Installation and Assembly

4.
4.1
Uncontrolled retraction
of the measuring wire is Do not pull the measuring wire over range.
incorrect!
> Damage to or destruction of the sensor is possible
> Danger of injury
from whiplash effect
Do not damage the measuring wire.
of the wire with as-
Do not oil or grease the measuring wire.
sembly bolts/clips
Do not bend the measuring wire.
> Destruction of wire
Do not pull the measuring wire at an angle.
and/or of sensor.
Do not allow to loop the measuring wire around objects.
Save the wire during
Fix the sensor with drawn in measuring wire to the target.
installation work.
Do not loop the measuring wire around parts of the body.
4.2
Model
MK30
MK46
MK77
MK60
MK88
MK120
The sensor does not have to be oriented in a special way.
This prevents liquids penetrating the measuring wire outlet.
i
wireSENSOR, WPS
Installation and Assembly

Precautionary Measures

Sensor Mounting

Screws Mounting clamp
3 x M2.5 yes
3 x M2.5 yes
3 x M3 yes
3 x M3 no
3 x M4 yes
3 x M6 no
Choose the installation position so that damage and soiling of the measuring wire is avoided.
Prefer an installation position with measuring wire outlet facing downwards if possible.
Do not let snap the measuring wire!
No warranty by damage through snapping.
