Output E
Level High
Level Low
Load High
Output
Output E830
Level High
Level Low
Load High
Output
4.5.2
Pin assignment E, E830
Cable color
White
Brown
Green
-
Yellow
-
Gray
Fig. 18 Pin assignment E, E830
wireSENSOR, WPS
Push-pull (5 VDC)
≥ UB -2.5 V
≤ 0.5 V
≤ 50 mA
A, B, 0
Push-pull (8 ... 30 VDC)
≥ UB -3 V
≤ 2.5 V
≤ 50 mA
A, B, 0

Pin Assignment

Assignment
0 V
+UB
A
A
B
B
0
