Installation and Assembly
4.4

Output Specifications Analog

4.4.1

Potentiometer Output

Output
Potentiometer output (P)
max. 32 VDC at
Supply voltage
1 kOhm / max. 1 W
1 kOhm ±10 %
Resistance
(potentiometer)
Temperature
±0.0025 % d.M./°C
coefficient
Viper current
≤ 10 μA
Depends on measuring
Sensitivity
range
Fig. 14 Table potentiometer output
Draw wire sensors with potentiometer output are connected according table, see
All potentiometers must only be used in a voltage divider circuit. Using them as a variable resistor, destroys the element. Ensure that
the maximum current through the viper is limited.
i
Use potentiometer only as voltage divider, not as variable series resistor!
1) Pin side sensor plug or solder side cable socket
wireSENSOR, WPS
Plug M16
Integrated cable-
-SA / -SR
CA / -CR
2
5
4
3
1
8
7
6
View
1
1 = input +
white = input +
2 = ground
brown = ground
3 = signal
green = signal
Open contacts
1 = input +
2 = signal
CCW
3 = ground
Fig.
14.
2
WIPER
1
3
CW
CLOCKWISE
Page 30
