ø21 (dia. 0.83)

4 (.16)

20

(.79)

26 (1.02)

11 (.43)

ø4.3

(dia. 017)

Fig. 22 Guide pulley TR3-WDS fix with mounting socket, dimensions in mm (inches), not to scale

wireSENSOR, WPS

Page 39
