Installation and Assembly

16

24.2

13.5 (0.53)

21.2 (.83)

0.5

50 (1.97)

27

(.02)

89.8 (3.53)

(1.06)

60 (2.36)

Fig. 8 Dimensional drawing WPS- ... -MK60-CR, with potentiometer, dimensions in mm, not to scale

wireSENSOR, WPS

Page 24
