Technical Data Mk60 - MICRO-EPSILON WireSensor Series Instruction Manual

Functional Principle, Technical Data
2.6
Model
Output type
Signals
Measuring range
Linearity (FSO)
Resolution/Sensibility
Sensor element
Operating temperature
Material
Wire diameter
Wire mounting
Sensor mounting
Wire retraction force (min)
Wire extension force (max)
Protection class
Electrical connection
Wire acceleration
Weight (with cable)
P = Potentiometer
TTL01/ TTL02 = Incremental encoder
FSO = Full Scale Output
1) Specifications for output P , U, I and E/E830, see Chap. 4.4, see Chap.
wireSENSOR, WPS

Technical Data MK60

1
Housing
Wire
U = Voltage
WPS-1500-MK60
P/U/I
-
mm 1500
±0.15 % FSO
Quasi infinite
Hybrid potentiometer
°C
Coated polamide stainless steel (ø 0.45 mm)
mm
Mounting holes on the sensor housing
N
N
m/s²
g
I = Current
WPS-2400-MK60-CR
TTL01
A, B, O A, /A, B, /B, O
2400
±0.05 % FSO
6.83 pulses/mm
Incremental encoder
-20 ... +80
Plastic, PBT GF20
0.45
Wire clip
1
8
IP 65
Cable radial, 1 m
5
290
4.5
TTL02
Page 15
