Voltage Output - MICRO-EPSILON WireSensor Series Instruction Manual

4.4.2
Voltage output (U)
Supply voltage
Current consumption
Output voltage
Output current
Load impedance
Signal noise
Temperature coefficient ±0.005 % FSO/°C
Einstellbereiche (if supported by the model)
Zero
Sensitivity
Fig. 15 Table voltage output
1) Non stabilized, measured on the input terminal of the sensor
2) Pin side sensor plug or solder side cable socket
wireSENSOR, WPS

Voltage Output

14 ... 27 VDC (non stabilized
max. 30 mA
0 ... 10 VDC
Options 0 ... 5 / ±5 V
2 mA max.
> 5 kOhm
0.5 mV
eff
±20 % d.M.
±20 %
)
1
2
5
4
3
1
8
7 6
View
2
1 = supply white = supply
2 = ground brown = ground
3 = signal green = signal
4 = ground yellow = ground
