62 Troubleshooting
It is typical for material to build up around the support
liquefier inlet tube under the inlet funnel. Do not remove
this material unless it interferes with reinstallation of the
inlet funnel.
d. Inspect for damage to the inlet tube.
e. Replace the liquefier inlet funnel.

Clearing the model liquefier inlet tube:

a. If material is extended out from the inlet tube,
b. Inspect for damage to the inlet tube
8. Clean the inside of the liquefier inlet tubes.
Carefully insert a 1/16" Allen wrench into each liquefier
inlet tube and gently push forward until it stops (about 1/4
inch).
9. Replace both drive-block assemblies.
Install the model drive block assembly first. Make sure the
block is seated flush against the swivel plate.
10. Repeat for the support drive block assembly.
11. Clean the drive wheels.
a. Press Select Drive repeatedly until the display shows
Both Drive Motors.
b. Press Reverse.
c. With the glue brush provided in the Startup Kit, clear
any material buildup from each drive by brushing its
serrated drive wheel.
Prodigy Plus User Guide
Note
gently remove material with the bronze brush or
needle-nose pliers, if necessary.
Be careful not to pinch the assembly's
wiring harness under the block or behind
the motor before replacing and tightening
the mounting screws.
IMPORTANT
