Installation and Assembly
Pin assignment TTL01
Cable color
Brown
Gray
White
Green
Yellow
Fig. 19 Pin assignment TTL01
Pin assignment TTL02
Cable color
Red
Black
Brown
Black
Orange
Black
Yellow
Black
Fig. 20 Pin assignment TTL02
Note the pin assignment for draw-wire displacement sensors with encoder output. The sensor contains an
additional supplement for detailed information.
wireSENSOR, WPS
Assignment
0 V
+UB
A
B
0
Assignment
+UB
0 V
A
A
B
B
0
n.c.
