Operation
RestoreResult: STRING(200);
RestoreErr: BOOL;
END_VAR
// Backup of the TwinSAFE logic program
fb_save(
bExecute:= StartBackup,
au8EcatNetId:= EL6910AmsNetID,
u16EcatPort:= EL6910port,
u32BufferAddress:= ADR(internalBuffer),
u32BufferSize:= SIZEOF(internalBuffer),
sFileName:= FileString,
sNetIDWriteFile:= LocalAmsNetID,
Done=> SaveDone,
sResult=> SaveResult,
bErr=> SaveErr);
// Restore of the TwinSAFE logic program
fb_restore(
bExecute:= StartRestore,
au8EcatNetId:= EL6910AmsNetID,
u16EcatPort:= EL6910port,
u32BufferAddress:= ADR(internalbuffer2),
u32BufferSize:= SIZEOF(internalBuffer2),
sFileName:= FileString,
sNetIDReadFile:= LocalAmsNetID,
Done=> RestoreDone,
sResult=> RestoreResult,
bErr=> RestoreErr);
4.9

Export/import of the safety project

The safety project can be archived via the context menu of the safety project. The data type of this archive is
*.tfzip.
Fig. 134: Archiving the safety project
The safety project can be exported to XML format one level below the safety project node. This XML format
can be used for exchange between TwinCAT 3 and TwinCAT 2.
The menu item Export project (as bin file) can be used to save the safety project in a binary format, so that it
can be used by the TwinSAFE loader, for sample.
