4.4.3
Current output (I)
Supply voltage
Current consumption
Output current
Load
Signal noise
Temperature coefficient ±0.01 % FSO/K
Adjustment range (if supported by the model)
Zero
Sensitivity
Fig. 16 Table current output
1) Non stabilized, measured on the input terminal of the sensor
2) Pin side sensor plug or solder side cable socket
wireSENSOR, WPS

Current Output

14 ... 27 VDC (non stabilized
max. 35 mA
4 ... 20 mA
< 600 Ohm
< 1.6 μA
eff
±18 % d.M.
±15 %
)
1
2
5 4
3
1
8
7 6
View
2
1 = Supply White = Supply
2 = Ground Brown = Ground
Page 32
