MICRO-EPSILON WireSensor Series Instruction Manual page 21

Installation and Assembly
Mounting hole
3x ø2.7
Fig. 3 Dimensional drawing WPS- ... -50MK30 with potentiometer or encoder, dimensions in mm (inches), not
to scale
wireSENSOR, WPS
8
(.31)
ø8
(dia. .31)
ø4.5
(dia. .17)
(dia. .10)
DO NOT
OPEN!
23.5 3.25
(.93)
(.12)
30
(1.18)
10.5
(.41)
2
(.07)
ø3
(dia. .11)
3 contact
>POM<
pins
0.6 42
(.02)
36.2 52
(1.42)
Mounting clamp
with screws M3
1 3
2
(1.65)
(2.04)
Page 21
