Installation and Assembly
Fig. 12 Dimensional drawing WPS-...-MK120-CR, measuring ranges 7500 mm, dimensions in mm (inches), not
to scale
wireSENSOR, WPS
53.1
(2.09)
Mounting hole
3x ø6
(dia. .24)
107
(4.21)
120
(4.72)
20.5
(.81)
27.5
(1.08)
73.5
(2.89)
Page 28
