liquefier inlet funnel and try pushing the
obstruction forward.
c. If this doesn't work, remove the liquefier inlet
funnel using a 1/4" nut driver (see
Dissolve support material from the funnel with the
Waterworks solution.
Figure
23) for material buildup. If material is
Liquefier inlet tubes are fragile. Be careful
not to damage them when removing
material.
Troubleshooting 61
Liquefier Inlet Funnel
(shown with support
drive block removed)
WARNING
Figure
Prodigy Plus User Guide
23).
