MICRO-EPSILON WireSensor Series Instruction Manual page 20

Installation and Assembly
Potentiometer/
incremental
encoder
Fig. 2 Dimensional drawing WPS- ... -MK30 with potentiometer or encoder, dimensions in mm (inches), not to
scale
wireSENSOR, WPS
10.5
(.41)
2
(.07)
ø 3
(.11 DIA)
Mechanics
21
(.83)
E: 40
(1.57)
P: 42.5
(1.67)
for MB 50/150: 8
for MB 250/500: 8
for MB 750:12
42
(1.65)
50
(1.97)
Mounting clamp
with screw M3
(.31)
ø 4.5
(.31)
(.18)
(.47)
ø 9
(.35)
23.5
(.93)
30
(1.18)
Mounting
hole 3x ø 2.7
(ø .10)
